Electra Accessories Scoot-N-Go 88700 Use and care manual

ELECTRIC SCOOTER
Assembly and User's Manual
Model#: 88700 / 88701 / 88702 / 88703 / 88705 / 88615
For the most recent version of this user's manual and for all updated
product information please visit www.electrausa.com or call
Electra Customer Service / Technical Support Toll-Free Number at:
1-888-467-1234
M-F 10am - 9pm EST
NEITHER ELECTRA ACCESSORIES NOR THE RETAIL SELLER OF THE
SCOOT - N - GO™ IS RESPONSIBLE FOR THE CONSEQUENCES OF
FAILURE TO COMPLY WITH STATE AND LOCAL ORDINANCES. THIS SCOOTER IS
NOT INTENDED FOR USE ON PUBLIC STREETS OR HIGHWAYS.
CHECK WITH DMV AND WITH LOCAL AND STATE LAWS AS YOUR CITY,
MUNICIPALITY OR STATE MAY PROHIBIT THEIR USE.
Electra Accessories Inc.
2 Corporate Drive
Cranbury, New Jersey 08512 USA
website: www.electrausa.com
READ THIS MANUAL BEFORE OPERATING YOUR SCOOT-N-GOTM
ELECTRA ACCESSORIES, INC. STRONGLY SUGGESTS THE
OPERATOR OF THIS PRODUCT BE 16 YEARS OF AGE OR OLDER.

1
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS
INVOLVING THE USE OF THE SCOOT - N - GO™. TO DETERMINE IF COVERAGE IS
PROVIDED YOU SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.

2
Features and Specifications
Motor, Battery, Performance,Tires______________________________
Contents of the Box______________________________________________
General Safety Guidelines & Restrictions________________________
Assembly Instructions
 Front Wheel Installation______________________________________
 Handlebars Installation___________________________________
  Throttle & Controls Installation_________________________
  Seat Installation__________________________________
  Fuse Installation________________________________
Pre-Ride Adjustments
Brakes___________________________________________________
 Tires/Wheel__________________________________________
  Drive Chain_______________________________________
Battery
Charging_________________________________________________
Starting Instructions
Keys & Ignition____________________________________________
Service & Maintenance
Drive Chain_______________________________________________
 Brakes_________________________________________________
 Tires______________________________________________
  Battery____________________________________________
Storage________________________________________________________
Trouble Shooting________________________________________________
Replacement Parts______________________________________________
Wiring Diagram_________________________________________________
30 Day Limited Warranty_________________________________________
Warranty Limitations____________________________________________
Warranty Service Options________________________________________
Return Policy___________________________________________________
Notes_________________________________________________________
TABLE OF CONTENTS
3
4
5,6,7,8
9
10
10
11
11
12
13
14
15
16
16
16
16, 17
17
18
19
19
20
21
21
22
23
24

Motor
l Output: 250W
l Voltage: 24V DC
l Rated current: 14.0A
l Non-loading rotate speed: 3350±5%
l Rated rotate speed: 2500 RPM
l Rated torsion: 0.90
Battery
l 12V 12Ah/5hr x (2) Qty
l Sealed lead acid
FEATURES & SPECIFICATIONS
Performance
l Maximum speed: 11 MPH
l Range: Nine (9) miles
l Incline rating: 40
l Net Weight: 45 lbs.
l Maximum load cap.: 178 lbs.
Tires
l Tire Size: 2 1/4" x 12 1/2"
l Tire Pressure: 45-50 PSI
Key Ignition
Headlight
Turn Signals
Turn Signals
Brake Light
Mag Wheels
Footrests
Working Gauges
Quick Connect Charging
3

4
l One (1) SCOOT - N - GO™
l User/assembly manual
l Tool kit containing 2 open ended wrenches,
combination Phillips/Flathead head screwdriver
l Spare fuses (30 Amp x 3 qty)
l 24V Battery charger
CONTENTS OF BOX
Charger
Manual
SCOOT - N - GO™
Tool Kit

