Electrolux EW7W5247A2 User manual

EW7W5247A2
EN Washer Dryer User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................6
3. INSTALLATION.................................................................................................. 7
4. PRODUCT DESCRIPTION.............................................................................. 11
5. CONTROL PANEL........................................................................................... 11
6. DIAL AND BUTTONS....................................................................................... 14
7. PROGRAMMES............................................................................................... 16
8. SETTINGS........................................................................................................23
9. BEFORE FIRST USE....................................................................................... 24
10. DAILY USE - WASHING ONLY......................................................................24
11. DAILY USE - WASHING & DRYING.............................................................. 28
12. DAILY USE - DRYING ONLY......................................................................... 30
13. FLUFF IN THE FABRICS............................................................................... 31
14. HINTS AND TIPS........................................................................................... 31
15. CARE AND CLEANING..................................................................................33
16. TROUBLESHOOTING....................................................................................37
17. CONSUMPTION VALUES..............................................................................41
18. TECHNICAL DATA.........................................................................................42
19. ACCESSORIES..............................................................................................43
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
www.electrolux.com2

Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
•Children of less than 3 years of age should be kept
away unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
ENGLISH 3

1.2 General Safety
•Do not change the specification of this appliance.
•This appliance is intended to be used in household
and similar applications such as:
–staff kitchen areas in shops, offices and other
working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments;
–areas for communal use in blocks of flats or in
launderettes.
•The appliance shall be installed as a freestanding
product or below the kitchen worktop if space margins
permit.
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, that would prevent the appliance door from being
fully open.
•Connect the mains plug to the mains socket only at
the end of the installation process. Make sure that the
mains plug is accessible after installation.
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•WARNING: The appliance must not be supplied
through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on
and off by a utility.
•Ensure good air ventilation in the room where the
appliance is installed to avoid the backflow of
unwanted gases into the room from appliances
burning gas or other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is
used for exhausting fumes from any appliances
burning gas or other fuels.
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
www.electrolux.com4

•Do not exceed the maximum load of 7 kg (refer to the
"Programme chart" chapter).
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Items that have been soiled with substances such as
vegetable or mineral oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes and wax
removers should be washed separately with an extra
amount of detergent before being dried in the washer
dryer.
•Do not use the appliance if items have been soiled
with industrial chemicals.
•Do not dry unwashed items in the wash dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, and rubber backed articles and
clothes, or pillows fitted with foam rubber pads should
not be dried in the washer dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
•Remove all objects from items that could be a source
of fire ignition such as lighters or matches.
•Never stop the washer dryer before the end of the
drying cycle unless all items are quickly removed and
separated so that residual heat can dissipate.
•The final part of the washer dryer cycle takes place
without heat (cool down cycle) to ensure that items
reach a temperature that will not cause damage to
them.
ENGLISH 5

•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• Always keep the appliance vertical
when it is being moved.
• Make sure that there is air circulation
between the appliance and the floor.
• Remove all the packaging and the
transit bolts.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
2.2 Electrical Connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the
E.E.C. Directives.
2.3 Water Connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
www.electrolux.com6

2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the glass door while a
programme is in operation. The glass
can get hot.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a
stain remover, carry out an additional
rinse cycle before starting a drying
cycle.
• Make sure that all metal objects are
removed from the laundry.
• Only dry fabrics that are suitable to
dry in the washer dryer. Follow the
cleaning instruction on the item label.
• Plastic items are not heat resistant.
– If a detergent ball is used, remove
it before starting a drying
programme.
– Do not use a detergent ball if
setting a non-stop programme.
WARNING!
Risk of injury or damage to
the appliance.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
appliance.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Unpacking
1. Remove the external film. If necessary,
use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
ENGLISH 7

