Eizo FLEXSCAN HD2441W - SETUP User manual

PRECAUTIONS
Chapter 1 Features and Overview
1-1 Features
1-2 Names of Switches
1-3 Functions
Chapter 2 Basic Operation
2-1 Operation Switch Usage
2-2 Menu Operation
2-3 Resumption of Default Settings
2-4 Locking Switches
Chapter 3 Settings and Adjustment
3-1 Input Signal Switching
3-2 Screen Adjustment
3-3 Color Adjustment
3-4 Sound Adjustment
3-5 PinP (Picture in Picture) Display
3-6 Screen Size Changing
3-7 Off Timer Setting
3-8 Monitor Power-saving Mode Setting
3-9 Power Indicator/EIZO Logo Display Setting
3-10 Beeper Setting
3-11 Information Checking
3-12 Language Setting to be Displayed
Chapter 4 Troubleshooting
Chapter 5 Reference
5-1 Attaching an Arm
5-2 Cleaning
5-3 Specifications
5-4 Glossary
5-5 Preset Timing
How to Setup
Please read the Setup Manual (separate volume)
Important
Please read this User’s Manual and Setup
Manual (separate volume) carefully to
familiarize yourself with safe and effective
usage.
HD2441W_UM_EN.indd cov.1HD2441W_UM_EN.indd cov.1 4/14/2007 6:21:47 PM4/14/2007 6:21:47 PM

SAFETY SYMBOLS
This manual uses the safety symbols below. They denote critical information. Please read them
carefully.
WARNING
Failure to abide by the information in a WARNING
may result in serious injury and can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION
may result in moderate injury and/or property or
product damage.
Indicates a prohibited action.
Indicates a mandatory action that must be followed.
Copyright© 2007 EIZO NANAO CORPORATION All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
EIZO NANAO CORPORATION is under no obligation to hold any submitted material or information confidential
unless prior arrangements are made pursuant to EIZO NANAO CORPORATION’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specifications are subject to change without notice.
ENERGY STAR is a U.S. registered mark.
Apple and Macintosh are registered trademarks of Apple Inc.
VGA is a registered trademark of International Business Machines Corporation.
DPMS is a trademark and VESA is a registered trademark of Video Electronics Standards Association.
Windows is a registered trademark of Microsoft Corporation.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
PowerManager is a trademark of EIZO NANAO CORPORATION.
FlexScan, ScreenManager and EIZO are registered trademarks of EIZO NANAO CORPORATION in Japan and other countries.
As an ENERGY STAR®Partner, EIZO NANAO CORPORATION has determined that this product
meets the ENERGY STAR guidelines for energy efficiency.
Using the special functions, such as screen size change (ex. changing the horizontal and vertical ratio of images input)
for commercial purposes or for the purpose of showing in public may violate copyright laws.
Product specification may vary with sales areas.
Confirm the specification in the manual written in language of the region of purchase.
HD2441W_UM_EN.indd cov.2HD2441W_UM_EN.indd cov.2 4/14/2007 6:21:47 PM4/14/2007 6:21:47 PM

1
PRECAUTIONS
PRECAUTIONS
IMPORTANT
• This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specified in the specifications.
• To ensure personal safety and proper maintenance, please read carefully this section and the caution statements on
the monitor.
[Location of Caution Statement]
WARNING
If the unit begins to emit smoke, smells like something is burning, or makes
strange noises, disconnect all power connections immediately and contact
your dealer for advice.
Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment
damage.
Do not open the cabinet or modify the unit.
Opening the cabinet or modifying the unit may result in fire, electric shock, or burn.
Refer all servicing to qualified service personnel.
Do not attempt to service this product yourself as opening or removing covers may result in
fire, electric shock, or equipment damage.
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the cabinet or spillage into
the cabinet may result in fire, electric shock, or equipment damage.
If an object or liquid falls/spills into the cabinet, unplug the unit immediately. Have the unit
checked by a qualified service engineer before using it again.
HD2441W_UM_EN.indd 1HD2441W_UM_EN.indd 1 4/14/2007 6:21:47 PM4/14/2007 6:21:47 PM

