Electrolux EW9W1165RC User manual

EW9W1165RC
EN User Manual | Washer Dryer

Welcome to Electrolux! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 6
3. PRODUCT DESCRIPTION............................................................................. 8
4. TECHNICAL DATA......................................................................................... 8
5. INSTALLATION...............................................................................................9
6. ACCESSORIES............................................................................................ 14
7. CONTROL PANEL........................................................................................ 15
8. DIAL AND BUTTONS....................................................................................17
9. PROGRAMMES............................................................................................ 19
10. BEFORE FIRST USE..................................................................................26
11. SETTINGS.................................................................................................. 26
12. DAILY USE..................................................................................................27
13. DAILY USE - WASHING & DRYING...........................................................32
14. DAILY USE - DRYING ONLY......................................................................33
15. FLUFF IN THE FABRICS............................................................................34
16. HINTS AND TIPS........................................................................................ 35
17. CARE AND CLEANING.............................................................................. 37
18. TROUBLESHOOTING................................................................................ 45
19. CONSUMPTION VALUES.......................................................................... 49
20. ENVIRONMENTAL CONCERNS................................................................51
1. SAFETY INFORMATION
Before beginning the installation and use of this
appliance, carefully read the supplied instructions.
The manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or usage.
Always keep the instructions in a safe and accessible location
for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
2 ENGLISH

• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep detergents away from children.
• Keep children and pets away from the appliance when the
door is open.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for washing and drying domestic-type
machine-washable and dryable laundry only.
• Do not use the dryer function if laundry has been soiled with
industrial chemicals.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• Do not change the specification of this appliance.
ENGLISH 3

• The appliance shall be installed as a freestanding product
or below the kitchen worktop if space margins permit.
• Do not install the appliance behind a lockable door, a sliding
door or a door with a hinge on the opposite side, that would
prevent the appliance door from being fully open.
• Connect the mains plug to the mains socket only at the end
of the installation process. Make sure that the mains plug is
accessible after installation.
• The ventilation opening in the base must not be covered by
a carpet, mat, or any floor covering.
• WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
• Ensure good air ventilation in the room where the appliance
is installed to avoid the backflow of unwanted gases into the
room from appliances burning gas or other fuels, including
open fires.
• Exhaust air must not be discharged into a flue which is used
for exhausting fumes from any appliances burning gas or
other fuels.
• The operating water pressure at the water entry point from
the outlet connection must be between 0.5 bar (0.05 MPa)
and 10 bar (1.0 MPa).
• The appliance maximum load is 10.0 kg. Do not exceed the
maximum load of each programme (refer to the
"Programmes" chapter).
• The appliance must be connected to the water mains using
the new supplied hose sets, or other new hose sets
supplied by the Authorised Service Centre.
• Old hose sets must not be reused.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
• Wipe away lint or packaging debris that has accumulated
around the appliance.
4 ENGLISH

• Do not run the appliance without filters. Clean the lint filter
before or after each use.
• Items that have been soiled with substances such as
vegetable or mineral oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers should
be washed separately with an extra amount of detergent
before being dried in the washer dryer.
• Do not use the appliance if items have been soiled with
industrial chemicals.
• Do not dry unwashed items in the wash dryer.
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, and rubber backed articles and clothes,
or pillows fitted with foam rubber pads should not be dried
in the washer dryer.
• Fabric softeners, or similar products, should only be used
as specified by the product manufacturer’s instructions.
• Remove all objects from items that could be a source of fire
ignition such as lighters or matches.
• WARNING: Never stop the washer dryer before the end of
the drying cycle unless all items are quickly removed and
separated so that residual heat can dissipate.
• The final part of the washer dryer cycle takes place without
heat (cool down cycle) to ensure that items reach a
temperature that will not cause damage to them.
• Do not use high pressure water sprays and/or steam to
clean the appliance.
• Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
• Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the socket.
ENGLISH 5