5
GENERAL SAFETY GUIDELINES & RESTRICTIONS
This Manual contains many notes concerning the consequences of failure to maintain or inspect your SCOOT - N -
GO™. Your safety and the safety of others is very important. We have provided important safety messages in this
manual and on the SCOOT - N - GO™. Please read these messages carefully. A safety message alerts you to
potential hazards that could hurt you or others. Each safety message is preceded by a safety alert symbol and one
of two words.
You CAN be SERIOUSLY HURT or KILLED if you don't follow instructions. Failure to follow the instructions
following it may result in injury to the rider or others during use, which may include loosing control and falling.
Because any fall can result in serious injury or even death, we do not repeat the warning of possible injury or death
whenever the risk of falling is mentioned
Failure to follow the instructions following it may result in damage to the SCOOT - N - GO™ or component during
assembly or use.(I.e.risk of property (product) damage only)
CHECK STATE & LOCAL LAWS
Your state department of motor vehicles (DMV),or the city or county where it will be used, may regulate the use of
devices like the SCOOT - N - GO™.Some states may require a driver's license or minimum age to use the SCOOT - N -
GO™, or require the SCOOT - N - GO™ to be registered or licensed or require some additional type of equipment
like a brighter headlight. Please check with your state DMV or local municipality on requirements for using the
SCOOT - N - GO™.They can be located in the phonebook. State DMV offices can also be located on the Internet at
such sites as the following www.dmv.org or www.statehousegirls.net/agencies/dmv.
If your state or municipality allows the SCOOT - N - GO™ to be used on vehicle roadways please make sure you are
familiar with all traffic laws as set forth by your state DMV, such as yielding to pedestrians and other motorists,
signaling, riding as far to the right edge of the roadway as possible, obeying traffic signs etc. Your state DMV can
provide you with materials setting forth these traffic laws.
In addition to those traffic laws abide by the following general principals:
1.You are sharing the road or the path with others -- motorists,pedestrians and other cyclists.Respect their rights,
and be tolerant if they infringe on yours.
2.Ride defensively.
3.Look ahead of where you're going,and be ready to avoid:
* Vehicles slowing or turning in front of you,entering the road or your lane ahead of you,or coming up behind you.
* Parked car doors opening in front of you.
* Pedestrians stepping out in front of you.
* Children or dogs playing near the road.
* Pot holes,sewer grating,railroadtracks,expansion joints,road or sidewalk construction,debrisandother obstructions
thatcould causeyou toswerveinto traffic,catchyourwheelorotherwisecauseyou tolose controland haveanaccident.
* ThemanyotherhazardsanddistractionswhichcanoccurwhileusingtheSCOOT-N-GO™duringaride.
4. Ride on the right side of the road,in the same direction as vehicle traffic and as close to the edge of the road as possible.
5.Stop at stop signs and traffic lights;slow down and look both ways at street intersections.Remember that the
SCOOT - N - GO™ will always lose in a collision with a motor vehicle,so be prepared to yield
even if you have the right of way.
6.Use hand signals for turning and stopping.Learn the local vehicle code for the correct signals.
7.Don't weave through traffic or make any moves that may surprise people with whom you are sharing the road.
8. Never carry anything which obstructs your vision or your complete control of the SCOOT - N - GO™, or which
could become entangled in the moving parts of the SCOOT - N - GO™.
9.Never hitch a ride by holding on to another vehicle.
NEITHER ELECTRA ACCESSORIES NOR THE RETAIL SELLER OF THE SCOOT - N - GO™ IS RESPONSIBLE FOR
THE CONSEQUENCES OF FAILURE TO COMPLY WITH STATE AND LOCAL ORDINANCES RELATING TO THE USE
OF THE SCOOT - N - GO™
CALIFORNIA PROPOSITION 65
THIS PRODUCT CONTAINS LEAD AND LEAD COMPOUNDS, CHEMICALS KNOWN TO THE STATE OF CALIFORNIA
TO CAUSE CANCER AND REPRODUCTIVE HARM.WASH HANDS AFTER HANDLING.

6
1" inch
25" inch
A
B
C
GENERAL SAFETY GUIDELINES & RESTRICTIONS
HELMET USE WHILE RIDING THE SCOOT - N - GO™
Your state DMV, or the city or county where it will be used, may require that you use a helmet that
meets the federal Department of Transportation "DOT" requirements (like those used by motorcycle
riders) while riding the SCOOT - N - GO™. Other states or municipalities may require that a helmet
meet the Consumer Product Safety Commission (CPSC) helmet requirements (like those used by
human powered bike riders) while riding the SCOOT - N - GO™. Even if your State or municipality has
no requirements concerning helmet use, the SCOOT - N - GO™ should not be used under any
circumstances without properly wearing a helmet that meets either the DOT or CPSC regulations.The
helmet must have a label inside which indicates which regulation it meets. If you are unsure contact
DOT at www.nhtsa.gov (888-327-4236) or CPSC at www.cpsc.gov (800-638-2772).
Follow Safety Guidelines:
*Your safety and the safety of others is very important. We have provided important safety
messages in this manual and on the SCOOT - N - GO ™. Please read these messages carefully. A
safety message alerts you to potential hazards that could hurt you or others.
• Never operate the SCOOT - N - GO™ without proper instructions.
• Never allow a child under the age of 16 to operate the SCOOT - N - GO™
• Failures to follow the warnings contained in this manual can result in serious injury or death.
• Read this manual and all warning labels carefully and follow the operating procedures as
described.
• Do not operate the SCOOT - N - GO™ unless you are able to safely start, stop,turn, and yield to all
obstacles in the environment.
• Follow all local and state laws for approved riding areas,rules and regulations.
• Never carry a passenger on the SCOOT - N - GO™.
• Never ride the SCOOT - N - GO™ on public streets, sidewalks,parking lots, highways,
freeways, or at night.
• Never operate on excessively rough, slippery or loose terrain.
• Never operate downhill or uphill.Always operate on level surfaces
• Never operate at excessive speeds.Always go at a speed that is proper for
the operating conditions and your experience.
• Never attempt wheelies,jumps,or other stunts.
• SCOOT - N - GO™ should not be ridden by any person weighing
more than 178 lbs
• SCOOT - N - GO™ should not be ridden by any person shorter than 60"
• SCOOT - N - GO™ should not be ridden by any person with an inseam
of less than 25"