2PRECAUTIONS
WARNING
Place the unit at the strong and stable place.
A unit placed on an inadequate surface may fall and result in injury or equipment damage.
If the unit falls, disconnect the power immediately and ask your dealer for advice. Do not
continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
Set the unit in an appropriate location.
Not doing so may result in fire, electric shock, or equipment damage.
• Do not place outdoors.
• Do not place in the transportation system (ship, aircraft, trains, automobiles, etc.)
• Do not place in a dusty or humid environment.
• Do not place in a location where the steam comes directly on the screen.
• Do not place near heat generating devices or a humidifier.
To avoid danger of suffocation, keep the plastic packing bags away from
babies and children.
Use the enclosed power cord and connect to the standard power outlet of your
country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may result in fire or electric shock.
To disconnect the power cord, grasp the plug firmly and pull.
Tugging on the cord may damage and result in fire or electric shock.
The equipment must be connected to a grounded main outlet.
Failure to do so may result in fire or electric shock.
Use the correct voltage.
• The unit is designed for use with a specific voltage only. Connection to another voltage
than specified in this User’s Manual may cause fire, electric shock, or equipment damage.
• Do not overload your power circuit, as this may result in fire or electric shock.
HD2441W_UM_EN.indd 2HD2441W_UM_EN.indd 2 4/14/2007 6:21:49 PM4/14/2007 6:21:49 PM

3
PRECAUTIONS
WARNING
Handle the power cord with care.
• Do not place the cord underneath the unit or other heavy objects.
• Do not pull on or tie the cord.
If the power cord becomes damaged, stop using it. Use of a damaged cord may result in fire
or electric shock.
Never touch the plug and power cord if it begins to thunder.
Touching them may result in electric shock.
When attaching an arm stand, please refer to the user’s manual of the arm
stand and install the unit securely.
Not doing so may cause the unit to become unattached, which may result in injury or
equipment damage. When the unit is dropped, please ask your dealer for advice. Do not
continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
When reattaching the tilt stand, please use the same screws and tighten them securely.
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth.
If any part of the skin or body comes in direct contact with the panel, please wash thoroughly.
If some physical symptoms result, please consult your doctor.
Lamps contain mercury, dispose according to local, state or federal laws.
HD2441W_UM_EN.indd 3HD2441W_UM_EN.indd 3 4/14/2007 6:21:49 PM4/14/2007 6:21:49 PM

4PRECAUTIONS
CAUTION
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the unit with the cord
attached is dangerous. It may result in injury.
When handling the unit, grip the bottom of the unit firmly with both hands
ensuring the panel faces outward before lifting.
Dropping the unit may result in injury or equipment damage.
Do not block the ventilation slots on the cabinet.
• Do not place any objects on the ventilation slots.
• Do not install the unit in a closed space.
• Do not use the unit laid down or upside down.
Blocking the ventilation slots prevents proper airflow and may result in fire, electric shock, or
equipment damage.
Do not touch the plug with wet hands.
Doing so may result in electrical shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a problem.
Do not set the sound volume too high when using a headphone.
Doing so may damage your hearing ability.
Periodically clean the area around the plug.
Dust, water, or oil on the plug may result in fire.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in electric shock.
If you plan to leave the unit unused for an extended period, disconnect the
power cord from the wall socket after turning off the power switch for the
safety and the power conservation.
HD2441W_UM_EN.indd 4HD2441W_UM_EN.indd 4 4/14/2007 6:21:50 PM4/14/2007 6:21:50 PM

5
PRECAUTIONS
LCD Panel
In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in
lower brightness is recommended.
The LCD panel is manufactured using high-precision technology. However, note that the appearance of any missing
pixels or lit pixels does not indicate damage to the LCD monitor.
Percentage of effective pixels: 99.9994% or higher.
The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to flicker, please contact
your dealer.
Do not press on the panel or edge of the frame strongly, as this may result in damage to the screen. There will be prints
left on the screen if the pressed image is dark or black. If pressure is repeatedly applied to the screen, it may deteriorate
or damage your LCD panel. Leave the screen white to decrease the prints.
Do not scratch or press on the panel with any sharp objects, such as a pencil or pen as this may result in damage to the
panel. Do not attempt to brush with tissues as this may scratch the LCD panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation
may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation
disappears, otherwise it may cause damage to the monitor.
To use the monitor comfortably
An excessively dark or bright screen may affect your eyes.Adjust the brightness of the monitor according to the
environmental conditions.
Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.
HD2441W_UM_EN.indd 5HD2441W_UM_EN.indd 5 4/14/2007 6:21:50 PM4/14/2007 6:21:50 PM

