Electrolux EW 1250 WI User manual

LAVADORA-SECADORA
WASHER-DRYER
MANUAL DE USO
INSTRUCTION BOOKLET
EW 1250 WI
124 972 040
GB
E

ENGLISH
27
Dear customer,
Please read these operating instructions carefully
and pay particular attention to the safety notes
indicated in the first pages. We recommend that you
keep this instruction booklet for future reference and
pass it on to any future owners.
Transport damages
When unpacking the appliance, check that it is not
damaged. If in doubt, do not use it and contact the
Service Centre.
The symbols you will see on some paragraphs of this booklet have the following meaning:
The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly
important for your safety or correct functioning of the appliance.
The information marked with this symbol provides additional instructions and practical tips on the use of
the appliance.
Tips and information about economical and ecological use of the machine are marked with this symbol.
Our contribution to the protection of the
environment: we use recycled paper.

28
Maintenance 47
Bodywork 47
Detergent dispenser drawer 47
Drain filter 47
Water inlet filter 47
Emergency emptying out 48
Frost precautions 48
Something not working? 49-50
Warnings 29-30
Disposal 30
Tips for environmental protection 30
Technical specifications 31
Installation 32
Unpacking 32
Positioning 32
Water inlet 33
Water drainage 33
Electrical connection 33
Building-in 34-35
Your new washer-dryer 36
Description of the appliance 36
Detergent dispenser drawer 36
Use 37
Control panel 37
Controls 37
Washing hints 37
Sorting the laundry 38
Temperatures 38
Before loading the laundry 38
Maximum loads 38
Laundry weights 38
Removing stains 38
Detergents and additives 39
Drying hints 40
Load 40
Garments not suitable for drying 40
Drying symbols on garment labels 40
Duration of the drying cycle 40
Modification of the drying time 40
Fibre residue 40
Additional drying 40
International wash code symbols 41
Operating sequence 42-43
Washing programmes 44-45
Drying times 46
Contents

ENGLISH
29
Installation
• All internal packing must be removed before using
the appliance. Serious damage may be caused to
the machine or adjacent furniture if the protective
transit devices are not removed or are not
completely removed. Refer to the relevant
paragraph in the instruction book.
• Any electrical work required to install this appliance
must be carried out by a qualified electrician.
• Any plumbing work required to install this
appliance must be carried out by a qualified
plumber.
• After having installed the machine, check that it is
not standing on its electrical supply cable.
• If the appliance is placed on a carpeted floor,
ensure that air can circulate freely between the feet
and the floor.
Use
• This appliance is designed for domestic use. It
must not be used for purposes other than those for
which it was designed.
• Only wash and dry fabrics which are designed to
be machine washed and dried. Follow the
instructions on each garment label.
• Do not overload the appliance. Follow the
instructions in the instruction book.
• Make sure that all pockets are empty. Objects such
as coins, safety pins, pins and screws can cause
extensive damage.
• Do not machine wash garments saturated with
petroleum, methylated spirits, trichlorethylene, etc.
If such fluids have been used to remove stains
prior to washing, wait until they have completely
evaporated from the fabric before placing garments
in the appliance.
• Place small items such as socks, belts, etc. in a
cloth bag or pillowcase to prevent them getting
trapped between the drum and the tub.
• If you use a liquid detergent with a dispenser which
has to be placed directly in the drum, remember to
remove this dispenser before drying.
• Use only the recommended quantities of fabric
softener. An excessive amount could damage the
laundry.
Warnings
• Leave the porthole door slightly ajar when the
appliance is not in use. This preserves the door
seal and prevents the formation of musty smells.
• Always check that water has emptied out before
opening the door. If not, drain the water following
the instructions in the instruction book.
• Always unplug the appliance and shut the water
tap after use.
General safety
• Repairs to the machine must be carried out only by
qualified personnel. Repairs carried out by
inexperienced persons could cause serious
danger. Contact your local Service Centre.
• Never pull the power supply cable to remove the
plug from the socket; always take hold of the plug
itself.
• During high temperature wash programmes and
during the drying cycle the door glass may get hot.
Do not touch it!
The following warnings are provided in the interests of overall safety. You must read them carefully before
installing or using the appliance.

