Electrolux EWW14012 User manual

EWW14012 EN
IN
VI
WASHER-DRYER
MESIN CUCI-PENGERING
MÁY GIẶT-MÁY SẤY KHÔ
PANDUAN BAGI PENGGUNA
TÀI LIỆU HƯỚNG DẪN SỬ DỤNG
38
76
USER MANUAL 2
........................................................ ....................................................................

CONTENTS
WE’RE THINKING OF YOU
CUSTOMER CARE AND SERVICE
2 www.electrolux.com
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with
it decades of professional experience and innovation. Ingenious and stylish, it has been
designed with you in mind. So whenever you use it, you can be safe in the knowledge that
you’ll get great results every time. Welcome to Electrolux.
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Visit our website to:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Subject to change without notice.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Caution, risk of fire.
SAFETY INFORMATION
PRODUCT DESCRIPTION
CONTROL PANEL
BEFORE FIRST USE
DAILY USE - WASHING
WASHING HINTS
INTERNATIONAL WASH CODE SYMBOLS
CARE AND CLEANING
TROUBLESHOOTING
.............................................................................................. 3
........................................................................................... 7
...................................................................................................... 8
................................................................................................. 15
............................................................................................ 16
...................................................................................................... 23
............................................................... 26
............................................................................................. 26
............................................................................................... 31
1
2
3
4
5
DAILY USE - WASHING & DRYING
DAILY USE - DRYING
........................................................................... 21
................................................................................................ 22
6
7
8
9
10
11
TECHNICAL DATA .................................................................................................... 3412
INSTALLATION.......................................................................................................... 3513
ENVIRONMENT CONCERNS .................................................................................... 3714
Being ensured permissible content limitaon of some toxic
chemicals (RoHS compliant)
RoHS
Compliant

ENGLISH 3
SAFETY INFORMATION
In the interest of your safety and to
ensure the correct use, before installing
and first using the appliance, read this
user manual carefully, including its hints
and warnings.
This appliance is intended to be used in
household and similar applications
such as:
Farm houses
By clients in serviced apartments,
holiday apartments and residential
type environments.
Conditions of use
To avoid unnecessary mistakes and
accidents, it is important to ensure that
all people using the appliance are
thoroughly familiar with its operation and
safety features.
Save these instructions and make sure
that they remain with the appliance if it
is moved or sold, so that everyone
using it through its life will be properly
informed on appliance use and safety.
1.1 GENERAL SAFETY
It is dangerous to alter the
specifications or attempt to modify this
product in anyway.
During high temperature wash
program the door glass may get hot.
Do not touch it!
Make sure that small pets do not
climb into the drum. To avoid this,
please check into the drum before
using the appliance.
Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
Only use the advised quantities of
fabric softener and detergent. Damage
to the fabric or appliance can occur if
you overfill. Refer to the manufacturer’s
recommendations of quantities.
Wash small items such as socks,
laces, washable belts etc in a washing
bag or pillow case as it is possible for
such items to slip down between the
tub and the inner drum.
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Do not use your washer-dryer to wash
articles with whalebones, material
without hems or torn material.
Always unplug the appliance and turn
off the water supply after use, clean
and maintenance.
This appliance is heavy. Care should
be taken when moving it.
When unpacking the appliance, check
that it is not damaged. If in doubt, do
not use it and contact the Service
Centre.
All packing and transit bolts must be
removed before use. Serious damage
can occur to the product and to
property if this is not adhered to. See
relevant section in the user manual.
Under no circumstances should you
attempt to repair the machine yourself.
Repairs carried out by inexperienced
persons may cause injury or serious
malfunctioning. Contact your local
Service Centre. Always insist on
genuine spare parts.
1.2 INSTALLATION
1.
-
-

