Electrolux EW30GC55G S User manual

Use & Care Guide
Gas Cooktop
318 200 691 (0709) Rev. A

2Finding Information
Finding Information
MAKE A RECORD FOR FUTURE USE
Brand_______________________________________________________________
Purchase Date_____________________________________________________
Model Number_____________________________________________________
Serial Number______________________________________________________
QUESTIONS?
For toll-free telephone support in the U.S. and Canada:
1-877-4ELECTROLUX (1-877-435-3287)
For on-line support and internet product information:
www.electrolux.com
©2007 Electrolux Home Products, Inc.
Post Office Box 212378,Augusta, Georgia 30917, USA
All rights reserved. Printed in the USA
NONO
NONO
NOTETE
TETE
TE
The serial plate is located under the burner box.

3
Finding Information
Finding Information
Finding Information
TABLE OF CONTENTS
Finding Information ............................................ 2
Make a Record for Future use ......................... 2
Questions? ....................................................... 2
Safety ................................................................ 4-6
Important Safety Instructions ........................... 4
Getting Start ........................................................ 7
Grounding Instructions ..................................... 7
Liquefied Petroleum (Propane)
Gas Conversion................................................ 7
Surface Cooking ............................................ 8-13
Flame Size ....................................................... 8
Proper BurnerAdjustments .............................. 8
Locations of the Burners .................................. 9
Placement of Burner Heads and Caps............. 9
Placement of Burner Grates........................... 10
Surface Cooking Utensils............................... 10
Setting Surface Controls .................................11
Using the Griddle............................................ 12
Using the Simmer Plate.................................. 12
Using the Wok Stand...................................... 13
General Care & Cleaning ............................. 14-16
Care & Cleaning Table ................................... 14
Cleaning the Burner Grates, Burner Caps,
and Burner Heads .......................................... 15
Porcelain Enamel Cooktop
Cleaning Instructions...................................... 16
Care & Cleaning of Stainless Steel ................ 16
Solutions to Common Problems ..................... 17
Surface Burner Do Not Light .......................... 17
Burner Flame Only Lights Half
Way Around Burner ........................................ 17
Burner Flame is Orange................................. 17
Warranty Information ........................................ 18
NONO
NONO
NOTETE
TETE
TE
Save these instructions for future reference.

4Safety
Safety
IMPORTANT SAFETY INSTRUCTIONS
Please read all safety instructions before using your new Electrolux cooktop.
!
WARNINGWARNING
WARNINGWARNING
WARNING
To reduce the risk of fire, electrical shock, or injury when using your gas cooktop, follow basic
precautions including the following:
!
WARNINGWARNING
WARNINGWARNING
WARNING
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, servicer or the gas
supplier.
This manual contains important safety symbols and instructions. Please pay attention to these
symbols and follow all instructions given.
!
WARNINGWARNING
WARNINGWARNING
WARNING
This symbol will help alert you to situations that may cause serious bodily harm, death or property
damage.
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
This symbol will help alert you to situations that may cause bodily injury or property damage.
• Remove all tape and packaging before using the Cooktop. Destroy the carton and
plastic bags after unpacking the cooktop. Never allow children to play with packaging
material. Do not remove the model/serial plate attached to the cooktop.
• Proper Installation-Be sure your appliance is properly installed and grounded by a
qualified technician in accordance with the National Fuel Gas Code ANSI Z223.1—
latest edition in the United States, or in Canada CAN/CGA B149.1, and CAN/CGA
B149.2, and the National Electrical Code ANSI/NFPA No. 70—latest edition in United
States,or in Canada CSA StandardC22.1, Canadian Electrical Code,Part 1, and local
code requirements. Install and/or adjust only per installation instructions provided in the
literature package for this cooktop.