30
Disposal
Tips for environmental protection
Packaging materials
The materials marked with the symbol are
recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of
them properly in appropriate collection containers.
Machine
Use authorised disposal sites for your old appliance.
Help to keep your country tidy!
To save water, energy and to help protect the
environment, we recommend that you follow these
tips:
• Normally soiled laundry may be washed without
prewashing in order to save detergent, water and
time (the environment is protected too!).
• The machine works more economically if it is fully
loaded (for both washing and drying cycles).
• The machine will consume less energy if the
laundry is adequately spun before being dried.
• With adequate pre-treatment, stains and limited
soiling can be removed; the laundry can then be
washed at a lower temperature.
• Measure out detergent according to the water
hardness, the degree of soiling and the quantity of
laundry being washed.
Child safety
• Children are often not aware of how dangerous
electrical appliances can be. When the machine is
working, children should be carefully supervised
and not be allowed to play with the appliance.
• The packaging components (e.g. plastic film,
polystyrene) can be dangerous to children - danger
of suffocation! Keep them out of children’s reach.
• Keep all detergents in a safe place out of children’s
reach.
• Make sure that children or pets do not climb into
the drum.
• When the appliance is to be scrapped, cut off the
electrical supply cable and destroy the plug with
the remaining cable. Disable the door catch in
order to prevent children from becoming trapped
inside while playing.

ENGLISH
31
DIMENSIONS Height 82 cm
Width 60 cm
Depth 54 cm
WASHING DRYING
MAXIMUM LOAD Cotton 4.5 kg 2.25 kg
Synthetics 2 kg 1.5 kg
Delicates 2 kg -
Woollens 1 kg -
SPIN SPEED 1200 rpm max.
POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz
TOTAL POWER ABSORBED 2200 W
MINIMUM FUSE PROTECTION 10 A
WATER PRESSURE Minimum 5 N/cm2
Maximum 80 N/cm2
This appliance complies with the following EEC Directives:
73/23/EEC of 19/02/73 relating to low voltage
89/336/EEC of 03/05/89 relating to electromagnetic compatibility.
Technical specifications

32
Unpacking
All transit bolts and packing must be removed
before using the appliance.
You are advised to keep all transit devices so that
they can be refitted if the machine ever has to be
transported again.
1. Using a spanner, unscrew and remove the rear
right-hand bolt and lay the machine on its back,
taking care not to squash the hoses. This can be
avoided by placing one of the corner packing
pieces between the machine and the floor.
2. Remove the polystyrene base and take off the
bottom panel by unscrewing the central screw.
3. Carefully remove the right-hand bag.
4. Carefully slide out the other bags.
5. Re-fit the bottom panel using the 4 screws
supplied with the door hinges (in the plastic bag)
and the previously removed screw.
P0453
P0016
P0015
P0457
P0255
6. Set the machine upright and remove the two
remaining bolts from the back.
7. Pull out the three plastic spacers from the holes
into which the bolts were fitted.
8. Plug the open holes with the plugs which you will
find in the plastic envelope containing the
instruction booklet.
Positioning
Install the machine on a flat hard floor.
Make sure that air circulation around the machine is
not impeded by carpets, rugs etc. Check that the
machine does not touch the wall or other kitchen
units.
Carefully level by screwing the adjustable feet in or
out. Never place cardboard, wood or similar
materials under the machine to compensate for any
unevenness in the floor.
P1051
P0020
P0256
Installation

