ElectrIQ EDD8L User manual

1





DesiccantDehumidifier
EDD8L
USERMANUAL






ThankyouforchoosingElectrIQ
PleasereadthisusermanualbeforeusingthisinnovativeDehumidifier
andkeepitsafeforfuturereference
Visitourpagewww.electrIQ.co.ukforourentirerangeofIntelligentElectricals

2
Contents
Safetyinstructions  3
Features 5
Parts 6
Controlpanel  6
Fronthumidityindicator 8
Operation  9
OperationalAdvice10
Positioning   11
WaterDrainage   11
ContinuousDrainage 12
CareandMaintenance 13
FAQ 14
Troubleshooting 15
TechnicalData  16

3
SAFETYINSTRUCTIONS
Important
• Carefullyreadtheinstructionsbeforeoperatingtheunit
• Thisapplianceonlyintendedforuseinanindoordomesticenvironment.Anyother
useisnotrecommendedbythemanufacturerandmaycausefire,electricalshocksor
otherinjurytopersonorproperty.
• Rating:Thisunitmustonlybeconnectedtoa220Ͳ240V/50Hzearthedoutlet.
• Installationmustbeinaccordancewithregulationsofthecountrywheretheunitis
used.
•Ifyouareinanydoubtaboutthesuitabilityofyourelectricalsupplyhaveitcheckedand,
ifnecessary,modifiedbyaqualifiedelectrician.
• Thisdehumidifierhasbeentestedandissafetouse.However,aswithanyelectrical
appliance–caremustbetakenduringuse.
• Disconnectthepowerplugfromsocketbeforedismantling,assemblingorcleaning.
•Avoidtouchinganymovingpartsoftheappliance.
• Neverinsertfingers,pencilsoranyotherobjectsthroughtheguard
• Thisapplianceisnotintendedforusebypersons(includingchildren)withreduced
physical,sensoryormentalcapabilities.Itisalsonotintendedforusebythosewitha
lackofexperienceandknowledge,unlesstheyhavebeengivensupervisionor
instructionconcerningtheuseoftheappliancebyapersonresponsiblefortheirsafety.
•Donotleavechildrenunsupervisedwiththisappliance.
•Donotcleantheunitbysprayingitorimmersingitinwater.
• Neverconnecttheunittoanelectricaloutletusinganextensioncord.Ifapoweroutlet
isnotavailable,oneshouldbeinstalledbyaqualifiedelectrician.
• Neveroperatethisapplianceifthecord,poweradapterorplugisdamaged.Ensurethe
powercordisnotstretchedorexposedtosharpobject/edges.
•Adamagedpowersupplycordshouldbereplacedbythemanufactureroraqualified
electricianinordertoavoidahazard.
•Any
serviceotherthanregularcleaningorfilterreplacementshouldbeperformedbyan
authorizedservicerepresentative.Failuretocomplycouldresultinavoidedwarranty.
•Donotusetheapplianceforanyotherpurposesthanitsintendeduse.
•Donottilttheunitwhileinuse.Theunitisdesignedtoworkonlyinaverticalposition.
• Thisdehumidifiermustalwaysbestoredupright,otherwiseirreparabledamagemaybe
caused
• Thisunitwillstilloperateforapproximatively3Ͳ4minuteafterpressingthepoweroff
button.Thisisnormalandensuresthedesiccantwheelisdrainedofwater.Avoid
restartingthedehumidifierunitunless5minuteshavepassedsincebeingturnedoff.
• Neverusethemainsplugasaswitchtostartandturnoffthedehumidifier.Usethe
providedON/OFFswitchlocatedonthecontrolpanel.
• Alwaysplacetheunitonadryandstablesurface.
• Theapplianceshouldnotbeinstalledinalaundryorwetroomwherethehumidityis
higherthan85%RH.Thisunitshouldbeoperatedatanambienttemperaturebetween
1°Cand32°C.

4
•Donotdrylaundrydirectlyabovetheunit.Topreventwaterenteringthedehumidifier,
laundryshouldbeplacedatleast40cmawayfromyourdehumidifier.
•Donotplacetheunitnexttoheatsources(e.g.electricalfires,fireplaces,etc.)
• Desiccantdehumidifierstendtoabsorbodoursfromthesurroundingenvironmentlike
cigarettes,cooking,cosmetics,newfurnitureetc.Thissmelldescribedasaburningor
soursmell.Thisreleasedduringoperationasthezeolitediscisheatedduring
operation.Thisisnotsignofafaultandthesmellwillfadewiththetime.
•Donotstoreorusegasoline,petrol,paint,solventsorotherflammablevapoursand
liquidsinthevicinityofthisdehumidifieroranyotherappliance.Donotuse
dehumidifierswhereflammablegasesorVOCcanbereleasedoraccumulate.