7
• SCOOT - N - GO™ should not be ridden by any person that is physically or mentally challenged
• SCOOT - N - GO™ should not be ridden by any person with vision,balance,hearing or
coordination impairments
• SCOOT - N - GO™ should not be ridden by any person using headphones or a cellular phone
(They mask traffic sounds and emergency vehicle sirens,distract you from concentrating on
what's going on around you,and their wires can tangle in the moving parts of the SCOOT - N -
GO™,causing you to lose control)
• SCOOT - N - GO™ should not be ridden by any person barefoot,wearing sandals, open
toed,high heeled,platform or slip on footwear
• Never stand on a SCOOT - N - GO™ whether moving or not
• Always keep both hands on the handlebars and both feet on the footrest during
operation.
• Always be alert to your surroundings while riding the SCOOT - N - GO™.
• Always follow proper procedures for turning as described in this manual.
Do not turn at excessive speeds or make sudden or sharp turns.
• Always check for obstacles before operating the SCOOT - N - GO™ in a new area.
• Do not attempt to accelerate and have the brake on at the same time.[This may cause
damage to the motor or drive train or cause the motor or drive train to overheat.]
• Never operate the SCOOT - N - GO™ without wearing an approved helmet that fits
properly. You should also wear eye protection, gloves, closed-toe shoes, long-sleeved shirt
or jacket,long pants,as well as elbow and kneepads
• Never consume drugs or alcohol before or while operating the SCOOT - N - GO™.
Drugs or alcohol can impair your judgment and reaction time
• Before starting the SCOOT - N - GO™, check throttle control and brakes for proper
operation
• Always inspect the SCOOT - N - GO™ each time you use it to make sure it is in safe
operating condition. Check for loose screw, nuts,bolts,parts, brakes, drivechain, etc.
• Always follow the inspection and maintenance procedures described in this manual.
• Always use the size and type tires specified in this manual. Always maintain proper tire
pressure as described in this manual.Type of tire and inflation can affect the SCOOT - N -
GO™ handling
• Do not operate near flammable liquids or materials
• Never attempt to repair when ignition is on
• Keep all loose clothing away from drive chain
DO NOT MAKE ANY ALTERATIONS OR MODIFICATIONS TO THE SCOOT - N - GO™, OR ADD ANY
PARTS NOT AUTHORIZED BY ELECTRA EXCEPT THOSE DISCUSSED IN THIS MANUAL OR THOSE
REQUIRED BY LAW. DO NOT REMOVE ANY REFLECTORS, LIGHTS OR OTHER STANDARD
EQUIPMENT. FAILURE TO FOLLOW THESE OPERATION INSTRUCTIONS CAN RESULT IN SERIOUS
INJURY OR DEATH OR COULD RESULT IN AN ELECTRICAL SHORT AND OR FIRE. All authorized
replacement parts are available at www.electraUSA.com or by calling Electra customer service a
1-888-467-1234 M-F 10am - 9pm EST.
NEITHER ELECTRA ACCESSORIES NOR THE RETAIL SELLER OF THE SCOOT - N - GO™ IS
RESPONSIBLE FOR THE CONSEQUENCES OF FAILURE TO COMPLY WITH STATE AND
LOCAL ORDINANCES RELATING TOTHE USE OFTHE SCOOT - N - GO™
Continued on Next Page
GENERAL SAFETY GUIDELINES & RESTRICTIONS