4 www.electrolux.com
Never tumble dry items which have
had contact with chemicals such as
dry cleaning fluid. These are of volatile
nature and could cause an explosion.
Only tumble dry items which have
been washed in water or require
airring.
Plastic detergent dispensers should
not remain in the drum during the
drying cycle, as the plastic used is not
designed to with stand the heat. If you
wish to wash-through-to dry you
should use the conventional detergent
dispenser drawer.
Never pull the power supply cable to
remove the plug from the socket;
always take hold of the plug itself.
Never use the washer-dryer if the
power supply cable, the control panel,
the working surface or the base are
damaged so that the inside of the
washer-dryer is accessible.
Never stop a washer-dryer before
the end of the drying cycle unless all
items are quickly removed and
spread out so that the heat is
dissipated.
CAUTION!
-
Do not dry cloths in washer-dryer
with dry clean solvents. Also do not
use laundry enhancement products
during the drying cycle.
-
After having installed the appliance,
check that it is not standing on the
inlet and drain hose and the worktop
is not pressing the electrical supply
cable.
If the machine is situated on a
carpeted floor, please adjust the feet
in order to allow air to circulate freely.
Always be sure, that there is no water
leakage from hoses and their
connections after the installation.
Any plumbing work required to install
this appliance should be carried out by
a qualified plumber.
Any electrical work required to install
this appliance should be carried out by
a qualified electrician.
This appliance is designed for
domestic use. It must not be used for
purposes other than those for which it
was designed.
Only wash fabrics which are designed
to be machine washed. Follow the
instructions on each garment label.
Do not overload the appliance. See
the relevant section in the user
manual.
Before washing, ensure that all
pockets are empty and buttons and
zips are fastened. Avoid washing
frayed or torn articles and treat stains
such as paint, ink, rust, and grass
before washing. Underwired bras
must NOT be machine washed.
Garments which have been in contact
with volatile petroleum products
should not be machine washed. If
volatile cleaning fluids are used, care
should be taken to ensure that the
fluid is removed from the garment
before placing in the machine.
1.3 USE
As some duvets and eiderdowns
should be washed/dried in large
commercial machine because of their
bulk, please check with the
manufacturer of the item before
washing/drying in a domestic
machine.
The users should always check that
they have not left their gas lighters
(disposable or otherwise) in their
clothing.

Items that have been spotted or
soaked with vegetable or cooking oil
constitute a fire hazard and should not
placed in a washer-dryer. Oil-affected
items can ignite spontaneously,
especially when exposed to heat
sources such as in washer-dryer. The
items become warm, causing an
oxidation creates heat. If the heat
cannot escape, the items can become
hot enough to catch fire. Piling,
stacking or storing oil-affected items
can prevent heat from escaping and
so create a fire hazard.
Items containing foam rubber (also
known as latex foam) or similarly
textured rubber, like materials should
not be dried in a washer-dryer on a
heat setting.
Fabric softeners or similar products
should not be used in a washer-dryer to
eliminate the effects of static electricity
unless this practice is specifically
recommended by the manufacturer of
the fabric softener or product.
Undergarments that contain metal
reinforcements should not be placed
in a washer-dryer.
Plastic articles such as shower caps
or babies’ waterproof napkin covers
should not be placed in washer-dryer.
Damage to the washer-dryer can
result if metal reinforcements come
loose during drying. When available a
drying rack could be used for such
itmes.
Foam rubber materials can, when
heated, produce fire by spontaneous
combustion.
If it is unavoidable that fabrics that
contain vegetable or cooking oil or
have been contaminated by hair care
products be placed in washer-dryer
they should first be washed in hot
water with extra detergent - this will
reduce, but not eliminate the hazard.
The ‘cool down’ cycle of washer-dryer
is used to reduce the temperature of
the items. They should not be
removed from the washer-dryer or
piled or stacked while hot.
Items that have been previously cleaned
in, washed in, soaked in or spotted with
petrol/gasoline, dry - cleaning solvents
or other flammable or explosive
substances should not be placed in
washer-dryer.
Highly flammable substances commonly
used in domestic environments include
acetone, denatured alcohol,
petrol/gasoline, kerosine, spot removers
(some brands), turpentine, waxes and
wax removers.
ENGLISH 5
To minimize the risk of fire in a
washer-dryer, following should be
observed:
This washer-dryer is not intended for
use by young children or infirm
persons without supervision.
Young children should be supervised
to ensure that they do not play with
the appliance.
The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach.
Make sure that children or pets do not
climb into the drum.
Keep all detergents in a safe place out
of children’s reach.
1.4 CHILD SAFETY

