ELECTRO FREEZE SOFT SERVE TWIST SL500 User manual

OPERATOR'SMANUAL
with Replacement Parts List
H.C. Duke & Son, LLC P/N 184599 October 2013 Printed in USA
SOFTSERVE
TWIST MODEL
SL500
184599 10/13

Operator'sManual
for the
ElectroFreezeModel
SL500
Soft Serve Freezer
All contents © Copyright 2013 H.C. Duke & Son, LLC, 2116 Eighth Avenue, East Moline Illinois 61244

ii
ELECTRO FREEZE Soft Serve Model SL500
WARNING
CAUTION
DANGER
2. Understand Signal Words ....
SAFETY FIRST!
Follow these four steps to safety ....
1. Recognize Safety Information ....Look for this
safety alert symbol throughout this manual.
Thesignalwords — DANGER, WARNING and
CAUTION — areusedwith the safety alert symbol
(DANGERdecalsonthefreezer may or may not
havethesafety alert symbol, but the message is
thesame). Decalswiththewords DANGER,
WARNING or CAUTION appear on thefreezer.
DANGER identifiesthe most serious hazard.
DecalswiththewordsDANGER orWARNING are
typicallynearspecifichazards on the freezer.
Generalprecautionsare listed on CAUTIONsafety
decals.
In thismanual,CAUTION messages with the safety
alertsymbol callattentionto safety messages.
When you see this symbol on your freezer or in this
manual,bealerttothepotential for personal injury.
Followrecommended precautions and safe
operatingpractices.

iii
ELECTRO FREEZE Soft Serve Model SL500
SAFETY FIRST!
3. Follow Safety Instructions ....
4. Operate Safely ....
Read and understand all safety messages in this
manual. Read and understand the decal safety
messages on your freezer. Take notice of the
location of all decals on the freezer and keep the
safety decals in good condition. Check them
periodically and replace missing, damaged or
illegible safety decals. The safety decals must
remain in place and legible for the life of the
freezer. If you need new decals, use the
information and illustrations on pages iv and v of
this manual to identify the decal and contact your
local distributor — or H.C. Duke & Son, LLC.
DO NOT attempt to operate the freezer until you
read and understand all safety messages and the
operating instructions in this manual.
DO NOT allowuntrainedpersonneltomaintainor
servicethismachine.Failure to follow this
instructionmayresultinseverepersonal injury. DO
NOT operatethefreezerunlessallservicepanels
andaccessdoorsaresecuredwithscrews. DO
NOT attempttomaintainorrepairthe freezer until
the main power supply has been disconnected.
Some freezers have more than one disconnect
switch. Contact your local Electro Freeze
Distributor for authorized service.

iv
ELECTRO FREEZE Soft Serve Model SL500
Safety Decal Locations
Youmaycontactyourlocalauthorized
ElectroFreezeDistributor,asfollows:
NAME:_______________________
ADDRESS:____________________
______________________________
PHONE:_______________________
or — forfactoryserviceassistance —
contactH.C.Duke&Son,LLC,Electro
FreezeServiceDepartmentbyphoneor
FAX:
Phone: [phone]
[phone]
FAX: [phone]
E-mail: [email protected]
(Thedecalsonthenextpagearenum-
bered1,2and3.Thosenumberscorre-
spondto thenumbersinthetablebelow.
Thetableprovidesthepartnumber,
description,andquantityforeachdecal.)
Donot attempttooperatethefreezeruntil
allsafetyprecautionsandoperating
instructionsin thismanualarereadand
understood.
Takenoticeofallwarning,caution,
instructionandinformationdecals(or
labels)on thefreezerasshowninthe
figureonthefollowingpage.Thelabels
havebeenputtheretohelpmaintaina
safeworkingenvironment.
Thelabelshavebeendesignedtowith-
standwashingandcleaning.Alllabels
mustremainlegible forthelifeofthe
freezer.Checklabelsperiodicallytobe
suretheycanberecognizedaswarning
labels.
Ifitisnecessarytoreplaceany label,
pleasecontactyourlocalauthorized
ElectroFreezeDistributor or H.C.Duke&
Son,LLC Whenreadytoorderyouwill
needtodeterminethe(1)partnumber,(2)
typeoflabel, (3)locationoflabel,and(4)
quantityrequired,andincludeareturn
shippingaddress.