3. Open the door. Remove all the items from
the drum .
4. Put the front polystyrene packaging
element on the floor under the appliance.
Carefully put down the appliance onto its rear
side.
5. Remove the polystyrene protection from
the bottom. Put the appliance back into an
upright position.
1
2
6. Remove the power supply cable and the
drain hose from the hose holders.
It is possible to see water flowing from the
drain hose. This is because the washing
machine has been tested at the factory.
7. Remove the three transit bolts and pull out
the plastic spacers.
8. Put the plastic caps, that you find in the
user manual bag, in the holes.
We recommend that you
keep the packaging and
the transit bolts for any
transport of the appliance.
3.2 Information for installation
1. Positioning and levelling
Correctly adjusting the appliance so that
it is level prevents vibration, noise and
movement of the appliance when in
operation.
1. Install the appliance on a flat hard
floor. The appliance must be levelled and
stable. Make sure that the appliance
does not touch the wall or other units and
www.electrolux.com8

there is air circulation below the
appliance.
2. Loosen or tighten the feet to adjust the
level. All feet must rest firmly on the floor.
x4
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
2. The inlet hose
CAUTION!
Make sure there is no
damage to hoses and there
are no leaks from the
couplings. Do not use an
extension hose if the inlet
hose is too short. Contact
the service centre for a
replacement inlet hose.
1. Connect the water inlet hose to the
back of the appliance.
20O 20O
45O 45O
2. Position it toward left or right
depending on the positon of the water
tap. Make sure that the inlet hose is not
in vertical position.
3. If necessary, loosen the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4'' thread.
3. Water drainage
The drain hose should stay at a height of
no less than 60 cm and not more than
100 cm.
You can extend the drain
hose to maximum 400 cm.
Contact the authorised
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose guide.
ENGLISH 9

2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when the
appliance drains and the
drain hose end is not
immersed in the water.
There may be a return of
dirty water into the
appliance.
3. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
4. To a stand pipe with vent-hole -
Insert the drain hose directly into a drain
pipe. Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter of
the drain hose.
5.Without the plastic hose guide, to a
sink spigot- Put the drain hose in the
spigot and tighten it with a clamp. Refer
to the illustration.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
6. Position the hose directly to a built-in
drain pipe in the room wall and tighten
it with a clamp.
www.electrolux.com10

4. PRODUCT DESCRIPTION
4.1 Appliance overview
1 2 3 9
5
7
4
10
8
11 12
6
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
5. CONTROL PANEL
5.1 Special features
Your new washer-dryer meets all modern
requirements for effective treatment of
laundry with low water, energy and
detergent consumption and detergent
consumption and proper care of fabric.
•FreshScent System, thanks to new
FreshScent steam programme, offers
the perfect solution for refreshing
even the most delicate garments
without washing. Use the delicate
fragrance exclusively developed by
ELECTROLUX to add a pleasant
feeling of "just-washed" garment to
the removing odours and wrinkles
action.
• Thanks to the Soft Plus option, the
fabric softener is uniformly spread out
in the laundry and deeply penetrates
the fabric fibres favouring a perfect
softness.
• The SensiCare System detects the
laundry load size defining the
programme duration in 30 seconds.
The washing programme is tailored to
the laundry load and the type of fabric
without consuming more time, energy
and water than necessary.
ENGLISH 11

5.2 Control panel description
Denim
Rinse
Mode Temp.
Wash
90
60
40
30
20
Cold
Dry
Cotton
Synthetics
Delicate
Cotton Eco
l
ooW
t
n
ecShserF
niarD/
nip
S
n
aelC e
nih
c
aM
y
grell
A-it
nA
r
aewstropS
Outdoor
Spin Prewash
Time
Manager
Delay
Start
23 4 5
12 11 8
1
7 6
910
The permanent options are
set by holding pressed the
relative button for at least 3
seconds.
1Programme dial
2Display
3Auto Dry touch button
4Time Dry touch button
5Start/Pause touch button
6Delay Start touch button
7Time Manager touch button and
permanent Child Lock option
8Prewash touch button and
permanent Extra Rinse option
9Spin touch button
10 Temperature touch button
11 Mode touch button:
• Wash
• Dry
12 On/Off push button
5.3 Display
Door locked indicator.
www.electrolux.com12