6 www.electrolux.com
To activate this device, rotate the
button (WITHOUT pressing it) inside
the door clockwise until the groove is
horizontal. If necessary use a coin.
When you activate this device, you
cannot close the door. This prevents
children or pets to be locked in the
drum.
To disable this device and restore the
possibility of closing the door, rotate
the button anti-clockwise until the
groove is vertical.
1.5 CHILD SAFETY DEVICE

ENGLISH 7
PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Door Blocking button
14
Rating Plate
15
Drain Pump Filter
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support
12
Level Adjustment Feet (Back)
Transit Bolts
To connect the drain hose on the edge
of a sink.
Plastic caps
To close the holes on the rear side of
the cabinet after the removal of the
transit bolts.
ACCESSORIES
Plastic hose guide
14
13
1
2
4
5
6
3
15
8
9
12
7
11
10

CONTROL PANEL3.
1
On/Off Button
2
Program Touchpads
3
Favourite Touchpad
4
Temperature Touchpad
5
Spin Selection Touchpad
6
Adjust Time Touchpad
7
Delay Start Touchpad
8
Display
9
10
Dryness Touchpad
11
Dry Time Touchpad
12
Prewash Touchpad
13
Vapour Touchpad
14
Start/Pause Touchpad
Rinse Plus Option (see page 11)
15
Child Lock Option (see page 21)
8 www.electrolux.com
1 9 13156 73
2 4 108 14 11 125
3.1 On/Off Button
On/Off button is used to turn on
and turn off your washer-dryer
machine.
3.2 Program Touchpads
Press the program icon to select
the wash or dry program. The
relevant light will light up.
(See page 12)
3.3 Favourite Touchpad
Program settings that are
frequently used can be saved (e.g.
Cotton, 60°C, 1200 rpm, with
Prewash and Rinse Plus).
To recall the favourite wash
program, press ‘Favourite’ button.
You will get acknowledgement on
the screen the Favourite program
is loaded.
You can recall a favourite wash
program ONLY when the
washer-dryer is:
Otherwise touching Favourite will
have no effect.
in the program selection mode.
To program/re-program Favourite
with your own selections and save
them, proceed as follows:
1. Put machine in Stand-by mode.
2. Select your desired wash
settings.
3. To save the new program touch
and hold ‘Favourite’ button for 3
seconds.

ENGLISH 9
3.4 Temperature Touchpad
Press this touchpad repeatedly to
increase or decrease the wash
temperature if you want your
laundry to be washed at a
temperature different from the one
proposed by the washer-dryer.
3.5 Spin Selection Touchpad
3.6 Adjust Time Touchpad
Press this touchpad repeatedly to
increase or decrease the spin
speed, if you want your laundry to
be spun at a speed different from
the one proposed by the washer-
dryer.
This option allows you to reduce
washing time.
Press this touchpad repeatedly to
decrease or return to default
washing time.
This option will adjust the number
of rinse according to selected
washing time.
3.7 Delay Start Touchpad
This option makes it possible to
delay the start of the program by
30 min, 60 min or 90 min and then
by every hour from 2 to 20 hours.
The delay you have selected is
indicated on the display. The end
time will increase in order to show
you the selected delay.
You must select this option after
you have set the program and
before you press the Start/Pause
button.
If you wish to add laundry in the
machine during the delay time,
press Start/Pause touchpad to put
the machine in pause mode. Add
laundry, close the door and press
Start/Pause touchpad again.
You can cancel the delay time at
any moment, by pressing ‘Delay
Start’ touchpad repeatedly till the
display shows delay time ‘ ’, then
press the Start/Pause touchpad.
No spin option eliminates all the
spin phases and increases the
number of rinses.
No Spin
By selecting this option, the
machine will not drain the water of
the last rinse to avoid wrinkling the
laundry. All spinning phases are
suppressed.
This washing cycle is very quiet, and
can be selected at night or other
appropriate times.
Extra Silent
By selecting this option the water of
the last rinse is not emptied out and
the drum turns regularly to prevent
the laundry creases.
The door stays locked with the
water in the drum. To continue
the cycle you must press
(Start/Pause).
The door is still locked to indicate
that the water must be emptied out.
Rinse Hold
The door stays locked with the
water in the drum. To continue
the cycle you must press
(Start/Pause).