ENGLISH
33
Water inlet
Connect the water inlet hose to a tap with a 3/4"
thread after having inserted the small filter “A”
supplied with the machine.
The other end of the inlet hose which connects to the
machine can be turned in any direction. Simply
loosen the fitting, rotate the hose and retighten the
fitting, making sure there are no water leaks.
The inlet hose must not be lengthened. If it is too
short and you do not wish to move the tap, you will
have to purchase a new, longer hose specially
designed for this type of use.
Water drainage
The end of the drain hose can be positioned in three
ways:
Hooked over the edge of a sink using the plastic
hose guide supplied with the machine. In this
case, make sure the end cannot come unhooked
when the machine is emptying.
This could be done by tying it to the tap with a piece
of string or attaching it to the wall.
In a sink drain pipe branch. This branch must be
above the trap so that the bend is at least 60 cm
above the ground.
Directly into a drain pipe at a height of not less
than 60 cm and not more than 90 cm.
The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain pipe
must be larger than the outside diameter of the drain
hose.
P0022
P0021
A
P0003
The drain hose must not be kinked. Run it along the
floor; only the part near the drainage point must be
raised.
Electrical connection
This machine is designed to operate on a 220-230 V,
single-phase, 50 Hz supply.
Check that your domestic electrical installation can
take the maximum load required (2.2 kW), also
taking into account any other appliances in use.
Connect the machine to an earthed socket.
The manufacturer declines any responsibility
for damage or injury through failure to comply
with the above safety precaution.
Should the appliance power supply cable
need to be replaced, this should be carried
out by our Service Centre.
P0023

Building-in
This appliance has been designed to be built into the
kitchen furniture.
The recess should have the dimensions shown in
picture A.
Preparation and assembly of the door
The machine is originally pre-arranged for the
assembly of a door opening from right to left.
In this case it is sufficient to screw in the hinges (1)
and the counter-magnet (6) provided with the
appliance, at the right level (Fig. B).
a) Door
The dimensions of the door should be:
- width 595-598 mm
- thickness 16-22 mm
The height (C-Fig. C) depends on the height of
the adjacent furniture's base.
4
12
3
6
1
2
3
P0982
7
8B
5
P0965
820 min
600 min.
600
596
416 176,5 818
541
195
490
160
120
90
8
515
165
A
b) Hinges
To mount the hinges it is necessary to drill two holes
(dia. 35 mm, depth 14 mm) on the inner side of the
door. The distance between the holes must be
416 mm.
The distance (B) from upper edge of the door to the
centre of the hole depends on the adjacent
furniture's dimensions.
The required dimensions are given in the picture C.
The hinges will be fixed to the door by means of
screws for wood (2-Fig. B).
c) Mounting the door
Fix the hinges to the machine by means of the M5x8
screws (3-Fig. B). The hinges can be adjusted to
compensate for possible uneven thickness of the
door.
To align the door perfectly it is necessary to loosen
the screw (3-Fig. B), adjust the door and tighten the
screw again.
Ø 35 mm - Depth 14 mm
16-22
B
C
22+1,5
595-598
416
P0026 C
34

ENGLISH
d) Counter-magnet (6)
The appliance is pre-arranged for a magnetic closure
of the door. To enable a correct operation of this
device, it is necessary to screw the counter-magnet
(6) (steel disk + rubber ring) into the inner side of the
door.
Its position must correspond to the magnet (4) on the
appliance (see picture D).
If the door has to be opened from left to right, invert
the position of the plates (7), the magnet (4) and the
rubber cap (5) (Fig. B and E). Mount the
countermagnet (6) and the hinges (1) as previously
described.
Important: the plastic screw (8) should never be
loosened (Fig. B and E).
When the appliance is installed the power supply
cable must be easily accessible.
46
51
2
3
7
8
E
P0983
P0984
6
4
8D
35

36
This new washing machine, which is fitted with the Direct Spray system, patented Electrolux, meets all modern
needs for effective treatment of laundry with low water, energy and detergent consumption.
Further savings are achieved by washing small loads of laundry, since water and electricity consumption is
proportional to the quantity and type of laundry being washed.
•The temperature selector dial will allow you to choose the most suitable temperature for your laundry.
•The special wool programme with its new delicate wash system treats your woollen with extreme
gentleness.
• The automatic cooling of the washing water from 90° to 60°C before draining will prevent old drain pipes
from being deformed.
•The two drying programmes will give your wash that soft, relaxed feel whatever the weather.
•The balance control device ensures the machine is stable during the spin.
1 Detergent dispenser drawer
2 Programme chart
3 Control panel
4 Door handle
5 Drain filter
6 Adjustable feet
Detergent dispenser drawer
Prewash
Main wash
Fabric softener, starch
Bleaching agent
Your new washer-dryer
Description of the appliance
1
4
5
6
2
3
P0238
Cl