No. Part No. Description (Qty)
1HC165025-02 Decal — Beater Warning Black(1)
2HC165025-01 Decal — Beater Warning Twist (1)
3HC165126 Decal— PanelRemoval Warning (3)

v
ELECTRO FREEZE Soft Serve Model SL500
HC165025-01
1HC165025-02
Hazardousrotatingbeatershaft.Donot
operateunitwithdispenseheadremoved .
Beforeremoving dispense head:
1.Turnall control switches to "OFF", and
2.Disconnect all powersupplies. Unit mayhave
morethan onepowersupply.
Located behind
the head
2
WARNING
!
Hazardous moving parts.
Machine starts automatically.
Do not operate with panel
removed.
HC165126
3

vi
ELECTRO FREEZE Soft Serve Model SL500
Table of Contents
Safety First! ...............................................................................................ii
Safety Decal Locations ................................................................... iv
PART I
1 Introduction ............................................................................................... 1
2 Note to Installer ...................................................................................... 1
2.1 UncratingandInspection............................................................................... 2
2.2 Installation ..................................................................................................... 3
2.3 ElectricalRequirements................................................................................. 3
2.4 ElectricalConnections ................................................................................... 4
3 Specifications .......................................................................................... 5
3.1 Particulars....................................................................................................... 5
3.2 DataPlate ....................................................................................................... 6
3.3 ReferenceInformation .................................................................................... 6
3.4 InstallationDate .............................................................................................. 6
3.5 Dimensions. .................................................................................................... 7
4 Part Names and Functions .......................................................... 8
5 Operator Controls & Indicators .............................................. 11
5.1 Day/NightSwitch......................................................................................... 11
5.2 SelectorSwitch........................................................................................... 12
5.3 Reset-Overload .......................................................................................... 12
5.4 Timer........................................................................................................... 12
5.5 "AddMix"IndicatorLight ........................................................................... 12
5.6 MixFeed Tube and Regulator.................................................................... 13
6 Disassembly and Cleaning ........................................................ 14
6.1 CleaningAccessories................................................................................... 14
6.2 DisassemblyInstructions.............................................................................. 15
6.3 CleaningInstructions ................................................................................... 17
7 Assembly ................................................................................................... 19

vii
ELECTRO FREEZE Soft Serve Model SL500
8 Start-up Instructions ........................................................................ 22
8.1 Sanitizing...................................................................................................... 22
8.2 Priming ......................................................................................................... 23
9 Closing Procedures ......................................................................... 26
9.1 NightSwitchOperation................................................................................ 26
9.2 DrainingProduct .......................................................................................... 27
10 Soft Serve Information ................................................................... 28
10.1 Overrun ....................................................................................................... 28
10.2 Rerun........................................................................................................... 28
11 Routine Maintenance ...................................................................... 29
12 Troubleshooting Table ................................................................... 33
PART II
REPLACEMENT PARTS with ILLUSTRATIONS *
* RefertoPartIITableofContentsforhelpwithlocatingpartnumbersandillustrations.
Table of Contents (continued)

ELECTRO FREEZE Soft Serve Model SL500
184599 1
2 Note to Installer
1 Introduction
GravityfedsoftservefreezermodelSL500
isdesignedtoproducesoftserveice
cream,icemilk,yogurt,andsimilar frozen
dairyproducts,withaproductserving
temperaturerangeof15to25°F(-9to-
4°C).Ifsuchproductsarepreparedfrom
powderedconcentrate,theyshouldbe
precooledto40°F(4°C)priortointroduction
tothefreezer.Useofotherproductsinthis
machineisconsideredmisuse
(seeWarranty).
Thismanualhasbeenpreparedtoassist
youintheproperoperationandgeneral
maintenanceoftheElectroFreezemodel
SL500freezers.
Makesureallpersonnelresponsiblefor
equipmentoperationcompletelyreadand
understandthismanualbeforeoperatingthe
freezer.Whenproperlyoperatedand
maintained,thefreezerwillproducea
consistentquality product.
Ifyourequiretechnicalassistance,please
contactyour localauthorized Electro
FreezeDistributor,asfollows:
Name:
Address:
Phone:
Forfactoryserviceassistance — contact
H.C.Duke&Son,LLC,ElectroFreeze
ServiceDepartmentasfollows.
Phone: [phone]
[phone]
FAX: [phone]
E-mail: [email protected]



This freezer must be installed and serviced by an Electro Freeze Distributor or
authorized service technician in accordance with the installation instructions.
After installation the warranty registration card must be completed and re-
turned to validate the warranty.

2 184599
ELECTRO FREEZE Soft Serve Model SL500
2.1 Uncrating and Inspection
Figure 2-1 Machine bolted to Shipping Base
CAUTION
Be sure to properly
support the machine when
removing bolts and
installing legs or casters.
Whentheunitisreceivedandwhile
thecarrierisstillpresent, inspect the
shippingcartonforanydamagethat
mayhave occurredintransit.Ifthe
SHOCKWATCH
®
labelindicatesredand/or
thecartonis broken,torn,orpunctured,
notethedamageonthecarrier’sfreight
billandnotifythecarrier’slocalagent
immediately.
1. Removethecartonfromthepallet,
andmove themachineascloseas
possibletothepermanentlocation.
2. Removetheshippingboltsonthe
bottomofthefreezer(figure2-1)andinstall
eitherthe legsorcasters(figure2-2).
Figure 2-2 Installing Mounting Legs or Casters
NOTE: Screw casters
or legs all the way in
coupling, then adjust
to level side to side
with a 1/4” slope to
the front.

