Electra Roller Instruction sheet

electrablinds.co.uk
Electra Roller and
XL Roller blinds
How to install,
programme and
operate your blind
Ref 11/18

Contents
The contents of your order
Battery Pack installation
Uncassetted Roller Blind Installation
Cassetted Roller Blind installation
Power up & testing - with a control
Power up & testing - without a control
Operation
Adjusting the upper & lower stop positions
Reset and reprogramme procedure
Add/delete controls
Multi channel programming
-Page 3
-Page 4
-Page 5
-Page 6-7
-Page 8
-Page 9
-Page 10
-Page 11
-Page 12-13
-Page 14
-Page 15

Uncassetted roller blind
2 x Fixing
brackets
complete with
fixings
Power supply
Rechargeable Battery Pack
The contents of your order
Each blind ordered will have
the following components:
Each blind ordered will have the
following components:
Rechargeable battery tube
complete with fixings + 10 x
AA NiMH rechargeable
batteries + 2 x mounting clips
Battery Charger
(if ordered)
Controls
If you ordered a control
with your blind(s), then
it will be one of the
following:
Four-Channel
3
Roller
cassette clips
complete with
fixings
Wall
Switch
Cassetted roller blind
Single-Channel

4
Battery pack Installation
Step 1: Fit the clips for your battery pack using
suitable fixings.
The battery pack is supplied with screws and wall
plugs suitable for fixing to a solid brick or block wall.
If you have ordered a blind that fits inside the
recess, fit your battery pack close to the window
frame at the back of the recess.
Please note: If the width of your window recess is
less than 55cm, your battery pack will need to be
fitted vertically inside the recess or external to the
reveal.
If you have ordered a blind that fits outside the
recess ('Exact'), fit your battery pack at the front of
the recess.
Once the clips are in place, mount the battery pack
ensuring that the supply cable is pointed towards
the blind motor position (middle of the blind).

STEP 1- Marking the bracket positions
Remember when positioning your blind to make sure the fabric will clear any window handles or obstructions. Slide
the brackets into each end of the blind, then position the blind where you’d like to fix it in your window. Make a pencil
mark in the positions of the 2 fixing holes per bracket for drilling. We recommend using a spirit level as shown below
to ensure the blind is fitted level . If your battery pack is fixed behind your blind, don't forget to leave enough space to
easily remove it for charging.
Uncassetted Roller Blind Installation
Electra Top Tip!
If securing the brackets to
plaster, stone, brick, etc.,
drill the holes at the
marked positions using a
5.5mm masonry drill bit,
then use the wall plugs
and screws supplied to fix
the brackets.
STEP 2- Fitting the brackets
Secure the brackets in place at the marks previously made using suitable fixings.
5
Face-Fix
Top-Fix
STEP 3- Mounting the Roller Blind
Hold the blind to the brackets with the fabric
hanging from the back of the blind and the
motor head aerial hanging vertically down
(pointing towards the floor). Slide the motor end
into its bracket first, then slide the opposing end
into its bracket as per the diagram. Make sure
the release lever is to the front for easy access.
Then slide the bracket covers on.
STEP 4 - Power up & Testing- go to page 8
Before fitting the uncassetted blind, we recommend you install the battery - see page 4 for guidance.

STEP 1 - Remember when positioning your blind to make sure the fabric will clear any window handles or obstructions. If
your blind is outside the recess it will require a face-fix - position your bracket a minimum distance of 3.2cm from the ceiling.
For inside the recess it will be a top-fix - position your bracket a minimum of 3.5cm from the battery pack mounting clips.
Top-fix
(inside
recess)
Cassetted Roller Blind Installation
Before fitting the cassetted blind, we recommend you install the battery pack- see page
4 for guidance.
6
STEP 2- Fixing positions
Secure the clips in place
using suitable fixings.
STEP 1- Clip spacing
Mark the clips approx
10cm in from each
end with the other
clips spaced evenly
between them.
Electra Top Tip!
If securing the brackets to
plaster, stone, brick, etc.,
drill the holes at the
marked positions using a
5.5mm masonry drill bit,
then use the wall plugs
and screws supplied to fix
the brackets.
Face-Fix
(outside
recess)

