Electrolux Icon E36WC45FSS User manual

Product No. E36WC45FSS
Market North America
Color stainless/glass
Exhaust-CFM 400 CFM
Volts 120
Owner's Guide 5995465548
Installation Instructions 5995465548
Wiring Diagram 8875
PL36WC40.eps 36WC45FSS Parts.eps 8875.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995465894
06/05/04
(EN/SERVICE/KC)
099
RANGE HOOD
Model No.
E36WC45F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995465894 E36WC45FSS
05/06 2
REPLACEMENT PARTS

E36WC45FSS Publication No: 5995465894
# Functional Parts 3 05/06
* Non-Illustrated Parts
REPLACEMENT PARTS
POS. NO PART NO. DESCRIPTION
9 # 5304455733 Filter, grease, aluminum
14 # 5304454900 Capacitor, motor
16 5304454949 Plate, mounting, electric system
19 5304454950 Bracket, transformer, protector
26 5304454951 Lamp, halogen, 20 W, 12 V
37 # 5304455734 Thermostat, Heat Sentry
38 5304454953 Control Box, PC board
39 5304454954 Cover, electrical box
45 5304454955 Housing, blower fan, scroll
48 # 5304454956 Motor, blower
49 # 5304454957 Blower Wheel, fan
53 5304454958 Washer, motor mount, rubber
60 # 5304454959 Power Cord, electric
62 5304454960 Housing, blower assembly
64 5304454970 Panel, filter support
76 # 5304454973 Canopy, hood, glass
86 # 5304454974 Discharge Collar, damper
92 5304454975 Bracket, switch support
110# 5304454976 Gasket, canopy seal
111# 5304454977 Gasket, chimney seal
118 5304455735 Chimney, duct cover, lower flue
119 5304455736 Chimney, duct cover, upper flue
120 5304454981 Bracket, chimney mount, top flue
144 5304454982 Clamp, wiring
145 5304454983 Terminal Box, wiring
146 5304454985 Cover, terminal box
147 5304454986 Clamp, wiring junction
151 5304454987 Wire Stop, terminal box
154 5304454988 Clamp, power cord
165 5304454989 Electrical Box
166# 5304454991 Control Board, printed circuit
208# 5304454992 Transformer
223 5304454993 Push Button, control switch
225# 5304454952 Control, switch board, with trim
230 5304454994 Cover, switch box
234 5304454995 Control Box, switch board
332 5304454996 Cover, blower, duct connector
407 5304454997 Bracket, blower support
472 5304454998 Bracket, canopy
474# 5304454999 Housing, lamp receptacle
477 5304455000 Cover, terminal, transformer
* # 5304455332 Fuse, 5 x 20 mm, 4 Amp, 125 V
* 5304455333 Fuse Holder
* 5304455001 Installation Kit, mtg. hardware

Publication No: 5995465894 E36WC45FSS
05/06 4
WIRING DIAGRAM