8
BEFORE EACH RIDE:
• Make sure you properly (per the instructions in the helmet) wear a helmet that
meets DOT or CPSC regulations
• Wear protective clothing and gloves
• Wear eye protection that does not interfere with your peripheral vision
• Make sure SCOOT - N - GO™ is fully charged
• Make sure the horn, turn signals and headlight are operational
• Make sure the brake is properly adjusted and working correctly
• Make sure you understand how the brake works and that your hands can reach and
squeezethe brake levercomfortablyand hardenoughtostopthe SCOOT-N-GO™safely.
• Make sure the chain is properly adjusted
• Make sure all screw, nuts, bolts and parts of the SCOOT - N - GO™ are properly and
securely fastened and adjusted.
• Make sure the tires are not excessively worn, do not have tears or cuts, and are
properly seated on the rim and inflated properly
• Make sure the wheels spin straight and that the rims are not bent or damaged
*REFER TO MANUAL FOR DETAILED INSTRUCTIONS
AFTER EACH RIDE:
• Make sure that the ignition key is turned off and that all keys are removed and kept
in a safe place.
• Make sure the throttle is rotated to the off position.
• Ensure that the kickstand is used so the SCOOT - N - GO™ will not fall over and get
damaged.
• Ensure the SCOOT - N - GO™ is not kept outdoors or where moisture can damage it.
• Do not charge or store the SCOOT - N - GO™ closer than 20 feet from any flame (e.g.
furnace, fireplace, water heater, space heater)
• Do not allow children under 16 to play on or near the unattended SCOOT - N - GO™.
*REFER TO MANUAL FOR DETAILED INSTRUCTIONS
GENERAL SAFETY GUIDELINES & RESTRICTIONS

9
ASSEMBLY INSTRUCTIONS
BEFORE ASSEMBLING YOUR SCOOT-N-GOTM,PLEASE BE SURE YOU HAVE ALL NECESSARY
PARTS. REFER TO PAGE #4. PLEASE FOLLOW PROPER ASSEMBLY INSTRUCTIONS. IF YOU
DO NOT HAVE THE PROPER PARTS NECESSARY TO ASSEMBLE YOUR SCOOT-N-GOTM,
PLEASE DO NOT RETURN THE UNIT TO THE ORIGINAL PLACE OF PURCHASE. CALL
ELECTRA CUSTOMER SERVICE AT: 1-888-467-1234 M-F 10am - 9pm EST.
1. Remove scooter from carton and all protective materials from the unit.
2. Use tool kit provided for installation
FRONT WHEEL INSTALLATION:
1. Place wheel (D) in the center of the forks
2. Insert one (1) spacer (C) between wheel (D) and fork
3. Carefully insert axle (E) through fork, spacer (C), and wheel (D)
4.Insert one (1) spacer (C) on opposite side between fork and wheel (D)
5. Continue to insert axle (E) through fork on opposite side
6. Place washers (B) and nuts (A) on both ends of axle and tighten with open ended
wrench provided in the tool kit.
7. Check nuts are tight and wheel moves freely
Parts Needed
A
Nut
Qty- 2
Lockwasher
Qty- 2
B
Spacer/
Bearing-holder
Qty- 2
C
D
Front Wheel
Qty- 1
E
Axle
Qty- 1
*Photos are not to scale
Spacer
Spacer
Axle
Washer
Washer
Nut
Nut

10
ASSEMBLY INSTRUCTIONS
HANDLEBARS INSTALLATION:
1.Insert handlebar post through tightening clamp
2.Insert the top of the fork base into bottom of handlebar post.
3.Line up handlebars and front wheel
4.Slide tightening clamp down to open end of fork base
5.Insert bolt and hand tightening nut into clamp and tighten.
6.Be sure that handlebars and wheel move at the same time.
THROTTLE & ACCESSORY CONTROL GRIP INSTALLATION:
1.Insert throttle into handle bars and secure with tightening screw.(Fig.2)
2.Insert accessory control grip and secure with tightening screw. (Fig.3)
3.Be sure screws,throttle and accessory control grip are secure and not loose.
Fig.1
*Tightening Clamp
must line up with
the opened end
of the fork base
Handlebar Post
Tightening Clamp
Fork Base
Fig.2
Tightening Screw Throttle
Fig.3

11
ASSEMBLY INSTRUCTIONS
SEAT INSTALLATION:
1.Insert tapered end of seat post into seat and tighten both seat brackets.
2. Place tightening clamp around the chassis base, insert seat post, adjust for the proper height of
the rider,and tighten clamp.
3.Be sure seat is facing the front of the scooter and it does not move.
INSERT FUSE:
1. Remove fuse cap
2. Insert fuse into fuse cylinder and Rescrew cap (Fig.5)
3. Do not stick any objects other than the fuse into fuse cylinder.
Continued on Next Page
Fig.5
Fuse Cylinder
Fuse
Fuse Cap
Fig. 4
Seat Post
Tightening Clamp