The digital indicator can show:
• Programme duration (e. g. , washing and/or drying
phase).
• Delay time (e. g. ).
• Cycle end ( ).
• Warning code (e.g. ).
• Error indicator ( ).
Time Manager indicator.
Extra Rinse indicator.
The spin area:
Spin speed indicator
No Spin indicator. Spin phase is off.
Rinse Hold indicator.
After the SensiCare System detection, it flashes when the
laundry load exceeds the maximum declared load of the selec‐
ted programme. Refer to "The SensiCare System load detec‐
tion " paragraph.
Auto Dry indicator:
Iron dry
Cupboard dry
Extra dry
Child safety lock indicator.
Time Dry indicator.
5.4 Multilingual badges
Adhesive badges in different languages
are supplied with the appliance.
The desired badge can be glued next to
the programme dial.
Outdoor
Puuvilla
Puuvilla
Koneenpuhdistus
Silkki
Villa
Tyhjennys/Linkous
Huuhtelu
Pika 14 min.
Hienopesu
Synteettiset
Denim
UltraWash
Anti-Allergy
ENGLISH 13

6. DIAL AND BUTTONS
6.1 Introduction
The options/functions are
not available with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set incompatible options/
functions.
6.2 On/Off
Press this button for a few seconds to
activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance after several
minutes to reduce the energy
consumption, you may need to activate
the appliance again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
6.3 Mode
Thanks to this button, a cycle can
perform:
•Only washing: Wash indicator is on
(default mode).
•Washing and drying: Wash and Dry
indicators are on.
•Only drying: Dry indicator is on.
6.4 Temperature
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Tap on this button to change the water
temperature.
The indicator of the set temperature
comes on.
The indicator Cold corresponds to cold
water.
6.5 Spin
When you set a programme, the
appliance automatically sets the
maximum spin speed allowed, except for
programme Denim. With this option you
can decrease the default spin speed.
Touch repeatedly this button to:
•Decrease the spin speed. The
display shows only the spin speeds
available for the set programme.
• Additional spin options No Spin
.
Set this option to deactivate all spin
phases. The appliance performs the
only draining phase of the selected
washing programme. Set this option
for very delicate fabrics. The rinses
phase uses more water for some
washing programmes
• Activate the Rinse Hold option.
The final spin is not performed. The
water of the last rinse is not drained
out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum.
The indicator is on display. The
door stays locked and the drum turns
regularly to reduce creasing. You
must drain the water to unlock the
door.
If you touch the Start/Pause
button, the appliance performs the
spinning phase and drains the water.
The appliance empties
the water out
automatically after 18
hours approximately.
6.6 Prewash
With this option you can add a prewash
phase to a washing programme.
The corresponding indicator above the
touch button illuminates.
• Use this option to add a pre-wash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
www.electrolux.com14

containing sand, dust, mud and other
solid particles.
The options can increase the
programme duration.
6.7 Permanent Extra Rinse
With this option you can permanently
have an extra rinse when you set a new
programme.
To activate/deactivate this option, hold
the Prewash button pressed for 3
seconds until the indicator comes on/
goes off on the display.
When it is activated, the appliance will
default to this option after you switch it
off or change/reset the programme.
This option increases the
programme duration.
6.8 Time Manager
With this option you can reduce the
programme duration depending on the
load size and the degree of soiling.
When you set a washing programme, the
display shows the default duration and
dashes.
Touch Time Manager button to reduce
the programme duration according to
your needs. The display shows the new
programme duration and a number of
dashes will decrease accordingly:
suitable for a full load of normally
soiled garments.
a quick cycle for a full load of lightly
soiled garments.
very quick cycle for a smaller lightly
soiled load (max. half load
recommended).
the shortest cycle to freshen up a
small amount of laundry.
The Time Manager is available only with
the programmes in the table.
indicator
Cotton
Cotton Eco
Synthetics
1) ■■■
■ ■ ■
■■■
■ ■ ■
■ ■ ■
1) Default duration for all programmes.
Time Manager with steam
programmes
When setting a steam programme, this
button allows to chose three steam levels
and the programme duration is reduced
accordingly:
•: maximum.
• : medium.
• : minimum.
6.9 Child Lock
With this option you can prevent children
from playing with the control panel.
To activate/deactivate this option, hold
the Time Manager button pressed until
the indicator comes on/goes off on
the display.
When it is activated, the appliance will
default to this option after you switch it
off or change/reset the programme. If
you press any button, the indicator
blinks to indicate that the buttons are
disabled.
6.10 Time Dry
Touch this button to set the time that
suits the fabrics you have to dry (refer to
"Timed drying" table). The display shows
the set value.
ENGLISH 15