ELECTRO FREEZE Soft Serve Model SL500
184599 3
2.2 Installation
CAUTION
All materials and
connections must conform
to local requirements and
be in compliance with the
National Electrical Code
(NEC).
1. The freezer is designed for
indoor use and must be protected from
outdoor weather conditions.
2. Wherecodespermit,Electro
Freeze recommends that the floor
model freezers be installed on casters
and have flexible water and electrical
connections for easier service and
cleaning.
2. Allmodelsrequireaminimum
6-inchclearanceonpanelswithlouversfor
adequateventilation.Anythingblocking
ventilationofthefreezer(includingcone
dispensers)willreducetheefficiencyof
thefreezer.
3. Water-cooledmodelSL500
requiresa3/8-inchMPTwaterinletand
waterwasteconnection. Theconnections
arefoundonthebottom,underthe
compressormountingarea.Theyare
tagged“WaterInlet”and“WaterWaste.”
Amanualshut-offvalveshouldbeinstalled
inthewaterinlet line at thetimeof
installation.Thewaterpressuremustbe
between35-140psig(241-965kPa)for
properoperation.
4. Placethefreezerinitsfinal
location and adjust the legs or casters
so that it is level side-to-side and the
front is approximately 1/4-inch lower
than the rear to allow proper drainage
of the freezing cylinder.
2.3 Electrical Requirements
CAUTION
To prevent accidental
electrical shock, a positive
earth ground is required.
1. Alwaysverifyelectricalspecifica-
tionsonthedataplate(figure3-1) ofeach
freezer.Dataplatespecificationswill
alwayssupersedetheinformationinthis
manual.
2. Supplyvoltagemustbewithin+
10%ofvoltageindicatedonthe
nameplate.Also,onthree-phasesystems,
voltagebetweenphasesmustbebalanced
within2%.(Morethana6voltdifference
betweenanytwovoltagemeasurements
at208-230voltsindicatesapossible
imbalance.)Requestyourlocalpower
companytocorrectanyvoltageproblem.
3. Aneasilyaccessiblemainpower
disconnect must be provided for all
poles of the wiring to the freezer.

4 184599
ELECTRO FREEZE Soft Serve Model SL500
CAUTION
To prevent accidental
electricalshock, a positive
earthgroundisrequired.
1. Freezerrequiresonepowersupply.
Checkthe dataplateforproperfusesize,
wireampacity,andelectricalspecifications.
2. Refertothewiringdiagrampro-
videdforproperpowerconnections.
3. Electricalconnectionsformodel
SL500aremadeinthejunctionboxlocated
mid-levelbehindthefrontpanel.
4. Useaflexibleconnectionwhen
permissible.Copperwiresarerequiredfor
connectiontofreezer.Allmaterialsand
connectionsmust conformtolocalcodes
and/ortheNationalElectricalCode.
5. Forall3phasefreezers,beater
shaftrotationmustbeclockwiseasviewed
fromthefrontofthefreezer.
2.4 Electrical Connections

ELECTRO FREEZE Soft Serve Model SL500
184599 5
SL500
3.1 Particulars
3 Specifications
Width(in/cm) ................................. 22.125/56.2
Height(in/cm) ................................... 58/146.77
Depth (in/cm) ..................................... 30/76.04
Weight(lb/kg) ...................................... 539/244
CylinderCompressor............ 2HP/10000(BTU/hr)
1.5kw(Motor)
3.2kw(Cooling)
HopperCompressor ............ 1/10hp/500(BTU/hr)
BeaterMotor ...............................(2) 2 HP/1.5 kw
Refrigerant-Cylinder ............................... R-404a
Refrigerant-Hopper .....................................134a
Charge-WCCylinder(lbs/kg) .............3.75/1.70
ACCylinder(lbs/kg)............ 4.375/1.98
Charge-Hopper (oz/kg) ............................. 7 / .2
Cooling ............................................AirorWater
Hopper(qt/ltr) ...................................(2)16/15.1
Cylinder(qt/ltr) ................................. (2) 3.7/3.5

6 184599
ELECTRO FREEZE Soft Serve Model SL500
Write in
Reference
Information
HERE!
3.3 Reference Information
Fillin thefollowinginformationassoonas
youreceivetheElectroFreezeSL500.(The
itemnumbers—encircled,below —corre-
spondtothecalloutnumbersinfigure3-1.)
1 ModelNumber:_________________
2 SerialNumber:__________________
3 Electrical Spec: Voltage ________
Phase _______ Hertz _________
4 Max.FuseSize:__________________
5 Min.CircuitAmpacity___________