EnergySavingandUnitSafetyProtectionTips
•Donotcoverorrestricttheairflowfromtheoutletorinletgrills.
•Formaximumperformancetheminimumdistancefromawallshouldbe20cmandit
shouldbekept50cmfromobjectswithintheroom.
• Keepthefiltersorgrillsoftheunitclean.Undernormalconditions,filtersorgrillsshould
onlyneedcleaningonceeverythreeweeks(approximately).Donotusetheunitwithout
themeshairfilterasthiswillallowdirttogatherinsidethedehumidifierandcould
invalidatethewarranty.Adirtyfilterwillrestricttheairflowintothemachinewhichwill
increasetheresistanceonthefanandcouldresultindamageandmightinvalidatethe
warranty.
Sincethefiltersremoveairborneparticles,morefrequentcleaningmaybenecessary,
dependingontheairquality.Vacuumandwashthemeshfilterswithhotsoapywater
anddrythembeforeplacingthembackintheunit.

Quickvisualguideonwherenottouseyourdehumidifier

5
FEATURES

YourElectrIQdehumidifierisatopoftherangedesiccantdehumidifierwithfeaturesnotfoundinother
units

1. Efficient,easytouse,quiet.
2. IntelligentCPUcontrolleddigitalhumidistatwith5humiditysettingscontinuous,40%,50%,60%,
70%RHandroomhumiditydisplay.
3. AirPurifiermodewithoptionalHEPAfilter
4. TurboandSleepmodesfortherightbalancebetweenquietoperationandmaximum
dehumidification
5. Easytousecontrolpanelwithledindicators.
6. FrontHumidityDisplaytoinstantlyshowtheambienthumidity.
7. Worksverywellatlowtemperaturescomparedwithclassiccompressordehumidifiers.
8. Laundrymodetohelpclothesdrying.
9. Heatstheairpassingthroughbetween5Ͳ10϶C,makingtheairdryandwarmreducingtheheating
bills.
10. Tankfullalarm&autoͲstopfunction.
11. Recessedcarryhandleforportability.
12. AntiͲtiltsafedesign.

ElectrIQdesiccantdehumidifiersusecompressorfreedesiccanttechnologytoextractwaterfromthe
environment.Thedesiccantdehumidifiersareidealbothatstandardandlowtemperaturesworkingon
ambientrangeofbetween1Ͳ32϶C.ElectrIQdesiccantdehumidifiersarelightandeasytomove,as
theydonotcontainaheavycompressor.Theyalsoworkintelligentlyastheyaredesignedtoextract
unwantedhumiditywhilesavingmoneyduetotheiradvancedpowersavinglogic.Theyfeaturean
intelligentdigitalhumidistatwithvariablehumiditysettingsat40%,50%,60%,70%RHensuringyour
roomisnotdriedtoomuchandpowerisnotwasted.TheEDD8Lalsofeaturesapowerfullaundrymode
andasleepmodegivingtheusertheabilitytoselectmaximumdehumidification,orquieteroperation.

INSTALLATION

Removeanywaterfromthewatertankbeforestartingtheunit.Inordertosaveenergy,donotopen
windowsordoorswhiletheunitisrunning.Placetheunitonahard/flatsurface.Wewouldadvisethe
unitisruncontinuouslyfor24hrsonitsfirstuse.

Toreducenoiselevels
Placeapieceofcarpetorarubbermatundertheunittoreduceanyvibrationswhiletheunitisrunning.
ForminimumnoiseruntheunitinSleepmode.


6
PARTS













CONTROLPANEL



PowerOn/OffButton
Usedtoturntheunitinandoutofstandbymode.Pleasenoteitmaytakeafewminutesfor
theunittoturnoffoncepressed


Humidity/TimerDisplayWindow
DisplaysthecurrentHumidityoftheroom
WhenHumiditybuttonpressed–Showsdesiredhumidityofroombeforereverting
backtoshowingthecurrenthumidity
WhentimerbuttonpressedͲ Showshowmanyhoursthetimerissetfor,before
revertingbacktoshowingthecurrenthumidity

7
“FullWater”Indicator
Theredlightwillflashwhenthewatertankrequiresemptying,orwhenthewatertankisnot
correctlylocatedwithintheunit


OnIndicator
GreenLight–Indicatestheunitisonandtheheatingelementisworking
RedFlashingLight–AntiTipsensor,detectingtheunitisnotupright.Iftheunithasbeen
tippedortilted,donotuseforatleast24hourstoallowittodryout.

