COMPRESSOR DIGITAL DEHUMIDIFIER
CD10L – 10 litres per day
CD20L – 20 litres per day
USER MA UAL
Thank you for choosing ElectriQ
Please read this user manual before using this innovative Dehumidifier
and keep it safe for future reference
Visit our page www.electrIQ.co.uk for our entire range of Intelligent Electricals
1
Contents
Safety Instructions ………………..……………….. 2
Installation ………………..……………….. 4
Parts ………………..……………….. 5
Control Panel ………………..……………….. 6
Quick reference guide ………………..……………….. 7
Positioning ………………..……………….. 10
ater Drainage ……………………………….. 11
Care and Maintenance ………………..……………….. 11
Troubleshooting ………………..……………….. 13
Technical Data ………………..……………….. 14
2
SAFETY I STRUCTIO S
Important
• Carefully read the instructions before operating the unit
• This appliance is for indoor use only and intended for use in a domestic environment only.
Any other use is not recommended by the manufacturer and may cause fire, electrical shocks
or other injury to user or property.
• Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
• Installation must be in accordance with regulations of the country where the unit is used.
• If you are in any doubt about the suitability of your electrical supply have it checked and, if
necessary, modified by a qualified electrician.
• This dehumidifier has been tested and is safe to use. However, as with any electrical
appliances - use it with care.
• Disconnect the power plug from socket before dismantling, assembling or cleaning.
• Avoid touching any moving parts of the appliance.
• Never insert fingers, pencils or any other objects though the guard
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities. It is also not intended for use by those with a lack of
experience and knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Do not leave children unsupervised with this appliance.
• Do not clean the unit by spraying it or immersing it in water.
• Never connect the unit to an electrical outlet using an extension cord. If a power outlet is
not available, one should be installed by a qualified electrician.
• Never operate this appliance if the cord, power adapter or plug is damaged. Ensure the
power cord is not stretched or exposed to sharp object/edges.
• A damaged power supply cord should be replaced by the manufacturer or a qualified
electrician in order to avoid a hazard.
• Any service other than regular cleaning or filter replacement should be performed by an
authorized service representative. Failure to comply could result in a voided warranty.
• Do not use the appliance for any other purposes than its intended use.
• Do not tilt the unit while in use. The unit is design to work only in vertical position.
• This dehumidifier must always be stored and transported upright, otherwise irreparable
damage may be caused to the compressor; if in doubt we suggest waiting at least 24 hours
before starting the unit.
• Avoid restarting the dehumidifier unit unless 5 minutes have passed since being turned off.
This prevents damage to the compressor.
• Never use the mains plug as a switch to start and turn off the dehumidifier. Use the provided
ON/OFF switch located on the control panel.
• Always place the unit on a dry and stable surface.
• The appliance should not be installed in laundry or wet rooms where the humidity is higher
than 85% RH
• Do not dry laundry above the unit to prevent water entering the dehumidifier. Place the
laundry at least 1 meter away from your dehumidifier.
• Do not place the unit next to heat sources (e.g. electrical fires, fireplaces, etc.)
3
• Avoid mishandling the dehumidifier. Dropping, throwing the unit can cause damage to its
internals and increases the risks of operating it.
• Do not store or use gasoline, petrol, paint, solvents or other flammable vapours or liquids in
the vicinity of this dehumidifier or any other appliance.
• This dehumidifier must not be used in spaces where there is a high concentration of gases,
solvent or other volatile organic compounds; in very dusty environments; in any domestic,
commercial or industrial environment where air composition is flammable.
Energy Saving and Unit Safety Protection Tips
• Do not cover or restrict the airflow from the outlet or inlet grills. Do not operate and follow
troubleshoot procedure if the self-opening louvers do not open on power on.
• For maximum performance the minimum distance from a wall or objects should be 20 cm
• Keep the filters or grills of the unit clean. Under normal conditions, filters or grills should
only need cleaning once every three weeks (approximately).
Since the filters remove airborne particles, more frequent cleaning maybe necessary,
depending on the air quality. Vacuum both mesh and optional carbon filters and wash the
mesh filters with hot soapy water and dry them before placing them back in the unit.
Quick visual safety guide on where or when not to use your dehumidifier
4
Installation
Remove any water from the water tank before starting the unit. In order to save energy, do
not open windows or doors while the unit is running. Place the unit on a hard / flat surface.
On first use run the unit continuously for 24 hrs.
To reduce noise levels:
Place a piece of carpet or a rubber mat under the unit to reduce any vibrations while the unit
is running.
CD10L & CD20L dehumidifiers use compressor technology to extract water from the
environment. The compressor dehumidifiers are ideal for normal domestic or office
environment which are heated during the winter months with temperatures above
12-15⁰C. For applications where temperature is lower than 18⁰C or we recommend our
range of desiccant dehumidifiers.
CD10L & CD20L are easy to move around on castors and will extract unwanted humidity,
with setting in increments of 5% from 30-90% RH insuring your room is not dried too
much and power is not wasted.
