Electrolux EW 1062 W User manual

WASHER-DRYER
INSTRUCTION BOOKLET
EW 1062 W
124 974 460
GB

2
YOUR NEW WASHER-DRYER
This new machine meets all modern needs for
effective treatment of laundry with low water,
energy and detergent consumption.
■The temperature selector dial will allow
you to choose the most suitable temperature
for your laundry.
■The special wool programme with its new
delicate wash system treats your woollen
with extreme gentleness.
■The automatic cooling of the washing
water from 95° to 60°C before draining will
prevent old drain pipes from being deformed.
■The two drying programmes will give your
wash that soft, relaxed feel whatever the
weather.
Hints on how to save energy
By following these hints you will obtain
economical washing without damaging the
environment:
■Whenever possible, wash the maximum load
for the selected programme, without
overloading the drum.
■Use a programme with prewash only for very
soiled laundry.
■Measure out detergent according to the
water hardness, the degree of soiling and the
quantity of laundry being washed.
Environment protection
■Packaging recycling
Materials marked with the symbol are
recyclable. To enable them to be recycled, they
must be placed in the appropriate collection
areas (or containers). Check with your local
authorities.
>PE<= polyethylene
>PS<= polystyrene
>PP<= polypropylene
■Machine scrapping
When the appliance is to be scrapped, cut off
the power supply cable and make the door
closing device inoperative to avoid it becoming
a death trap for a child.
For correct disposal of the machine, contact
your local authority department which provides
for collection of urban solid refuse.
i
The symbols you will see on some paragraphs of this booklet have the following meaning:
Important information concerning the
safety in the use of your machine.
Disregarding this information might
lead to damages.
Information for correct use of your
machine and to obtain the best
performance.
Important information concerning
environment protection.
Our contribution to the protection of the
environment: we use recycled paper.

ENGLISH
3
CONTENTS
Warnings 4
Description of the appliance 5
■Detergent dispenser drawer 5
■Programme card 5
Technical specifications 5
Installation 6
■Transit devices 6
■Positioning 6
■Water inlet 7
■Water drainage 7
■Electrical connection 8
Use 9
■Control panel 9
■Controls 9
■Programme selection 10
■Washing and drying hints 11
Sorting the laundry 11
Temperatures 11
Before loading the laundry 11
Maximum loads 11
Removing stains 11
Detergents and additives 12
Drying 12
■International wash code symbols 13
■Operating sequence 14-15
■Washing and drying programmes 16-17
Maintenance 18
■Bodywork 18
■Detergent dispenser drawer 18
■Drain filter 18
■Water inlet filter 19
■Emergency emptying out 19
■Frost precautions 19
Something not working? 20-21

4
WARNINGS
General warnings
■When unpacking the appliance, check that it
is not damaged. If in doubt, do not use it and
contact the Service Centre.
■This appliance is designed to be used by
adults. Children must not be allowed to touch
the controls or play with the product.
■During high temperature washing and drying
cycles the glass door becomes very hot. Do
not touch it.
■Pets sometimes climb into washing
machines. Check the drum before each use.
Installation
■All internal packing must be removed before
using the appliance. Serious damage may be
caused to the machine or adjacent furniture if
the protective transit devices are not removed
or are not completely removed. Refer to the
relevant paragraph in the instruction book.
■Any electrical work required to install this
appliance must be carried out by a qualified
electrician.
■Any plumbing work required to install this
appliance must be carried out by a qualified
plumber.
■After having installed the machine, check that
it is not standing on its electrical supply cable.
■If the appliance is placed on a carpeted floor,
ensure that air can circulate freely between
the adjustable feet and the floor.
Use
■This appliance is designed for domestic use.
It must not be used for purposes other than
those for which it was designed.
■Only wash and dry fabrics which are
designed to be machine washed and dried.
Follow the instructions on each garment
label.
■If you use a liquid detergent with a dispenser
which has to be placed directly in the drum,
remember to remove this dispenser before
drying.
■Do not overload the appliance. Follow the
instructions in the instruction book.
■Make sure that all pockets are empty. Objects
such as coins, safety pins, pins and screws
can cause extensive damage.
■Do not machine wash garments saturated
with petroleum, methylated spirits,
trichlorethylene, etc. If such fluids have been
used to remove stains prior to washing, wait
until they have completely evaporated from
the fabric before placing garments in the
appliance.
■Place small items such as socks, belts, etc. in
a cloth bag or pillowcase to prevent them
getting trapped between the drum and the
tub.
■Use only the recommended quantities of fabric
softener. An excessive amount could damage
the laundry.
■Leave the porthole door slightly ajar when the
appliance is not in use. This preserves the
door seal and prevents the formation of
musty smells.
■Always check that water has emptied out
before opening the door. If not, drain the
water following the instructions in the
instruction book.
■Always unplug the appliance and shut the
water tap after use.
Service/repair
■In the event of a fault, do not attempt to repair
the appliance yourself. Repairs carried out by
inexperienced persons may cause damage.
■If repairs are needed, contact an authorised
service centre and ask for genuine spare
parts.
It is important that this instruction book be kept with the appliance for future reference. If you sell or
give the appliance away, make sure that the book is passed to the new owners so that they can
familiarise themselves with its operation and relevant warnings.
The following warnings are provided in the interests of overall safety. You must read them carefully
before installing or using the appliance.

