resher air and
stunning designs.
The Electrolux range of cooker hoods is segmented
into three levels, INSIGHT, INSPIRE & INTUITION, allowing
you to create the look you are seeking, from creating a
stunning focal point to being discreetly built into
a cupboard.
The aesthetics of the Electrolux cooker hood range
complement the other kitchen appliances as well as
today’s kitchen trends. The clever use of lighting
including down lights and up lighters helping to create the
perfect ambience for food preparation as well as dining.
Make your kitchen a pleasing and
attractive place to be
Electrolux Pleasant Kitchen symbols will help you
to easily choose the most appropriate cooker hood
for the dimensions of your kitchen whilst removing
unwanted vapour, airborne grease and odours from
your kitchen.
To maximise the performance of the cooker hood it is
essential to install the cooker hood with the correct
size of ducting, this will enable the cooker hood to
extract virtually all the vapour, cooking odours and
airborne grease from the kitchen and keep the
noise level to a minimum.
The measurements in each
of the boxes relates to the
floor space of the kitchen.
This may help to ensure that
you select the right hood for
your kitchen that will deal with
the vapour, airborne grease
and odours.
Global design
The Electrolux cooker hood range echoes the Global
Design concept which is geared for modern people in
today’s modern society. Electrolux cooker hoods are
designed to be effective, practical, stylish and unobtrusive
in your kitchen creating a pleasant atmosphere.

44 electrolux Thinking of you
Island hoods
Island hoods are designed to be suspended over a
central cooking island thus creating a dramatic focal
point in the kitchen.
Chimney hoods
Chimney hoods are designed to provide a visual focus
whilst offering various styles & widths to suit your kitchen.
These are designed to perform well and please the eye.
Telescopic hoods
Ideal for the kitchen where the hood needs to perform
well and be out of sight. These hoods are fitted into
the wall cupboard and then pulled out from the wall
when needed.
Perimeter Extraction.
The air flow is directed to the outer edges of the cooker
hood; so the entire external perimeter of the hood is
utilised, thereby reducing energy consumption and
noise level whilst delivering outstanding air filtration.
Canopy hoods
Canopy hoods are designed to fit snugly under a
decorative canopy, kitchen unit or wall cupboard.
These hoods save space and are discreet.
Integrated hoods
Appear to be part of the kitchen, hidden behind the
furniture door and simply pulled out when required.
Traditional hoods
Traditional hoods fit neatly
underneath a wall cupboard with
easy to reach front controls.
Take your choice.
550m /h
3
Indicates the
hood’s free blowing
extraction rate
electrolux cooking 45
EFC90680
HIGH performance 90cm stainless steel horizontal hood
Hood featu es:
• Maximum extraction 700m3/h
• 4 speed fan including intensive setting with electronic touch
controls - sleek and easy to use
• Automatic switch off for each speed
• Light bar - stylishly designed
• Recirculation or extraction options - charcoal filter included
• 4 concealed, washable aluminium cassette grease filters
- easy to clean
• Indicator LED for both grease and charcoal filter saturation
- you don’t have to remember
• Noise level 59dBA
• 3 x 20W halogen lamps - for excellent cooking visibility
• 2 x 20W halogen uplighters together with the lightbars
- for ambient illumination
• Width 90cm
Colou :
• Stainless Steel (E C90680X)
Accesso ies:
• Ducting Kit (CDK6 R)
Maximum
extraction
700m3/h
4 speed fan
including
intensive setting
700m /h
3
Suitable for kitchens up to this size -
for optimum performance and clean air
Indicates the
variation of
the fan setting

electrolux cooking 47
EFC60671
