Electrolux Professional T4900 User manual

User manual
Tumble dryer
T4900, T41200
Type N4...
Original instructions
487054631/EN
2022.09.07

Contents
Contents
1 Safety Precautions ..............................................................................................................................5
1.1 General safety information..........................................................................................................6
1.2 Commercial use only..................................................................................................................6
1.3 Symbols....................................................................................................................................7
2 Warranty terms and exclusions.............................................................................................................8
3 Program description ............................................................................................................................9
4 Handling...........................................................................................................................................10
4.1 Operating panel.......................................................................................................................10
4.2 Load ....................................................................................................................................... 11
4.3 To start the machine................................................................................................................. 11
4.4 When program has ended ........................................................................................................12
5 Error codes.......................................................................................................................................13
6 Maintenance .....................................................................................................................................14
6.1 General...................................................................................................................................14
6.2 Every day................................................................................................................................14
6.3 Machines with residual moisture control (RMC) ..........................................................................15
6.4 Sliding door .............................................................................................................................15
6.5 Maintenance to be carried out by qualified service personnel ......................................................16
7 Disposal information..........................................................................................................................17
7.1 Disposal of appliance at end of life ............................................................................................17
7.2 Disposal of packing..................................................................................................................17
The manufacturer reserves the right to make changes to design and component specifications.

User manual 5
1 Safety Precautions
• Servicing shall be carried out only by authorized personnel.
• Only authorized spare parts, accessories and consumables shall be used.
• The machine is not to be used if industrial chemicals have been used for cleaning.
• Do not dry unwashed items in the machine.
• Items that have been soiled with substances such as cooking oil, acetone, alcohol, pet-
rol, kerosene, spot removers, turpentine, waxes and wax removers should be washed
in hot water with an extra amount of detergent before being dried in the machine.
• Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber
backed articles and clothes or pillows fitted with foam rubber pads should not be dried
in the machine.
• Fabric softeners or similar products should be used as specified by the fabric softener
instructions.
• The final part of a drying cycle occurs without heat (cool down cycle) to ensure that the
items are left at a temperature that ensures that the items will not be damaged.
• Remove all objects from pockets such as lighters and matches.
• WARNING. Never stop the machine before the end of the drying cycle unless all items
are quickly removed and spread out so that the heat is dissipated.
• Adequate ventilation has to be provided to avoid the back flow of gases into the room
for appliances burning other fuels, including open fires.
• Exhaust air must not be discharged into a flue which is used for exhausting fumes from
appliances burning gas or other fuels.
• The machine must not be installed behind a lockable door, a sliding door or a door with
a hinge on the opposite side to that of the machine in such a way that a full opening of
the machine is restricted.
• If the machine has a lint trap this has to be cleaned frequently.
• The lint must not be accumulated around the machine.
• DO NOT MODIFY THIS APPLIANCE.
• When performing service or replacing parts, the power must be disconnected.
• When the power is disconnected, the operator must see that the machine is discon-
nected (that the plug is removed and remains removed) from any point to which he has
access. If this is not possible, due to the construction or installation of the machine, a
disconnection with a locking system in the isolated position shall be provided.
• In accordance with the wiring rules: mount a multi-pole switch prior to the machine to
facilitate installation and service operations.
• WARNING: The appliance must not be supplied through an external switching device,
such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
• If different rated voltages or different rated frequencies (separated by a /) are stated at
the machine data plate, instructions for adjusting the appliance for operation at the re-
quired rated voltage or rated frequency are stated in the installation manual.
• Stationary appliances not fitted with means for disconnection from the supply mains
having a contact separation in all poles that provide full disconnection under overvolt-
age category III, the instructions state that means for disconnection must be incorpo-
rated in the fixed wiring in accordance with the wiring rules.
• The openings in the base, shall not be obstructed by a carpet.