DIMENSIONS Height 85 cm
Width 60 cm
Depth 60 cm
WASHING DRYING
MAXIMUM LOAD Cotton 5.0 kg 2.50kg
Synthetics 2.0 kg 1.50kg
Delicates 2.0 kg -
Woollens 1.0 kg -
SPIN SPEED 1000 rpm max.
POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz
TOTAL POWER ABSORBED 2200 W
MINIMUM FUSE PROTECTION 10 A
WATER PRESSURE Minimum 5 N/cm2
Maximum 80 N/cm2
This appliance complies with the following EEC Directives:
73/23/EEC of 19/02/73 relating to low voltage
89/336/EEC of 03/05/89 relating to electromagnetic compatibility
ENGLISH
5
DESCRIPTION OF THE APPLIANCE
01 Detergent dispenser drawer
02 Programme card
03 Drying pilot light
04 Drying time selector dial
05 Option buttons
06 On/Off button
07 Operating pilot light
08 Temperature selector dial
09 Programme selector dial
10 Door handle
11 Filter
12 Adjustable feet
Detergent dispenser drawer
Prewash
Main wash
Fabric softener
Programme card
A programme card in symbols is in the interior
part of the detergent dispenser drawer.
TECHNICAL SPECIFICATIONS
C0012
12
2
9
8
5
3
1
4
11
Programmes
67
10

6
INSTALLATION
Unpacking
You are advised to keep all transit devices so that
they can be refitted if the machine ever has to be
transported again.
1. Using a spanner, unscrew and remove the rear
right-hand bolt and lay the machine on its
back, taking care not to squash the hoses.
This can be avoided by placing one of the
corner packing pieces between the machine
and the floor.
2. Remove the polystyrene block from the bottom
of the machine and release the two plastic
bags by removing the adhesive strip.
3. Carefully remove the right-hand bag (1) then
the left-hand bag (2) by pulling them towards
the centre of the machine.
4. Set the machine upright and remove the two
remaining bolts from the back.
5. Pull out the three plastic spacers from the
holes into which the bolts were fitted.
6. Plug the open holes with the plugs which you
will find in the plastic bag containing the
instruction booklet.
Positioning
Install the machine on a flat hard floor.
Make sure that air circulation around the machine
is not impeded by carpets, rugs etc. Check that
the machine does not touch the wall or other
kitchen units.
Carefully level by screwing the adjustable feet in
or out. Never place cardboard, wood or similar
materials under the machine to compensate for
any unevenness in the floor.
All transit bolts and packing must be
removed before using the appliance.
P0255
P0234 P0233
21
P0256
P0020
P1051