12
PRE-RIDE ADJUSTMENTS
THE REAR BRAKE ON YOUR SCOOT - N - GO™ HAS BEEN PRE-ASSEMBLED AND PRE-ADJUSTED BY
THE MANUFACTURER.
HOWEVER,THE CABLE AND BRAKE MAY NEED ADJUSTMENT IF IT IS NOT SLOWING OR STOPPING
THE SCOOT - N - GO™ PROPERLY. THE BRAKE CAN BE ADJUSTED AT TWO POINTS ON THE THE
SCOOT - N - GO™ . ONE ADJUSTING SCREW IS AT THE REAR WHEEL AND OTHER IS AT THE BRAKE
LEVER.
REAR BRAKE ADJUSTMENT:
1. Determine brake lever has proper slack
*Brake lever cannot be too tight or it can snap the cable!
*Brake lever cannot be to loose or your SCOOT - N - GO™ may not stop correctly
2. To adjust slack, rotate brake adjustment knob to desired position.
Check slack by engaging the brake lever. (FIG. 2)
*Proper slack should be similar to FIG.1 (A properly adjusted brake lever should leave approximately
1"- 1 1/4" between the brake lever and throttle grip)
3.If desired slack is achieved,rotate the locking nut clockwise until tight.
4.To adjust rear brake,locate adjustment screw at the rear wheel.
5.Loosen or tighten screw for proper adjustment. Rotate 3 to 4 times, and then check for desired
tension by rolling the scooter forward and engaging the brake.
6.If desired brake tension has been achieved, rotate the locking nut clockwise until tight.
7. Rear wheel should not roll when brake is engaged.
IF THE PROPER TENSION IS STILL NOT ACHIEVED,CHECK THE BRAKE AND CABLE TO ENSURE EVERY
PART IS PROPERLY CONNECTED. DAMAGED OR FAULTY BRAKE COMPONENTS (CABLE, BRAKE
ASSEMBLY) WILL NOT ALLOW FOR THE SCOOTER TO STOP PROPERLY AND SHOULD BE REPLACED
IMMEDIATELY TO AVOID ANY SERIOUS INJURIES TO THE USER OR OTHERS. REPEAT PROCEDURE
UNTIL DESIRED TENSION IS ACHIEVED.
Periodically check the control cables,cable housings, and brake lever.Any rust? Kinks? Fraying? If so,DO
NOT ride the SCOOT - N - GO™.Call Electra customer service at1-888-467-1234 M-F 10am - 9pm EST or
visit your local bicycle dealership and have them adjusted or replaced.
Continued on Next Page
Adjustment Knob
Locking Nut
Brake Lever
FIG.2
FIG.3
Rear Adjustment Screw Locking Nut

13
PRE-RIDE ADJUSTMENTS
TIRE ADJUSTMENTS:
Make sure that the air pressure for all tires is between 45-50 PSI . If the tires have less than the
recommended amount of pressure, a decrease in battery usage time, poor handling, and damage
to the tires and rims may occur. Use an air pressure gauge to check for the air pressure of the tire.
DO NOT USE GAS STATION AIR FILLING STATIONS AS THE PRESSURE IS USUALLY TOO HIGH AND THE
GAUGES ARE INACCURATE.OVER INFLATION OF THE TIRE COULD CAUSE A BLOW OUT AND CRASH.
WHEEL ADJUSTMENTS/MAINTANENCE:
1. Wheels should rotate straight and freely
2. A lubricant or oil should be applied to the wheel bearings monthly or more often if ridden in
extremely wet or dusty conditions.
Periodically check tires, wheels, bearings, and cables. Any rust? Kinks? Fraying? If so, DO NOT ride the
SCOOT - N - GO™. Call Electra customer service at 1-888-467-1234 M-F 10am - 9pm EST or visit your
local bicycle dealership and have them adjusted or replaced.
ProperTire Pressure 45-50 PSI
IMPORTANT INFORMATION!!!
40
PSI
20 60
080
10 70
30 50
45