Each time you touch this button the time
value increases by 5 minutes.
You cannot set all time
values for different types of
fabrics.
6.11 Auto Dry
Touch this button to set one the
automatic dryness levels proposed by
the appliance.
On the display the relevant dryness
indicator goes on:
• Iron dry: laundry to be ironed.
• Cupboard dry: laundry to be put
in store.
• Extra dry: laundry to be fully dried.
You can not set all
automatic levels for each
type of fabrics.
6.12 Delay Start
With this option you can delay the start of
a programme to a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases in
steps of 1 hour up to 20 hours.
The corresponding indicator above the
touch button illuminates.
The display shows the selected delay
time. After touching the Start/Pause
button, the appliance begins the
countdown and the door is locked.
6.13 Start/Pause
Touch the Start/Pause button to
start, pause the appliance or interrupt a
running programme.
7. PROGRAMMES
7.1 Programme Chart
Programme
Default tempera‐
ture
Temperature
range
Refer‐
ence spin
speed
Spin
speed
range
Maxi‐
mum
load
Programme description
(Type of load and soil level)
Washing programmes
Cotton
40 °C
90 °C - Cold
1400 rpm
(1400-
400 rpm)
7 kg White cotton and coloured cotton. Nor‐
mal, heavy and light soil.
Cotton Eco1)
40 °C
60 °C - 40 °C
1400 rpm
(1400-
400 rpm)
7 kg White cotton and fast-coloured cotton.
Normal soil. The energy consumption de‐
creases and the time of the washing pro‐
gramme is extended.
Synthetics
40 °C
60 °C - Cold
1200 rpm
(1200 -
400 rpm)
3 kg Synthetic items or mixed fabric items.
Normal soil.
www.electrolux.com16

Programme
Default tempera‐
ture
Temperature
range
Refer‐
ence spin
speed
Spin
speed
range
Maxi‐
mum
load
Programme description
(Type of load and soil level)
Delicate
40 °C
40 °C - Cold
1200 rpm
(1200-
400 rpm)
3 kg Delicate fabrics such as acrylics, vis‐
cose and mixed fabrics requiring gentler
washing. Normal soil.
Wool
40 °C
40 °C - Cold
1200 rpm
(1200 -
400 rpm)
1.5 kg Machine washable wool, hand washable
wool and other fabrics with «hand wash‐
ing» care symbol2).
Steam programme with FreshScent System
Steam programme can be used for reducing wrinkles and odours3) of garments that
just need to be refreshed, avoiding washing. The fabric fibres are relaxed and after‐
wards ironing becomes effortless. When the programme is completed, quickly re‐
move the laundry from the drum4). Steam programmes do not perform any hygienic
cycle. Do not set one of these programmes with the following type of items:
• Items that are not suitable for tumble drying.
• All items with plastic, metal, wooden parts or alike.
ELECTROLUX fragrance. If you use this special gentle fragrance, your laundry will
scent as just washed: pour a single dose bottle in the compartment and simply
start a steam programme. Reduce the fragrance dosage when treating smaller load.
By means of the Time Manager button, you can reduce the programme duration
when treating items labeled to be washed at low temperature.
DO NOT:
• Tumble dry the garments treated with fragrance. Its benefit would evaporate.
• Use the fragrance with different purposes than those here described.
• Use the fragrance on new garments. New garments may contain residual finishing
compounds which are not compatible with it.
The fragrance dose bottles are available on ELECTROLUX web shop or
by authorised dealer.
FreshScent
-
1 kg Cottons, Synthetics, Delicates. Short and
gentle steam programme to refresh even
your very delicate garments, including very
delicate garments with sequins, lace etc.
When treating smaller loads, the pro‐
gramme duration can be further reduced by
means of the Time Manager option.
WARNING!
Do not use this programme
with wool and garments label‐
led as dry-clean only.
ENGLISH 17