6CONTENTS
CONTENTS
PRECAUTIONS ......................................................1
LCD Panel................................................................... 5
To use the monitor comfortably............................... 5
Chapter 1 Features and Overview .....................7
1-1 Features............................................................ 7
1-2 Names of Switches.......................................... 9
1-3 Functions........................................................ 10
Chapter 2 Basic Operation...............................12
2-1 Operation Switch Usage ............................... 12
2-2 Menu Operation ............................................. 13
●Basic operation of the Input Selection menu.... 13
●Basic operation of the Setting menu ................ 13
2-3 Resumption of Default Settings................... 14
●To reset the color adjustment [Reset]............... 14
●To reset all settings [Reset].............................. 14
2-4 Locking Switches .......................................... 14
●To lock the available functions
[Operation Lock]............................................... 14
Chapter 3 Settings and Adjustment ................15
3-1 Input Signal Switching.................................. 15
●To switch the input signal for the desired
image sent from the equipment
[Input Selection]................................................ 15
3-2 Screen Adjustment (Only for analog
input signal sent from a PC)......................... 16
3-3 Color Adjustment........................................... 19
Simple Adjustment.............................................. 19
●To select the color mode [Color Mode]............. 19
Advanced Adjustment......................................... 20
●To adjust/set Color Mode.................................. 20
●Adjustment items.............................................. 21
●To adjust the brightness automatically
[Auto Brightness].............................................. 22
3-4 Sound Adjustment......................................... 23
●To adjust [Volume/Treble/Bass/Balance/
Sound Level]. ................................................... 23
3-5 PinP (Picture in Picture) Display.................. 24
●To display the PC input signal screen (Main
Window) and the VIDEO input signal screen (Sub-
Window) simultaneously [PinP]........................ 24
●To change the Sub-Window position
[Sub-Window Position]..................................... 26
●To set the translucent level for Sub-Window
[Translucent]..................................................... 26
●To select the Sub-Window display size
[Sub-Window Size]........................................... 26
3-6 Screen Size Changing................................... 27
●To change the screen image/projected image
size appearing on the screen [Screen Size]..... 27
3-7 Off Timer Setting............................................ 29
●To set monitor power-off time [Off Timer] ......... 29
3-8 Monitor Power-saving Mode Setting............ 29
●To set the resume conditions from the
power-saving mode [Signal Detection]............. 29
3-9 Power Indicator/EIZO Logo Display
Setting............................................................. 30
●To turn off the power indicator while a screen is
displayed [Power Indicator].............................. 30
●To set EIZO logo display/no EIZO logo display
when the monitor turns on
[EIZO Logo Appearing Function]...................... 30
3-10 Beeper Setting ............................................... 30
●To set the beeper [Beep].................................. 30
3-11 Information Checking.................................... 31
●To check settings, usage time, etc.
[Information] ..................................................... 31
3-12 Language Setting to be displayed .............. 31
●To set the language displayed in the menu
[Language] ....................................................... 31
Chapter 4 Troubleshooting...............................32
Chapter 5 Reference .........................................37
5-1 Attaching an Arm........................................... 37
5-2 Cleaning.......................................................... 38
5-3 Specifications ................................................ 39
5-4 Glossary ......................................................... 43
5-5 Preset Timing................................................. 45
HD2441W_UM_EN.indd 6HD2441W_UM_EN.indd 6 4/14/2007 6:21:50 PM4/14/2007 6:21:50 PM