7
STEP 3- Fitting
Place the front lip of your cassette into the front
hook of the clip and push upwards into the clip
until there is a firm 'click'.
Note: Diagrams show face-fix. For top-fix use the
grooves on the top of the cassette.
Removing
If you need to remove the blind,
lever the lip of the clip at the back
of the cassette using the head of a
screwdriver.
Cassetted Roller Blind Installation continued
[Diagram shows face-fix]
STEP 4 - Power up & Testing. Go to Page 8.

8
Power up & testing - blind supplied with a control
Before we dispatch your blind, we test it to ensure it's operating correctly. We also set the upper and lower
stop positions based on your individual window height measurement. Lastly, your remote control or wall
switch will be paired to your motor so you're ready to go!
Once your blind is fixed securely in place,
you are ready to connect the battery pack.
Take the motor supply cable and connect
the long plug into the long socket of the
battery pack. You can then tuck any excess
cables away behind the blind.
If you ordered a control with your blind follow
the instructions on page 10.
If you didn't order a control with your blind
follow the instructions on the next page.

Power up & testing-
blind supplied without a control
New blind - Existing Remote control/wall switch
Before you begin
The following instructions are relevant if you already have a remote control/wall switch and selected 'no control needed'
when ordering your Electra blind. The blind supplied has been set up with the up and down stop position preset for your
convenience.
Pairing your remote control/wall switch to your blind
STEP 1: Initiate programming.
Press both up and down
buttons together briefly and
let go - the blind will "jiggle".
A jiggle is a brief up and down
motion .
STEP 2: Pair the control. Press
and hold the programming
button* on the back of the your
handset or wall switch until the
blind jiggles. Your control is
now paired to the blind motor.
Electra Top Tip!
If you have a 4 channel
handset, make sure
you select the channel
the blind is to operate
in before pressing the
programme button.
*How to locate the programming button on your
control:
Single
channel
and 4-
remote
Wall
switch
9
channel

10
Operation
General control
We have programmed your roller blind to automatically stop at preset upper and lower stop positions. It couldn't be simpler- just
press the Up or Down button until the blind starts moving and your blind will move in the respective direction until it reaches the
preset stop position, where it will stop automatically. You can stop the blind at any point between the preset stop positions by
pressing the middle ‘my’ button.
Lowering the blind
Press the down button briefly to
send the blind to the lower stop
position.
Raising the blind
Press the up button briefly to
send the blind to the upper stop
position.
Stopping the blind
Press the 'My' button briefly to
stop the blind at an intermediate
position.
Operating your Roller Blind

11
Adjusting the upper & lower stop positions
2. Press and hold the
Up and Down buttons
until the blind jiggles.
3. Adjust to the desired
upper/lower stop
position using either
the Up or Down button.
4. Press and hold the 'my'
button until the blind
jiggles.
1a. Adjust upper stop position
- press the up button and send
the blind to the current upper
stop position.
1b. Adjust lower stop position -
press the down button and send
the blind to the current lower stop
position.
Setting
Use either Up or Down to operate the blind and press 'my' to stop
at the desired intermediate position.
Once the desired intermediate position is reached, press and hold
the 'my' button until the blind jiggles (approx 5 secs). The 'my'
position has now been set.
Using the 'my' position
Send the blind to the 'my' position by pressing
'my' from ANY position (the blind must be
stationary prior to activating the 'my' position
function).
Delete the ‘my’ position
Send the blind to the 'my' position, then press
and hold 'my' until the blind jiggles (approx. 5
secs). The 'my' position has now been deleted.
Using the ‘my’ position (intermediate position)
The 'my' position is a memorised intermediate position between the
upper and lower stop positions. You can set this anywhere you want and
send the blind to it at the touch of the 'my' button.

