TWN3 MINI READER MIFARE NFC

INTEGRATION MANUAL

TABLE OF CONTENTS

1INTRODUCTION.................................................................................................................................................................. 3

1.1 ABOUT THIS MANUAL ..................................................................................................................................................3

1.2 ABOUT TWN3 MINI READER MIFARE NFC.................................................................................................................3

1.3 ELATEC SUPPORT........................................................................................................................................................3

1.4 REVISION HISTORY......................................................................................................................................................3

2SAFETY INFORMATION ..................................................................................................................................................... 3

3INTEGRATION INSTRUCTIONS......................................................................................................................................... 4

3.1 GENERAL.......................................................................................................................................................................4

3.2 LIST OF APPLICABLE RULES ......................................................................................................................................4

3.3 SPECIFIC OPERATIONAL USE CONDITIONS.............................................................................................................4

3.4 LIMITED MODULE PROCEDURES ...............................................................................................................................4

3.5 TRACE ANTENNA DESIGN...........................................................................................................................................4

3.6 RF EXPOSURE CONSIDERATIONS.............................................................................................................................4

3.7 ANTENNAS ....................................................................................................................................................................4

3.8 LABEL AND COMPLIANCE INFORMATION .................................................................................................................5

3.9 TEST MODES AND ADDITIONAL TESTING REQUIREMENTS...................................................................................5

3.10 MECHANICAL INSTALLATION......................................................................................................................................5

3.11 ELECTRICAL CONNECTION.........................................................................................................................................5

3.12 PROGRAMMATION/SOFTWARE INTEGRATION ........................................................................................................5

4COMPLIANCE STATEMENTS ............................................................................................................................................ 6

4.1 EU ...................................................................................................................................................................................6

4.2 RF EXPOSURE COMPLIANCE .....................................................................................................................................6

5INTEGRATOR AND HOST REQUIREMENTS .................................................................................................................... 6

APPENDIX ....................................................................................................................................................................................... 7

A – TERMS AND ABBREVIATIONS...........................................................................................................................................7

B – RELEVANT DOCUMENTATION ..........................................................................................................................................7

1INTRODUCTION

1.1 ABOUT THIS MANUAL

This integration manual explains how to integrate ELATEC RFID reader module TWN3 Mini Reader MIFARE NFC into a host device

and is mainly intended for integrators and host manufacturers.

The content of this integration manual is subject to changes without prior notice and printed versions might be obsolete. Integrators

and host manufacturers are required to use the latest version of this integration manual.

For the sake of better understanding and readability, this manual might contain exemplary pictures, drawings and other illustrations.

Depending on your product configuration, these pictures might differ from the actual design of your product.

1.2 ABOUT TWN3 MINI READER MIFARE NFC

ELATEC TWN3 Mini Reader MIFARE NFC is designed for integration into machines, handheld computers or any other device. The

focus has especially been set on size, low power consumption, price and flexibility. Thanks to its compact dimensions, integration

directly on a PC board is possible.

1.3 ELATEC SUPPORT

In case of any technical questions, refer to the ELATEC website (www.elatec.com) or contact ELATEC technical support at:

support-rfid@elatec.com

1.4 REVISION HISTORY

VERSION

CHANGE DESCRIPTION

EDITION

First edition

10/2021

2SAFETY INFORMATION

•ELATEC TWN3 Mini Reader MIFARE NFC is an electronic component and should be installed exclusively by a trained and qualified

personnel.

•ELATEC recommends the integrators to follow general ESD protective measures during the installation of

TWN3 Mini Reader MIFARE NFC into a host device, e.g. the use of an antistatic wristband or special gloves.

•The integrator should not touch the antennas (if not shielded), printed circuit boards, connectors or other sensitive components on

TWN3 Mini Reader MIFARE NFC.

•Before installing TWN3 Mini Reader MIFARE NFC into a host device, the integrator should also make sure that he/she has read

and understood the ELATEC technical documentation related to TWN3 Mini Reader MIFARE NFC, as well as the technical

documentation related to the host device. In particular, the instructions and safety information given in the user manual of

TWN3 Mini Reader MIFARE NFC should be read carefully and listed in the technical documentation of the host manufacturer as

well, as soon as these instructions and safety information are required for a safe and proper use of the host device containing

TWN3 Mini Reader MIFARE NFC.

3INTEGRATION INSTRUCTIONS

3.1 GENERAL

TWN3 Mini Reader MIFARE NFC may be installed in any host devices, as long as it is operated under the operational conditions

stated in the user manual and other technical documents (e.g. data sheet). TWN3 Mini Reader MIFARE NFC is equipped with one

integrated antenna. Thus, no antenna installation is required.

3.2 LIST OF APPLICABLE RULES

Refer to the approval certificates, grants and declarations of conformity issued for TWN3 Mini Reader MIFARE NFC, and to Chapter

“Compliance Statements” for a detailed list of the rules applicable to TWN3 Mini Reader MIFARE NFC.

3.3 SPECIFIC OPERATIONAL USE CONDITIONS

There are no specific operational use conditions for TWN3 Mini Reader MIFARE NFC other than the conditions mentioned in the user

manual and data sheet of TWN3 Mini Reader MIFARE NFC. The host manufacturer or integrator must ensure that these use conditions

comply with the use conditions of the host device. In addition, these use conditions must be stated in the user manual of the host

device.

