ElectrIQ eiQTTGSS User manual

USER MANUAL
GAS PATIO HEATER
WARNING: FOR
OUTDOOR USE ONLY OR IN WELL VENTILATED AREAS
PLEASE KEEP THE MANUAL FOR FUTURE REFERENCE
eiQTTGSS
STAINLESS STEEL
eiQTTGBL
BLACK

2
CONTENTS
SAFETY
3
PARTS LIST
5
ASSEMBLY
7
OPERATION
13
LEAK TESTING
14
GAS INFORMATION
14
MAINTENANCE
15
STORAGE
15
TROUBLESHOOTING
16
TECHNICAL SPECIFICATIONS
17
SUPPORT
17

3
IMPORTANT SAFETY INFORMATION
Please read this user manual before using this heater and keep it safe for future
reference.
⚫Read the following instructions carefully and be sure your patio heater is properly
installed, assembled and cared for. Retain the instructions for future reference.
⚫Failure to follow these instructions may result in serious bodily injury and/or
property damage.
⚫WARNING - Risk of Suffocation! Gas heaters must be used outdoors and must
not be used in enclosed areas such as sheds or marquees!
⚫Read the instruction manual before using the appliance.
⚫WARNING: Accessible parts may be very hot. Keep young children away.
⚫This appliance must be kept away from flammable materials during use.
⚫Do not move the appliance during use.
⚫The appliance should be secured to the ground when in use.
⚫Turn off the gas supply at the gas cylinder after use.
⚫Do not modify this appliance.
⚫If you have any questions concerning assembly or operation, consult the retailer
or Bottled Gas Company.
⚫Always place the appliance and cylinder on flat level ground.
⚫Turn off the gas cylinder if gas leak is suspected.
⚫Parts sealed by the manufacturer must not be altered by the user. No
modifications should be made to any part of this heater and repairs and
maintenance should only be carried out by a registered Gas Safe service
engineer.
⚫Use only regulator and hose approved for LP Gas at the correct pressures and
gas type.
⚫The regulator should comply with the standard EN16129 and current regulations
in the country where it is installed, which may be found at your nearest retailer of
gas items.
⚫Refer to the technical data. It is strictly prohibited to use adjustable pressure.
⚫The life expectancy of the regulator is estimated as 10 years. It is recommended
that the regulator is changed within 10 years of the date of manufacture or the
national conditions require it.
⚫The type of replaceable hose should be compliant with EN16436-1.
⚫The hose used must conform to the relevant standard for the country of use. The
length of the hose must be 0.7 meters (minimum) and 1.5 meters (maximum). A
worn or damaged hose must be replaced. Ensure that the hose is not obstructed
or kinked. It is recommended that the hose is changed within 1 year of the date
of manufacture or as the national conditions require.

4
For use outdoors or in well ventilated areas.
•A well-ventilated area must have a
minimum of 25% of the surface area
open.
•The surface area is the sum of the walls
surface.
•The use of this appliance in enclosed
areas can be dangerous and is
PROHIBITED.
•Children and adults should be aware of
the high operating temperatures of areas
above the post when operating this
heater. Children should be carefully
supervised when in the vicinity of the
heater.
NEVER hang anything, including clothes or
any other flammable items, on this heater.
DO NOT operate this heater unless it is fully assembled.
Respect the minimum clearances from combustible materials.
GENERAL INFORMATION FOR
SUCCESSFUL ASSEMBLY
Please read the assembly instructions carefully and follow the safety precautions. Allow sufficient
time for assembly. Before starting assembly, clear an area measuring approximately two to three
square meters. Remove the item from the packaging and lay out all of the parts and any necessary
tools so that they are within easy reach.
Only tighten all of the screw connections firmly when you have finished assembly or are instructed
to within the manual. Otherwise this can result in unwanted tension and instability.
NOTE: Gas supply sold separately.
2m
2m
2m
Minimum clearance from combustible surfaces

5
PRODUCT OVERVIEW AND PART LIST

6
#
PART
NAME
QTY
1
Burning
System
Assy
1
2
Base
1
3
Heat
cover
1
4
Door
1
5
Left Side
Panel
1
6
Right
Side
Panel
1
7
Wheels
Assembly
1
8
Handle
1
9
Control
Dial
1
PART
PART
NAME
QTY
QTY
AA
M4 x 10
4
BB
M5 x 12
10
CC
M6 x 10
2
DD
M6 x 20
2
EE
M4
4
Note: Some of the fittings may be provided pre-attached to the unit.