ENGLISH
7
Water inlet
Connect the water inlet hose to a tap with a 3/4"
thread after having inserted the small filter “A”
supplied with the machine.
The other end of the inlet hose which connects to
the machine can be turned in any direction.
Simply loosen the fitting, rotate the hose and
retighten the fitting, making sure there are no
water leaks.
The inlet hose must not be lengthened. If it is too
short and you do not wish to move the tap, you
will have to purchase a new, longer hose
specially designed for this type of use.
Water drainage
The end of the drain hose can be positioned in
three ways:
Hooked over the edge of a sink using the
plastic hose guide supplied with the machine.
In this case, make sure the end cannot come
unhooked when the machine is emptying.
This could be done by tying it to the tap with a
piece of string or attaching it to the wall.
In a sink drain pipe branch. This branch must
be above the trap so that the bend is at least
60 cm above the ground.
Directly into a drain pipe at a height of not less
than 60 cm and not more than 90 cm.
The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain
pipe must be larger than the outside diameter of
the drain hose.
The drain hose must not be kinked. Run it along
the floor; only the part near the drainage point
must be raised.
A
P0003
P0022
P0023
P0021

8
Electrical connection
This machine is designed to operate on a
220-230 V, single-phase, 50 Hz supply.
Check that your domestic electrical installation
can take the maximum load required (2.2 kW),
also taking into account any other appliances in
use.
WARNING: THIS APPLIANCE MUST BE
EARTHED.
The manufacturer declines any liability
should this safety measure not be
observed.
The appliance is supplied with a 13amp plug
fitted.
In the event of having to change the fuse in the
plug supplied, a 13amp ASTA approved
(BS1363A) fuse must be used.
Should the plug need to be replaced for any
reason, proceed as described below.
The wires in the mains lead are coloured in
accordance with the following code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
The wire coloured green and yellow must be
connected to the terminal marked with the letter
«E» or by the earth symbol or coloured
green and yellow.
The wire coloured blue must be connected to
the terminal «N» or coloured black.
The wire coloured brown must be connected to
the terminal marked «L» or coloured red.
Upon completion there must be no cut, or stray
strands of wire present and the cord clamp must
be secure over the outer sheath.
WARNING:
A cut off plug inserted into a 13 amp
socket is a serious safety (shock)
hazard.
Ensure that the cut off plug is disposed
of safely.
GREEN & YELLOW
BROWN
CORD CLAMP
BLUE
13A
P1041
E
NL

ENGLISH
9
USE
Control panel
1 Detergent dispenser drawer
2 Drying pilot light
It illuminates when drying starts.
3 Drying time selector dial
Graduated up to 120 minutes for cotton and
synthetics, allows drying time to be selected
according to the type and amount of laundry and
the required degree of dryness:
- blue sector for cotton
- orange sector for synthetics
Turn the dial clockwise only.
Cooling phase
To allow the laundry to cool down, a cooling
phase starts automatically 10 minutes before the
end of drying and this phase must in no
circumstances be reduced or interrupted.
4 Extra rinse button
By depressing this button on programmes A-B-C
and D the machine will perform rinses with more
water.
To be used in areas where the water is very soft
or for people who are allergic to detergents.
5 Anti-crease button
By depressing this button the water of the last
rinse is not emptied out to avoid any creasing in
the laundry. To empty out water and spin the
laundry, release the button .
To drain water without spinning, select
programme Q.
This button is not compatible with the
NON-STOP-programme washing+drying for
cotton and synthetics.
6 On/Off button
Press this button to start the machine, press it
again to interrupt or change a programme or
switch off the power supply to the machine.
7 Operating pilot light
This light is on whilst the machine is operating
and goes out when the ON/OFF button is
pressed again.
8 Temperature selector dial
Turn this dial clockwise or anti-clockwise to select
the required temperature.
Position means that the machine will wash
with cold water.
9 Programme selector dial
To select the required programme, turn this dial
clockwise until the programme letter is exactly
opposite the pointer.
12345678 9

