Electrolux thermaline S90
4-burners boiling top on base
The Electrolux thermaline S90 cooking equipment is designed for the very heavy duty requirements of small institutions,
hotels and restaurants. The range consists of a wide choice of modular elements that can be installed as individual
free-standing or wall mounted units, or assembled into a complete cooking suite. Construction based on an internal
stainless steel frame combined with a new plug-connection system ensures that individual modules can be solidly
connected with a virtually seamless working surface.The modules described in detail on this sheet have 4 independently
controlled open burners, mounted on a base unit. These models are available for operation either on one side only or
from both sides to suit a central cooking island. The installation options floor mounted on 200mm high feet or on a plinth
that can be either in stainless steel or of masonry construction.
599516+SS plinth+shelf fixation
EASY TO USE
• Two different sizes of burners to suit
different cooking requirements from
rapid boiling to a gentle simmer
process.
• Manual gas valves with fixed high
and low positions allow precise
control of the flame intensity.
• Large sized pan support in cast iron
with long center fins to allow the use
of the largest down to the smallest
pans.
• The level of the pan support and the
top of the unit is the same, which
means it is possible to move pans
around the surface without lifting.

EASY TO MAINTAIN
• Removable pan supports, burner
rings and flame ignition components.
• Simply, convenient operation with
highly visible control panels and
knobs.
• Gas main valve built in as standard.
EASY ON THE ENVIRONMENT
• 98% of the unit is recyclable by
weight.
• Packing free of toxic substances.

MATERIALS
• Body and base compartment are
made of stainless steel AISI 304 and
pan supports are made of cast iron.
• 3 mm work top in AISI 304 stainless
steel.
• “Lasertec connection system” in
AISI 304 stainless steel creates a
nearly seamless work top .

APPROVALS
• The appliances are IPX5 certified
against water jets.
• All appliances are developed and
assembled according to European
safety and hygiene standards and are
H marked.
MODELS
• All the models are delivered with
four square stainless steel feet.
• Some models are supplied with the
Ecoflam pan detection system, which
has the advantage of saving energy
and reducing unnecessary heat
radiation in the kitchen.
• The models installed against the
wall have a C-board of 43 mm. The
C-board on the rear side of the
appliances closes any kind of gap
between the unit and the wall, for
better hygiene.
• The 2 side operating models have a
pass-through base.
• Available as variation models with
open base in hygienic designed
execution with large rounded corners
for easier cleaning.

Electrolux thermaline S90
4-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0302013-10-03Subject to change without notice
SOLID TOP PLATE F.OPEN BURNER-360X360MM 910718 910718 910718 910718 910718 910718
SIDE PANEL RIGHT-AGAINST WALL+CB,H=700MM 911950 911950
SIDE PANEL RIGHT-AGAINST WALL, H=700MM 911952 911952
SIDE PANEL RIGHT - BACK TO BACK 911954 911954
SIDE PANEL LEFT-AGAINST WALL+CB,H=700MM 911951 911951
SIDE PANEL LEFT-AGAINST WALL, H=700MM 911953 911953
SIDE PANEL LEFT - BACK TO BACK 911955 911955
SIDE PANEL FREESTANDING 911949 911949 911949 911949
SHELF FOR OPEN & HOT BASE,W=1000,1-S 910783 910783 910783 910783
SHELF FOR OPEN & HOT BASE 900,W=1000,2-S 910782 910782
SHELF FIXATION FOR OPEN&HOT BASE,1-S 910771 910771 910771 910771
SHELF FIXATION F.OPEN&HOT BASE 800,2-S 910772 910772
S90 PAN REST CNS 430X430 MM THERMA 911988 911988 911988 911988 911988 911988
S/S SIDE KICKING STRIPS LEFT+RIGHT -WALL 911639 911639 911639 911639
S/S SIDE KICKING STRIPS LEFT+RIGHT - FS 911638 911638 911638 911638
S/S SIDE KICKING STRIPS L+R-BACK-TO-BACK 911640 911640
S/S SIDE KICKING STRIPS BACK TO BACK C-B 911844 911844
S/S FRONT+BACK KICKING STRIP 1000MM - FS 911533 911533 911533 911533
S/S FRONT KICKING STRIP 1000MM - WALL 911560 911560 911560 911560
PORTIONING SHELF 1000X200 MM 911878 911878 911878 911878 911878 911878
PORTIONING SHELF 1000X130 MM 911856 911856 911856 911856 911856 911856
PAN REST STAINLESS STEEL-430X380 MM 910729 910729 910729 910729 910729 910729
LOWER SIDE PANEL WALL MOUNTING 300 MM RI 911672 911672 911672 911672
LOWER SIDE PANEL WALL MOUNTING 300 MM LE 911671 911671 911671 911671
KIT FOR WALL MOUNTING H = 700MM 911670 911670 911670 911670
KIT FOR BACK TO BACK INSTALLATION,1-PCE 911619 911619
KIT BACK TO BACK INSTALLATION C-BOARD 911845 911845
FLEXIBLE CONNECTION HOSE 3/4'' 910720 910720 910720 910720 910720 910720
ACCESSORIES
PAN REST CAST-IRON-430X399 MM 1 1 1 1 1 1
INCLUDED ACCESSORIES
Net weight - kg. 120 120 120 120 120 120
gas 24 24 24 24 24 24
Power - kW
Front burners power - kW 5, 7 5, 7 5, 7 5, 7 5, 7 5, 7
Front burners dimension - mm 420x440,
420x440
420x440,
420x440
420x440,
420x440
420x440,
420x440
420x440,
420x440
420x440,
420x440
Back burners power - kW 7, 5 7, 5 7, 5 7, 5 7, 5 7, 5
Back burner dimensions - mm 420x440,
420x440
420x440,
420x440
420x440,
420x440
420x440,
420x440
420x440,
420x440
420x440,
420x440
height 358 358 358 358 358 358
depth 738 738 860 860 738 738
width 770 770 770 770 770 770
Storage cupboard - mm
height 900 900 900 900 900 900
depth 900 900 900 900 900 900
width 1000 1000 1000 1000 1000 1000
External dimensions - mm
Configuration One-Side
Operated
One-Side
Operated
Both-Sides
Operated
Both-Sides
Operated
One-Side
Operated
One-Side
Operated
Installation Standing as an
island; Standing
back to back
Standing as an
island; Standing
back to back
Standing as an
island
Standing as an
island
Standing against
wall; Standing
back to back;
Wall mounted
Standing against
wall; Standing
back to back;
Wall mounted
Power supply Gas Gas Gas Gas Gas Gas
TECHNICAL DATA
GC1G21A1B
584244
GC1G21A1BF
584245
GC1G21A2B
584246
GC1G21A2BF
584247
GC1G21C1B
584248
GC1G21C1BF
584249

Electrolux thermaline S90
4-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0302013-10-03Subject to change without notice
G - Gas connection 3/4" 3/4"
LEGEND
GC1G21A1B
584244
GC1G21A1BF
584245
584244, 584245

Electrolux thermaline S90
4-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0302013-10-03Subject to change without notice
G - Gas connection 3/4" 3/4"
LEGEND
GC1G21A2B
584246
GC1G21A2BF
584247
584246, 584247

Electrolux thermaline S90
4-burners boiling top on base
Internet: http://www.electrolux.com/foodservice
CFAA0302013-10-03Subject to change without notice
G - Gas connection 3/4" 3/4"
LEGEND
GC1G21C1B
584248
GC1G21C1BF
584249
584248, 584249