High performance 60cm stainless steel chimney hood
Hood featu es:
• Maximum extraction 720m3/h
• 4 speed fan including intensive setting with electronic push button
controls - stylish and easy to use
• Automatic switch off for each speed
• Recirculation or extraction options - charcoal filter included
• 2 washable aluminium cassette grease filters - easy to clean
• Indicator LED for both grease and charcoal filter saturation
- you don’t have to remember
• Noise level 57dBA
• 2 x 20W halogen lamps - for excellent cooking visibility
• Width 60cm
Colou :
• Stainless Steel (E C60671X)
Accesso ies:
• Ducting Kit (CDK6 R)
Maximum
extraction
720m3/h
4 speed fan
including
intensive setting
730m /h
3
3 speed fanMaximum
extraction
720m3/h
4 speed fan
including
intensive setting
730m /h
3
Maximum
extraction
720m3/h
4 speed fan
including
intensive setting
730m /h
3
Suitable for kitchens up to this size -
for optimum performance and clean air
46 electrolux cooking
EFC90673
HIGH performance 90cm stainless steel CHIMNEY hood
Hood featu es:
• Maximum extraction 720m3/h
• 4 speed fan including intensive setting with electronic touch controls
- sleek and easy to use
• Automatic switch off for each speed
• Temperature sensor - maintains low temperature controls
• Perimeter extraction - for improved airflow and energy consumption
and lower noise levels
• Light bar - stylishly designed
• Recirculation or extraction options - charcoal filter included
• 2 concealed, washable aluminium cassette grease filters
- easy to clean
• Indicator LED for both grease and charcoal filter saturation
- you don’t have to remember
• Noise level 57dBA
• 3 x 20W halogen lamps - for excellent cooking visibility
• Width 90cm
Colou :
• Stainless Steel (E C90673X)
Accesso ies:
• Ducting Kit (CDK6 R)
EFC90671
HIGH performance 90cm stainless steel CHIMNEY hood
Hood featu es:
• Maximum extraction 720m3/h
• 4 speed fan including intensive setting with electronic push button
controls - stylish and easy to use
• Automatic switch off for each speed
• Recirculation or extraction options - charcoal filter included
• 4 washable aluminium cassette grease filters - easy to clean
• Indicator LED for both grease and charcoal filter saturation
- you don’t have to remember
• Noise level 57dBA
• 3 x 20W halogen lamps - for excellent cooking visibility
• Width 90cm
Colou :
• Stainless Steel (E C90671X)
Accesso ies:
• Ducting Kit (CDK6 R)
Suitable for kitchens up to this size -
for optimum performance and clean air
Suitable for kitchens up to this size -
for optimum performance and clean air
Maximum
extraction
450m3/h
450m /h
3
EFC60670
60cm stainless steel chimney hood
Hood featu es:
• Maximum extraction 450m3/h
• 3 speed fan with push button controls - easy
• to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 62dBA
• 2 x 20W halogen lamps - for excellent cooking visibility
• Width 60cm
Colou :
• Stainless Steel (E C60670X)
Accesso ies:
• Ducting Kit (CDK6 R)
Suitable for kitchens up to this size -
for optimum performance and clean air

electrolux cooking 49
EFA90950
High performance 90cm curved glass island hood
Hood featu es:
• Maximum extraction 660m3/h
• 4 speed fan including intensive setting with electronic push button
controls - stylish and easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 62dBA
• 4 x 20W halogen lamps - for excellent cooking visibility
• Width 90cm
Colou :
• Stainless Steel (E A90950X)
Accesso ies:
• Charcoal ilter (E 72)
• Ducting Kit (CDK6 R)
Maximum
extraction
660m3/h
4 speed fan
including
intensive setting
660m /h
3
Maximum
extraction
660m3/h
4 speed fan
including
intensive setting
660m /h
3
EFC90950
High performance 90cm curved glass chimney hood
Hood featu es:
• Maximum extraction 660m3/h
• 4 speed fan including intensive setting with electronic push button
controls - stylish and easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 62dBA
• 2 x 20W halogen lamps- for excellent cooking visibility
• Width 90cm
Colou :
• Stainless Steel (E C90950X)
Accesso ies:
• Charcoal ilter (E 72)
• Ducting Kit (CDK6 R)
Suitable for kitchens up to this size -
for optimum performance and clean air
Suitable for kitchens up to this size -
for optimum performance and clean air
48 electrolux cooking
Maximum
extraction
440m3/h
440m /h
3
EFC70710
60cm Stainless steel and glass canopy chimney hood -
extends from 60cm to 70cm using side trims
Hood featu es:
• Maximum extraction 440m3/h
• 3 speed fan with push button controls
- easy to use
• Suitable for low ceiling heights
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 61dBA
• 2 x 40W hob lights - for good visibility
• Width 60cm-70cm
Colou :
• Stainless Steel (E C70710X)
Accesso ies:
• Charcoal ilter (E 72)
• Ducting Kit (CDK5 /CDK5 R)
Suitable for kitchens up to this size -
for optimum performance and clean air
Maximum
extraction
640m3/h
4 speed fan
including
intensive setting
550m /h
3
3 speed fan
EFC90620
High performance 100cm stainless steel island hood
Hood featu es:
• Hood eatures
• Maximum extraction 640m3/h
• 4 speed fan including intensive setting with electronic
touch controls - sleek and easy to use
• Auto switch off delay - for intensive setting
• Recirculation or extraction options - charcoal filter included
• Perimeter Extraction - for improved airflow and energy
consumption and lower noise levels
• 2 concealed, washable aluminium cassette grease filters
- easy to clean
• Indicator LED for both grease and charcoal filter saturation
- you don’t have to remember
• Noise level 61dBA
• 2 x 20W halogen lamps - for excellent cooking visibility
• Width 90cm
Colou :
• Stainless Steel (E C90620X)
Accesso ies:
• Ducting Kit (CDK6 R)
Suitable for kitchens up to this size -
for optimum performance and clean air

electrolux cooking 51
EFC90001/EFC70001/EFC60001
90cm/70cm/60cm chimney hoods
Hood featu es:
• Maximum extraction 450m3/h
• 3 speed fan with slider controls - easy to use.
• Suitable for low ceiling heights
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
(3 for E C90001)
• Noise level 61dBA
• 2 x 40W hob lights - for good visibility
• Width 90cm/70cm/60cm
Colou s:
• 90cm Stainless Steel (E C90001X) Black (E C90001K) White (E C90001W)
• 70cm Stainless Steel (E C70001X)
• 60cm Stainless Steel (E C60001X) Black (E C60001K) White (E C60001W)
Accesso ies:
• Charcoal ilter (E 62)
• Ducting Kit (CDK5 /CDK5 R)
Maximum
extraction
450m3/h
450m /h
3
Suitable for kitchens up to this size -
for optimum performance and clean air
50 electrolux cooking
Maximum
extraction
550m3/h
3 speed fan
550m /h
3
3 speed fanMaximum
extraction
310m3/h
310m /h
3
EFP90033
High performance 90cm fully integrated telescopic hood
Hood featu es:
• Maximum extraction 550m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 4 washable aluminium cassette grease filters - easy to clean
• Noise level 65dBA
• 2 x 9W “cool look” - energy saving lamps
• Width 90cm
Colou :
• Silver/Grey (E P90033X)
Accesso ies:
• Charcoal ilter (E 55)
• Ducting Kit (CDK6 R)
EFP60032
60cm fully integrated telescopic hood
Hood featu es:
• Maximum extraction 310m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 63dBA
• 2 x 40W hob lights - for good visibility
• Width 60cm
Colou :
• Silver/Grey (E P60033X)
Accesso ies:
• Charcoal ilter (E 70)
• Ducting Kit (CDK5 /CDK5 R)
Maximum
extraction
450m3/h
3 speed fan
450m /h
3
3 speed fan
EFC90700/EFC70700
90cm/70cm curved stainless steel CHIMNEY hood with aluminium trim
Hood featu es:
• Maximum extraction 450m3/h
• 3 speed fan with electronic push button controls
- controls positioned on chimney front - see installation diagram
for full details
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 62dBA
• 2 x 20W halogen lamps - for excellent cooking visibility
• Width 90cm/70cm
Colou :
• Stainless Steel (E C90700X), Stainless Steel (E C70700X)
Accesso ies:
• Charcoal ilter (TYPE 160)
• Ducting Kit (CDK6 R)
Suitable for kitchens up to this size -
for optimum performance and clean air

electrolux cooking 5352 electrolux cooking
EFG70023
High performance 70cm/50cm Canopy hood
Hood featu es:
• Maximum extraction 620m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 68dBA
• 2 x 20W halogen lamps - for excellent cooking visibility
• Width 70cm
Colou s:
• Silver/Grey (E G70023S)
Accesso ies:
• Charcoal ilter (E 70)
• Ducting Kit (CDK6 R)
Maximum
extraction
620m3/h
620m /h
3
Maximum
extraction
320m3/h
320m /h
3
EFG50022
50cm Canopy hood
Hood featu es:
• Maximum extraction 320m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 64dBA
• 2 x 40W hob lights - for good visibility
• Width 50cm
Colou :
• Silver/Grey (E G50022S)
Accesso ies:
• Charcoal ilter (E 70)
• Ducting Kit (CDK5 /CDK5 R)
Maximum
extraction
280m3/h
280m /h
3
Maximum
extraction
510m3/h
510m /h
3
EFG50021
50cm Canopy hood
Hood featu es:
• Maximum extraction 280m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• Acrylic grease filter
• Noise level 61dBA
• 2 x 40W hob lights - for good visibility
• Width 50cm
Colou :
• Silver/Grey (E G50021S)
Accesso ies:
• Charcoal ilter (E 70)
• Ducting Kit (CDK5 /CDK5 R)
EFi60013
HIGH performance 60cm Integrated hood
Hood featu es:
• Maximum extraction 510m3/h
• Variable electronic speed control - easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 66dBA
• 2 x 40W hob lights - for good visibility
• Width 60cm
Colou :
• Silver/Grey (E i60013S)
Accesso ies:
• Charcoal ilter (TYPE 29)
• Ducting Kit (CDK5 /CDK5 R)
3 speed fan 3 speed fan 3 speed fan Variable
electronic
speed fan

electrolux cooking 5554 electrolux cooking
EFi60012
60cm INTEGRATED hood
Hood featu es:
• Maximum extraction 320m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 65dBA
• 2 x 40W hob lights - for good visibility
• Width 60cm
Colou s:
• Silver/Grey (E i60012S)
Accesso ies:
• Charcoal ilter (TYPE 29)
• Ducting Kit (CDK5 /CDK5 R)
Maximum
extraction
320m3/h
320m /h
3
Maximum
extraction
220m3/h
220m /h
3
EFi60011
60cm INTEGRATED hood
Hood featu es:
• Maximum extraction 220m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• Acrylic grease filter
• Noise level 58dBA
• 2 x 40W hob lights - for good visibility
• Width 60cm
Colou :
• Silver/Grey (E i60011S)
Accesso ies:
• Charcoal ilter (TYPE 29)
• Ducting Kit (CDK5 /CDK5 R)
Maximum
extraction
180m3/h
180m /h
3
EFB60/90/120 EFB675/975/175
Splashbacks
Splashback featu es:
• Stylish stainless steel splashback to complement our range of
stainless steel ovens, hobs & hoods - easy wipe clean
Sizes:
• E B60X 60cm wide x 70cm high, E B90X 90cm wide x 70cm high,
E B120X 120cm wide x 70cm high, E B675X 60cm wide x 75cm high,
E B975X 90cm wide x 75cm high, E B175X 100cm wide x 75cm high
EFT60004W / EFT60004K / EFT60004X
60cm Traditional hood with glass visor
Hood featu es:
• Maximum extraction 180m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 1 replaceable acrylic grease filter
• Noise level 59dBA
• 1 x 40W hob lights - for good visibility
• Width 60cm
Colou :
• Stainless steel (E T60004X), Black (E T60004K), White (E T60004W)
Accesso ies:
• Charcoal ilter (E 57)
• Ducting Kit (CDK5 /CDK5 R)
Maximum
extraction
240m3/h
240m /h
3
EFT60003
60cm Stainless steel traditional hood with glass visor
Hood featu es:
• Maximum extraction 240m3/h
• 3 speed fan with slider control - easy to use
• Recirculation or extraction options
• 2 washable aluminium cassette grease filters - easy to clean
• Noise level 64dBA
• 2 x 40W hob lights - for good visibility
• Width 60cm
Colou :
• Stainless steel (E T60003X)
Accesso ies:
• Charcoal ilter (E 57)
• Ducting Kit (CDK5 /CDK5 R)
3 speed fan 3 speed fan
3 speed fan 3 speed fan
