ELECTRIC WHEELS EW-620 Manual

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Assembly and Setup Instructions
EW-620

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Please observe and follow these instructions closely as it will ensure safe and reliable operation.
1. Remove the EW-620 from it’s carton. Lift the bike out of the carton, assistance will be needed. If no
assistance available start by opening the top to allow access to the inside of the carton. Use a knife to cut
each corner from the inside out (Figure A). Once all four corners are cut it will allow a 360 degree access to
your new bike eliminating the heavy lifting.
2. Place the EW-620 on it’s kickstand as shown (Figure B).
Tools you will need to assemble the EW-620
1. Philips Screwdriver
2. 15mm wrench
3. Knife
4. 6mm Allen Wrench

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
3. After you have placed the bike on it’s kickstand make sure you have all the components in the bike as shown in
Figure C.
Handlebar Installation
1. Insert handlebar and set to proper height onto Fork/Steer tube and align correspondingly with the tire (Figure A).
2. Use the 6mm Allen Wrench to tighten the steering wheel until it is fully tightened (Figure B).
Components included on the EW-620
A. Pedals.
B. Derailleur protector.
C. Basket holder frame with bolts and nuts.
D. Charger.
E. 15mm Wrench.
F. 6mm Allen Wrench.
G. Basket.
Tools you will need to attach the Handlebar
- 6mm Allen Wrench

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Basket Installation
1. Remove bolts and nuts on each side of the steering fork (Figure A).
2. Place the Frame and tighten up with the bolts and nuts previously removed (figure B).
3. Place basket in place and attach using the bolts, nuts and bottom bracket (Figure C).
4. Start with parts C and parts B as shown in Figure D.
Tools you will need to attach the Basket
-Philips screwdriver
-Basket
-Part C (bolts, nuts and frame)

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
5. Drop both D screws into place (Figure E).
6. Place Bracket A underneath and tighten it up (Figure E).
Pedals Installation
1. Make sure you insert each pedal with its correspondent side (Figure A).
2. Hand tighten each pedal and tighten with 15 mm wrench (Figure B).
Tools you will need to attach the Pedals
-15 mm Wrench

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Adjusting the Seat
1. Adjust seat to desired height, tighten it by turning seat lever clockwise until secure (Figure A).
Installing the Derailleur Guard
1. Remove the two screws as shown in Figure A.
2. Put the Derailleur Guard in place, insert the previously removed screws and tighten using the Philips screw driver until
secure (Figure B).
Tools you will need to attach the Derailleur Guard
-Philips Screwdriver

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
How to properly remove the Battery Pack
1. Unlock the Battery lock located at the bottom of the Battery Pack.
2. Press on the lever underneath the seat to unlock the sea (Figure A).
3. Use Battery pack handle to remove Battery Pack (Figure B).

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Charging the Battery
1. Plug Charger into Battery Pack (Figure A).
2. Leave Battery pack charge Until green light on charger appears
Warning!
(1) Charge in dry and airiness place, forbidden to charge in room.
(2) Charging far away clothing,, gasoline, alcohol, gas and so on the flammable things.
(3) When charging, the charger must not be touched by children.
(4) When charging, do not cover the battery charger with anything.
(5) Don’t directly touch the output plug with conductive object

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
How to Turn the Bike on
How to Turn Headlight On/Off
Insert Key in ignition located on Battery Pack and turn to the right (Figure A).
Locate and flip On/Off switch below the headlight (Figure B).

Electric Wheel LLC – electricwheelstore.com -888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
How to use the throttle
How to read the Battery Meter
- Turn the throttle down to start riding on electric power (Figure A).
- Red = 0%
-Green 1= 25%
-Green 2= 50 %
-Green 3= 75%
-Green 4= 100%