10 www.electrolux.com
A
Rinse hold icon
B
Spin speed
C
Wash temperature
D
Cold water icon
E
Door lock icon
F
Maximum load capacity of selected program
G
Load weight
H
I
Extra silent icon
J
Text bar
K
Time manager icon
L
Washing cycle time/
Delay start time
M
Delay start icon
N
Rinse plus icon
Child lock icon
3.8 Display
B
D E GF H J
AC I N
K L M
The display shows and
indicators when the door is open.
GH
-
3.9 Dry Time 3.10 Dryness
If you wish to carry out a timed drying
program, keep pressing this touchpad
untill the designed time is reached.
Maximum allowable timed drying
changes based on wash
program selected.
The final time value is the total
duration of the washing +
detachment + drying cycles.
-
-
At the end of the program the
appliance performs the
anti-crease phase for approx. 10
minutes. During this time the
display will show time remaining
“ ” and door is locked ( ).
-
Press this touchpad to set the
level of dryness of your laundry.
The display shows the name of
the set level.
(Dryness option guides, see
page 14)
Extra dry
Cupboard dry
Iron dry
Dryness levels settings are
based on wash program
selected.
-
-
The final time value is the total
duration of the washing +
detachment + drying cycles,
calculated on a default load size.

ENGLISH 11
3.12 Vapour Touchpad
3.11 Prewash Touchpad
3.14 Rinse Plus Option
This option is recommended for
people who are allergic to
detergents, and in areas where the
water is very soft.
To activate this option, press ‘Dry
Time’ and ‘Prewash’ touchpads at
the same time until the display
shows the symbol ‘ ’.
To deactivate this option, press
‘Dry Time’ and ‘Prewash’
touchpads at the same time
until the symbol ‘ ’ goes off.
* Vapour option cannot be
selected, if drying option
has been combined with
the program.
3.13 Start/Pause Touchpad
To start the selected program, press
the ‘Start/Pause’.
To interrupt a program which is
running, press the ‘Start/Pause’ to
pause the machine.
To restart the program from the point
at which it was interrupted, press the
‘Start/Pause’ again.
If you have chosen a delayed start,
after pressing ‘Start/Pause’ the
machine will begin the countdown.
Select this option if you wish your
laundry to be pre-washed before
the main wash. Use this option for
heavy soil. The indicator of this
option comes on.
When you set this function, put the
detergent into the “ ”
compartment. (Refer page 18-19)
This function increases the
program duration.
Select this option*to add
approximately 45 minutes of
tumbling in vapour during the wash
cycle. Vapour helps open fabric
fibers up to allow laundry additives
to release tough stains.
The indicator of this option comes on.
Vapour may not necessarily be
visible inside the drum during a
vapour wash cycle. Vapour is
created below the drum and
allowed to naturally rise into the
clothes.
NOTE:
At the end of the Vapour cycle the
clothes will be warmer, softer and
detached from the drum.
If Vapour option is selected,
rinse temperatures will be
elevated.
During a vapour cycle you may
notice vapour exiting from the
drain hose of the washer-dryer,
this is normal and there is no
cause for alarm.
Vapour may not be present during
the entire vapour wash cycle.
Vapour function is more effective
with half load.
-
At the end of the program the
appliance performs the
anti-crease phase for approx.
10 minutes. During this time
the display will show time
remaining “ ” and door is
locked ( ).