6User manual
• Oil-affected items can ignite spontaneously, especially when exposed to heat sources
such as in a tumble dryer. The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot
enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat from
escaping and so create a fire hazard.
• If it is unavoidable that fabrics that contain vegetable or cooking oil or have been conta-
minated by hair care products be placed in a tumble dryer they should first be washed
in hot water with extra detergent – this will reduce, but not eliminate, the hazard.
• Maximum mass of dry cloth: T4900: 50 kg, T41200: 67 kg.
• A-weighted emission sound pressure level at working stations: < 70 dB(A).
Gas heated tumble dryer:
• Before installation, check that the local distribution conditions, nature of gas and pres-
sure and the adjustment of the appliance are compatible.
• The machine is not to be installed in rooms containing cleaning machines with per-
chloroethylene, TRICHLOROETHYLENE or CHLOROFLUOROCONTAINING HY-
DROCARBONS as cleaning agents.
• If you can smell gas:
– Do not switch on any equipment
– Do not use electrical switches
– Do not use telephones in the building
– Evacuate the room, building or area
– Contact the person responsible for the machine
• Additional requirements for the following countries; AT, BE, BG, HR, CY, CZ, DK, EE,
FI, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH,
TR, UK:
– CAUTION: This appliance shall not be installed where the public has access.
• Additional requirements for other countries:
– This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
1.1 General safety information
In order to prevent damage to the electronics (and other parts) that may occur as the result of condensation, the ma-
chine should be placed in room temperature for 24 hours before being used for the first time.
1.2 Commercial use only
The machine/machines covered by this manual is/are made for commercial and industrial use only.

User manual 7
1.3 Symbols
Caution
Caution, hot surface
Caution, high voltage
Read the instructions before using the machine

8User manual
2 Warranty terms and exclusions
If the purchase of this product includes warranty coverage, warranty is provided in line with local regulations and sub-
ject to the product being installed and used for the purposes as designed, and as described within the appropriate
equipment documentation.
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance
in accordance with Electrolux Professional user and maintenance documentation made available in paper or elec-
tronic format.
Electrolux Professional strongly recommends using Electrolux Professional approved cleaning, rinse and descaling
agents to obtain optimal results and maintain product efficiency over time.
The Electrolux Professional warranty does not cover:
• service trips cost to deliver and pick up the product;
• installation;
• training on how to use/operate;
• replacement (and/or supply) of wear and tear parts unless resulting from defects in materials or workmanship re-
ported within one (1) week from the failure;
• correction of external wiring;
• correction of unauthorized repairs as well as any damages, failures and inefficiencies caused by and/or resulting
from;
– insufficient and/or abnormal capacity of the electrical systems (current/voltage/frequency, including spikes and/
or outages);
– inadequate or interrupted water supply, steam, air, gas (including impurities and/or other that does not comply
with the technical requirements for each appliance);
– plumbing parts, components or consumable cleaning products that are not approved by the manufacturer;
– customer’s negligence, misuse, abuse and/or non-compliance with the use and care instructions detailed within
the appropriate equipment documentation;
– improper or poor: installation, repair, maintenance (including tampering, modifications and repairs carried out
by third parties not authorized third parties) and modification of safety systems;
– Use of non-original components (e.g.: consumables, wear and tear, or spare parts);
– environment conditions provoking thermal (e.g. overheating/freezing) or chemical (e.g. corrosion/oxidation)
stress;
– foreign objects placed in- or connected to- the product;
– accidents or force majeure;
– transportation and handling, including scratches, dents, chips, and/or other damage to the finish of the product,
unless such damage results from defects in materials or workmanship and is reported within one (1) week of deliv-
ery unless otherwise agreed;
• product with original serial numbers that have been removed, altered or cannot be readily determined;
• replacement of light bulbs, filters or any consumable parts;
• any accessories and software not approved or specified by Electrolux Professional.
Warranty does not include scheduled maintenance activities (including the parts required for it) or the supply of
cleaning agents unless specifically covered within any local agreement, subject to local terms and conditions.
Check on Electrolux Professional website the list of authorized customer care.

User manual 9
3 Program description
Programs for machines with RMC
Program Process Textiles
P 01 Extra dry Denim
P 02 Ready to put away 100% cotton / poly cotton mixture / terry
P 03 Ironing dry (5% moisture) Polyester / nylon
P 04 Ironing dry (10% moisture) Wool / silk
P 05 Ironing dry (15% moisture) Viscose / acetate
P 06 Ironing dry (20% moisture) Mixed textiles
P 07 10 minutes drying All textiles
P 08 20 minutes drying All textiles
P 09 30 minutes drying All textiles
Programs for machines with Auto stop
Program Process Textiles
P 01 Extra dry Denim
P 02 Ready to put away 100% cotton / poly cotton mixture / terry
P 03 10 minutes drying All textiles
P 04 20 minutes drying All textiles
P 05 30 minutes drying All textiles
Temperature
High Non-iron / normal wash Cotton and mixed fabrics
Medium Non-iron / normal wash Cotton and mixed fabrics
Low Fine wash / mild wash Delicate fabrics
No heat Airing bedspreads, duvets and bedclothes