7
ASSEMBLY
Required Tools: Philips Screwdriver / Adjustable Spanners / Wrenches
Leak Detection Solution: One-part detergent and three parts water
Before assembly, ensure all packing material and any transit protection is removed.
Step 1
Parts required:
Base
Wheels Assembly
2 x DD M6x20 Nuts and
Bolts
Using the M6x20 nuts and bolts, attach the Wheels Assembly to the Base
Step 2
Parts required:
Left Side Panel
Right Side Panel
6 x BB M5x12 Screws
Using the M5x12 Screws, faster the Left Side Panel and the Right Side Panel to the Base

8
Step 3
Parts required:
Door
4 x AA M4x10 Screw
4 x EE M4 Nut
Using the M4 Screws and Nuts attach the Dooe by its hinges
Step 4
Parts required:
Burning System Assembly
Control Dial
4 x BB M5x12 Screws
Fit the Control Dial into the front of the unit. Screw the Side Panels to the body.

9
Step 5
Parts required:
Heat cover
Handle
2 x CC M6x10 Screws
Attach the Handle to the heat cover using the M6x10 screws
Step 6
Clip the heat cover onto the Burning System Assembly. Use the handle to slide the heat cover around the mesh to
block heat from that partciuclar section.

10
Step 7
When not in use, the heat cover can be clipped lower down the body of the patio heater.
Step 8
Parts required:
Screw the regulator onto the gas hose

11
Step 9
Connect the regulator to the gas cylinder (not supplied).

12
Step 10
Place the gas cylinder inside the Patio Burner. It is now ready to use.

13
OPERATING INSTRUCTIONS
BEFORE FIRST USE AND AFTER EVERY GAS CYLINDER CHANGE, GAS DELIVERY SYSTEM MUST BE
PURGED OF AIR BEFORE IGNITING! TO DO THIS, TURN THE CONTROL DIAL ANTI-CLOCKWISE TO THE
PILOT SETTING. PRESS THE DIAL IN AND HOLD FOR 1 MINUTE BEFORE ATTEMPTING IGNITION.
BATTERY REPLACMENT
Remove the control dial. Install 1 AA battery. The negative end of battery goes in first, then replace the control dial.
LIGHTING THE PATIO HEATER
•Check all connections prior to each use.
•Turn on the gas supply at source.
•Press and turn the control dial anti-clockwise to the LOW (small flame)
marking. You will hear a click and this will light the burner.
•Keep control dial depressed for up to 30 seconds then release the
control dial.
•If the gas fails to ignite, press and turn the dial clockwise to OFF before repeating the lighting steps.
•Turn the dial further anticlockwise to the LOW position.
•Adjust the heat by turning the dial from the LOW position to the HIGH position as required.
Note: it is possible to light the appliance using a long match by lighting the
burner through the ignition hole in the emitter screen.
RE-LIGHTING
•Turn the Dial to the OFF position.
•Wait 5 minutes, to let gas dissipate, before attempting to re-light burner.
•Repeat the “Lighting” steps.
TO EXTINGUISH
•Hold the dial down and turn clockwise to the OFF position
•Turn off the valve on the gas cylinder or the regulator after use.
•Disconnect the gas bottle and allow this appliance to cool before moving the appliance.
Note: After use, some discoloration of the emitter screen is normal. Turn off the regulator after use and allow
the appliance to cool before moving.

14
LEAK TESTING
NEVER USE A NAKED FLAME TO CHECK FOR LEAKS.
NEVER LEAK TEST WHILE SMOKING.
The gas connections on this appliance are leak tested
at the factory prior to shipment.
This appliance needs to be periodically checked for
leaks and an immediate check is required if the smell
of gas is detected.
•Make a soap solution using 1 part of liquid washing
up liquid to 3 parts water. The soap solution can be
applied with a soap bottle, brush, or rag to the leak
tested points shown in the figure above.
•The valve of the gas cylinder should be in the OFF
position. Once the soapy solution is applied to the
gas connections, the valve of the gas cylinder
needs to be turned to the ON position.
•Soap bubbles will begin to form in the soapy
solution if a leak is present.
•In case of a leak, turn off the gas supply. Tighten
any leaking fittings, then turn the gas supply on and
recheck.
GAS REQUIREMENTS
•The regulator and hose assembly used must conform to local safety requirements.
•Never use a gas cylinder with a damaged body, valve, collar, or foot ring. A dented or rusty gas tank may be
hazardous and should be checked by a gas supplier.
•Never connect this appliance to an unregulated gas source.
•When the appliance is not in use, turn the gas cylinder OFF, before disconnecting it.
•Always perform a leak test on gas connections whenever a cylinder is connected. If bubbles form in the leak test
solution, do not use. Never use a flame to test for leaks.
CONNECTING TO A GAS CYLINDER
•Use a gas cylinder no larger than 31.8cm diameter x 58cm. Please refer to your gas supplier for suitable gas
cylinder.
•Refer to your gas supplier for instructions on the use of your gas cylinder.
•Only change gas cylinders outdoors or in a well-ventilated area away from naked flames and any other source of
ignition.
•The gas cylinder must always be used in an upright position.
•Close the heater control dial by turning fully clockwise.
•Close the gas cylinder tap and then attach the regulator onto the gas cylinder.
•Tighten all connections firmly and with a spanner where appropriate. The cylinder should be located on the cylinder
base.
•Check for leaks at all joints using soapy water. If a leak is found, tighten the joint and then re-test.