5
Safety
Safety
Safety
!
WARNINGWARNING
WARNINGWARNING
WARNING
• Stepping, leaning or sitting on this cooktop can result in serious injuries and also cause damage to
the cooktop. Do not allow children to climb or play around the cooktop.
• NEVER use this appliance as a space heater to heat or warm the room. Doingso mayresult incarbon
monoxide poisoning and overheating of the oven.
Askyourdealertorecommendaqualifiedtechnicianandanauthorizedrepairservice.Knowhow
toshutoffgassupplyatthemeteranddisconnecttheelectricalpowertothecooktopatthecircuit
breaker or fuse box in case of an emergency.
• User servicing—Do not repair or replace any part of the appliance unless specifically
recommendedinthemanuals.Allotherservicingshouldbedoneonlybyaqualifiedtechnician,
This may reduce the risk of personal injury and damage to the cooktop.
• Never modify or alter the construction of a cooktop by removing panels, wire covers
or any other part of the product.
• Storage on Appliance—Flammable materials should not be stored on the cooktop or
near surface units. This includes paper, plastic and cloth items, such as cookbooks,
plasticware and towels, as well as flammable liquids. Do not store explosives, such as
aerosol cans, on or near the cooktop. Flammable materials may explode and result in fire
or property damage.
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
Do not store items of interest to children in the cabinets above the cooktop. Children
climbing on the cooktop to reach items could be seriously injured.
• Do Not Leave Children Alone—Children should not be left alone or unattended in the
area where appliance is in use. They should never be allowed to sit or stand on any part
of the appliance.
• DO NOT TOUCH SURFACE BURNERS/UNIT, GRATES OR AREAS NEAR THESE
BURNERS/UNIT. Surface burners/unit may be hot even though flames are not visible/ unit
is dark in color. Areas near surface burners/unit may become hot enough to cause burns.
During and after use, do not touch, or let clothing or other flammable materials touch these
areas until they have had sufficient time to cool. Among these areas are the cooktop and
surfaces facing the cooktop.
• WearProperApparel—Loose-fittingorhanginggarmentsshouldneverbewornwhile
using the appliance. Donotlet clothing orother flammablematerials contacthotsurfaces.
• Do Not Use Water or Flour on Grease Fires—Smother the fire with a pan lid, or use
baking soda, a dry chemical or foam-type extinguisher.
• When heating fat or grease, watch it closely. Fat or grease may catch fire if allowed to
become too hot.
• Use Only Dry Potholders—Moist or damp potholders on hot surfaces may result in
burns from steam. Donot let potholders touch hot heating elements, the flameor burners.
Do not use a towel or other bulky cloth instead of a potholder.
• Do Not Heat Unopened Food Containers—Buildup of pressure may cause container
to burst and result in injury.