Programme
Default tempera‐
ture
Temperature
range
Refer‐
ence spin
speed
Spin
speed
range
Maxi‐
mum
load
Programme description
(Type of load and soil level)
Spin/Drain
1400 rpm
(1400 -
400 rpm)
7 kg To spin the laundry and to drain the water in
the drum. All fabrics, except woollens
and delicate fabrics.
Rinse
1400 rpm
(1400-
400 rpm)
7 kg All fabrics, except woollens and very
delicate fabrics. Programme for rinsing
and spinning the laundry. The default spin
speed is the one used for cotton pro‐
grammes. Reduce the spin speed accord‐
ingly to the type of laundry. If necessary, set
the Extra Rinse option to add rinses. With a
low spin speed, the appliance performs deli‐
cate rinses and a short spin.
Machine Clean
60 °C
1200 rpm
(1200 -
400 rpm)
-
Maintenance cycle with hot water to clean
and freshen the drum and to remove resi‐
due that may cause odour. For the best re‐
sult use this cycle once a month. Before
running this cycle, remove all items from the
drum. In the washing phase compartment of
the detergent dispenser, put the flap of the
compartment in upward position. Pour a
cup of chlorine bleach or a washing ma‐
chine cleaner in the washing phase com‐
partment. DO NOT use both together.
After the drum cleaning, run a
further rinse cycle with empty
drum and no detergent to re‐
move any residue of bleach.
If you set this programme with the Dry, the
appliance performs the anti-fluff action. Re‐
fer to chapter 'Fluff in the fabrics'.
Anti-Allergy
60 °C
1400 rpm
(1400 -
400 rpm)
7 kg White cotton items. This programme re‐
moves micro-organisms thanks to a wash‐
ing phase with the temperature maintained
above 60°C for several minutes. This helps
remove germs, bacteria, micro-organism
and particles. An additional rinsing phase
ensures a proper removal of detergent resi‐
dues and pollens/allergenic items. In this
way the wash is more effective.
www.electrolux.com18

Programme
Default tempera‐
ture
Temperature
range
Refer‐
ence spin
speed
Spin
speed
range
Maxi‐
mum
load
Programme description
(Type of load and soil level)
Sportswear
30 °C
40 °C - Cold
1200 rpm
(1200-
400 rpm)
3 kg Synthetic sport items. This programme is
designed to gently wash modern outdoor
sportswear and is also suitable for gym, cy‐
cling or jogging clothes or similar.
Outdoor
30 °C
40 °C - Cold
1200 rpm
(1200-
400 rpm)
2 kg Do not use fabric softener and
make sure that there is no soft‐
ener residue in the detergent
dispenser.
Outdoor clothing, technical, sport fab‐
rics, waterproof and breathable jackets,
shell jackets with a removable fleece or
inner insulation.
By performing a non-stop wash
and dry programme, the drying
phase also acts as water-repel‐
lent restorer. Make sure that
the garment care label permits
tumble drying.
Denim
30 °C
40 °C - Cold
1200 rpm
(1200 -
400 rpm)
3 kg Special programme for Denim clothing
with delicate washing phase to minimize
colour fading and marks. For better care
a reduced load size is recommended.
OneGo 1h 1kg
30 °C
40 °C - 30 °C
1200 rpm
(1200 -
400 rpm)
1 kg Mixed fabrics (cotton and synthetic
items). Complete short programme to wash
and dry laundry loads up to 1 kg in one go.
It only lasts 1 hour.
Reset position. The display shows dashes only.
1) Cottons energy saving programme. This programme at 60ºC with a load of 7 kg is the
reference programme for data entered in the energy label, in compliance with 96/60/EC Di‐
rective. Set this programme to have a good washing results and decrease the energy con‐
sumption. The time of the washing programme is extended.
2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the
drum doesn't rotate or doesn't rotate properly, but this is normal for this programme.
3) Steam programme doesn't remove particularly intense odour.
4) After the steam treatment the laundry can be humid. Hang items out for a few minutes.
ENGLISH 19

Programme options compatibility
Programme
Spin
No Spin
Prewash
Time Manager
Delay Start
Cotton ■ ■ ■ ■ ■ ■ ■
Cotton Eco ■ ■ ■ ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■ ■
Delicate ■ ■ ■ ■ ■ ■
Wool ■ ■ ■ ■
FreshScent ■ ■
Spin/Drain ■■1) ■
Rinse ■ ■ ■ ■ ■
Machine Clean ■ ■ ■
Anti-Allergy ■ ■ ■ ■ ■ ■
Sportswear ■ ■ ■ ■ ■ ■
Outdoor ■ ■ ■ ■ ■
Denim ■ ■ ■ ■ ■
OneGo 1h 1kg ■
1) If you set the No Spin option, the appliance performs draining only.
www.electrolux.com20