10
Programme selection
■Washing only
Load size:
– cotton, linen max 5 kg
– synthetics, delicate fabrics 2 kg
– woollens 1 kg
– Place the detergent and additive in the
dispenser drawer.
– Select the temperature and the wash
programme.
– Press button and/or if desired.
– Press the ON/OFF button .
■Drying only
Load size:
– cotton, linen max 2.5 kg
– synthetics 1.5 kg
– Select the drying time.
– Select the drying programme Gor K.
– Press the ON/OFF button .
■Automatic washing and drying
(NON-STOP programme)
Automatic washing and drying is only
possible with linen, cotton and synthetics
programmes.
The maximum load size is 2.5 kg for cotton
and 1.5 kg for synthetics.
Do not exceed these quantities.
– Select the temperature and the wash
programme.
– Select the drying time.
– Press button if desired (only for cotton).
– Press the ON/OFF button .
The laundry will be washed and dried without
any further action by you.

ENGLISH
11
Washing and drying hints
Sorting the laundry
Follow the wash code symbols on each garment
label and the manufacturer’s washing instructions.
Sort the laundry as follows:
whites, coloureds, synthetics, delicates, woollens.
Temperatures
95° for normally soiled white cottons
and linen (e.g. tea cloths, towels,
tablecloths, sheets...)
60°for normally soiled, colour fast
garments (e.g. shirts, night dresses,
pyjamas....) in linen, cotton or
synthetic fibres and for lightly soiled
white cotton (e.g. underwear).
(cold)
30°-40° for delicate items (e.g. net curtains),
mixed laundry including synthetic
fibres and woollens bearing the
label «pure new wool, machine
washable, non-shrink».
Before loading the laundry
Never wash whites and coloureds together.
Whites may lose their “whiteness” in the wash.
New coloured items may run in the first wash;
they should therefore be washed separately the
first time.
Make sure that no metal objects are left in
the laundry (e.g. hair clips, safety pins, pins).
Button up pillowcases, close zip fasteners,
hooks and poppers. Tie any belts or long tapes.
Remove persistent stains before washing. Rub
particularly soiled areas with a special detergent
or detergent paste.
Treat curtains with special care. Remove hooks
or tie them up in a bag or net.
Maximum loads
Recommended loads are indicated in the
programme charts.
General rules:
Cotton, linen: drum full but not too tightly
packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no more
than one third full.
Washing a maximum load makes the most
efficient use of water and energy.
For heavily soiled laundry, reduce the load size.
Laundry weights
The following weights are indicative:
bathrobe 1200 g
napkin 100 g
quilt cover 700 g
sheet 500 g
pillow case 200 g
tablecloth 250 g
towelling towel 200 g
tea cloth 100 g
night dress 200 g
ladies’ briefs 100 g
man’s work shirt 600 g
man’s shirt 200 g
man’s pyjamas 500 g
blouse 100 g
men’s underpants 100 g
Removing stains
Stubborn stains may not be removed by just
water and detergent. It is therefore advisable to
treat them prior to washing.
Blood: treat fresh stains with cold water. For
dried stains, soak overnight in water with a
special detergent then rub in the soap and
water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and dab
the stain; treat several times.
Dried grease stains: moisten with turpentine,
lay the garment on a soft surface and dab the
stain with the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust
removing product used cold. Be careful with rust
stains which are not recent since the cellulose
structure will already have been damaged and
the fabric tends to hole.
Mould stains: treat with bleach, rinse well
(whites and fast coloureds only).
Grass: soap lightly and treat with bleach (whites
and fast coloureds only).
Ball point pen and glue: moisten with acetone
(*), lay the garment on a soft cloth and dab the
stain.
Lipstick: moisten with acetone as above, then
treat stains with methylated spirits. Remove any
residual marks from white fabrics with bleach.
i