ENGLISH
37
Use
1 Programme chart
It will help you to choose the most suitable washing
and drying programme.
2 Drying pilot light
It illuminates when drying starts.
3 Drying time selector dial
Graduated up to 120 minutes for cotton and
synthetics, allows drying time to be selected
according to the type and amount of laundry and the
required degree of dryness:
-blue sector for cotton
-yellow sector for synthetics
Turn the dial clockwise only.
Cooling phase
To allow the laundry to cool down, a cooling phase
starts automatically 10 minutes before the end of
drying and this phase must in no circumstances be
reduced or interrupted.
4 Spin speed reduction button
By depressing this button the spin speed is reduced
as follows:
- from 1200 to 650 rpm on programmes for cotton
and linen,
- from 900 to 650 rpm on programme “P” for
synthetics and delicates,
- from 1000 to 650 rpm on programme “P” for wool.
This button should not be used when performing the
automatic washing & drying in order to avoid lengthy
driying times.
5 Quick wash button
By pressing this button on programmes for cotton
and synthetics the washing time is reduced by
approx. 35 minutes. To be used for lightly soiled
laundry.
6 On/Off button
Press this button to start the machine, press again to
interrupt a programme or switch off the power supply
to the machine.
7 Operating pilot light
This light is on whilst the machine is operating and
goes out when the ON/OFF button is pressed again.
8 Temperature selector dial
Depress the dial to pop it out and then turn it
clockwise or anti-clockwise to select the required
temperature.
Position means that the machine will wash with
cold water.
9 Programme selector dial
To select the required programme, turn this dial
clockwise until the programme letter is exactly
opposite the pointer.
Depress the dial to pop it out before turning it.
123 45 67 8 9
Control panel

38
Washing hints
Sorting the laundry
Follow the wash code symbols on each garment
label and the manufacturer’s washing instructions.
Sort the laundry as follows:
whites, coloureds, synthetics, delicates, woollens.
Temperatures
90° for normally soiled white cottons and linen
(e.g. tea cloths, towels, tablecloths,
sheets...)
60° for normally soiled, colour fast garments
(e.g. shirts, night dresses, pyjamas....) in
linen, cotton or synthetic fibres and for
lightly soiled white cotton (e.g. underwear).
(cold)for delicate items (e.g. net curtains), mixed
30°-40° laundry including synthetic fibres and
woollens bearing the label «pure new
wool, machine washable, non-shrink».
Before loading the laundry
Never wash whites and coloureds together. Whites
may lose their “whiteness” in the wash.
New coloured items may run in the first wash; they
should therefore be washed separately the first time.
Make sure that no metal objects are left in the
laundry (e.g. hair clips, safety pins, pins).
Button up pillowcases, close zip fasteners, hooks
and poppers. Tie any belts or long tapes.
Remove persistent stains before washing. Rub
particularly soiled areas with a special detergent or
detergent paste.
Treat curtains with special care. Remove hooks or tie
them up in a bag or net.
Maximum loads
Recommended loads are indicated in the
programme charts.
General rules:
Cotton, linen: drum full but not too tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no more than
one third full.
Washing a maximum load makes the most efficient
use of water and energy.
For heavily soiled laundry, reduce the load size.
Laundry weights
The following weights are indicative:
bathrobe 1200 g
napkin 100 g
quilt cover 700 g
sheet 500 g
pillow case 200 g
tablecloth 250 g
towelling towel 200 g
tea cloth 100 g
night dress 200 g
ladies’ briefs 100 g
man’s work shirt 600 g
man’s shirt 200 g
man’s pyjamas 500 g
blouse 100 g
men’s underpants 100 g
Removing stains
Stubborn stains may not be removed by just water
and detergent. It is therefore advisable to treat them
prior to washing.
Blood: treat fresh stains with cold water. For dried
stains, soak overnight in water with a special
detergent then rub in the soap and water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and dab the
stain; treat several times.
Dried grease stains: moisten with turpentine, lay
the garment on a soft surface and dab the stain with
the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust
removing product used cold. Be careful with rust
stains which are not recent since the cellulose
structure will already have been damaged and the
fabric tends to hole.
Mould stains: treat with bleach, rinse well (whites
and fast coloureds only).
Grass: soap lightly and treat with bleach (whites and
fast coloureds only).
Ball point pen and glue: moisten with acetone (*),
lay the garment on a soft cloth and dab the stain.
Lipstick: moisten with acetone as above, then treat
stains with methylated spirits. Remove any residual
marks from white fabrics with bleach.
Red wine: soak in water and detergent, rinse and
treat with acetic or citric acid, then rinse. Treat any
residual marks with bleach.

ENGLISH
39
Ink: depending on the type of ink, moisten the fabric
first with acetone (*), then with acetic acid; treat any
residual marks on white fabrics with bleach and then
rinse thoroughly.
Tar stains: first treat with stain remover, methylated
spirits or benzine, then rub with detergent paste.
(*) do not use acetone on artificial silk.
Detergents and additives
Good washing results also depend on the choice of
detergent and use of the correct quantities to avoid
waste and protect the environment. Although
biodegradable, detergents contain substances
which, in large quantities, can upset the delicate
balance of nature.
The choice of detergent will depend on the type of
fabric (delicates, woollens, cottons, etc.), the colour,
washing temperature and degree of soiling.
All commonly available washing machine detergents
may be used in this appliance:
– powder detergents for all types of fabric,
– powder detergents for delicate fabrics (60°C max)
and woollens,
– liquid detergents, preferably for low temperature
wash programmes (60°C max) for all types of
fabric, or special for woollens only.
The detergent and any additives must be placed in
the appropriate compartments of the dispenser
drawer before starting the wash programme.
If using concentrated powder or liquid detergents, a
programme without prewash must be selected.
The washing machine incorporates a recirculation
system which allows an optimal use of the
concentrated detergent.
Pour liquid detergent into the dispenser drawer
compartment marked just before starting the
programme.
Any fabric softener or starching additives must be
poured into the compartment marked before
starting the wash programme.
The bleaching agent (chlorine) can be used only for
white or fast coloured cotton and linen items.
Pour it into the compartment marked .
Follow the product manufacturer’s recommendations
on quantities to use and do not exceed the «MAX»
mark in the detergent dispenser drawer.
Quantity of detergent to be used
The type and quantity of detergent will depend on
the type of fabric, load size, degree of soiling and
hardness of the water used.
Water hardness is classified in so-called “degrees” of
hardness. Information on hardness of the water in
your area can be obtained from the relevant water
supply company, or from your local authority.
Follow the product manufacturers’ instructions on
quantities to use.
Use less detergent if:
– you are washing a small load,
– the laundry is lightly soiled,
– large amounts of foam form during washing.
Degrees of water hardness
Level Characteristic
Degrees
German
°dH French °T.H.
soft
medium
hard
very hard
0- 7
8-14
15-21
more than
21
0-15
16-25
26-37
more than
37
1
2
3
4

40
Drying hints
As a dryer, the machine works on the condensation
principle.
Therefore, the water tap must be open and the
drain hose must drain water into a sink or into
the drain pipe, even during the drying cycle.
Load
Warning:
Loads of washed laundry exceeding these values
must be divided before being dried, otherwise
poor results will be obtained.
Garments not suitable for drying
• Particularly delicate items such as synthetic
curtains, woollen and silk, garments with metal
inserts, nylon stockings, bulky garments such as
anoraks, bedcovers, quilts, sleeping bags and
duvets must not be machine dried.
• Garments padded with foam-rubber or materials
similar to foam-rubber must not be machine dried;
they represent a fire hazard.
• Also, fabrics containing residues of setting lotions
or hair sprays, nail solvents or similar solutions
must not be machine dried in order to avoid the
formation of harmful vapours.
Drying symbols on garment labels
Always look at the garment label to check whether
garments can be machine dried.
The following symbols refer to drying:
Machine drying is usually possible
Normal drying (normal temperature)
Gentle drying (reduced temperature)
Do not machine dry
Duration of the drying cycle
The drying time can vary according to
• the final spin speed;
• the required degree of drying (store dry or iron
dry);
• the type of laundry;
• the size of load.
The usual drying times are indicated in the
programme chart. As you become more familiar with
the appliance, you will discover the drying times that
best suit your needs according to the various type of
fabric. It is a good idea to make a note of these
times.
Modification of the drying time
If you wish to modify the drying time when a drying
programme is running, turn the time selector dial
clockwise to the required time.
Fibre residue
After drying fluffy fabrics, such as new towels, it is
advisable to perform a gentle rinse (progr. N) to be
sure that any residue that may remain in the tub is
completely removed and does not stick to garments
dried afterwards.
After each drying cycle the filter should be
checked and cleaned.
Additional drying
Should the laundry still be too wet at the end of the
programme, set another short drying cycle.
Warning! To prevent the formation of creases or
shrinking of fabrics, avoid excessive drying.
max. load
(dry weight)
2.25 kg
1.5 kg
Linen and cottons
Synthetics
Sort of laundry

ENGLISH
41
International wash code symbols
These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.
Energetic wash
Delicate wash
Max. wash
temperature
95°C
Max. wash
temperature
60°C
Max. wash
temperature
40°C
Max. wash
temperature
30°C Hand wash Do not
wash
at all
Bleaching Bleach in cold water Do not bleach
Ironing Hot iron
max 200°C Warm iron max 150°C Lukewarm iron max 110°C Do not iron
Dry cleaning Dry cleaning
in all solvents Dry cleaning in perchlorethylene,
petrol, pure alcohol,
R 111 & R 113
Dry cleaning
in petrol,
pure alcohol
and R 113
Do not
dry clean
Drying Flat On the line On clothes
hanger Tumble dry
high
temperature
low
temperature
Do not
tumble dry
A
P
F
95
60
60
40
40
40
30
30

42
4.Select the temperature
Turn the dial to the required setting.
5.Select the required option(s)
6.Select the programme and start
the machine
Turn the programme selector dial clockwise to the
required programme and press the On/Off button:
the operating pilot light comes on and the machine
starts to operate.
P0228S
P0429
A
P0455
90
Operating sequence
Washing only
Before washing your first load of laundry, we
recommend that you run a cotton cycle at 60°C, with
the machine empty, in order to remove any
manufacturing residue from the drum and tub.
Pour half a measure of detergent into the main wash
compartment and start up the machine.
1.Place the laundry in the drum
Open the door.
Place the laundry in the drum, one item at a time,
shaking them out as much as possible.
Close the door.
2.Measure out the detergent
Pull out the dispenser drawer until it stops. Measure
out the amount of detergent recommended by the
manufacturer in a graduated cup and pour it into the
main wash compartment .
If you wish to carry out the prewash, pour detergent
into the appropriate compartment marked .
3.Measure out the additives
If required, pour fabric softener into the compartment
marked , and bleach into the compartment
marked without exceeding the «MAX» mark.
P0163
Cl
P0164
Cl
P0004