FanSpeedButton
Usedtoselectthefanspeed,thecurrentspeedisindicatedbytheLEDLightsabovethe
button.
SLEEP–Theunitwillruninlowfanspeed,withalowerheat,ensuringtheunitrunsasquietly
aspossible
STANDARD–Theunitwillrunatmediumfanspeed,withthehighheatsetting
TURBO–Theunitwillrunathighfanspeed,withthehighheatsetting
Note:Oncetheairhasreachedthedesiredhumiditysetting,theheaterwillstop,butthefanwillcontinue
tooperateatthesetspeedforashortperiodthentheunitwillstop,resumingoperationafter30minutes
whenwillcheckhumidityagain.Ifhumidityintheroomis<settargetthanthedehumidifierwillgoto
standbyforanother30minutes;otherwiseifhumidityintheroomis>settargetthenthedehumidifierwill
startdehumidifying.Thisprocessensureenergysavingswhilemaintainingthesethumidity.

LaundryMode
Thismodeisidealforcreatingagreatenvironmentfordryingclothes.Theunitwillworkfor
8hourscontinuouslywiththedesiredhumiditysetat40%beforerestingfor30minutes.The
unitwillthencheckthehumidityoftheroom.Ifitisabove40%theunitwillworkfor
another8hoursbeforerepeatingtheprocess.Ifthehumidityoftheroomisfoundtobe
below40%,theunitwillrestforanother30minutesbeforerecheckingthehumidityofthe
room.TheLEDabovethebuttonislitwhenLaundryModeisselected.


HumidityButton
ThisAllowstheusertoselectthedesiredhumidityfortheroom.Thebuttonshouldbe
repeatedlypressedtocyclebetweenthedifferentoptionsCO(ContinuousMode),40%,50%
60%or70%RH

PleaseNote:After8hoursoftheheaterrunningcontinuously,theunitwillrestfor30minutesbefore
resumingthepreviouslyselectedoperation.

TimerButton
WiththeunitTurnedOn–RepeatedlypresstheTimerbuttontoselectinhowmanyhours
timeyourequirethemachinetoturnoff.ThenumberofhoursisdisplayedontheDisplay
Window
WiththeunitTurnedOffͲRepeatedlypresstheTimerbuttontoselectinhowmanyhourstimeyou
requirethemachinetoturnon.ThenumberofhoursisdisplayedontheDisplayWindow

Thetimercanbedeactivatedonceset,byrepeatedlypressingthetimerbuttonuntil00isshownonthe
DisplayWindow.



8

SMARTMode
Thismodeensureminimumhumaninterventionandmaximumsavings.Smartmodesetsthe
desiredhumidityfortheunitto55%RHwhichistherecommendhumidityfornormal
households,andadjuststhefanspeeddependingonthecurrenthumidityoftheroom,
followingthetablebelow.

Above70%UnitwillruninTURBOmode
Between55%and70%UnitwillruninSleepMode
Lessthan55%Unitstopsfor30minutesbeforerecheckingroomshumidity.Willnotrestart
untilhumidityisabove55%

AirpurificationMode
Thismoderunsthefanwithoutdehumidifyingtheair.Thisisgreatforpurifyingtheair
whenthedesiredroomhumidityhasbeenreached,especiallywhentheoptionalHEPAfilter
isinstalled.IfusingaHEPAfilterwhiledehumidifyingpleasenotethatperformanceofthe
unitmaybereducedby10%.

FRONTHUMIDITYINDICATOR

TheElectrIQEDD8Linequippedwithanintelligenthumiditydisplayonthefront,givingtheuseran
immediatevisualindicationoftheambienthumidity.ThefrontLED’swillchangecolourtoindicatethe
currenthumiditylevel



















Pleasenote:Thisindicatorisnotshownduringsleepmode.
Blue light – room humidity > 70%
Green light – room humidity 50~70%
Red light –room humidity < 50%

9
OPERATION
Beforeoperatingtheunit,pleaseensureitispluggedintoamainssocket,andopentheairdeflectoron
thetopoftheunit.

SwitchingtheunitONandOFF
Pressthepowerbuttontoturnontheunit.Theunitwillstarttoworkinsleepmode,withadesired
humidityof50%set.Toturnofftheunitpressthepowerbuttonagain.
Pleasenotethatwhenturningitoff,thedehumidifierwillstilloperateforanumberofminutesto
dischargetheremainingwaterfromthedesiccantdiskandpreventmouldgrowth.