3.4 LIMITED MODULE PROCEDURES

n/a

3.5 TRACE ANTENNA DESIGN

n/a

3.6 RF EXPOSURE CONSIDERATIONS

The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 4 cm and any additional testing

and authorization process as required.

Refer to Chapter “Compliance Statements” for detailed information about the radio frequency exposure conditions applicable to TWN3

Mini Reader MIFARE NFC.

These RF exposure conditions must be stated in the end-product manual(s) of the host product manufacturer.

3.7 ANTENNAS

TWN3 Mini Reader MIFARE NFC is equipped with the following antenna:

HF antenna (13.56 MHz)

Dimensions: 27.5 x 25 mm / 1.08 x 0.98 inch

Number of turns: 4

For more information, refer to the related product data sheet or

other technical documents.

3.8 LABEL AND COMPLIANCE INFORMATION

Refer to Chapters “Compliance Statements” and “Integrator and Host Requirements” for detailed label and compliance information.

3.9 TEST MODES AND ADDITIONAL TESTING REQUIREMENTS

No specific testing method has been defined by ELATEC for TWN3 Mini Reader MIFARE NFC.

TWN3 Mini Reader MIFARE NFC has been tested and found in compliance with the specifications noted on the approval certificates

and other relevant approval documents. However, the integrator is still responsible for any additional testing and authorization process

required for the end product.

3.10 MECHANICAL INSTALLATION

The module is plugged onto socket connectors. No further mechanical fixation is provided.

3.11 ELECTRICAL CONNECTION

Fig. 1 - Pin spacing 2.54 mm

NAME

DESCRIPION

RESET

Asynchronous reset

PWRDWN

Hard power down

GND

Ground

VCC

3.3 – 5 V

RXD/MOSI

UART/SPI receiver input

TXD/MISO

UART/SPI transmitter input

SCK

SPI serial clock input

SPI slave select input

VSAM

3.0V regulated supply for SAM

SAM_IO

Bidirectional SAM I/O line

GPIO3

General purpose input/output 3

GPIO2

General purpose input/output 2

GPIO1

General purpose input/output 1

GPIO0

General purpose input/output 0

SAM_CLK

SAM clock output

SAM_RST

SAM reset output

3.12 PROGRAMMATION/SOFTWARE INTEGRATION

n/a

4COMPLIANCE STATEMENTS

4.1 EU

TWN3 Mini Reader MIFARE NFC is in compliance with the EU directives and regulations as listed in the respective declaration of

conformity.

4.2 RF EXPOSURE COMPLIANCE

RF exposure statement (mobile and fixed devices)

This device complies with the RF exposure requirements for mobile and fixed devices. However, the device shall be used in such a

manner that the potential for human contact during normal operation is minimized.

5INTEGRATOR AND HOST REQUIREMENTS

Compliance statements

All statements listed in Chapter “Compliance statements” of this integration manual must be also listed in the user manual of the host

device.

Special accessories

Where special accessories such as shielded cables and/or special connectors are required to comply with the emission limits, the

instruction manual shall include appropriate instructions on the first page of the text describing the installation of the device.

Simultaneous transmission

When the host product supports simultaneous-transmission operations the host manufacturer needs to check if there are additional

RF exposure filing requirements due to the simultaneous transmissions. When additional application filing for RF exposure compliance

demonstration is not required (e. g. the RF module in combination with all simultaneously operating transmitters complies with the RF

exposure simultaneous transmission SAR test exclusion requirements), the host manufacturer may do his own evaluation without any

filing, using reasonable engineering judgment and testing for confirming compliance with out-of-band, restricted band, and spurious

emission requirements in the simultaneous-transmission operating modes. If additional filing is required please contact the person at

ELATEC GmbH responsible for certification of the RF module.

APPENDIX

A – TERMS AND ABBREVIATIONS

TERM EXPLANATION

host device

Also “host” or “host product”. Device in which an RFID module is intended to be installed for operation.

Integrator

Responsible party for the integration of an RFID module into a host device. The integrator might be the

module manufacturer, the host manufacturer, the end user or any other third party.

modular type

Physical configuration in which a modular transmitter operates when installed within a host device. It can

be a single-modular, a limited single-modular, a split-modular or a limited split-modular type.

n/a

Not applicable

RFID (reader)

module

Device intended to be used within another device or product. Depending on the equipment configuration

and intended use, an RFID module has to meet different requirements to get a modular grant.

B – RELEVANT DOCUMENTATION

ELATEC documentation

•TWN3 Mini Reader MIFARE NFC data sheet

•TWN3 Mini Reader MIFARE NFC functional description

•TWN3 Mini Reader MIFARE NFC user manual

External documentation

Document name

Document title/description

Source

n/a

Technical documentation related to the

host product

Host product manufacturer

For more information about this integration manual or TWN3 Mini Reader MIFARE NFC, go to www.elatec.com or contact ELATEC.

Elatec reserves the right to change any information or data in this document without prior notice. Elatec declines all responsibility for the use of this product with any other specification but the one mentioned above. Any

additional requirement for a specific customer application has to be validated by the customer himself at his own responsibility. Where application information is given, it is only advisory and does not form part of the