7
Chapter 1 Features and Overview
Chapter 1 Features and Overview
Thank you very much for choosing an EIZO color LCD monitor.
1-1 Features
• 24” wide format LCD with Video signal input connector
• Resolution 1920 dots × 1200 lines
• Equipped with the ContrastEnhancer and OutlineEnhancer functions
• Equipped with PinP (Picture in Picture) function
• Enable to adjust the screen brightness automatically corresponding to the
brightness of the image and the environment.
• Employing the slide bar and realizing the excellent operability.
• The ArcSwing 2 Stand enables to adjust the monitor height and monitor angle
freely
• Equipped with the Utility Software, “ScreenManager Pro for LCD
(Windows)”, which is operated via a keyboard or a mouse.
[Applicable to PC signal input]
• DVI-D connector × 1, D-Sub mini 15-pin connector × 1 (two input
connectors)
• Horizontal scan frequency and Vertical scan frequency are as follows:
Horizontal scan
frequency Digital input signal 31.5 - 76kHz: each preset signal ±1kHz
Analog input signal 31.5 - 80kHz: each preset signal ±1kHz
Vertical scan
frequency Digital input signal 59 - 61Hz: each preset signal ±1Hz (VGATEXT: 69 - 71Hz)
(49 - 51Hz is also available@720p/1080p*)
Analog input signal 55 - 76Hz: each preset signal ±1Hz
(49 - 51Hz is also available@720p/1080p*)
* For some AV equipment
• Compliance with frame synchronization mode (49.60 - 50.40Hz, 59.50 -
60.50Hz)
• Equipped with USB ports (Upstream × 2, Downstream × 2)
• Compliance with DVI digital input signal (HDCP)
• Equipped with USB audio function
• Enable to use connected USB devices on two PCs
[Applicable to Video signal input]
• HDMI connector × 2 (two input connectors)
NOTE
• The stand of the unit can be replaced
with an arm or another stand. (Refer
to “5-1 Attaching an Arm” on page
37.)
HD2441W_UM_EN.indd 7HD2441W_UM_EN.indd 7 4/14/2007 6:21:50 PM4/14/2007 6:21:50 PM

8Chapter 1 Features and Overview
Connecting to peripheral devices equipment
Speakers
(with built-in amplifier)
Allows you to enjoy sound from a
connected PC or AV equipment, etc.
NOTE
• Enables you to adjust the speaker
volume connected to the monitor
using the volume adjustment function
of the monitor. .......................page 23
• Enables you to enjoy sound by
connecting a headphone to the
headphone jack.
USB devices
Keyboard
(Also available to connect a printer or a
scanner, etc.)
Attention
• Use a PC/OS applicable to USB devices.
[Applicable OS]
- Windows 2000/XP/Vista
- Mac OS 8.5.1 or later
Mouse
PC
Enables you to use as a monitor by connecting to
a Windows PC or a Macintosh.
Attention
• The [USB] setting is required to change
depending on a PC used. ......page 15
HD2441W
AV equipment
HDMIconnector
DVDplayer,etc.
Game,etc.
Enables you to display projected images by
connecting a DVD, Video, game, etc.
HD2441W_UM_EN.indd 8HD2441W_UM_EN.indd 8 4/14/2007 6:21:51 PM4/14/2007 6:21:51 PM

9
Chapter 1 Features and Overview
1-2 Names of Switches
12 3 456
Switch
Setting menu (ScreenManager®*)
1. Sensor (Detects the environmental brightness.)
2. Input Signal Selection switch ( )
3. Slide bar
4. Menu switch ( )
5. Power switch ( )
6. Power indicator
Indicator status Operation status
Blue The screen is displayed
Orange Power saving
Off Power off
* ScreenManager
®is an EIZO’s nickname of the Setting menu.
(In this manual, the setting/adjustment item names in the Setting menu are put in angle brackets
< >. ex.: <Color>)
NOTE
• As well as touching , if you touch
the , or slide bar, the
monitor turns on.
• While the screen is displayed, the
power indicator that is lighting
blue can be turned off (see “Power
Indicator/EIZO Logo Display
Setting,” on page 30).
HD2441W_UM_EN.indd 9HD2441W_UM_EN.indd 9 4/14/2007 6:21:51 PM4/14/2007 6:21:51 PM