10 User manual
4 Handling
4.1 Operating panel
Buttons and symbols
P
P button
Program selection button.
Not active on coin operated
machines.
With RMC: When pushing the
button during operation, the dis-
play shows the residual moisture
in the clothes.
Reversing
Reversing on/off.
Only on OPL machines.
Time button
Setting of drying time.
Not active on coin operated
machines.
Cool-down time
Setting of cool-down time.
Only on OPL machines.
Temperature selection button
When pushing the button during
operation, the display shows the
outlet temperature.
Heat
When the lamp is lit the heat is
on.
Selected temperature
Lamp is lit at selected
temperature.
Filter
When lamp is lit filter door/filter
drawer is open.
Start/stop button
To start: Push the button.
To stop: Push the button or open
the door.
Gas reset button
Only on machines with standard
loading door.
Program status
“d xx” = Time controlled drying - xx indicates the time.
“c xx” = Time controlled cool-down - xx indicates the time.
“c - -” = Temperature controlled cool-down.
“ 00” = Standby. The machine runs an anti-crease program for 120 minutes or until the door is opened.
Options for machines with sliding door and tilt
Indicator lamp for finished drying
cycle.
Knob for adjusting the rotation
speed of the drum.
Tilt
Drum rotation while emptying the
machine.
Rotation of drum in both direc-
tions during the emptying
process.
Tilting the machine.
The tilting can be disconnected by turning the knob back to upright position.

User manual 11
4.2 Load
Load the goods into the machine according to recommendations and close the door.
Make sure the filter is clean and clean if necessary.
Maximum load
T4900 45 kg
T41200 60 kg
4.3 To start the machine
Select program or set the drying time.
Program Process Textiles
P 01 Extra dry Denim
P 02 Ready to put away 100% cotton / poly cotton mixture / terry
P 03 Ironing dry (5% moisture) Polyester / nylon
P 04 Ironing dry (10% moisture) Wool / silk
P 05 Ironing dry (15% moisture) Viscose / acetate
P 06 Ironing dry (20% moisture) Mixed textiles
P 07 10 minutes drying All textiles
P 08 20 minutes drying All textiles
P 09 30 minutes drying All textiles
Select temperature.
1 High
2 Medium
3 Low
4 No heat
1
2
3
4
The cool-down period can be changed by pressing the cool-down button.
The reversing can be turned on and off by pressing both buttons at the same time.

12 User manual
Start the machine by pressing the start/stop button.
The machine stops automatically when the clothes are dry or when the selected time has expired.
4.4 When program has ended
Note!
For the best possible drying result it is important to empty the machine as soon as the program has ended.
If the machine is not emptied as soon as the program has ended the drum will rotate in short intervals in order to keep
the goods from being wrinkled.
Clean the filter after each drying cycle for best performance.
Tilting operation for easy unloading
When program has ended open the sliding door.
Start tilting by turning the knob all the way to right position. The machine will start tilting forward and it will be easier
to unload.
Rotating the drum when unloading
Push and turn the rotation knobs at the same time to rotate the drum when unloading.

User manual 13
Note!
Rotating the drum when unloading the machine must only be made by one person.
When the machine has been unloaded, turn the tilting knob back into upright position.
When the tilting knob is in upright position it is possible to rotate the drum with or without the Sliding door being open
by pushing the rotation button.
5 Error codes
A fault in the program or in the machine is displayed as a flashing code.
Some of these error codes can be solved easily without contacting service personnel.
Error code Cause/Action
E05 The motor is too hot.
Stop the machine and wait for 5 minutes. Start again and choose a program.
E06 The motor is too hot.
Stop the machine and wait for 5 minutes. Start again and choose a program.
E12 The tumble dryer is overfilled with clothes that are too wet.
Remove some of the clothes, close the door and press the start button.
E14 When the ignition control fails to detect a flame, a signal is sent to the PCB and error code E14 is displayed.
When this condition occurs, the gas valve is shut off and the ignition control must be reset manually.
Press the gas reset button (A) on the control panel. (If there is no gas reset button; contact authorized service personnel.
A
E15 The machine is overfilled.
Remove some of the clothes, close the door and press the start button.
E16 The error code is displayed if the user presses the start button while the vacuum switch is already closed.
Reset by open / close the door and press the start button.
For other error codes or repeated error codes, disconnect the power for 30 seconds. If the error code keeps coming
back, contact authorized service personnel.