14
PRE-RIDE ADJUSTMENTS
DRIVE CHAIN ADJUSTMENTS
CHECKING CHAIN TENSION:
1.Make sure key is not in ignition
2.Lay bike on its side to check drive chain
3.Squeeze chain using your thumb and index finger to determine if chain is too loose or too tight.(FIG.1)
4.Also move chain side by side to check if chain could jump of sprocket teeth.
5.Chain should not move passed sprocket teeth when moving side by side. (FIG. 2)
TIGHTEN DRIVE CHAIN:
1. Loosen the rear axle nuts (counter clockwise)
2. Tighten the chain adjustment eye bolts (clockwise) evenly so that the rear wheel doesn't become
misaligned.
3. Once the proper drive chain tension has been achieved, tighten the axle nuts (clockwise).
CHAIN MUST HAVE NO LESS THAN AND NO MORE THAN A 1/4" OF MOVEMENT.
IF CHAIN IS TOO TIGHT,IT CAN BREAK AND CAUSE SERIOUS INJURY
LOOSEN DRIVE CHAIN:
1. Loosen the rear axle nuts (counter clockwise).
2. Loosen the chain adjustment eye bolts (counter clockwise) evenly so that the rear wheel doesn't
become misaligned.
3. Once the proper drive chain tension has been achieved, tighten the axle nuts (clockwise).
CHAIN MUST HAVE NO LESS THAN AND NO MORE THAN A 1/4" OF MOVEMENT.
IF CHAIN IS TOO LOOSE,IT CAN JUMP OFF OR BREAK FROM THE DRIVE TRAIN AND CAUSE SERIOUS
INJURY
The chain should be cleaned and lubricated with bicycle chain lubricant (available at local bike
shops) after every 100 miles of riding (approx.ten rides) or after riding the SCOOT - N - GO ™ in wet
road conditions
Axle Nut
Sprocket
Drive Tension Nut
Chain
Drive Chain Requires
No More & No Less Than
1/4" Movement
1/4"
1/4"

15
BATTERY
BEFORE OPERATING YOUR NEW SCOOT - N - GO™ FOR THE FIRST TIME,THE BATTERY MUST BE
FULLY CHARGED! FAILURE TO KEEP THE SCOOT - N - GO ™ BATTERY CHARGED WILL CAUSE TOTAL
BATTERY FAILURE.DO NOT ALLOW BATTERY TO BE FULLY DISCHARGED!
ONCE CHARGER IS PROPERLY ATTACHED TO SCOOTER AND A SUFFICIENT POWER SOURCE,THE
CHARGER INDICATOR LIGHT WILL FLASH INDICATING THE UNIT IS BEING PROPERLY CHARGED.
ONCE FULLY CHARGED THE INDICATOR LIGHT WILL REMAIN GREEN
Be sure to charge the SCOOT - N - GO™ after each use.Keeping the battery
properly charged will help extend the battery life.The battery must be charged while installed in the
SCOOT - N - GO™.If you notice anything unusual about the battery such as a
cracked or leaking battery case,a battery that gets hot while being used or charged, a battery case that
appears "puffy" or "bloated" etc, or there are any other problems with the battery, please contact
Electra Customer Service / Technical Support Toll-Free at 1-888-467-1234 M-F 10am - 9pm EST.
The battery is sealed and is NOT user serviceable.Do not attempt to repair, remove, adjust or in any
way alter any internal or electrical components,controls or wiring without first speaking with a
customer service representative.
THE SCOOT - N - GO™ IS EQUIPPED WITH A 24V BATTERY CHARGER THAT WILL
INTERRUPT THE CHARGING PROCESS ONCE THE BATTERY HAS RECEIVED A SUFFICIENT CHARGE.
CHARGING THE BATTERY
• DO NOT CHARGE OR STORE THE SCOOT - N - GO™ CLOSER THAN 20 FEET
FROM ANY FLAME (E.G.FURNACE,FIREPLACE,WATER HEATER, SPACE HEATER)
• Be sure to only use 110V AC with the SCOOT - N - GO™ charger.Also make sure
the plug is inserted into a three prong grounded AC outlet.
• PLUG the POWER INPUT CORD into the SCOOT - N - GO™ charging receptacle.
• Plug the SCOOT - N - GO™ 24V battery charger into a 110V AC power source.
• The CHARGER INDICATOR LIGHT will illuminate confirming that power is connected to the charger.If
the light does not come on check all connections.If it still does not come on after checking all
connections,fuses and that your AC plug is working,unplug the charger and call Electra Customer
Service / Technical Support Toll-Free at 1-888-467-1234 M-F 10am - 9pm EST
• When the light on the 24V charger light is solid green, your SCOOT - N - GO™ is fully charged
• Disconnect the Input Cord from the Charging Receptacle.
• Disconnect the charger from the 110V Power Source.
• NEVER LEAVE THE BATTERY CHARGER CONNECTED TO THE 110V POWER SOURCE OR THE
SCOOT - N - GO™ WHEN NOT CHARGING THE BATTERY.KEEPING THE CHARGER
PLUGGED INTO THE 110V POWER SOURCE AND NOT THE BATTERY COULD CAUSE THE CHARGER
TO OVERHEAT AND OR CAUSE A FIRE.
• When storing your SCOOT - N - GO™ for lengthy periods of time, the battery
should be charged at least once a month to avoid full battery depletion.
CALIFORNIA PROPOSITION 65
BATTERY POSTS,TERMINALS,POWER CORDS AND BRAKE CABLES MAY CONTAIN LEAD AND LEAD
COMPOUNDS, CHEMICALS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND
REPRODUCTIVE HARM.WASH HANDS AFTER HANDLING.