12 www.electrolux.com
3.15 Programs + Options
Program;
Temperature
White and coloured cotton with
heavy level of soil;
max. load 10 kg (if drying option
combined, please reduce to 7 kg)
Wash
Rinses
Long spin
Dry (If drying
option
combined)
Spin Reduction
(1400 to 400 rpm, No Spin,
Rinse Hold, Extra Silent) /
(Iron Dry, Cupboard Dry,
Extra Dry)
Type of load;
Max. weight of load
Cycle
description
Options can be
combined
Mixed;
(Cold) to
60 °C
Synthetic or mixed fabric items
with normal level of soil;
max. load 4 kg (if drying option
combined, please reduce to 3 kg)
Delicates;
(Cold) to
40 °C
Quick 18;
30 °C
Drying
Cottons
Delicate fabrics as acrylics,
viscose, polyester items with
normal soil;
max. load 4 kg
Wash
Rinses
Short spin
Synthetic and mixed fabric
items. Light soil and items to
freshen up;
max. load 1.5 kg
Wash
Rinses
Short spin
Drying program for cotton
items;
max. load 7 kg
- Dry
Refresh
Vapour program for White and
coloured cotton. This cycle
removes odours and helps to
dewrinkle the laundry;
max. load 1.5 kg.
1)2)
2)
2)
Spin Reduction
(1200 to 400 rpm, No Spin,
Rinse Hold, Extra Silent) /
(Cupboard Dry)
Spin Reduction
(1200 to 400 rpm, No Spin,
Rinse Hold, Extra Silent) /
1)
Spin Reduction
(800 to 400 rpm, No Spin,
Rinse Hold) /
-
-
-
-
Wash
Rinses
Short spin
Dry (If drying
option
combined)
-
-
-
-
-
-
-
-
-
-
/ / / / / /
(Iron Dry, Cupboard Dry,
Extra Dry)
2)
2)
/ /
1)2)
/ /
/ /
/ / / /
/ / /
Cottons / 4);
(Cold) to
90 °C
Clothes
tumble in
vapour.
-
Drying
Mixed
Drying program for synthetic or
mixed fabric items;
max. load 3 kg.
Dry
-
(Cupboard Dry)
2)
2)
/ /
Wool;
(Cold) to
40 °C
More >>
Specially tested program for
woollen garments bearing the
‘pure new woollen, non-shrink,
machine washable’ label;
max. load 2 kg (if drying option
combined, please reduce to 1 kg)
Spin Reduction
(1200 to 400 rpm, No Spin,
Rinse Hold, Extra Silent) /
2)
/
Wash
Rinses
Short spin
Dry (If drying
option
combined)
-
-
-
-

ENGLISH 13
Program;
Temperature
Type of load;
Max. weight of load
Cycle
description
Options can be
combined
Bedding;
(Cold) to
60 °C
Special program for one synthetic
blanket, duvet, bedspread and so on;
max. load 3 kg.
Spin Reduction
(800 to 400 rpm, No Spin) /
- Vapour option can be combined with temperature 40 to 90 °C only.
- Vapour option cannot select, if drying option has been combined with the program.
Do not select a spin speed LOWER than that proposed by the appliance to avoid a too long drying time so saving
energy. In any case the reduction of the spin speed is only possible after selecting drying.
Refresh
Mixed
Vapour program for synthetic or mixed
fabric items. This cycle removes odours
and helps to dewrinkle the laundry;
max. load 1.5 kg.
1)
/ /
Wash
Rinses
Long spin
-
-
-
2)
1)
Energy Saver program with 60 °C option selected is recommended for a full load of normally soiled cottons, and is the
water and energy rating label program.
3)
Clothes
tumble in
vapour.
-
Wash
Rinses
Short spin
-
-
-
Baby;
(Cold) to
40 °C
Baby cotton clothes and delicate
knitting items with normal soil;
max. load 4 kg.
Energy Saver
40 °C,
60 °C
3)
White and colourfast, cotton with
normal soil. Set this program to have
a good washing results and
decrease the energy consumption.
The time of the washing program is
extended;
max. load 10 kg (if drying option
combined, please reduce to 7 kg)
Spin Reduction
(1400 to 400 rpm, No Spin,
Rinse Hold) /
(Iron Dry, Cupboard
Dry, Extra Dry)
2)
Wash
Rinses
Short spin
Dry (If drying
option
combined)
-
-
-
-1)2)
/ /
/
/ / /
Spin Reduction
(1400 to 400 rpm, No Spin) /
Spin To spin the laundry and drain the
water in the drum;
max. load 10 kg (if drying option
combined, please reduce to 7 kg)
- Drain
- Spin phase
Dry (If drying
option
combined)
2)
(Iron Dry, Cupboard Dry,
Extra Dry)
2)
/ /
Rinse To rinse and spin the laundry;
max. load 10 Kg (if drying option
combined, please reduce to 7 kg)
Spin Reduction
(1400 to 400 rpm, No Spin,
Rinse Hold) /
-
(Iron Dry, Cupboard Dry,
Extra Dry)
2)
2)
/ /
Three rinses
with softener
Spin phase
Dry (If drying
option
combined)
-
-
-
The wool wash cycle of this machine has been approved by The Woolmark
Company for the washing of machine washable wool products provided
that the products are washed according to the instructions on the garment
label and those issued by the manufacturer of this machine.
M1354
WOOLMARK CERTIFICATE
4) Anti allergen ( ) program is available on Cottons 60 °C with vapour action option for up to 4kg load.
1)
Spin Reduction
(1200 to 400 rpm, No Spin,
Rinse Hold, Extra Silent) /
/ / /