12
Red wine: soak in water and detergent, rinse
and treat with acetic or citric acid, then rinse.
Treat any residual marks with bleach.
Ink: depending on the type of ink, moisten the
fabric first with acetone (*), then with acetic acid;
treat any residual marks on white fabrics with
bleach and then rinse thoroughly.
Tar stains: first treat with stain remover,
methylated spirits or benzine, then rub with
detergent paste.
(*) do not use acetone on artificial silk
Detergents and additives
Good washing results also depend on the
choice of detergent and use of the correct
quantities to avoid waste and protect the
environment. Although biodegradable,
detergents contain substances which, in large
quantities, can upset the delicate balance of
nature.
The choice of detergent will depend on the type
of fabric (delicates, woollens, cottons, etc.), the
colour, washing temperature and degree of
soiling.
All commonly available washing machine
detergents may be used in this appliance:
– powder detergents for all types of fabric,
– powder detergents for delicate fabrics (60°C
max) and woollens,
– liquid detergents, preferably for low
temperature wash programmes (60°C max)
for all types of fabric, or special for woollens
only.
The detergent and any additives must be placed
in the appropriate compartments of the
dispenser drawer before starting the wash
programme.
If using concentrated powder or liquid
detergents, a programme without prewash must
be selected.
The washing machine incorporates a
recirculation system which allows an optimal use
of the concentrated detergent.
Pour liquid detergent into the dispenser drawer
compartment marked just before starting
the programme.
Any fabric softener or starching additives must
be poured into the compartment marked
before starting the wash programme.
Follow the product manufacturer’s
recommendations on quantities to use and do
not exceed the «MAX» mark in the detergent
dispenser drawer.
Quantity of detergent to be used
The type and quantity of detergent will depend
on the type of fabric, load size, degree of soiling
and hardness of the water used.
Water hardness is classified in so-called
“degrees” of hardness. Information on hardness
of the water in your area can be obtained from
the relevant water supply company, or from your
local authority.
Follow the product manufacturers’ instructions
on quantities to use.
Use less detergent if:
– you are washing a small load
– the laundry is lightly soiled
– large amounts of foam form during washing.
Drying
■All laundry to be dried must be thoroughly
spun. The higher the spin speed, the lower
the power consumption and the shorter the
drying time.
■Scrupulously follow the instructions on each
garment label, making sure that it is suitable
for tumble-drying.
■Do not tumble dry the following:
– wool, silk, synthetic curtains;
– articles with a plasticised finish, nylon
tights or stockings, sleeping bags, quilts,
articles made of foam rubber or containing
materials similar to foam rubber, fabrics
with metal inserts;
– fabrics which tend to fray.
Important: during the drying cycle, the water
tap must be left open and the drain hose must
be correctly positioned.
0,0-15
16-25
26-37
more than 37
Level
1
2
3
4
soft
medium
hard
very hard
00-07
08-14
15-21
more than 21
Characteristic Degrees
German
°dH French °T.H.
Degrees of water hardness

ENGLISH
13
International wash code symbols
These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.
i
Energetic wash
Delicate wash
Max. wash
temperature
95°C
Max. wash
temperature
60°C
Max. wash
temperature
40°C
Max. wash
temperature
30°C Hand wash Do not
wash
at all
Bleaching Bleach in cold water Do not bleach
Ironing Hot iron
max 200°C Warm iron max 150°C Lukewarm iron max 110°C Do not iron
Dry cleaning Dry cleaning
in all solvents Dry cleaning in perchlorethylene,
petrol, pure alcohol,
R 111 & R 113
Dry cleaning
in petrol,
pure alcohol
and R 113
Do not
dry clean
Drying Flat On the line On clothes
hanger Tumble dry
high
temperature
low
temperature
Do not
tumble dry
APF
95
60
60
40
40 40
30
30