10 Chapter 1 Features and Overview
1-3 Functions
Switching the Input Signal
PinP (Picture in Picture) display
●To switch the input signal for the Main Window/
Sub-Window …………………………see page 25
●To hide the Sub-Window display with its sound
being heard [Sub-Window Off] ……see page 25
Single display
Input Selection menu (As for the menu operation, refer to page 13.)
●To switch the input signal for the desired display
sent from the equipment [Input Selection] …see page 15
1Screen Adjustment
Screen menu
●Adjusting the screen automatically
[Auto Screen Adjust]
2Advanced Screen Adjustment
●To eliminate vertical bars
[Clock] ………………………………see page 17
●To remove flickering or blurring
[Phase] ………………………………see page 17
●To correct screen position
[Hor.Position] ………………………see page 18
[Ver.Position]…………………………see page 18
●
To set when the image is not displayed with
proper resolution [Resolution]
………see page 33
●To adjust color gradation automatically
[Auto Range Adjust] ………………see page 18
●To set when noise appears on the screen
[Signal Filter] ………………………see page 33
(Only for analog input signal from PC: PC 2 Input)
Page 16
Setting/Adjusting the Monitor
Color Adjustment
(Simple Adjustment)
Color menu
●To select the color mode [Color Mode]
Color Adjustment
(Advanced Adjustment)
●[Brightness / Black Lebel / Contrast / Saturation
/ Hue / Temperature / OutlineEnhancer /
ContrastEnhancer / Gain / Gamma / Noise Filter
/ I/P Conversion] can be set for each mode.
Settable functions vary with the display mode.
Resumption of Default Settings
●To reset the color adjustment
[Reset] ………………………………see page 14
Page 19
Setting menu
(As for the menu operation, refer to page 13.)
Page 20
PinP (Picture in Picture) Display
PinP Settings menu
●To display the PC input signal screen
(Main Window) and Video input signal screen
(Sub-Window) on the monitor simultaneously
[PinP]…………………………………see page 24
●To change the Sub-Window position
[Sub-Window Position] ……………see page 26
●To set the translucent level for Sub-Window
[Translucent]…………………………see page 26
●To select the Sub-Window display size
[Sub-Window Size] …………………see page 26
Page 24
Sound Adjustment
Sound menu
●To adjust [Volume / Treble / Bass / Balance /
Sound Level]
Page 23
●[ ] stands for the function name.
●Settable functions differ depending on the input
signal.
HD2441W_UM_EN.indd 10HD2441W_UM_EN.indd 10 4/14/2007 6:21:52 PM4/14/2007 6:21:52 PM

11
Chapter 1 Features and Overview
Setting/Adjusting the Monitor (Continued)
Resumption of Default Settings
●To reset all settings [Reset]
Page 14
Setting menu
(As for the menu operation,
refer to page 13.)
Monitor Settings menu
Language Setting to be displayed
●To set the language displayed in the menu
[Language] …………………………see page 31
Adjusting the Brightness automatically
●To adjust the screen brightness automatically
corresponding to the brightness of the image
and the environment
[Auto Brightness]……………………see page 22
Monitor Power-saving Mode Setting
●To set the resume conditions from the power-
saving mode [Signal Detection]……see page 29
Power Indicator Setting
●To turn off the Power indicator while a screen is
displayed [Power Indicator] ………see page 30
Beeper Setting
●To set the beeper [Beep]……………see page 30
Changing the Screen Size automatically
●To change the screen size automatically
according to the aspect information of the input
signal [Auto Screen Size] …………see page 27
Color Space Setting
●To set when the image color is not displayed
correctly [Color Space] ……………see page 35
Field Rate Setting
●To select the setting according to the area where
the monitor is used [Field Rate] …see page 35
Changing the USB Setting
USB menu
●To change the setting according to the PC used
(when USB is connected) [USB]
Page 15
Screen Size Changing
Screen Size menu
●To change the screen image/projected image
size appearing on the screen [Screen Size]
Page 27
Information Checking
Information menu
●To check settings, usage time, etc. [Information]
Page 31
Off Timer Setting
Off Timer menu
●To set monitor power-off time [Off Timer]
Page 29
EIZO Logo Display Setting
●To set EIZO logo display/no EIZO logo display
when the monitor turns on
[EIZO Logo Appearing Function]
Page 30
Locking Switches
●To lock the available functions [Operation Lock]
Page 14
●[ ] stands for the function name.
●Settable functions differ depending on the input
signal.
HD2441W_UM_EN.indd 11HD2441W_UM_EN.indd 11 4/14/2007 6:21:52 PM4/14/2007 6:21:52 PM