14 www.electrolux.com
Level of dryness Type of fabric Load
Extra Dry
Ideal for towelling
materials
Suitable for items
to put away
without ironing
Cotton and linen
(bathrobes, bath towels, etc) up to 7 Kg.
Cupboard Dry
Suitable for ironing
Iron Dry
Cotton and linen
(bathrobes, bath towels, etc)
Synthetics and mixed fabrics
(jumpers, blouses, underwear, household linen)
Cotton and linen
(sheets, tablecloths, shirts, etc.)
up to 7 Kg.
up to 7 Kg.
up to 3 Kg.
3.16 Dryness Option Guides
Type of fabric Load
(Kg)
Spin Speed
(rpm)
Suggested
Times (mins)
Cotton and linen
(bathrobes, bath towels, etc.).
3.17 Manual Dry Time Option Guides
7
5
2
1400
1400
1400
240 - 250
120 - 180
60
Synthetic or mixed fabric items
( jumpers, blouses, underwear,
household linen, etc.).
Wool and hand washable wool.
3
1
1200
1200
120 - 180
60
1 1200 120
The drying time can vary
according to
the final spin speed;
the required degree of drying
(Extra Dry or Cupboard Dry or
Iron Dry);
the type of laundry;
the size of load
3.18 Duration of the drying cycle 3.19 Fibre residue
After drying fluffy fabrics, such
as new towels, it is advisable
to perform a Rinse program to
be sure that any residue that
may remain in the tub is
completely removed and does
not stick to garments dried
afterwards. After each
drying cycle, clean the
drain pump filter. Please
refer to care and cleaning
in section 10.

ENGLISH 15
To prevent the formation of
creases or shrinking of
fabrics, avoid excessive
drying.
WARNING!
Should the laundry still be too
wet at the end of the program,
set another short drying cycle.
The final part of a washer-
dryer cycle occurs without
heat (cool down cycle). This
ensures the laundry will be
left at a low temperature.
3.20 Additional drying 3.21 Buzzer Sounds
The program is completed.
The appliance has a malfunction.
The buzzer sounds operate when:
If you want to disable the buzzer
sound (except for event of
appliance malfunction), press
“Dryness” and “Vapour” touchpads
at the same time for 3 seconds,
and listen for ‘BEEP, BEEP’.
To return to default configuration
press these 2 touchpads at the
same time for 3 seconds, and listen
for ‘BEEP’.
The message “Set dosage
detergent” comes on in the text bar.
Press repeatedly to set the
detergent dosage to maximum
manufacturer recommendation on
the packaging which is the 100%
equivalent.
For the maximum detergent quantity
see the detergent manufacturer
recommendation on packaging.
Press to confirm.
BEFORE FIRST USE4.
Ensure that the electrical and water
connections comply with the
installation instructions.
Put 2 litres of water in the detergent
compartment for washing phase.
This activates the drain system.
1.
2.
3. Select a Cottons cycle at 90 °C,
without any laundry in the machine,
to remove any manufacturing residue
from the drum and tub. Pour 1/2 a
measure of detergent into the
dispenser drawer and start the
machine.
The text bar also gives the indication
about the detergent quantity, when
the door is closed after the laundry
load.
You can set the indication as ml to
have more precision, by pressing
and at the same time for some
seconds.
By default, the detergent quantity
indication is given as a percentage.
100% is the maximum detergent
quantity that you can put in the
compartment of the detergent drawer.
Detergent Quantity Setting