2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply with
relevant national regulations.
• Follow the installation instructions supplied
with the appliance.
• Do not install or use the appliance where
the temperature can be less than 5°C or
higher than 35 °C.
• Always keep the appliance vertical when it
is being moved.
• To make sure the compressor works
properly, wait 6 hours after the installation
before using the appliance.
• Make sure that there is air circulation
between the appliance and the floor.
• Remove all the packaging and the transit
bolts.
• The floor area on which the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Keep the transit bolts in a safe place. If the
appliance is to be moved in the future they
must be reattached to lock the drum to
prevent an internal damage.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Do not install the appliance where the
appliance door cannot be fully opened.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• When the appliance is in its permanent
position, check if it is levelled correctly
with the aid of a spirit level. If it is not,
adjust the feet accordingly.
2.2 Electrical Connection
WARNING!
Risk of fire and electric shock.
• WARNING: This appliance is designed to
be installed / connected to a grounding
connection in the building.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Do not touch the mains cable or the mains
plug with wet hands.
2.3 Water Connection
• The inlet water shall not exceed 25 °C.
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not
used for a long time, where repair work
has been carried out or new devices fitted
(water meters, etc.), let the water flow until
it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of the
appliance.
• Do not use an extension hose if the inlet
hose is too short. Contact the Authorised
Service Centre for the replacement of the
inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing of the
appliance with the use of water in the
factory.
• You can extend the drain hose to
maximum 400 cm. Contact the Authorised
Service Centre for the other drain hose
and the extension.
• Make sure that there is access to the tap
after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock, fire, burns
or damage to the appliance.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
• Do not touch the glass door while a
programme operates. The glass can get
hot.
• Do not dry damaged (torn, frayed) items
that contain padding or fillings.
6 ENGLISH

• If laundry has been washed with a stain
remover, carry out an additional rinse
cycle before starting a drying cycle.
• Make sure that all metal objects are
removed from the laundry.
• Dry only fabrics that are suitable to dry in
the appliance. Follow the cleaning
instruction on the item label.
• Do not sit or stand on the open door of the
appliance.
• Do not dry dripping wet clothes in the
appliance.
• Do not let hot items to touch the plastic
parts of the appliance.
• Remove a detergent ball (if used) before
starting a drying programme.
• Do not use a detergent ball if setting a
non-stop programme.
2.5 Compressor
WARNING!
Risk of damage to the appliance.
• The compressor and its system in the
washer-dryer is filled with the special
agent which is free from fluoro-
chlorohydrocarbons. This system must
stay tight. The damage of the system can
cause a leakage.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts are available for
at least 10 years after the model has been
discontinued: motor and motor brushes,
transmission between motor and drum,
pumps, shock absorbers and springs,
washing drum, drum spider and related
ball bearings, heaters and heating
elements, including heat pumps, piping
and related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware including
reset software, door, door hinge and
seals, other seals, door locking assembly,
plastic peripherals such as detergent
dispensers. The duration may be longer in
your country. For further information,
please visit our website.
• Please note that some of these spare
parts are only available to professional
repairers, and that not all spare parts are
relevant for all models.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.7 Disposal
• Disconnect the appliance from the mains
electrical and water supplies.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door catch to prevent children
or pets from becoming trapped in the
drum.
• Dispose of the appliance in accordance
with local requirements for the disposal of
Waste Electrical and Electronic Equipment
(WEEE).
ENGLISH 7

3. PRODUCT DESCRIPTION
3.1 Appliance overview
1 32 4 11
6
7
8
9
5
12
10
13 14
1Worktop
2Detergent dispenser
3Air filter(s)
4Control panel
5Door handle
6Rating plate
7Drain pump filter
8Feet for levelling the appliance
9Airflow slots
10 Water drain hose
11 Water inlet valve
12 Mains cable
13 Transit bolts
14 Hose supports
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate
6
reports the model name (A),
product number (B), electrical ratings (C) and serial
number (D)).
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59.7 cm /87.0 cm /66.0 cm
8 ENGLISH

Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2100 W
10 A
50 Hz
Level of protection against ingress of solid particles and moisture
ensured by the protective cover, except where the low voltage
equipment has no protection against moisture
IPX4
Water supply 1) Cold water
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Ambient temperature Minimum
Maximum
5 °C
35 °C
Maximum wash load Cotton
Synthetics
Wool
10.0 kg
4.0 kg
1.5 kg
Maximum dry load Cotton
Synthetics
Wool
6 kg
4 kg
1 kg
Spin Speed Maximum spin speed 1551 rpm
This product contains HFC - R134a/GWP1430 0.14 kg fluorinated gas hermetically sealed.
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
WARNING!
Remove all the packaging and the transit
bolts before installing the appliance.
WARNING!
As you will put down the appliance on the
rear side, wait about 6 hours before
you use it. This time is necessary to
enable the compressor to work properly.
WARNING!
Use the gloves.
1. Remove the external film. If necessary,
use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
3. Remove the internal film.
ENGLISH 9

4. Open the door and remove the
polystyrene piece from the door seal and
all the items from the drum.
5. Carefully put the appliance down on its
rear side.
6. Put the front polystyrene packaging
element on the floor under the appliance.
Make sure not to damage the hoses.
7. Remove the polystyrene protection from
the bottom.
1
2
8. Pull up the appliance in vertical position.
9. Remove the power supply cable and the
drain hose from the hose holders.
It is possible to see water flowing
from the drain hose. This is due to
the testing with water of the appliance
in factory.
10. Remove the three bolts by using the
spanner supplied with the appliance.
10 ENGLISH

11. Pull out the plastic spacers.
12. Put the plastic caps, that you find in the
user manual bag, in the holes. We recommend that you keep the
packaging and the transit bolts for any
movement of the appliance.
5.2 Installation under a counter
630 mm
600 mm
≥ 870 mm
The appliance can be installed as freestanding or
below the kitchen counter with correct space (see
picture).
CAUTION!
Do not install the appliance inside a sealed
hollow!
Make sure that there is air circulation throw
the bottom of the furniture.
CAUTION!
To assure free air circulation under the
appliance, do not attach the sound barriers
(if available).
5.3 Positioning and levelling
1. Install the appliance on a flat hard floor.
Make sure that carpets do not stop the
air circulation below the appliance.
Make sure that the appliance does not
touch the wall or other units.
2. Loosen or tighten the feet to adjust the
level.
WARNING!
Do not put cardboard, wood or equivalent
materials below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
ENGLISH 11

A correct adjustment of the appliance
level prevents the vibration, noise and
the movement of the appliance when in
operation.
When the appliance is installed on a
plinth, use the accessory described in
chapter 'Accessories'. Read carefully the
instructions supplied with the appliance
and with the accessory.
5.4 The inlet hose
1. Connect the water inlet hose to the back
of the appliance.
2. Position it toward left or right depending
on the position of the water tap.
20º20º
45º45º
Make sure that the inlet hose is not in
vertical position.
3. If necessary, loose the ring nut to set it in
the correct position.
4. Connect the water inlet hose to the cold
water tap with 3/4" thread.
WARNING!
The inlet water shall not exceed 25 °C.
CAUTION!
Make sure that there are no leaks from
the couplings.
Do not use an extension hose if the inlet
hose is too short. Contact the service
centre for the replacement of the inlet
hose.
5.5 Water-stop device
The inlet hose has a water stop device. This
device prevents water leaks in the hose
because of its natural ageing.
The red sector in the window «A» shows this
fault.
A
If this occurs, close the water tap and contact
the authorized service centre to replace the
hose.
5.6 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not more
than 100 cm from the floor.
12 ENGLISH

You can extend the drain hose to
maximum 400 cm. Contact the
authorized service centre to buy the other
drain hose and the extension.
It is possible to connect the drain hose in different ways:
min.600 mm
max.1000 mm
• Connect the drain hose to the spigot and
tighten it with a clamp.
• Position the hose directly to a built-in drain
pipe in the room wall and tighten it with a
clamp.
• Without the plastic hose guide, to a sink
spigot - put the drain hose in the spigot
and tighten it with a clamp.
• To a stand pipe with vent hole - insert the
drain hose directly into a drain pipe or
stand pipe.
• The drain hose can be bent into U shape
and put around the plastic guide. On the
edge of a sink - fasten the guide to the
water tap or to the wall.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
Make sure that the plastic guide cannot
move when the appliance drains and the
drain hose end is not immersed in the
water. There may be a return of dirty
water into the appliance. Buy accessories
from authorised supplier.
The end of the drain hose must always
be ventilated , i.e. the inner diameter of
the drain pipe (min. 38 mm - min. 1.5")
must be larger than the external diameter
of the drain hose.
5.7 Electrical connection
At the end of installation you can connect the
mains plug to the mains socket.
ENGLISH 13