6Safety
Safety
!
WARNINGWARNING
WARNINGWARNING
WARNING
DoNot Use StoveTopGrills onYourSealed GasBurners—Ifyouuseastovetopgrillonasealedgasburner,
it will cause incomplete combustion and can result in exposure to carbon monoxide levels above allowable
current standards. This can be hazardous to your health.
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANT SAFETY NOANT SAFETY NO
ANT SAFETY NOANT SAFETY NO
ANT SAFETY NOTICETICE
TICETICE
TICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause cancer, birth defects or other reproductive
harm, and requires businesses to warn customers of potential exposure to such substances.
!
WARNINGWARNING
WARNINGWARNING
WARNING
Use Proper Flame Size—Adjust flame size so it does not extend beyond the edge of the utensil. Theuse
of undersized utensils will expose a portion of the burner flame to direct contact and may result in ignition of
clothing. Proper relationship of utensil to flame will also improve efficiency.
!
WARNINGWARNING
WARNINGWARNING
WARNING
Use proper pan size. This cooktop can be equipped with one or more surface units of different sizes. Select
utensilshavingflatbottoms largeenoughtocover thesurfaceunit. The useofundersized utensilswillexpose
aportion of the surfaceheating unit to direct contact and may result inignition of clothing. Proper relationship
of utensil to the surface unit will also improve efficiency.
• Knowwhichknobcontrolseachsurfaceburner.AlwaysturntheknobtotheLITEposition
when igniting the burners. Visually check that the burner has lit. Then adjust the flame so it
does not extend beyond the edge of the utensil.
• Clean the appliance regularly to keep all parts free of grease that could catch fire.
Exhaust fan ventilation hoods and grease filters should be kept clean. Do not allow grease
to accumulate on hood or filter. Greasy deposits in the fan could catch fire. When flaming
food under the hood, turn fan on. Refer to hood manufacturer’s instructions for cleaning.
• Utensil Handles Should Be Turned Inward and Not Extend Over Adjacent Surface
Burners/Unit —To reduce the risk of burns, ignition of flammable materials, and spillage
due to unintentional contact with the utensil, the handle of the utensil should be positioned
so that it is turned inward, and does not extend over adjacent surface burners.
• NeverLeaveSurfaceBurners/UnitUnattendedatHighHeatSettings—Boiloverscause
smoking and greasy spillovers that may ignite, or a pan that has boiled dry may melt.
• Protective Liners—Do not usealuminum foil to line any part ofthe cooktop, use aluminum
foil only to cover food during cooking. Improper installation of these liners may result in risk
of electric shock, or fire.
• GlazedCookingUtensils—Onlycertaintypesofglass,glass/ceramic,ceramic,earthenware,
orother glazed utensils are suitable for cooktop service without breaking due to the sudden
change in temperature. Check the manufacturer’s recommendations for cooktop use.
• Do Not Use Decorative Surface Burner Covers. Ifa burner/unit is accidentally turnedon,
the decorative cover will become hot and possibly melt. You will not be able to see that the
burnerison.Burnswilloccurifthehotcoversaretouched.Damagemayalsobedonetothe
cooktop or burners because the covers may cause overheating. Air will blocked from the
burner/unit and cause combustion problems.

7
Getting S
Getting S
t
t
art
art
art
GROUNDING INSTRUCTIONS
For personal safety, the cooktop must be properly grounded. For
maximum safety, the power cord must be plugged into an
electrical outlet that is correctly polarized and properly grounded.
DO NOT operate the cooktop using a 2-prong adapter or an
extension cord. If a 2-prong wall receptacle is the only available
outlet, it is the personal responsibility of the consumer to have it
replaced with a properly grounded 3-prong wall receptacle
installed by a qualified electrician.
See the INSTALLATION INSTRUCTIONS packaged with this
cooktop for complete installation and grounding instructions.
LIQUEFIED PETROLEUM (PROPANE) GAS CONVERSION
This appliance can be used with Natural Gas and Propane Gas. It is shipped from the
factory for use with natural gas.
A kit for converting to LP gas is supplied with your cooktop. The kit is marked “FOR LP/
PROPANE GAS CONVERSION”. Follow the installation instructions which are inside the
envelope.
The conversion must be performed by a qualified service technician in accordance with
the kit instructions and all local codes and requirements. Failure to follow instructions
could result in serious injury or property damage. The qualified agency performing this
work assumes responsibility for the conversion.
!
WARNINGWARNING
WARNINGWARNING
WARNING
This appliance is equipped with a 3-prong grounding plug for your protection
against shock hazard and should be plugged directly into a properly
grounded receptacle. DO NOT cut or remove the grounding prong from this
plug.
Avoid fire hazard or electrical shock. DO NOT use an adapter plug, an
extension cord, or remove grounding prong from electrical power cord.
!
WARNINGWARNING
WARNINGWARNING
WARNING
Severe shock, or damage to the cooktop may occur if the cooktop is not installed by a qualified installer or
!
CACA
CACA
CAUTIONUTION
UTIONUTION
UTION
Any additions, changes or conversions required in order for this appliance to satisfactorily meet the
application needs must be made by a qualified service technician in accordance with the manufacturer’s
instructions and all codes and requirements of the authority having jurisdiction. Failure to follow the
instructions could result in serious injury or property damage. The qualified agency performing this work
assumes responsibility for the conversion.
Do not, under any
circumstances, cut,
remove, or bypass the
grounding prong.
Power supply cord with
3-prong grounding plug
Grounding
type wall
receptacle

8Surface Cooking
Surface Cooking
FLAME SIZE
For most cooking, start on the highest control setting and then turn to a lower one to
complete the process. Use the chart below as a guide for determining proper flame size
for various types of cooking. The size and type of utensil used and the amount of food
being cooked will influence the setting needed for cooking.
For deep fat frying,use a thermometer and adjust the surface control knob accordingly.
If the fat is too cool, the food will absorb the fat and be greasy. If the fat is too hot, the food
will brown so quickly that the center will be undercooked. Do not attempt to deep fat fry too
much food at once as the food will neither brown nor cook properly.
*Flame Size Type of Cooking
High Flame Start most foods; bring water to a boil; pan broiling
Medium Flame Maintain a slow boil; thicken sauces, gravies; steam
Low Flame Keep foods cooking; poach; stew
*These settings are based on using medium-weight aluminum pans with
lids. Settings may vary when using other types of pans.
Never extend the flame beyond the outer edge of the utensil. A higher flame
simply wastes heat and energy, and increases your risk of being burned by the
flame.
PROPER BURNER ADJUSTMENTS
The color of the flame is the key to proper burner adjustment. A good flame is clear, blue
and hardly visible in a well-lighted room. Each cone of flame should be steady and sharply
defined. Adjust or clean burner if flame is yellow-orange. To clean burner, see instructions
under General Care & Cleaning.
RIGHT
WRONG

9
Surface Cooking
Surface Cooking
Surface Cooking
Burner Cap
Burner
Head
OFF
OFF OFF
OFF
PLACEMENT OF BURNER HEADS AND CAPS
LOCATIONS OF THE BURNERS
The 30” cooktop is equipped with different sized burners.
The surface burners are located on the cooktop as follows (See Figure):
-a5 000 BTU (natural gas) burner located at the right rear position;
-a18 000 BTU (natural gas) burner located at the left rear position;
-a9 500 BTU (natural gas) burner located at the left front position;
- and a 14 000 BTU (natural gas) burner located at the right front position.
30” cooktop
The 36” cooktop is equipped with different sized burners.
The surface burners are located on the cooktop as follows (See
Figure):
-a5 000 BTU (natural gas) burner located at the right rear position;
- two 9 500 BTU (natural gas) burners located at the left front and left
rear positions;
-a18 000 BTU (natural gas) burner located at the center position;
- and a 14 000 BTU (natural gas) burner located at the right front
position.
36” cooktop
For the 18 000 BTU burner :
Place the burner head over the gas orifice (Figure 1). Be careful not to damage the
electrode while placing the burner head over the orifice. Make sure electrode fits
correctly into slot in burner head.
Figure 1
Burner
Head
Gas Opening
For all burners :
Place a burner cap on each burner
head (see Figure 2), matching the cap
size to the head size. The cap for each
burner has an inner locating ring which
centers the cap correctly on the burner
head. Be sure that all the burner caps
and burner heads are correctly placed
BEFORE using your appliance.
Make sure each burner cap is properly
aligned and level.
Turn the burner on to determine if it will
light. If the burner does not light,
contact a Service Center. Do not
service the sealed burner yourself.
Figure 2
Gas
Opening

10 Surface Cooking
Surface Cooking
Note: Always use a utensil for its intended purpose. Follow manufacturer's
instructions. Some utensils were not made to be used in the oven or on the cooktop.
*GOOD
• Flat bottom and straight sides.
• Tight fitting lids.
• Weight of handle does not tilt pan.
Pan is well balanced.
• Pan sizes match the amount of
food to be prepared and the size of
burner.
• Made of material that conducts
heat well.
• Easy to clean.
POOR
• Curved and warped pan bottoms.
• Pan overhangs unit by more than
2.5 cm (1”).
• Heavy handle tilts pan.
• Flame extends beyond unit.
Pans should have flat bot-
toms. Check for flatness by
rotating a ruler across the bot-
tom. There should be no gaps
between the pan and ruler.
*Specialty pans such as lob-
ster pots, griddles and pres-
sure cookers may be used but
must conform to the above
recommended cookware re-
quirements.
SURFACE COOKING UTENSILS