3.2 Data Plate
The data plate provides important
information that the operator should
record and have available for parts
ordering, warranty inquiries and service
requests.
Figure 3-1
3.4 Installation Date
Fill in the date of installation, and the name, address, and phone number of the
installer in the space provided below. This information will be needed when ordering
parts or service for the freezer.
Date of installation: ____________________________________
Installed by: ____________________________________
Address: ____________________________________
____________________________________
Phone: ____________________________________

ELECTRO FREEZE Soft Serve Model SL500
184599 7
Figure3-2 ElectroFreeze ModelSL500
ThedimensionsoftheSL500freezeris
providedinfigure3-2below.
3.5 Dimensions

8 184599
ELECTRO FREEZE Soft Serve Model SL500
4 Part Names and Functions
6 ROD - PLUNGER
Starts the freezer when dispensing.
Must be in place for proper
operation.
7 PIN - HANDLE
Secures handle to the head.
8 KNOB - HAND
Secures the head to the freezing
cylinder.
9 HANDLE - DISPENSE - SIDE
Opens and closes the plunger to
start and stop the flow of product
from the freezer.
10 HANDLE - DISPENSING - CENTER
Opens and closes the plunger to
start and stop the flow of swirl
product from the freezer.
11 NOZZLE - SERRATED
Forms the frozen product as it is
dispensed.
1 HEAD - DISPENSE
Encloses the freezing cylinder and
provides an opening for product to be
dispensed.
2 O-RINGS - HEAD
Seals the head to the freezing
cylinder. Must be lubricated.
3 PLUNGERS - DISPENSE - SIDE
Seals the product opening in the head
when closed. Allows product to flow
when open.
4 O-RINGS - PLUNGER
Seals the plunger in the head. Must be
lubricated to seal and slide freely.
5 PLUNGER - DISPENSE - CENTER
Seals the product opening in the head
when closed. Combines ice cream
from both cylinders to form swirl
cones.
Thefollowingdescriptionsrefertofigure4-1.Thenumberprecedingthepartnamecorre-
spondsto thenumberinthefigure.
Figure 4-1 Head Assembly

ELECTRO FREEZE Soft Serve Model SL500
184599 9
4 Part Names and Functions (continued)
Figure4-2 BeaterShaftAssembly
Thefollowingdescriptionsrefertofigure4-2.Thenumberprecedingthepartnamecorre-
spondsto thenumberinthefigure.
SEAL-BEATERSHAFT
Sealstheopeningbetweenthe
freezingcylinderandthebeatershaft.
Consistsofthefollowing:
4 SEAL-BEATERSHAFT
5 WASHER-DOUBLESHAFT
SEAL
1 BAR-BREAKER
Keepsproductblendedinthecenter
ofthebeatershaft.
2 SHAFT-ASSY.BEATER
Rotatesinthefreezingcylinder,
blendingairandmix.Ejectsproduct
whendispensingplungerisopened.
3 BLADE-SCRAPER
Scrapesthefrozenproductfromthe
freezingcylinder.

10 184599
ELECTRO FREEZE Soft Serve Model SL500
4 Part Names and Functions (continued)
Figure 4-3 Mix Feed Tube Assembly
1 TUBE - MIX FEED.
Meters the correct amount of mix
and air into the freezing cylinder
from the hopper.
2 REGULATOR.
Provides adjustment on mix feed
rate and a positive shut-off of mix
flow to the freezing cylinder.
3 O-RING - TUBE.
Seals the opening between the
hopper and mix feed tube. (O-ring
does not need lubrication.)
Thefollowingdescriptionsrefertofigure4-3.Thenumberprecedingthepartnamecorre-
spondsto thenumberinthefigure.

ELECTRO FREEZE Soft Serve Model SL500
184599 11
This two-position switch controls the
day and night refrigeration modes.
a. “DAY” (left) — The low tem-
perature thermostat controls the
system refrigeration to maintain the
product serving temperature between
18° to 21ºF (-8° to -6°C). This is the
normal operating position.
5.1 Day– Night Switch 1
b. “NIGHT” (right) — This energy-
saving mode will reduce product agita-
tion. The freezer will automatically cycle
to maintain temperatures below 40
º
F
(4
º
C). Use this position when the freezer
will not be in use for periods of more
than an hour.
The following paragraphs describe the
operator controls and indicators. Refer
to figure 5-1 for location of these
controls and indicators on the freezer.
NOTE: The dispense head must be in
place before the freezer will operate.
CAUTION
Test operation of the head
switch prior to placing the
freezer in service. See
Section 11, Routine
Maintenance, Monthly.
5 Operator Controls and Indicators
Figure 5-1