16 www.electrolux.com
DAILY USE - WASHING5.
Step 1 - Setting A Program
1
3
5
4
5.1 Four Steps Start Up Guide
Connect the mains plug to the mains socket.
Turn the water tap on.
2
pess the Spin ‘ ’ and the temperature
‘ ’ touchpads repeatedly to change
the spin speed and temperature.
1.
Press the On/Off button to turn on the
washer-dryer.
3.
If you want your laundry to be spun or
use temperature different from the one
proposed by the washer-dryer,
4.
Press the option touchpads, if you want
your laundry to be washed or dryed
with special functions.
Different functions can be
combined which is dependent
on the program selected.
2.
Touch one of the Program ICONS, to
choose the wash or dry program you
require.
The relevant light will light up.
-
Once you selected a program, the
program selected will stay at that
position for the whole of the cycle.
-
The display shows the level of the
‘Time Manager’, the program duration
and the indicators of the phases of the
program.
-
5.
When these touchpads are pressed,
the corresponding pilot lights come on.
When they are pressed again, the pilot
lights go out.
If you want to reduce washing time,
press the ‘Adjust Time ’ touchpad
repeatedly to reduce the time.
If you want to delay the start of the
program
, press the ‘Delay Start ’
touchpad repeatedly to choose your
washer-dryer delay time.
For a correct operation of the
weight sensor, activate the
appliance and set a wash program
BEFORE loading the laundry in the
drum.

ENGLISH 17
Make sure that no laundry
remains between the seal and
the door.
4.
Close the door.
5.
Step 2 - Loading The Laundry
Open the door by carefully pulling
the door handle outwards.
Check and remove objects (if
there are any) that could be
trapped in the fold.
2.
This machine has “Load Sensing
Device” which shows how much
load you put in the machine and
maximum load recommended for
selected wash program.
The display will show “Loading
completed” when max limit is
reached for selected program.
On the display, the weight of the
laundry updates by 0.5 kg steps.
The weight is a general indication
that changes with the type of the
laundry.
Maximum load capacity
of selected program.
Load Weight
Place the laundry in the drum,
one item at a time, shaking them
out as much as possible.
3.
The weight shown on
display is an approximate
weight only.
The display shows these
indicators when the door is
open.
Wash bras, pantyhose and other
delicates in a mesh laundry bag,
which you can purchase from
your supermarket.
1.
Make sure that you wash lint
collectors separately from lint
producers.
IMPORTANT!
Button up pillowcases, close zip
fasteners, hooks and poppers.
Tie any belts or long tapes.
Make sure that no metal
objects are left in the laundry
(e.g. hair clips, safety pins,
pins).
Before loading the laundry, please
make sure:

18 www.electrolux.com
Measure out the amount of
detergent required, pour it into
the main wash compartment
( ).
Step 3 - Using Detergent And Additives
Detergent Dispenser Drawer
1.
The detergent dispenser is divided
into three compartments.
Compartment ‘SOFTENER’
Compartment ‘PREWASH’
This compartment is used for
fabric conditioner and starching
agent.
This compartment is only used
for detergent when a Prewash
is selected.
-
-
Compartment ‘MAIN WASH’
This compartment is used for
detergent on all programs.
Detergent flap
Flap for powder or liquid
detergent.
-
Powder or liquid detergent.
3
1
POSITION USING
POWDER DETERGENT
Position down :
for liquid
detergent.
Position up :
for powder
detergent
(factory setting).
2
Position down :
for liquid
detergent.
Position up :
for powder
detergent
(factory setting).
Do not use gelatinous or thick
liquid detergents.
-
Do not put more liquid than
the maximum level.
-
Do not set the DELAY START.
-
Do not set the PREWASH
phase.
-
When you use the liquid
detergent:
Pull out the dispenser drawer
until it stops.
-
-
Measure out the detergent and
the fabric softener;
2.