12
Press with
a paperclip
for approx
12 secs
STEP 3: Press the down
button. Does the blind
move down?
YES- the blind moves down
while pressing the down
button - Go to step 5.
NO - the blind moves up
while pressing the down
button - continue to step 4.
STEP 4: To reverse the
direction of the motor,
press and hold the 'my'
button for approx 2
seconds until the blind
jiggles.
Reprogramme
STEP 2: Press and hold
simultaneously the Up
and Down buttons for
approx 5 seconds until the
blind jiggles.
Reset and reprogramme procedure
Before you begin - Disconnect the power to all other powered blinds while programming. Note: for a cassetted blind, you'll need
to remove the cassette cover to access the program button. Slide the two clear plastic sliders on the bottom of the cassette
box towards the middle of the blind and lift the cassette cover upwards to remove.
Reset
STEP 1 - Initiate reset
Take a paper clip and press the PROGRAM button on the motor head until
the blind has jiggled 3 times (approx 12 secs). This deletes all the motor's
settings and memory.
2

13
Reset procedure continued
STEP 5: Use the up
button to move the
blind until it reaches
the upper limit position.
Press and hold the 'my'
and down buttons until
the blind starts to
move down.
Stop the blind at the
desired lower limit
position (adjust with
the up and down
buttons if required).
STEP 6 : Press and hold
the 'my' and up button
until the blind starts to
move up.
The blind will
automatically stop at
the up position.
Press and hold the
'my' button until the
blind jiggles to
confirm the limit
settings.
STEP 7: Press the
program button on your
remote control or wall
switch until the blind
jiggles.
OR

14
Step 1 - Take a handset or wall
switch that is already
programmed to the blind
motor.
Step 2 - Press and hold the
program button of the
handset or wall switch until
the blind jiggles (approx
2-3 secs).
Step 3 - Press the program
button again to unpair the
control.
Add/delete controls
Delete a control
Control already paired to the
blind
Add a control
Control to add to the blind
memory
Step 1 - Press the program
button on your handset or
wall switch that already
controls the blind for about
2 seconds until the blind
jiggles. If using a 4 channel
handset, make sure you
have the right channel
selected.
Step 2- Press and hold the
program button of the new
handset or wall switch until
the blind jiggles (approx 1
sec).
Or Or

Assigning additional channels with a 4 channel control
All 4 lights will
light up when
the fifth
channel is
selected
This is your
channel
selector
button. Press
this repeatedly
to change
between
channels.
Your 4-Channel
remote control
Example: Two blinds with independent control on channels 1 (blind 1) & 2 (blind 2) - set up the blinds for group control so that when
you press channel 3, blinds 1 & 2 will operate together).
Step 1 - Select Channel 1 which operates blind 1.
Step 2 - Using a paper clip, press and hold the program
button on the rear of the handset until blind 1 jiggles
(approx 2-3 secs).
Step 3 - Select Channel 3 on the controller.
Step 4 - Press the program button on the rear of the
handset until blind 1 jiggles (approx 1 sec). Channel 3 will
now operate blind 1.
Step 5 - Select Channel 2 which operates blind 2.
Step 6 - Press and hold the program button on the
rear of the handset until blind 2 jiggles (approx 2-3 secs).
Step 7 - Select Channel 3 on the handset.
Step 8 - Press the program button on the
rear of the handset until blind 2 jiggles (approx 1 sec).
Channel 3 will now operate blind 2.
When all programming steps have been completed, Channel 3 will operate blinds 1 & 2 together. All
other blinds should be disconnected from their respective power while programming is in progress.
While programming, the blind should not be inactive for longer than 2 minutes or the motor will exit
the programming mode.
Multi-channel programming
15

electrablinds.co.uk