Features
1. Easy to use controls
2. Lightweight, portable design.
3. Great for up to 3 bed (CD10L) and 5 bed (CD20L) houses
4. Cost effective way to combat mould, condensation and damp
5. Top directional dry air outlet for efficient operation and laundry mode
6. Dries laundry more efficiently than a tumble dryer
7. Designed to complement any modern space
8. Easy to carry handle
9. Castors for improved mobility (CD20L only)
10. Intelligent CPU controlled digital humidistat with 30-90% RH and room humidity display
11. Quiet fan operation ensures the right balance between low noise operation and maximum
dehumidification
12. 24 hours start / stop timer
13. Tank operation or permanent drainage option
14. Tank full alarm & auto-stop function
5
PARTS
CD10L
CD20L
1. Front Case 2. Dry Air Outlet 3. Handle
4. Control Panel 5. Air Inlet/ Filter housing 6. Back case
7. ater Tank 8. heels / Feet 9. Power supply cord
6
CO TROL PA EL
CD10L
LED Indicators
1. ater Full – Red
2. Compressor on – Green
3. Defrost – Green
4. Timer – Orange
Buttons
A. Power on/ off
B. Down (Humidity Settings)
C. Up (Humidity Settings)
D. Timer
7
CD20L
LED Indicators
1. Power indicator – Green
2. Timer – Orange
3. ater tank full – Red
4. Fan speed low – Green
5. Fan speed high – Green
6. Laundry mode - Green
POWER
Turn on/off the appliance
Timer
hen the unit is on standby, press the timer button to set the delay until it turns on. hen the
unit is on, press the timer button to set the delay until it turns off. Press the timer button to
select the delay time you require in hours cycling from 0 to 24 hrs.
Up & Down
HUMIDISTAT
Press to up/down arrows to select the desired humidity in the room. 50-55% is the
recommended setting for normal domestic settings.
The humidistat range can be selected from 30-90% RH with continuos mode option (CO)
Laundry Mode
Press this button to activate laundry mode. Laundry mode will run the dehumidifier constantly
and with the highest fan setting to quickly dry your washing.
FA SPEED (CD20L only)
Sets fans speed to Low or High
8
Humidity Level & Timer 2 digit display
The led indicator performs the following functions: 1. hen the unit is plugged in, it will indicate
the room humidity level 2. hen the humidity level is selected, it will indicate the set humidity
3. hen the start / stop timer is programmed will show the set timer
otes:
hen humidity level is outside the normal operational parameters will show
LO/HI. If ambient humidity is lower than 35%, it will show “LO” If ambient humidity
is higher than 95%, it will show “HI”. Also the display will show the error codes.
Quick Reference Guide
Power Key Press to turn the dehumidifier on and off.
Timer: select timer settings key to adjust the timer (1-24 hrs, start/ stopping timer). In
power on mode the set number will represent the number of hours the unit will run for before
turning off. This will remain unaffected if unit goes in to defrost mode or the tank is emptied then
reinserted. In standby mode the set number represents the period in hours after which the unit
will start. To cancel start / stop mode press the timer key again until is set to 0.
Press Up or Down
Settings Key when the unit is displaying the current relative
humidity to select the desired humidity level. Humidity level can be set within a range of 30% RH
(Relative Humidity) to 90% RH in 5% increments.
hen the humidity is lower by 2% than the set humidity the unit will stop the compressor and
work for 3 minutes in fan only. hen humidity is higher by 2% than selected humidity the
compressor will start working after a 3 minutes delay. There is humidity measurement tolerance.
Laundry Mode:
For CD20L press to automatically set the dehumidifier in laundry mode. Fan is set to
high on laundry mode
For CD10L set the humidity to CO to operate continuously with maximum water extraction until
the tank is full. Alternatively you can set the humidity level to 35%-40%RH. <40% is very dry and
the unit will work until water tank is full as 35%RH is hardly achievable in UK domestic
environment. Do not place clothes directly over any of the dehumidifier vents. Make sure that
there is nothing blocking the hot air exhaust air flow and for best results place the laundry within
1.5 meters of the dehumidifier.
ote that if permanent drainage pipe is fitted the unit will not stop operation. Humidity set to
achieve room humidity of around 35% is good for quick drying boost on initial run or emergencies,
laundry mode. Not recommended for long normal operation in domestic/ office environment.
For allowing more moisture in the air, press the humidity control key and set to a higher percent
value (e.g. 60-70%).
Humidity set to 50-55% RH; recommended setting, great for domestic operation and dry storage
Humidity set to 60% RH; great for personal comfort and applications where 50% RH is considered
too dry
Humidity set to 70% RH; ideal for unoccupied properties or where economical run is needed
without the need to go drier than 70% RH
9
Other features and Indicators
Tank Full Light
Red light will be on and the unit will beep when the tank is ready to be emptied, or when the
tank is removed or not replaced in the proper position. The water level control switch shuts off
the dehumidifier when the tank is full, or when the tank is removed or not replaced in the proper
position. Empty and replace to resume operation.
Auto Defrost
hen frost builds up on the evaporator coils, the compressor will cycle off and the unit will go in
to defrost mode
hen the unit is running in a room with temperature between 5
o
C and 12
o
C, it enters the defrost
mode about once every 30 minutes.
hen the unit is running in a room with temperature between 12⁰C and 20⁰C, it enters the
defrost mode about once every 45 minutes.
Normal operation will resume after defrost mode.
Humidistat control and fan/ compressor operation
hen the selected humidity is 2% lower than the user selected humidistat setting; the
dehumidifier’s compressor will be shut off automatically but the fan will still move to ensure air is
not stale in the room. The unit will use only a minimal amount of energy in fan mode.
hen the humidity is equal or higher than user selected humidity the compressor will restart
once the 3 minutes delay compressor protection expires.
Power
After the unit has stopped, it is not recommended to resume operation for at least 10 minutes.
This is to protect the compressor. Operation can resume after this period lapses. hen the unit is
restarted there is a 3 minutes delay before compressor will start.
Lightweight Portable Design
The dehumidifier is built to be compact and lightweight.
Your CD10L/CD20L dehumidifier is an advanced micro-CPU controlled device able of
self-diagnostics. The LED display may also show the error and protections codes.