14
Operating sequence
Automatic washing and drying
(non-stop programme)
This option is only possible for cottons and
synthetics.
Maximum load:
– cotton, linen 2.5 kg
– synthetics 1.5 kg
Before washing your first load of laundry, we
recommend that you run a cotton cycle at 60°C,
with the machine empty, in order to remove any
manufacturing residue from the drum and tub.
Pour half a measure of detergent into the main
wash compartment and start up the machine.
1.Place the laundry in the drum
Open the door.
Place the laundry in the drum, one item at a
time, shaking them out as much as possible.
Close the door.
2.Measure out the detergent
Pull out the dispenser drawer until it stops.
Measure out the amount of detergent
recommended by the manufacturer in a
graduated cup and pour it into the main wash
compartment .
If you wish to carry out the prewash, pour
detergent into the appropriate compartment
marked .
3.Measure out the additive
If required, pour fabric softener into the
compartment marked without exceeding
the «MAX» mark.
4.Select the desired option
Depress button if you have to wash & dry
cotton items and you wish to rinse the laundry
with more water.
5.Select the temperature
Turn the dial to the required temperature setting.
i
P0876
P0877
P0004
95°
P0880S

ENGLISH
15
6.Select the drying time
Turn the selector dial clockwise to the required
time setting (blue or orange sector).
7.Select the programme and start
the machine
Turn the programme selector dial clockwise to
the required programme and press the On/Off
button: the operating pilot light comes on and
the machine starts to operate.
8.At the end of the programme
The machine stops automatically.
Wait one or two minutes before opening the
door to give the electric locking mechanism time
to release it.
Depress the On/Off button again to switch the
machine off. The operating pilot light goes out.
Remove the laundry.
Turn the drum by hand to make sure it is
completely empty, so as to avoid any forgotten
items being damaged in a subsequent wash
(e.g. shrinking) or their colour running into a
load of whites.
Release the button which has been pressed.
Turn the water tap off and unplug the machine.
Leave the door ajar to air the machine.
M0041
60
90
120
P0917
B
P0080

16
Energetic programmes for cotton and linen
Maximum load: washing 5 kg
washing+drying 2.5 kg
Washing
Progr.
A
Temp. Type of laundry Cycle description Possible
option
60°-95°
Whites with prewash
heavy soiled
Prewash at 40°C
Wash at 60°-95°C
3 rinses
Long spin
B
60°-95°
30°-60°
Whites without prewash
normally soiled Wash at 60°-95°C
3 rinses
Long spin
CWhites and coloureds
lightly soiled Wash at 30°-60°C
3 rinses
Long spin
DRinses 3 rinses with additive
Long spin
The temperatures indicated are the optimum temperatures for each programme and depend on the
type of laundry and degree of soiling.
Drying: maximum load 2.5 kg
Drying time selector 0-120 min, blue sector.
TimeProgramme Type of laundry Degree of drying Quantity
80-90
50-60
GCotton and linen spun
at 1000 rpm
Store dry 2.5 kg
1.5 kg
50-60
30-40
Iron dry 2.5 kg
1.5 kg
A
40°-60°
Coloureds with prewash Prewash at 40°C
Wash at 40°-60°C
3 rinses
Long spin
B
40°-60°
Coloureds without
prewash Wash at 40°-60°C
3 rinses
Long spin
FSpin Drain and long spin

ENGLISH
17
Progr. Temp. Type of laundry Cycle description Possible
option
J
40°-60°
40°-60°
Synthetics without prewash
normally soiled Wash at 40°-60°C
3 rinses
Short spin
L
30°-40°
Woollens Wash at 30°-40°C
3 rinses
Short spin
M
30°-40°
Delicate fabrics,
silk Wash at 30°-40°C
3 rinses
Short spin
HSynthetics with prewash
heavy soiled
Prewash at 40°C
Wash at 40°-60°C
3 rinses
Short spin
PShort spin Drain and short spin
NRinses 3 rinses with additive
Short spin
QDrain Empty out water
TimeProgramme Type of laundry Degree of drying Quantity
70-80
50-60
KSynthetics,
spun at 900 rpm
Store dry 1.5 kg
1.0 kg
60-70
40-50
Iron dry 1.5 kg
1.0 kg
Gentle programmes for synthetics, mixed fibres, delicates and
woollens
Maximum load: washing 2 kg (woollens 1 kg)
washing+drying (synthetics) 1.5 kg
Washing
The temperatures indicated are the optimum temperatures for each programme and depend on the
type of laundry and degree of soiling.
Drying: maximum load 1.5 kg
Drying time selector 0-120 min, orange sector.

