Electrolux ECT6151S User manual

8VHUPDQXDO
ϡΪΨΘδϤϟ΍ϞϴϟΩ
(1
$5
ECT6151S
ECT9151S

2www.electrolux.com
CONTENTS
1. RECOMMENDATIONS AND SUGGESTIONS .................................................................. 3
2. USE ........................................................................................................................................... 6
3. MAINTENANCE ...................................................................................................................... 6
4. CONTROLS ............................................................................................................................. 6
5. LIGHTING ................................................................................................................................ 6
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings
with it decades of professional experience and innovation. Ingenious and stylish, it has
been designed with you in mind. So whenever you use it, you can be safe in the knowledge
that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.

3
ENGLISH
1. SAFETY INFORMATION
For your safety and correct operation of the appliance,
read this manual carefully before installation and use.
Always keep these instructions with the appliance even if
you move or sell it. Users must fully know the operation
and safety features of the appliance.
The wire connection has to be done by specialized
technician.
• The manufacturer will not be held liable for any damages
resulting from incorrect or improper installation.
• The minimum safety distance between the cooker top and
the extractor hood is 650 mm (some models can be installed
at a lower height, please refer to the paragraphs on working
dimensions and installation).
• If the instructions for installation for the gas hob specify a
greater distance, this must be respected.
• Check that the mains voltage corresponds to that indicated
on the rating plate xed to the inside of the hood.
• Means for disconnection must be incorporated in the xed
wiring in accordance with the wiring rules.
• For Class I appliances, check that the domestic power
supply guarantees adequate earthing.
• Connect the extractor to the exhaust ue through a pipe of
minimum diameter 120 mm. The route of the ue must be
as short as possible.
• Regulations concerning the discharge of air have to be
fullled.
• Do not connect the extractor hood to exhaust ducts carrying
combustion fumes (boilers, replaces, etc.).
• If the extractor is used in conjunction with non-electrical
appliances (e.g. gas burning appliances), a su󰀩cient degree
of aeration must be guaranteed in the room in order to
prevent the backow of exhaust gas. When the cooker hood
is used in conjunction with appliances supplied with energy
other than electric, the negative pressure in the room must
not exceed 0,04 mbar to prevent fumes being drawn back
into the room by the cooker hood.
• The air must not be discharged into a ue that is used for

4www.electrolux.com
exhaustingfumesfromappliancesburninggasorotherfuels.
• If the supply cord is damaged, it must be replaced from the
manufacturer or its service agent.
• Connect the plug to a socket complying with current
regulations, located in an accessible place.
• With regards to the technical and safety measures to be
adopted for fume discharging it is important to closely follow
the regulations provided by the local authorities.
WARNING: Before installing the Hood, remove the
protective lms.
• Use only screws and small parts in support of the hood.
WARNING: Failure to install the screws or xing device
in accordance with these instructions may result in
electrical hazards.
• Do not look directly at the light through optical devices
(binoculars, magnifying glasses…).
• Do not ambè under the range hood; risk of re.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaninganduser maintenanceshall notbemadebychildren
without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• Theapplianceis nottobeusedby persons(including children)
with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction.
Accessiblepartsmay becomehot whenusedwithcooking
appliances.
• Clean and/or replace the Filters after the specied time
period (Fire hazard). See paragraph Care and Cleaning.
• There shall be adequate ventilation of the room when the
range hood is used at the same time as appliances burning
gas or other fuels (not applicable to appliances that only

5
ENGLISH
discharge the air back into the room).
• The symbol on the product or on its packaging indicates
that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the
environment and human health, which could otherwise
be caused by inappropriate waste handling of this
product. For more detailed information about recycling
of this product, please contact your local city o󰀩ce, your
household waste disposal service or the shop where you
purchased the product.
“In case of replacement with halogen lamp use only
self-shielded tungsten halogen lamps or self-shielded
metal halide lamps.”

6www.electrolux.com
2. USE
• The extractor hood has been designed
exclusively for domestic use to elimi-
nate kitchen smells.
• Never use the hood for purposes other
than for which it has been designed.
• Never leave high naked ames under
the hood when it is in operation.
• Adjust the ame intensity to direct it
onto the bottom of the pan only, making
sure that it does not engulf the sides.
• Deep fat fryers must be continuously
monitored during use: overheated oil
can burst into ames.
3. MAINTENANCE
- The Activated charcoal lter
is not washable and cannot
be regenerated, and must be
replaced approximately every
4 months of operation, or more
frequently for particularly heavy
usage (W).
W
- The Grease lters must be cleaned
every 2 months of operation, or more
frequently for particularly heavy us-
age, and can be washed in a dish-
washer (Z).
Z
Z
Z
- Control lights, if present.
• Clean the hood using a damp cloth
and a neutral liquid detergent.

7
ENGLISH
4. CONTROLS
BUTTON FUNCTIONS
L Light Turns the Lighting System on and o󰀨.
V1 Speed Turns the Motor on at Speed one.
Turns the Motor o󰀨.
V2 Speed Turns the Motor on at Speed two.
V3 Speed Turns the Motor on at Speed three.
5. LIGHTING
Lamp Power (W) Socket Voltage (V) Dimension (mm) ILCOS Code
4 E14 220 – 240 107 x 37 DRBB/F-4-220-240-E14-35/100

8www.electrolux.com