SettingtheLaundryMode
PresstheLaundryButton.Laundrymodewillsetthefanandheaterontomaximumand
humidistatcontrolwillbedisabled.


Donotdrylaundryabovetheunitto
preventwaterenteringthedehumidifier.
Placethelaundryatleast40cmawayfrom
yourdehumidifier.Directtheunitwith
frontventstowardstheclothesaireror
hangingclothes.Hotdryaircomesfroma
45degreesangle.Laundrymodecanbe
usedinconjunctionwiththestopping
timer.

IMPORTANT:Pleasefollowthedistances
shownonthediagram,toensurethatthe
walls,clothing,andotherobjectsarekepta
safedistancefromtheunit.




SettingtheTimer
Onpressingthetimerkeythe2digitsLEDdisplaywillcyclethrough1Ͳ24showingthenumber
hoursafterwhichthedehumidifierwillstop.Thedisplayedtimewillreverttohumiditydisplaya
numberofsecondsafterselectionwasmade.
Whenselecting'4hours'forexampletheunitwillstopoperatingafter4hoursattheselected
humidity/fansettings.Ifthetankbecomesfullbeforethefinishtime,theunitwillstop,andthe
TankFullLEDwillflash.

Atanypointthetimerkeycanbepressedrepeatedlytochangethedesireddurationoruntil00is
displayedtocancelthetimer.

Ifthetimerbuttonisusedwhiletheunitisturnedoff(ButPluggedin),youcanspecifythenumberof
hoursuntiltheunitturnson.

10
SettingtheDehumidificationlevel
Starttheunitandleaveitfor5Ͳ10minutesonsleepmode(50%RH)untilthehumidistatisableto
correctlyreadthehumiditywithintheroom.
Pressthehumiditylevelkeytoselectthedesiredhumidistatcontrolsfromcontinuous
operation(CO)to40%50%60%70%.
Whilepressingthehumiditylevelkeythedisplaycyclesthehumidistatsetrangeforthisunitfrom40%
through50%60%70%backtocontinuousmode.

Intelligentdehumidificationandpowersaving
YourElectrIQdehumidifierfeaturesanintelligentmicroCPUthatensuremaximumwaterextraction
withminimumpowerusefortheselectionmade.
Theunitwilltrytomaintainhumiditylevelselectedintheroombyturningofftheheatingelement
whenthedesiredhumidityisreached.Notethataccordingtothespacewheretheunitisused,
obstaclesinthedirectflow,extrahumiditybeingaddedatanytime,settingsselected,aswellasother
environmentalfactorstheresultsmayvary.

OPERATIONALADVICE
1. Plugtopower,pressthepowerbuttontoturnͲonthemachine;pressthepowerbuttonagainto
turnͲoffthedehumidifier.
2. MakesurewaterͲtankisplaced/fittedcorrectly.Ifthewatertankisnotfitted/placedcorrectlythe
'waterfull'light  willflashandthemachinewillnotoperate.
3. Whenthedehumidifierfirststarts,defaulthumiditysettingissetto50%RH.
4. Whenunpluggingfromthewallsocketuseonehandtoholdtheplugandtheotherhandagainst
sockettoavoidpowercorddamage.
WARNING:Usingpoorqualitysockets,extensionsoroverloadingthecircuitsmaycausedamageto
themachineormaystartafire.
5. WhenswitchingOFFthemachine,donotsimplyunplugtheunitfromthesocketͲensureyouturn
offthemachineproperlyandhaveallowedittocompletethedryingcycle(waitforthefantostop),
beforeunplugging.

TiltProtection
YourElectrIQdehumidifierwasdesignedwithsafetyinmind.Whenunitistilteditwillbeshutdownto
minimizesafetyriskordamage.TheOnlightwillflashred,toindicateantitiltprotectionhasactivated.

Iftheunithasbeentilted,pleasedonotuseifforadayortwountiltheinternalsarecompletelydried,as
usingtheunitafterithasbeentiltedcouldresultinashortcircuit,whichwouldinternallydamagetheunit.
Consulttheservicecentreifinanydoubts

