Eizo CuratOR EX4342 User manual

Important
Please read this “Installation Manual”, and “Instructions for Use”
(separate volume) carefully to familiarize yourself with safe and
e󰀨ective usage.
•Refer to the “Instructions for Use” for information on the
installation / connection of the monitor. The “Installation Manual” is
part of the “Instructions for Use”.
Color LCD Monitor
Installation Manual

This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO GmbH.
EIZO GmbH is under no obligation to hold any submitted material or information condential unless prior
arrangements are made pursuant to EIZO GmbH’s receipt of said information. Although every e󰀨ort has
been made to ensure that this manual provides up-to-date information, please note that EIZO product
specications are subject to change without notice.
2

CONTENTS
CONTENTS ............................................................. 3
Chapter 1 Basic Adjustment / Setting .............. 4
1-1. Loading the Monitor Settings ...................... 4
●Saving current settings to “User1”
through ”User5” ............................................... 5
1-2. Switching Input Signals ............................... 5
1-3. Using Custom Keys ...................................... 6
●Setting a function to custom keys ................... 6
1-4. Locking Operation Buttons ......................... 6
Chapter 2 Advanced Adjustments / Settings ... 7
2-1. Basic Operation of the Setting Menu ......... 7
2-2. Setting Menu Functions ............................... 9
●Color ................................................................ 9
●Signal .............................................................10
●Preferences ....................................................11
●Information .....................................................13
●PbyP ...............................................................13
●PinP ................................................................14
Chapter 3 Troubleshooting .............................. 15
3-1. No Picture Displayed ...................................15
3-2. Imaging Problems ........................................16
3-3. Other Problems ............................................16
Chapter 4 Reference ........................................ 17
4-1. Main Default Settings ..................................17
4-2. Pin Specications ........................................18
Appendix .............................................................. 19
Trademark ................................................................19
License .....................................................................19
LIMITED WARRANTY ............................................. 20
Recycling Information ............................................21
3
CONTENTS

3
Chapter 1 Basic Adjustment / Setting
Chapter 1 Basic Adjustment / Setting
This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front
of the monitor.
1-1. Loading the Monitor Settings
Basic settings are made in advance at the factory.
It is possible to switch to the following preset settings that have been set in advance.
DisplayPort [sRGB]
DisplayPort [BT.2020]
Basic settings for DisplayPort. The input signal is set to DisplayPort when this item is
selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page
3).
HDMI [BT.2020] Basic settings for HDMI. The input signal is set to HDMI when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page
3).
SDI [BT.2020] Basic settings for SDI 1. The input signal is set to SDI 1 when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page
3).
“User1” through ”User5” You can save the current setting values and display status in the following items.
These items are not selectable unless they have been saved. For details, see “Saving
current settings to “User1” through ”User5”” (page 4).
1. Press PRESET.
The preset menu is displayed.
2.
Press F1/Left, F2/Right, F3/Down and F4/Up to select the item to load, and then
press ENTER.
The pre-made settings are loaded and the settings are changed.
Note
• The preset menu will disappear after ve seconds have elapsed if no operation is performed.

4Chapter 1 Basic Adjustment / Setting
●Saving current settings to “User1” through ”User5”
You can save the current setting values and display status to “User1” through ”User5”.
1. Press MENU.
The Setting menu appears.
2.
Press F3/Down or F4/Up to select “Preferences”, and then press ENTER.
The “Preferences” menu appears.
3.
Press F3/Down or F4/Up to select “PRESET Save”, and then press ENTER.
The “PRESET Save” menu appears.
4.
Press F3/Down or F4/Up to select one from “User1” to “User5”, and then press
ENTER.
Current setting values and display status will be saved in the selected item.
1-2. Switching Input Signals
Select the signal input to the monitor and display it on the screen.
1. Press INPUT.
The input port menu appears.
2.
Press F3/Down or F4/Up to select an input signal.
This switches to the selected input signal.
3.
Press INPUT.
This exits the menu screen.
Note
• If you press INPUT while the input port menu is displayed in dual screen mode (PbyP or PinP), the “PbyP” / “PinP”
menu is displayed. For details, see “PbyP” (page 9) and “PinP” (page 10).
• After the input port menu is displayed, the input port menu will disappear after 10 seconds if no key operations
are performed.

5
Chapter 1 Basic Adjustment / Setting
1-3. Using Custom Keys
Execute the functions assigned to the custom keys ( F1/Left, F2/Right, F3/Down and F4/Up) . For
information on how to set a function to each custom key, see “Setting a function to custom keys” (page
5) .
1. Press F1/Left, F2/Right, F3/Down and F4/Up.
The function associated with the custom key that is pressed will run.
Note
• For dual screen display (PbyP or PinP), adjust the “Active Window” side.
●Setting a function to custom keys
1. Press MENU.
The Setting menu appears.
2.
Press F3/Down or F4/Up to select “Preferences”, and then press ENTER.
The “Preferences” menu appears.
3.
Press F3/Down or F4/Up to select “Custom Key”, and then press ENTER.
The “Custom Key” menu appears.
4.
Press F3/Down or F4/Up to select which custom key to set the function to, and
then press ENTER.
5.
Press F3/Down or F4/Up to select the function, and then press ENTER.
The selected function is assigned to the corresponding custom key.
1-4. Locking Operation Buttons
Adjusted or set states can be made unchangeable.
Procedure
1. Press the MENU and ENTER keys for at least 4 seconds.
Note
• Press the MENU and ENTER keys for at least 4 seconds to exit Key Lock.