14 User manual
6 Maintenance
6.1 General
It is the responsibility of the owner of the machine/the laundry manager to make sure that maintenance is periodically
performed.
Note!
Lack of maintenance may deteriorate the performance of the machine and may cause damage to
components.
6.2 Every day
Check that the machine does not operate with the door or the filter door open, if so, the machine must be placed out
of order until repairs are made.
Note!
Contact qualified service personnel to disconnect power from the affected machine.
Check that the machine does not start until the start/stop button is activated.
Check the filter compartment. Clean if necessary:
• Remove the door by opening it, detach the wire fastened to the finger protector and pull the door upwards.
It is unnecessary to remove the lint filter for cleaning. The air system of the machine ensures that lint and dust set-
tle automatically at the bottom of the filter compartment. Remove with a broom or a vacuum cleaner.
• Vacuum the filter door switch (A).
• Check that the lint filter is unbroken. Replace if necessary.
A
fig.W01112

User manual 15
Check the door packing (B) and clean if necessary (use a moist cloth).
B
fig.W01113
Remove any lint and dust around the machine.
Clean the door, door glass, door gasket and other external parts.
6.3 Machines with residual moisture control (RMC)
At regular basis, wipe off/clean drum and lifters with citric acid (Acidum citricum). If soap/softener residue remains, it
is recommended also to use a coarse sponge.
Lack of cleaning can affect the functionality of the residual moisture control. This can result in more moist load than
requested at program end.
6.4 Sliding door
Clean the panels at regular basis:
• Open Sliding Door completely.
• Open the panels (C).
• Vacuum clean thoroughly.
• Close the panels when ready.
C
fig.W01114

16 User manual
6.5 Maintenance to be carried out by qualified service personnel
Contact qualified service personnel to perform the following maintenance:
Once a month:
• Steam heated machines: Clean the filter in front of the steam calorifier.
After 1600 hours of operation or once a year, whichever comes first:
• Clean the fan, the exhaust duct and the fresh-air intake to the room
• On machines with RMC: Clean the glide surface on the RMC graphite collector
• Clean the door gasket
• Clean the component unit
• Clean the area around the drum
• Clean the fan/fan wheel
• Check the belt tension

User manual 17
7 Disposal information
7.1 Disposal of appliance at end of life
Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of
the structure that can give or break during scrapping.
The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. met-
als, oils, greases, plastic, rubber, etc.).
Different regulations are in force in the various countries, therefore comply with the provisions of the laws and com-
petent bodies in the country where scrapping takes place.
In general, the appliance must be taken to a specialised collection/scrapping centre.
Dismantle the appliance, grouping the components according to their chemical characteristics, remembering that the
compressor contains lubricant oil and refrigerant fluid which can be recycled, and that the refrigerator and heat pump
components are special waste assimilable with urban waste.
The symbol on the product indicates that this product should not be treated as domestic waste, but must be correctly disposed
of in order to prevent any negative consequences for the environment and human health. For further information on the recy-
cling of this product, contact the local dealer or agent, the Customer Care service or the local body responsible for waste
disposal.
Note!
When scrapping the machine, any marking, this manual and other documents concerning the appliance
must be destroyed.
7.2 Disposal of packing
The packing must be disposed of in compliance with the current regulations in the country where the appliance is
used. All the packing materials are environmentally friendly.
They can be safely kept, recycled or burned in an appropriate waste incineration plant. Recyclable plastic parts are
marked as following examples.
PE
Polyethylene:
• Outer wrapping
• Instructions bag
PP
Polypropylene:
• Straps
PS
Polystyrene foam:
• Corner protectors

Electrolux Professional AB
341 80 Ljungby, Sweden
www.electroluxprofessional.com