The rating plate and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are compatible
with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any other
appliances in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install this
appliance, contact our Authorised Service
Centre.
The manufacturer does not accept any
responsibility for damage or injury through
failure to comply with the above safety
precaution.
6. ACCESSORIES
6.1 Available in
www.electrolux.com/shop or from
authorised dealer
Read carefully the instructions supplied with
the accessory.
Only appropriate accessories approved
by ELECTROLUX ensure the safety
standards of the appliance. If unapproved
parts are used, any claims will be
invalidated.
6.2 Fixing plate kit
If you install the appliance on a plinth that is
not an accessory supplied by ELECTROLUX,
secure the appliance in the fixing plates.
Read carefully the instructions supplied with
the accessory.
14 ENGLISH

7. CONTROL PANEL
7.1 Control panel description
23
6
12 11 10 8
1
4
5
7
9
13
1Programme dial
2Display
3Drying time touch button (Minuterie)
4Drying level touch button (Niveau
séchage)
5Washing and drying mode touch button
(Mode)
• Lavage
• Séchage
6Start and pause touch button (Départ/
Pause)
7Delay Start touch button (Départ Différé)
8Time Saving touch button (Time
Manager)
9Anti-crease touch button (Antifroissage)
10 Anti-stain and prewash touch button
(Taches/Prélavage)
11 Spin reduction touch button (Essorage)
12 On/Off push button (Marche/Arrêt)
13 Temperature touch button (Température)
7.2 Display
ENGLISH 15

Maximum load indicator. The icon flashes during laundry load estimation (refer to
"PROSENSE load detection" paragraph).
Maximum laundry indicator. It flashes when the laundry load exceeds the maximum de‐
clared load of the selected programme.
Child safety lock indicator.
Drying time indicator.
Door locked indicator.
The digital indicator can show:
• Programme duration (e. g. , washing and/or drying phase).
• Delay time (e. g. or ).
• Cycle end ( ).
• Warning code (e.g. ).
Washing phase indicator: it flashes during prewash and wash phase.
Rinsing phase indicator. It flashes during rinse phase.
The permanent Extra Rinse option:
• - one additional rinse.
• - two additional rinses.
Spin and drain phase indicator. It flashes during spin and drain phase.
Steam phase indicator.
Drying phase indicator.
Indicator for the cleaning of air filters.
Iron drying indicator.
Cupboard drying indicator.
Extra drying indicator.
Temperature indicator. The indicator appears when a cold wash is set.
Spin speed indicator.
Rinse hold indicator.
16 ENGLISH

Extra silent indicator.
Pre-wash indicator.
Stain indicator.
Delay start indicator.
8. DIAL AND BUTTONS
8.1 Marche/Arrêt
Pressing this button for a few seconds allows
to activate or deactivate the appliance. Two
different tunes sound while switching the
appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease the
energy consumption in a few cases, you may
need to activate the appliance again.
For more details, refer to Stand-by paragraph
in Daily Use chapter.
8.2 Introduction
The options/functions are not selectable
with all washing programmes. Check the
compatibility between options/functions
and washing programmes in the
"Programme Chart". An option/function
can exclude another one, in this case the
appliance doesn't allow you to set the
incompatible options/functions together.
Make sure the screen and touch buttons
are always clean and dry.
8.3 Température
When you select a washing programme, the
appliance automatically proposes a default
temperature.
Touch this button repeatedly until the desired
temperature value appears on the display.
When the display shows the indicators
and , the appliance does not heat the
water.
8.4 Essorage
When you set a programme, the appliance
automatically selects the default spin speed.
Touch this button repeatedly to:
•Change the spin speed.
The display shows only the spin
speeds available for the set
programme.
•Activate the Rinse Hold option .
The water of the last rinse is not drained
out to prevent the fabrics from creasing.
The washing programme ends with water
in the drum and the final spin phase is not
performed.
The display shows the indicator .
The drum turns regularly to reduce
creasing.
The door stays locked. The drum turns
regularly to reduce creasing. You must
drain the water to unlock the door.
Touch Départ/Pause button: the appliance
performs the spinning phase and drains
the water.
•Activate the Extra silent option.
All spinning phases (intermediate spin and
final spin) are suppressed and the
programme ends with water in the drum.
This helps to reduce creasing.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are available. In
some programmes the rinses are
performed with more water.
The display shows the indicator .
ENGLISH 17