3
Chapter 2 Advanced Adjustments / Settings
Chapter 2 Advanced Adjustments / Settings
This chapter describes advanced monitor adjustments and settings procedures using the main menu.
2-1. Basic Operation of the Setting Menu
1. Menu display
1. Press MENU.
*The control panel key is located to the lower right on the back of the
housing frame.
The Setting menu appears.

4Chapter 2 Advanced Adjustments / Settings
2.
Adjustments / Settings
Pressing MENU during adjustment/setting will cancel the adjustment/setting and restore the state
prior to making changes.
1. Press F3/Down or F4/Up to select a menu to adjust/set, and then press ENTER.
The submenu appears.
2. Press F3/Down or F4/Up to select an item to adjust/set, and then press ENTER.
The Adjustment/Setting menu appears.
3. Press F1/Left or F2/Right to adjust/set the selected item, and then press ENTER to conrm the
settings.
The submenu appears.
3.
Exiting
1. Press MENU.
The Setting menu appears.
2. Press MENU.
Exits the Setting menu.

5
Chapter 2 Advanced Adjustments / Settings
2-2. Setting Menu Functions
●Color
Function Settings Description
Active
Window*1
PbyP Left Window /
Right Window
Select which window to adjust settings when dual screen display (PbyP
or PinP).
Note
• For dual screen display (PbyP or PinP), color adjustment can be
performed for each screen selected in “Active Window”.
PinP Large Window /
Small Window
Single All
Backlight 0 to 100 Adjust screen brightness by changing the brightness of the backlight
(light source from the LCD back panel).
Note
• For dual screen display (PbyP or PinP), settings are applied to “Left
Window” / “Large Window”.
• During PbyP/PinP, the backlight is disabled when either “Right
Window” or “Small Window” are selected in the Active Window.
Brightness 0 to 100 Adjust the brightness of black.
Contrast 0 to 100 Contrast can be adjusted.
Adjust the brightness of the screen by changing the video signal level.
Temperature Native / 6500K / 9300K
/ User
Adjust the color temperature. The color temperature is normally
used to express the hue of “White” and / or “Black” with a numerical
value. The value is expressed in degrees “K” (Kelvin). The screen
becomes reddish at low color temperatures and bluish at high color
temperatures, similar to the temperatures of a ame.
Note
• Select “Native” to display the original colors of the LCD panel.
• “Gain” allows you to perform more advanced adjustment. When
gain is changed, “Temperature” is changed to “User”.
• The gain preset values are set for each color temperature setting
value.
Gamma 1.8 / 2.0 / 2.2 / 2.4 / 2.6 /
DICOM / HLG / PQ
Adjust the gamma. While the brightness of the monitor varies
depending on the input signal, the variation rate is not proportional to
the input signal. Maintaining the balance between the input signal and
brightness of the monitor is referred to as “Gamma correction”.
Color Gamut Native / sRGB / BT.2020 Set the color reproduction area (color gamut). Color Gamut is the
range of colors that can be represented. Multiple standards are
dened.
Note
• Select “Native” to display the original color gamut of the LCD panel.
Hue -100 to 100 Adjust the hue.
Saturation -100 to 100 Adjust the color saturation.
Gain 0 to 255 The brightness of each color component (red, green, and blue) is
called “gain”. The hue of “white” can be changed by adjusting the gain.
*1 Disabled when single screen display.

6Chapter 2 Advanced Adjustments / Settings
●Signal
Function Settings Description
Active
Window*1
(When single screen display mode.)
All
(When “Multi Window” is set to
“PbyP”.)
Left Window / Right Window
(When “Multi Window” is set to
“PinP”.)
Large Window / Small Window
Select which window to adjust settings when dual screen
display (PbyP or PinP).
Input Color
Format*2
(When input signal is DisplayPort.)
Auto / YUV / RGB
(When input signal is HDMI.)
Auto / YUV 4:2:2 / YUV 4:4:4 / RGB
(When input signal is SDI.)
Auto / YCC4:2:2 10bit / YCC4:2:2
12bit / YCC4:4:4 10bit / YCC4:4:4
12bit / RGB4:4:4 10bit / RGB4:4:4
12bit
The color space of the input signal can be specied.
Try changing this setting if colors are not displayed
correctly. Normally, select “Auto”. When an SDI signal
is input, the bit depth is specied using the “Input Color
Format”. If the specied bit depth is invalid, a signal error is
displayed.
YUV Color
Matrix*2
Auto / BT.601 / BT.709 / BT.2020 Select the YUV format of the input signal. Use this setting
for gradation collapse or other occurrences where the
screen is displayed incorrectly because of a problem with
the input signal.
Input Range (When input signal is DisplayPort or
HDMI.)
Auto / Full / Limited
(When input signal is SDI or DVI.)
Full / Limited
Depending on the video reproduction device, there may be
a restriction on black and white video signal levels output
to the monitor. This kind of signal is called “Limited range”.
On the other hand, unlimited signals are called “Full range”.
• “Auto”
Input signal brightness range is automatically judged
and is displayed appropriately (recommended setting).
Depending on the video reproduction device, Limited
range and Full range may not be able to be judged by
the monitor. In such a case, selecting “Full” or “Limited”
will allow it to be displayed appropriately.
• “Full”
To be selected in case of Full range signals.
Appropriate display can be obtained when this is
selected, in case both blacks and whites are corrupted.
• “Limited”
To be selected in case of Limited range signals. When
this is selected, the output signal range is expanded
from 0 to 255 to obtain an appropriate display when
black is pale and white is dull.
*1 Disabled when single screen display.
*2 Disabled when input signal is DVI.