15
MAINTENANCE
To enjoy years of outstanding performance from your heater, make sure you perform the following maintenance
activities on a regular basis:
•Keep exterior surfaces clean.
•Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents.
•While washing your unit, be sure to keep the area around the burner and pilot assembly dry at all times. If
the gas control is exposed to water in any way, DO NOT try to use it. It must be replaced.
•Airflow must be unobstructed. Keep controls, burner and circulation air passageways clean. Signs of
possible blockage include:
•Gas odour with extreme yellow tipping of flame.
•Heater does NOT reach the desired temperature.
•Heater glow is excessively uneven.
•Heater makes popping noises.
•Spiders and insects can nest in burner or orifices. This dangerous condition can damage the heater and
render it unsafe for use. Clean burner holes by using a heavy-duty pipe cleaner. Compressed air may help
clear away smaller particles.
•Carbon deposits may create a fire hazard. If any carbon deposits develop, clean the dome and burner with
warm soapy water.
Note: In environments with a high salt content (such as near the sea), corrosion occurs more quickly
than normal. Frequently check the corroded areas and repair them.
SERVICING
•Please consult your supplier for servicing this appliance and replacement of its parts. The servicing of the
appliance shall be carried out only by authorised personnel.
•Do not use unauthorised parts or components for this appliance, only use original equipment replacement
parts and components. The use of unauthorised parts or components will void the warranty and can create
unsafe condition.
STORAGE
There is no limitation on the storage of the appliance indoors provided that the cylinder is disconnected
and removed from the appliance.
Between uses or before storage:
•Turn the control dial OFF
•Turn the gas cylinder OFF
•Disconnect the gas bottle.
Store the heater upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail,
snow, dust and debris). If desired, cover to protect exterior surfaces and to prevent build up in air passages.
Note: Wait until heater is cool before covering.

16
TROUBLESHOOTING
PROBLEM
CONDITION
FIX
Burner won’t light
Cylinder valve is closed
Open valve
Blockage in orifice or pilot tube
Clean or replace orifice or pilot tube
Air in the gas line
Open gas line and bleed it (pressing
control dial in) for not more than 1-
2 minutes or until you smell gas
Low gas pressure
Gas cylinder low or empty
Burner won’t stay lit
Dirt build up around the pilot
Clean dirt from around the pilot
Connection between the
gas valve and pilot assembly is loose
Tighten the connection and perform a
leak test
Bad thermocouple
Replace the thermocouple
Burner flame is low
Note: Do not operate
heater below 5 ℃ (40°F)
Gas pressure is low
Replace the gas cylinder
Tank is almost empty.
Replace the gas cylinder
Supply hose is bent or kinked
Straighten hose and perform leak test on
the hose
Control dial is fully " ON"
Turn control dial to "OFF", let it cool to
room temperature and check burner and
orifices for blockage
Emitter glows uneven
Note: Bottom 2.5cm of
emitter does not
normally glow
Gas pressure is low
Replace the gas cylinder
Base is not on a level surface
Place heater on a level surface
Heater not level
Level the heater
Carbon build-up
Dirt or film on the burning system
Clean the burning system
Thick black smoke
Blockage in burner
Turn the control dial to the OFF position, let
it cool to room temperature and remove
blockage and clean burner inside and
outside.

17
TECHNICAL SPECIFICATIONS
electriQ
SUPPORT
www.electriQ.co.uk/support
Call: 0330 390 3061 or complete the online form
Office hours: 9AM - 5PM Monday to Friday
www.electriQ.co.uk
Unit J6, Lowfields Business Park
Lowfields Way, Elland
West Yorkshire, HX5 9DA
Model: eiQTTGSS eiQTTGBL
Nominal Heat input =6.0kW
Consumption: 436.3g/h(G30)/428.5g/h(G31)
Country Code
BE-CH-CY-
CZ-ES-FR-
GB-GR- IE-
IT-LT-LU-LV-
PT-SK-SI
BG-CY-DK-
EE-FI-FR-
HR-HU-IS-
IT-LT-LU-
MT-NL-NO-
RO-SE-SI-
SK-TR
AT-CH-DE-
SK
PL
Gas Category
I3+(28-30/37)
I3B/P(30)
I3B/P(50)
I3B/P(37)
Type of Gas
Butane/
Propane
Butane/
Propane/
Mixture
Butane/
Propane/
Mixture
Butane/
Propane/
Mixture
Gas pressure
28-
30/37mbar
20/30mbar
50mbar
37mbar
Injector
Diameter
1.18mm
1.18mm
1.04mm
1.11mm
Warning
Read the instructions before using this appliance.
The appliance must be installed in accordance with instructions and local
regulations.
The use of this appliance in enclosed areas can be dangerous and is
PROHIBITED.
For use outdoors or in amply ventilated areas.
An amply ventilated area must have a minimum of 25% of the surface area
open.
The surface area is the sum of the walls surface.
0063-20