18
1.Bodywork
Clean the outside of the machine with warm
water and a neutral, non-abrasive household
detergent. Rinse with clean water and dry with a
soft cloth.
Important: do not use methylated spirits,
solvents or similar products to clean the
bodywork.
2.Detergent dispenser drawer
After a while, detergents and fabric softeners
leave deposits in the drawer.
Clean the drawer from time to time by rinsing it
under a running tap. To remove the drawer from
the machine, press the button in the rear left-
hand corner.
To facilitate cleaning, the top part of the additive
compartments can be removed.
Detergent can also accumulate inside the
drawer recess: clean it with an old toothbrush.
Refit the drawer after cleaning.
3.Drain filter
The drain filter collects threads and small
objects inadvertently left in the laundry. Check
regularly that the filter is clean.
Open the filter door.
Place a container under the filter and unscrew it.
Pull out the filter.
Clean the filter under a running tap, then refit it,
screwing it fully in.
MAINTENANCE
P0879
P0038
P0878
P0861 P0860
P0859 P0040

ENGLISH
19
4.Water inlet filter
If you notice that the machine is taking longer to
fill, check that the filter in the water inlet hose is
not blocked.
Turn off the water tap.
Unscrew the hose from the tap and remove the
filter.
Clean it with a stiff brush.
Refit the filter and screw the hose back onto the
tap.
5.Emergency emptying out
If the water is not discharged (outlet pump is
blocked, filter or outlet hose are clogged),
proceed as follows to empty out the machine:
■pull out the plug from the power socket;
■close the water tap;
■if necessary, wait until the water has cooled
down;
■place a bowl on the floor;
■put the outlet hose end into the bowl and let
the water come out.
Should it not be possible to have access to the
outlet hose because, for example, the appliance
is built in the kitchen furniture, slightly loosen the
outlet filter after placing a bowl on the floor, to let
the water come out slowly.
At the end screw the filter again.
6.Frost precautions
If the machine is installed in a place where the
temperature could drop below 0°C, proceed as
follows:
■Close the water tap and unscrew the water
inlet hose from the tap.
■Place the end of the outlet hose and that of
the inlet hose in a bowl placed on the floor.
■Select programme Qand run it until the
machine stops.
■Remove the plug from the socket.
■Screw the water inlet hose back on and put
the outlet hose back in its place.
By doing this, any water remaining in the
machine is removed, avoiding the formation of
ice and, consequently, breakage of the affected
parts.
When you use the machine again, make sure
that the ambient temperature is above 0°C.
P0041

20
SOMETHING NOT WORKING?
Problems which you can resolve yourself
Problem Possible cause
■The machine does not start up: ■Check that the door is firmly closed.
■Check that the machine is plugged in and
that there is power at the socket.
■Check that the main fuse or the fuse in the
plug has not blown.
■Check that the programme selector dial is
positioned correctly and the ON/OFF button
depressed.
■The machine does not fill: ■Check that the water tap is open.
■Check that water is coming out of the tap.
■Check that the inlet hose is not squashed or
kinked.
■Check that the filter in the inlet hose is not
blocked.
■Check that the door is closed.
■The machine fills then empties
immediately: ■The end of the drain hose is too low. Refer to
relevant paragraph in “water drainage”
section.
■The machine does not empty
and/or does not spin:
■There is water on the floor: ■Too much detergent or unsuitable detergent
(creates too much foam) has been used.
■Check whether there are any leaks from one
of the inlet hose fittings. It is not always easy
to see this as the water runs down the hose;
check to see if it is damp.
■Check that the drain hose is not damaged.
■The machine vibrates or is noisy: ■Check that all the transit bolts and packing
have been removed.
■Check that the machine is not resting against
anything.
■Check that the support feet are resting firmly
on the ground and that the lock nuts are
securely tightened.
■Check that the laundry is evenly distributed in
the drum.
■Maybe there is very little laundry in the drum.
■Check that the drain hose is not squashed or
kinked.
■A programme with the option has been
selected.
■Check that the laundry is evenly distributed in
the drum.