16
STARTING INSTRUCTIONS
1.Make sure you have READ ALL SAFETY GUIDELINES AND PRE-RIDE ADJUSTMENTS IN THIS MANUAL
2.Make sure battery is fully charged
3.Check brakes
4.Insert key in ignition and turn right
5.Check throttle
6.Check all lights
7.Rotate throttle to accelerate
DRIVE CHAIN
*Refer to Pre-Ride Adjustments in this manual
BRAKES
*Refer to Pre-Ride Adjustments in this manual
FLAT TIRE REPAIR
To change a tire or inner tube, it is a good idea to keep the SCOOT - N - GO™ tool kit with you when
you ride.You should also carry plastic "tire levers" (available at local bike shops),a spare inner tube that
fit the wheel and tire size available from Electra at www.electraUSA.com or by calling Customer Service
at 1-888-967-1234 M-F 10am-9pm EST as well as a manual hand pump to re-inflate the tire if you have
a flat or it becomes low during use.
1.Depress the tire valve to let all the air out of the tube.
2. Remove the wheel from the scooter using the wrench provided or your own wrench. Loosen the
nuts by turning counterclockwise. Be sure to remember where all the spacers and washers belong. For
rear tire removal you will also need to slip the chain off the rear sprocket to remove the wheel. The
chain must be properly reinstalled and re-tensioned when reinstalling the rear wheel.Make certain the
chain is properly position on both front and rear sprockets before re-tightening rear wheel.
3.Remove one bead of the tire from the rim by grasping it at a point opposite the valve stem with both
hands and, at the same time, lifting and peeling one side of the tire off the rim. If the bead is on too
tight for you to unseat it with your hands use tire levers to lift the bead carefully over the tire rim.Tire
levers can be purchased at any local bike shop. Push the valve stem through the wheel rim. Remove
the inner tube.
4. Carefully check the outside and inside of the tire for the cause of the puncture and remove any
debris or damaging material from the inside or outside of the tire.
Continued on Next Page
SERVICE & MAINTENANCE

17
PATCHING ATUBEISAN EMERGENCYREPAIR.CARELESS PATCHINGORAPPLYING SEVERALPATCHES CAN
SERIOUSLY WEAKEN THE TUBE, RESULTING IN POSSIBLE TUBE FAILURE, WHICH COULD CAUSE YOU TO
LOOSECONTROL ANDFALL.REPLACEAPATCHEDTUBEASSOONASPOSSIBLE.
5. Reinstall the tire and tube. Slip one tire bead over the rim. Insert the valve stem through its hole in
the rim. Feed the tube carefully into the cavity of the tire. Inflate the tube just enough to give it some
shape. Starting at the valve stem and working around both sides of the rim to the side opposite the
valve stem,use your thumbs to push and seat the other bead of the tire inside the rim.Be careful not to
pinch the tube between the tire bead and the wheel rim. If you have trouble getting the last few
inches of bead over the edge of the rim with thumb pressure, use a tire lever and be careful not to
pinch the tube.
6. Check to make sure that the tire is evenly seated around both sides of the rim and that the tube is
inside the tire beads. Push the valve stem into the tire to make sure that its base is seated within the
tire's beads. Inflate the tube slowly to the recommended pressure on the tire sidewall. Check to make
sure that the tire beads stay seated in the rim.Replace the valve cap.Replace the wheel in the scooter.
RIDING YOUR SCOOT - N - GO™ WITH A CUT TIRE, FLAT OR UNDER- INFLATED TIRE CAN SERIOUSLY
DAMAGE THE TIRE, RIM (WHEEL), TUBE, AND THE SCOOTER. IT MAY ALSO CAUSE YOU TO LOSE
CONTROL AND FALL. IF YOU USE A SCREWDRIVER OR ANY TOOL OTHER THAN A TIRE LEVER, YOU
ARE LIKELY TO PUNCTURE THE TUBE.Replacement parts are able to be purchased by calling the
Electra Customer Service at 1-888-967-1234 M-F 10am - 9pm EST or by visiting Electra's website at
www.electraUSA.com.
DO NOT USE GAS STATION AIR FILLING STATIONS AS THE PRESSURE IS USUALLY TOO HIGH AND THE
GAUGES ARE INACCURATE.OVER INFLATION OF THE TIRE COULD CAUSE A BLOW OUT AND CRASH
BATTERY MAINTENANCE
*Refer to battery charging instructions
BATTERY RECYCLING
When maintained and used properly,(by following charging and storage guidelines),the Lead Acid Battery
used in this product has a normal life span of many miles.When the battery no longer holds a charge or is
unable to be charged properly, it should be removed from the SCOOT - N - GO™ and delivered to a
recycling facility. State Laws prohibit disposal of lead-acid batteries in everyday trash. Please contact your
local solid waste or recycling authority for recycling information in your area.
SERVICE & MAINTENANCE