12 Chapter 2 Basic Operation
2-1 Operation Switch Usage
Chapter 2 Basic Operation
NOTE
• There are three methods of operation:
• Touching the switch
• Tapping the slide bar
• Tracing the slide bar
■Turning the power On/Off
■Displaying/Quitting a menu
InputSelectionmenu Settingmenu
Volumemenu
(Whenthemenuisnotdisplayedonthescreen)
■Selecting a menu item
Setting and Adjusting
*Theincrease/decreasespeedofthe
adjustmentvaluemaychange
dependingonthetracingspeedof
theslidebar.
Atfineadjustment
*
Tappingoncechangestheadjustmentvaluetoonestepupordown.
Touchingtheslidebarcontinuouslymaychangethevalueserially.
■Fixing an item
Deciding the setting and adjusting value
PowerOff:Touch .
PowerOn:Touchanyofthekeystoturnonthemonitor.
Touch .Touch .
Taptheslidebar.
Tracetheslidebarleftandright.
Tapeitherendoftheslidebar,markedwith and .
Taptheslidebar.
HD2441W_UM_EN.indd 12HD2441W_UM_EN.indd 12 4/14/2007 6:21:53 PM4/14/2007 6:21:53 PM

13
Chapter 2 Basic Operation
2-2 Menu Operation
●Basic operation of the Input Selection menu
[Displaying the Input Selection menu and selecting the input signal]
(1) Touch on the operation panel.
The Input Selection menu appears.
(2) Trace the slide bar left and right to select the input signal and tap the slide
bar.
The screen image appears.
[Quitting the Input Selection Menu]
(1) Touch .
The Input Selection menu quits.
●Basic operation of the Setting menu
[Displaying the Setting menu and selecting function]
(1) Touch on the operation panel.
The Main menu appears.
(2) Trace the slide bar left and right to select the function and tap the slide bar.
The Sub menu appears.
(3) Trace the slide bar left and right to select the function and tap the slide bar.
The setting/adjustment menu appears.
(4) Trace the slide bar left and right to set/adjust the monitor and tap the slide
bar.
The setting/adjustment value is saved.
[Quitting the Setting Menu]
(1) Touch .
The Setting menu quits.
NOTE
• Some menus may not have a
sub-menu.
HD2441W_UM_EN.indd 13HD2441W_UM_EN.indd 13 4/14/2007 6:21:54 PM4/14/2007 6:21:54 PM

14 Chapter 2 Basic Operation
NOTE
• The following operations are available
in the locked status.
- Power ON/OFF by touching .
- Power ON by touching ,
or the slide bar.
- Operation lock function ON/OFF
- EIZO Logo appearing function
ON/OFF (Page 30)
NOTE
• For default settings, refer to “Main
default settings (factory settings)” on
page 42.
2-3 Resumption of Default Settings
●To reset the color adjustment [Reset]
Only the hue in the color mode currently set will revert to the default settings
(factory settings).
[Procedure]
(1) Choose the <Color> icon in the Setting menu and tap the slide bar.
(2) Choose the <Reset> icon in the <Color> menu and tap the slide bar.
“Your current color data will be lost.” appears on the screen.
(3) Trace the slide bar left and right to select “Reset” and tap the slide bar.
The reset operation is completed.
●To reset all settings [Reset]
Reset all the settings/adjustments status except for [Field Rate], [USB] and
[Volume] to the default settings (factory settings).
[Procedure]
(1) Choose the <Reset> icon in the Setting menu and tap the slide bar.
“All settings except for the field rate and USB are reset.” appears on the screen.
(2) Trace the slide bar left and right to select “Reset” and tap the slide bar.
The reset operation is completed.
2-4 Locking Switches
●To lock the available functions [Operation Lock]
This function enables you to lock the switches to retain the setting/adjustment
set once and restrict the available functions.
[Locking]
(1) Touch to turn off the monitor.
(2) Touch for approx. three seconds.
The operation lock is performed (“Operation Lock: ON” is displayed) and the screen
is displayed with the operation lock.
[Unlocking]
(1) Touch to turn off the monitor.
(2) Touch for approx. three seconds.
The operation lock is released (“Operation Lock: Off” is displayed) and the screen is
displayed with the operation unlock.
HD2441W_UM_EN.indd 14HD2441W_UM_EN.indd 14 4/14/2007 6:21:54 PM4/14/2007 6:21:54 PM