ENGLISH
43
Drying only
Warning! Do not exceed the maximum laundry
loads:
- 2.25 kg for linen and cottons
- 1.5 kg for synthetics.
The water tap must be open and the drain hose must
be positioned in the sink or connected to the drain
pipe.
1. Select the drying programme “G” for cotton or “K”
for synthetics.
2. Select the drying time in the appropriate sector.
3. Press the ON/OFF button to start the
programme.
4. At the end of the cycle, press the ON/OFF button
again to switch the appliance off.
5. Remove the laundry.
Automatic washing and drying
(NON-STOP programme)
Warning! For NON-STOP programmes, it is also
essential not to exceed the maximum load sizes of
2.25 kg for cotton and 1.5 kg for synthetics.
If you use a dosing device in a washer-dryer,
please ensure the dosing device/ball is removed
before carrying out a drying programme.
1. Load the laundry.
2. Add detergent and additives.
3. Select the wash programme and the temperature.
4. Select eventually the required options by means
of the relevant buttons. If possible, do not reduce
the spin speed to avoid a too long drying time so
saving energy.
5. Select the drying time.
6. Start the programme by depressing the ON/OFF
button.
7. At the end of the programme, press the ON/OFF
button again to switch the machine off.
8. Remove the laundry.
P0864S
60
90
1
2
0
7.At the end of the programme
The machine stops automatically.
If you have selected a programme which ends with
the water of the last rinse left in the tub, drain the
water before opening the door. Select programme
“Q” (drain) or “P” (short spin).
Wait one or two minutes before opening the door to
give the electric locking mechanism time to release
it.
Depress the On/Off button again to switch the
machine off. The operating pilot light goes out.
Remove the laundry.
Turn the drum by hand to make sure it is completely
empty, so as to avoid any forgotten items being
damaged in a subsequent wash (e.g. shrinking) or
their colour running into a load of whites.
Release any buttons which have been pressed.
Turn the water tap off and unplug the machine.
Leave the door ajar to air the machine.

44
Programme table
Washing programmes for cotton and linen
In compliance with EC directive 92/75, the consumption figures indicated on the energy label refer to the 60°C
wash programme for cotton (programme “B”).
* The consumption data shown on this chart is to be considered purely indicative, as it may vary depending on
the quantity and type of laundry, on the inlet water temperature and on the ambient temperature. It corresponds
to the highest temperature for each wash programme.
Programme
A
B
B
C
D
Rinses
F
Spin
60°-90°
60°-90°
40°-60°
30°-40°
COLD
Temp. Fabrics Additional
functions
4.5 kg
4.5 kg
4.5 kg
4.5 kg
4.5 kg
4.5 kg
2.2
1.9
1.1
0.6
0.1
-
Max. load
Consumptions*
Energy
kWh
67
56
53
53
40
-
Water
lt
150
130
125
100
45
10
Duration
min.
WHITES HEAVY
SOILED, WITH
PREWASH, for
example work
garments, sheets,
household linen,
underwear, towels
WHITES
NORMALLY
SOILED, WITHOUT
PREWASH, for
example household
linen, sheets, shirts,
underwear
FAST
COLOUREDS, for
example shirts,
blouses, terry cloths
NON-FAST
COLOUREDS, for
example shirts,
blouses, underwear
This programme can
be used for rinsing
hand washed
garments
Separate spin for
cotton and linen

ENGLISH
45
Programme table
At the end of these programmes the machine stops with the water of the last rinse left in the tub to prevent the
fabrics from creasing. To drain the water select programme “P” or “Q”.
When the automatic NON-STOP washing plus drying programme is used, the water is emptied out
automatically and there is a short spin at 900 rpm before drying starts.
* The consumption data shown on this chart is to be considered purely indicative, as it may vary depending on
the quantity and type of laundry, on the inlet water temperature and on the ambient temperature.
Washing programmes for synthetics, mixed fabrics, delicates and wool
Programme
SYNTHETICS
HEAVY SOILED,
WITH PREWASH,
underwear,
coloured items,
shirts, blouses
SYNTHETICS
NORMALLY
SOILED,
WITHOUT
PREWASH, for
example shirts,
blouses, mixed
fabrics
WOOL
Special
programme for
garments bearing
the “Pure new
wool, non-shrink,
machine
washable” label
DELICATES, for
example curtains
This programme
can be used for
rinsing hand
washed garments
Separate spin for
synthetics,
delicates and wool
For emptying out
the last rinse water
of these
programmes
H
J
L
M
N
Rinses
P
Short
spin
Q
Drain
30°-60°
30°-60°
30°-40°
30°-40°
COLD
Temp. Fabrics Additional
functions
2 kg
2 kg
1 kg
2 kg
2 kg
2 kg
2 kg
1.0
0.8
0.6
0.6
-
-
-
Max. load
Consumptions*
Energy
kWh
70
62
58
56
41
-
-
Water
lt
95
80
60
55
20
5
1
Duration
min.