18
STORING YOUR SCOOT - N - GO™
Proper storage preparation is essential for keeping your SCOOT - N - GO™
trouble free and in good working order. The following steps will help you keep
rust and corrosion from impairing your SCOOT - N - GO™ functions and
appearance.
STORAGE PRECAUTIONS
• Select a well-ventilated storage area away from any heat, flames, such as a
furnace, water heater, or clothes dryer.
• Avoid leaving your SCOOT - N - GO™ outside or in damp, moist areas to prevent
rust and corrosion.
• Do not wash your SCOOT - N - GO™ with a hose or water.To clean your SCOOT - N -
GO™ use a damp cloth to wipe dirt.
• Do not leave key in ignition.
• Keep Upright when storing
REMOVING FROM LONG TERM STORAGE
After removing your SCOOT - N - GO™ from long term storage,go through the
proper assembly steps and pre-ride adjustments.Make sure all bolts, nuts and
fasteners are securely tightened. Check the drive chain tension and wheel bearings .
Inspect entire unit for any rust or corrosion.Make sure there are no cuts or splits in
the rubber tires.Following these steps will ensure a safe unit and fun riding
experience.
STORAGE

19
To order replacement and/or spare parts for your SCOOT - N - GO™., make
sure you call the Electra Customer Service / Technical Support Toll-Free
Number 1-888-467-1234 M-F 10am - 9pm EST or view the SCOOT - N - GO™
replacement parts available at www.electraUSA.com.
TROUBLE SHOOTING
Problem
1.Scooter motor does not run
2.Scooter does not accelerate
3. The actual driving range is
shorter than the estimated range
Possible Cause
1.Key ignition is in OFF position
2.Fuse has burned out/failed
3. Battery is undercharged
1.Battery is undercharged or
completely drained
2.Electric throttle is not attached or in
need of repair
3.Drive chain has become unseated
1.The tires are under inflated
2.The battery is undercharged
3. Poor riding conditions
4. Weight of rider
5.Drive Chain
Correction
1.Rotate Key to ON position
2.Remove,inspect, and replace
with additional fuses from tool kit
3. Charge the battery for a sufficient
amount of time;replace battery
1.Charge the battery for a sufficient
amount of time;replace battery
2.Check all throttle connections and
wiring;replace throttle if necessary
3.Reseat the drive chain on both
sprockets and adjust tension
1.Inflate to 45-50 PSI
2. Charge the battery for a sufficient
amount of time; replace battery
3.Do not ride in sand,ice,snow,or
unstable riding areas
4. Mfg.suggest rider not exceed
178 lbs.
5. Adjust Drive chain tension
REPLACEMENT PARTS
If your SCOOT - N - GO™ sustains an impact:
A CRASH OR OTHER IMPACT CAN PUT EXTRAORDINARY STRESS ON COMPONENTS, CAUSING THEM
TO FATIGUE PREMATURELY. COMPONENTS SUFFERING FROM STRESS FATIGUE CAN FAIL SUDDENLY
AND CATASTROPHICALLY,CAUSING LOSS OF CONTROL,SERIOUS INJURY OR DEATH.
First,check yourself for injuries, and take care of them as best you can. Seek medical help if necessary.
Next, if your SCOOT - N - GO™ is damaged, perform the checks described in this manual. If you are
unable to fix any or all damage/problems,or if you find any bent,scored,or discolored parts,please call
Electra Customer Service at 1-888-467-1234 M-F 10am - 9pm EST or visit the Electra website at
electraUSA.com for replacement parts.
IF YOU HAVE ANY DOUBT ABOUT THE CONDITION OF THE SCOOT - N - GO™ OR ANY OF ITS PARTS,
CALL ELECTRA CUSTOMER SERVICE AT 1-888-467-1234 M-F 10AM - 9PM EST AND THEY WILL
ASSIST YOUR IN PERFORMING A THOROUGH CHECK.