15
Chapter 3 Settings and Adjustment
Attention
• If the [USB] setting is not set
properly, the USB devices connected
to the monitor may not work or
no sound may come out from the
speakers.
• Please note the following when
switching the setting.
- When connecting a memory device
such as a USB memory to the
monitor, the data may be lost and
damaged. Be sure to change the
USB setting after removing the
memory device.
- When an application such as a
sound playback, etc. works, the
sound may not output if the setting
is returned to the original. Be sure
to change the USB setting after
exiting from the application.
Chapter 3 Settings and Adjustment
3-1 Input Signal Switching
●To switch the input signal for the desired image sent from
the equipment [Input Selection]
[Procedure]
(1) Touch .
The Input Selection menu appears.
(2) Trace the slide bar left and right to select the input signal for the desired
image sent from the equipment or tap the slide bar.
The desired image appears.
■When connecting a PC with USB connection [USB]
Switch the [USB] setting according to the input signal of the PC used.
Settings Using status
PC 1 (Digital signal) When using PC 1.
PC 2 (Analog signal) When using PC 2.
[Procedure]
(1) Choose the <USB> icon in the Setting menu and tap the slide bar.
The <USB> menu appears.
(2) Trace the slide bar left and right to select either “PC 1” or “PC 2” and tap
the slide bar.
The USB setting is completed.
[When the following message appears]
When the following message appears, “If the USB setting is changed, the USB
connection to the selected PC will be lost. Do you change the setting?” confirm on
the right (for switching the USB setting) to proceed the step 3.
(3) Trace the slide bar left and right to select “Yes” and tap the slide bar.
The USB setting is completed.
NOTE
• When “PinP” is selected, the monitor
display changes to PinP (Picture in
Picture) mode.
• When switching the input signal in
the PinP mode, refer to page 25.
HD2441W_UM_EN.indd 15HD2441W_UM_EN.indd 15 4/14/2007 6:21:54 PM4/14/2007 6:21:54 PM

16 Chapter 3 Settings and Adjustment
Attention
• This function works correctly when
an image is fully displayed over the
Windows or Macintosh display area.
It does not work properly when an
image is displayed only on a part of
the screen (DOS prompt window, for
example) or when a black background
(wallpaper, etc.) is in use.
• The Auto Adjust function may not
work properly with some graphics
boards.
NOTE
• When the screen image is not
displayed with the proper resolution
even after Auto Screen Adjust is
performed, set the resolution of
the input signal manually. If the
resolution is set, the [Auto Screen
Adjust] is performed again. (Refer to
Chapter 4, “Troubleshooting” on page
33.)
NOTE
• When digital input signals are used,
images are displayed correctly based
on the preset data of the monitor.
No screen adjustment is required.
3-2 Screen Adjustment (Only for analog input signal
from a PC)
The monitor screen adjustment is used to suppress flickering of the screen or
to adjust the screen position and screen size correctly according to the PC to be
used. To use the monitor comfortably, adjust the screen when the monitor is set
up for the first time or when the settings of the PC in use are updated.
The Auto ScreenAdjust function works in the following cases:
• When a signal is input into the monitor for the first time.
• When a signal is input into the monitor for the first time after the
resolution or refresh rate of input signals is changed.
[Adjustment Procedures]
1Choose the <Screen> icon in the Setting menu and tap the
slide bar.
The <Screen> menu appears.
2Choose the <Auto Screen Adjust> icon in the <Screen> menu
and tap the slide bar.
“Your current setting will be lost, if you perform “Auto Screen Adjust”.
Do you continue?” appears on the screen.
3Trace the slide bar left and right to select “Yes” and tap the
slide bar.
The Auto Screen Adjust function is activated and the clock, phase and
screen position are adjusted automatically.
If satisfactory adjustment cannot be obtained with the Auto Screen
Adjust function, perform the adjustment following the procedure
below. When the screen is displayed correctly, go to step 6 “Auto
Range Adjust”.
Attention
• The Auto Screen Adjust function does
not work for the input signal of low
resolution, such as VGA, etc.
• Wait 30 minutes or more from
monitor power on before starting the
color adjustment.
NOTE
• Use the “Screen Adjustment Program”
on the supplied EIZO LCD Utility
Disk.
HD2441W_UM_EN.indd 16HD2441W_UM_EN.indd 16 4/14/2007 6:21:55 PM4/14/2007 6:21:55 PM