ENGLISH 19
If you wish to carry out the
“Prewash” phase, pour it into
the compartment marked .
If required, pour fabric softener
into the compartment marked
(the amount used must not
exceed the “MAX” mark in the
drawer).
-
Close the drawer gently.
After washing cycle finish,
residues of detergent,
softener and water may
remain in the dispenser. It is
recommended to clean the
dispenser regularly to
remove any residue.
-
-
The appliance will automatically
adjust the selected program
duration according to the type and
size of the load.
-
The display will show adjusted
program duration.
-
Step 4 - Starting a program
To start a program, press the Start/
Pause ( ) touchpad, the correspond-
ing pilot light will stop flashing and a
default program duration will be
displayed on the screen.
After approx. 15 minutes from
the start of a program:
If you use thick softeners
it is recommended to
dilute with water.
To pause press Start/ Pause. The
indicator will start flashing.
-
Press the Start/Pause again. The
program will continue.
-
Changing a running program is possible
only by switching off the appliance.
Press the ‘On/Off’ button to cancel the
program and to turn off the appliance.
-
5.2 Interruption Of A Program
5.3 Changing A Program
It is possible to change only some
option after the program has
started.
Press the touchpad Start/Pause.
The indicator will start flashing.
1.
Change the options.2.
Press Start/Pause again. The
program will continue.
3.
Press the ‘On/Off’ button again to start
the appliance. Now, you can set a new
washing program.
The appliance will not drain the
water.
-
5.4 Changing The Options

20 www.electrolux.com
At the end of the program the
time remaining can suddenly
decrease from 7 minutes or less
to 0 due to the overestimated
total program time during the
load sensing phase. In some
cases (with perfectly balanced
load) the program time can be
shorter than the time estimated
after the load sensing phase is
completed. This is a normal
behavior of the machine and not
a cause for concern as it does
not compromise its performance.
When the program is completed
and the door lock indicator ‘ ’
goes off, you can open the door.
While a program or the Delay Start
is operating, the appliance door is
locked and the display shows the
indicator ‘ ’.
First set the machine to PAUSE by
pressing the “Start/Pause” touchpad.
Wait until the door lock indicator ‘ ’
goes off, then the door can be opened.
If the door lock indicator ‘ ’ does not
disappear, this means that the machine
is already heating and the water level is
above the bottom edge of the door or
the drum is turning. In this case the door
CAN NOT be opened.
If you can not open the door but you
need to open it you have to switch the
machine off by pressing the ‘On/Off’
button to deactivate the appliance. After
about 5 minutes the door can be
opened.
Pay attention to the water
level and water temperature.
CAUTION!
1.
3.
2.
When The Washing Program
Is Completed, But There Is
Water In The Drum
The drum turns regularly to
prevent the creases in the
laundry.
You must drain the water to open
the door.
The door lock indicator ‘ ’ is
on. The door stays locked.
To drain the water:
Press the touchpad Start/Pause.
The appliance will drain the
water and spin.
If necessary, decrease the spin
speed.
Set the “Spin” program.
4.
Press the ‘On/Off’ button to
deactivate the appliance.
5.
-
-
5.5 Opening The Door
5.7
The appliance stops automatically.
The acoustic signal will operate.
The display will show ‘ ’.
The indicator of the touchpad
Start/Pause goes off.
-
-
-
-
-
-
-
-
The door lock indicator ‘ ’
goes off.
Remove the laundry from the
appliance. Make sure that the
drum is empty.
Keep the door ajar, to prevent the
mildew and odours.
Turn off the water tap.
5.6 At The End Of The Program
AUTO Stand-by Option
5.8
The AUTO Stand-by option
automatically deactivates the
appliance to decrease the energy
consumption when:
