Electrolux Professional DC6-8 User manual

Installation manual
Drying Cabinet
DC6-8
Original instructions
427001186/EN
2022.02.03

Contents
Contents
1 Safety Precautions ..............................................................................................................................5
1.1 General safety information..........................................................................................................5
1.2 Symbols....................................................................................................................................5
2 Technical data.....................................................................................................................................6
3 Installation kit......................................................................................................................................7
4 Recycling instruction for packaging.......................................................................................................8
5 Installation ..........................................................................................................................................9
5.1 Placement.................................................................................................................................9
5.2 Mechanical installation ...............................................................................................................9
5.3 Narrow spaces ........................................................................................................................10
6 Evacuation system ............................................................................................................................12
6.1 Fresh air..................................................................................................................................12
7 Electrical connection..........................................................................................................................14
7.1 Connecting an external payment system ...................................................................................16
8 Function check..................................................................................................................................18
9 Disposal information..........................................................................................................................19
9.1 Disposal of appliance at end of life ............................................................................................19
9.2 Disposal of packing..................................................................................................................19
The manufacturer reserves the right to make changes to design and component specifications.

Installation manual 5
1 Safety Precautions
This appliance can be used in public areas.
Remove all objects from pockets such as lighters and matches.
WARNING. This appliance is intended only for drying textiles washed in water.
DO NOT MODIFY THIS APPLIANCE.
Servicing shall be carried out only by authorized personnel.
Only authorized spare parts shall be used.
When performing service or replacing parts, the power must be disconnected.
A-weighted emission sound pressure level at workstations: <70 dB
Additional requirements for the following countries: AT, BE, BG, HR, CY, CZ, DK, EE, FI,
FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH, TR,
UK:
• This appliance can be used in public areas.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction con-
cerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children without supervision.
Additional requirements for other countries:
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental ca-
pabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do
not play with the appliance.
1.1 General safety information
Do not hose down the machine with water.
In order to prevent damage to the electronics (and other parts) that may occur as the result of condensation, the ma-
chine should be placed in room temperature for 24 hours before being used for the first time.
1.2 Symbols
Caution
Caution, hot surface
Read the instructions before using the machine.
Be careful. The drying cabinet is top heavy and can tip over easily.

6Installation manual
2 Technical data
A
E
K
D
1
4
H
F
I
J
G
2 3
B
C
5
fig.W01238
1 Control panel
2 Electrical connection
3 Air outlet
4 Elux decal
5Air flow decal
A B C D E F G H I J K
mm 1200 580 1820 1635 185 811 529 450 215 600 850
Exhaust air connection ⌀125 mm, maximum permitted pressure drop 70 Pa, which corresponds to a straight pipe with
a length of approx. 23 m. ⌀160 mm corresponds to a straight length of approx. 70 m.
Net weight: 134 kg.

Installation manual 7
3 Installation kit
IM
OM
D x4
A x2
B x2
C x4
E x2
fig.W01226
A Screw T6S 6x75
B Washer 8.4x17x1.6
C Wall plug
D Cover plug 15-12
E User Manual / Installation Manual

8Installation manual
4 Recycling instruction for packaging
fig.X02424
Fig. Description Code Type
1 Wrapping film LDPE 4 Plastics
2 Plastic band PET 1 Plastics
3 Cardboard protection bars
top
PAP 20 Paper
4 Cardboard protection bars
corners
PAP 20 Paper
5Cardboard protection bars PAP 20 Paper
6 Undercarriage protection FOR 50 Wood
7 Plastic cover LDPE 4 Plastics
8 Green tape LDPE 4 Plastics
9 Wrapping film LDPE 4 Plastics
10 Plastic bag LDPE 4 Plastics
11 Plastic bag LDPE 4 Plastics

Installation manual 9
5 Installation
Place the drying cabinet on its final position.
The straps around the adjustable feet can be used to raise the drying cabinet.
Level the drying cabinet with the adjustable feet. Make sure that the top edges of the doors are level with each other.
5.1 Placement
The drying cabinet should be positioned so that there is plenty of room for working, both for the user and service
personnel.
5.2 Mechanical installation
The drying cabinet must be secured to the wall to prevent it from tipping over.
The wall brackets are secured at the top of the drying cabinet upon delivery. Remove the wall brackets, turn them
over, and mount as shown. (Screws and plastic plugs are included upon delivery.)
fig.W01239

10 Installation manual
5.3 Narrow spaces
The upper part of the drying cabinet can be removed. Removing the upper part reduces the height by 185 mm.
• Loosen the two screws (Torx T20) on the underside of the front panel, square holes in the frame. Slide the front
panel upwards until it detaches from the guide flanges. Then remove it.
fig.W01240
• Remove the four screws (T20) securing the door switch bracket and then slide it back towards the inner bearing.
fig.W01241

Installation manual 11
• Remove the four screws (T30) from the front and rear rail sitting in the ceiling of the drying cabinet.
fig.W01242
The upper part of the drying cabinet can now be removed.

12 Installation manual
6 Evacuation system
6.1 Fresh air
The drying cabinet must be connected directly to the ventilation duct (not via any intermediate pipes or hoses).
The drying cabinet has an exhaust air flow of up to 250 cubic meters per hour. This air is initially taken from the room
where the drying cabinet is situated.
It is therefore important to ensure that fresh air can enter the room from the outside to replace the humid air that is
vented out.
The area of the air intake must be five times larger than the area of the evacuation pipe. The resistance in the grid/
damper must not exceed 10 Pa (0.1 mbar).
5 x A
A
fig.W01229
The drying cabinet works most efficiently if the air flow is optimal.
The top of the drying cabinet houses a damper that can be adjusted to a value equal to the pressure drop in the duct.
The maximum permitted pressure drop is 70 Pa. If the pressure drop is greater than this, an external fan must be in-
stalled. The drying cabinet has an electrical connection for an external fan.
0 Pa
30 Pa
50 Pa
80 Pa
90 Pa
fig.W01230

Installation manual 13
If multiple drying cabinets or dryers are connected to the same air duct, a non-return valve must be installed on each
appliance to prevent cold air from entering or the air pressure of one appliance affecting the other.
fig.W01243
Number of
cabinets 1 2 3 4 5 6 7 8 9 10
Evacuation pipe
dia.
[mm] 125 160 200 315 315 315 315 315 400 400
Recommended
area for fresh air
intake [m2]0.061 0.101 0.157 0.390 0.390 0.390 0.390 0.390 0.628 0.628
Minimum area for
fresh air intake [m2]0.035 0.069 0.104 0.139 0.174 0.208 0.243 0.278 0.313 0.347

14 Installation manual
7 Electrical connection
The electrical installation may only be performed by qualified personnel.
The drying cabinet must be connected to an all-pole circuit breaker.
Heating options Mains voltage Hz Heat output
kW
Total output
kW
Recommended fuse
A
Electrically heated 230V 1N ~ 50 6.0 6.2 30
400V 3N ~ 50 6.0 6.2 10
Loosen the two screws (Torx T20) on the underside of the front panel, square hole in the frame. Slide the front panel
upwards until it detaches from the guide flanges. Then remove it.
fig.W01240

Installation manual 15
Insert the cable in the hole (A) on the top of the drying cabinet.
A
fig.W01244
Connect the ground cable and the other cables as illustrated.
230V 1N ~
Ext. Fan
230V 50Hz
Pos. 17
Pos. 5
8
2
1
L1
N
PE
400V 3N ~
Ext. Fan
230V 50Hz
Pos.5
Red/L3
12
11
10
9
8
2
1
Brown/L2
Black/L1
Blue/N
L1
L2
L3
N
PE
Reinstall the front panel when you are done.

16 Installation manual
7.1 Connecting an external payment system
Note!
Can only be used on premium products.
Loosen the two screws (Torx T20) on the underside of the front panel, square hole in the frame. Slide the front panel
upwards until it detaches from the guide flanges. Then remove it.
fig.W01240
Connect the cables of the external payment system to the connections (A). If run information is needed, it is found on
the two pin contacts on the right (Aa).
A: requires potential-free switch. In other words, the signal comes from the card and must not receive any more
voltage.
Aa: is a potential-free relay that can handle 250 VAC.
Aa
A
11 21 2
2 3 4
1 2 3
123
4
5 6 7
456
8
fig.W01247

Installation manual 17
A red eight-pin DIP switch is located on the left side of the electrical unit. Set the first DIP switch (B) to the ON
position.
ON DIP
1 2 3 4 5 6 7 8
B
fig.W01248
If the drying cabinet is not connected to an external payment system, all eight DIP switches must be in the OFF posi-
tion for the drying cabinet to start.
ON DIP
12345678
fig.W01249
Note!
The relay output of the payment system must be closed during the entire drying process. If this is not the
case, heating will not work. (The fan will run, but heating will not be activated).

18 Installation manual
8 Function check
May only be performed by qualified personnel.
A function check must be performed when the installation is finished and before the appliance can be used.
Whenever a repair has been made, a function check must be performed before the appliance can be used again.
• Select any program and check that the drying cabinet is heating and that there are no odd noises.
Ready for use
If all tests are OK the appliance is now ready for use.
If any of the tests fail, or deficiencies or faults are detected, please contact your local service organization or supplier.

Installation manual 19
9 Disposal information
9.1 Disposal of appliance at end of life
Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of
the structure that can give or break during scrapping.
The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. met-
als, oils, greases, plastic, rubber, etc.).
Different regulations are in force in the various countries, therefore comply with the provisions of the laws and com-
petent bodies in the country where scrapping takes place.
In general, the appliance must be taken to a specialised collection/scrapping centre.
Dismantle the appliance, grouping the components according to their chemical characteristics, remembering that the
compressor contains lubricant oil and refrigerant fluid which can be recycled, and that the refrigerator and heat pump
components are special waste assimilable with urban waste.
The symbol on the product indicates that this product should not be treated as domestic waste, but must be correctly disposed
of in order to prevent any negative consequences for the environment and human health. For further information on the recy-
cling of this product, contact the local dealer or agent, the Customer Care service or the local body responsible for waste
disposal.
Note!
When scrapping the machine, any marking, this manual and other documents concerning the appliance
must be destroyed.
9.2 Disposal of packing
The packing must be disposed of in compliance with the current regulations in the country where the appliance is
used. All the packing materials are environmentally friendly.
They can be safely kept, recycled or burned in an appropriate waste incineration plant. Recyclable plastic parts are
marked as following examples.
PE
Polyethylene:
• Outer wrapping
• Instructions bag
PP
Polypropylene:
• Straps
PS
Polystyrene foam:
• Corner protectors

Electrolux Professional AB
341 80 Ljungby, Sweden
www.electroluxprofessional.com