17
Chapter 3 Settings and Adjustment
●Advanced Screen Adjustment
4Run the Screen Adjustment Program.
Load the EIZO LCD Utility Disk on the PC, and start the Screen
Adjustment Program compatible with the PC in use.
After the program starts up, perform the adjustment in step 5 following the
instructions of the program.
5Perform the advanced adjustment using the <Screen> menu in
the Setting menu.
●To eliminate vertical bars [Clock]
(1) Choose the <Clock> icon in the <Screen> menu and tap the slide
bar.
The <Clock> menu appears.
(2) Trace the slide bar left and right to eliminate the vertical bars and
tap the slide bar.
The adjustment is completed.
●To remove flickering or blurring [Phase]
(1) Choose the <Phase> icon in the <Screen> menu and tap the slide
bar.
The <Phase> menu appears.
(2) Trace the slide bar left and right to remove the flickering or
blurring and tap the slide bar.
The adjustment is completed.
NOTE
• Trace the slide bar slowly to adjust
since the adjustment point is easily
missed.
• When blurring, flickering or bars
appear on the screen after adjustment,
proceed to [Phase] to remove
flickering or blurring.
Attention
• The flickering or blurring may not
be eliminated perfectly depending on
your PC or graphics board.
NOTE
• When vertical bars appear on the
screen after adjustment, go back
to “To eliminate the vertical bars
[Clock]” and perform again. (Clock
→Phase →Position)
NOTE
• For how to start the Screen
Adjustment Program, refer to the
“Readme.txt” or the “Readme” file.
When you are using a Windows PC,
you can run the program directly from
the start menu of the disk.
• If no adjustment program is available
for your PC, display a checkerboard
pattern on the screen (see below) and
go to the following steps.
HD2441W_UM_EN.indd 17HD2441W_UM_EN.indd 17 4/14/2007 6:21:55 PM4/14/2007 6:21:55 PM

18 Chapter 3 Settings and Adjustment
●To correct screen position [Hor.Position/Ver.Position]
Since the number of pixels and the pixel positions are fixed on
the LCD monitor, only one position is provided to display images
correctly. The position adjustment is made to shift an image to the
correct position.
Settings Screen status
Hor.Position When the screen position on the monitor is
shifted horizontally, perform the screen position
adjustment.
Ver.Position When the screen position on the monitor is
shifted vertically, perform the screen adjustment.
(1) Choose the <Hor.Position>/<Ver.Position> icon in the <Screen>
menu and tap the slide bar.
The <Hor.Position>/<Ver.Position> menu appears.
(2) Trace the slide bar left and right to adjust so that the whole display
area, drawn by the dotted line frame, appears on the screen. Then
tap the slide bar.
The adjustment is completed.
6Adjust the signal output range.
●To adjust color gradation automatically [Auto Range Adjust]
Every color gradation (0 to 255) can be displayed by adjusting the
signal output level.