The door stays locked. The drum turns
regularly to reduce creasing. You must
drain the water to unlock the door.
Touch the Départ/Pause button: the
appliance performs only the draining
phase.
The appliance empties the water out
automatically after approximately 18
hours.
8.5 Taches/Prélavage
Press this button repeatedly to activate one of
the two options.
The relevant indicator goes on in the display.
•Taches
Select this option to add an anti-stain
phase to a programme in order to treat
heavily soiled or stained laundry with stain
remover.
Pour the stain remover into compartment
. The stain remover will be added in
the appropriate phase of the washing
programme.
This option can increase the
programme duration.
This option is not available with a
temperature lower than 40 °C.
•Prélavage
Use this option to add a prewash phase at
30 °C before the washing phase.
This option is recommended for heavily
soiled laundry, especially if containing
sand, dust , mud and other solid particles.
This option can increase the
programme duration.
These two options cannot be set
together.
8.6 Départ Différé
With this option you can delay the start of a
programme in a more convenient time.
Tap on the button repeatedly to set the
required delay. The time increases by steps
of 30 minutes up to 90' and from 2 hours up
to 20 h.
After starting the cycle by the means of the
Départ/Pause button, the display shows the
selected delay time and the appliance begins
the countdown.
8.7 Time Manager
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly soiled,
it may be advisable to shorten the washing
programme. Touch this button once to
decrease the duration.
• In case of smaller load, touch this button
twice to set an extra quick programme.
On the display the programme duration is
adjusted accordingly.
When this button is set, the led above the
button is on.
This option can also be used to shorten
the steam programme duration.
8.8 Antifroissage
This option adds a short anti-crease phase at
the end of the programme.
This phase reduces fabric creasing and
facilitates the fabric ironing.
When this option is set, the led above the
button is on and then blinks during anti-
crease phase.
This option can increase the programme
duration.
By touching any button the anti-crease
movements stop and the door unlocks.
To interrupt the anti-crease phase, you can
also:
18 ENGLISH

• Press the Marche/Arrêt button for a few
seconds to activate or the deactivate the
appliance.
• Turning the programme dial in another
position.
8.9 Minuterie
In the programme where it is selectable,
touch this button to set the time that suits the
fabrics you have to dry (refer to "Timed
drying" table). The display shows the set
value.
Each time you touch this button the time
value increases by 5 minutes.
You cannot set all time values for
different types of fabrics.
8.10 Niveau séchage
Touch this button to set one of 3 automatic
dryness levels proposed by the appliance.
On the display the relevant dryness indicator
goes on:
• Iron dry: laundry to be ironed.
• Cupboard dry: laundry to be
put in store.
• Extra dry: laundry to be fully
dried.
You can not set all automatic levels
for each type of fabrics.
8.11 Mode
Thanks to this button, a cycle can perform:
•Only washing : Lavage indicator is on.
•Washing and drying : Lavage and
Séchage indicators are on.
•Only drying : Séchage indicator is on.
8.12 Départ/Pause
Touch the Départ/Pause button to start,
pause the appliance or interrupt a running
programme.
9. PROGRAMMES
9.1 Programme Chart
Additional programmes and settings are available downloading the APP.
ENGLISH 19

Programme
Default temperature
Temperature range
Reference spin
speed
Spin speed range
Maxi‐
mum
load
Programme description
Eco 40-60 (Wash only
mode)
40 °C1)
1600 rpm
1600 rpm - 400 rpm 10.0 kg
White cotton and fast-coloured cotton. Normally
soiled items.
Eco 40-60 + Cupboard
dry level (Wash & Dry
mode)
40 °C2)
1600 rpm
1600 rpm -1000 rpm 6 kg
Eco 40-60 + Cupboard
dry level (Dry only
mode)
- 6 kg White cotton and fast-coloured cotton.
Coton
40 °C
95 °C - Cold
1600 rpm
1600 rpm - 400 rpm 10.0 kg
White cotton and coloured cotton. Normally,
heavily and lightly soiled items.
Synthétiques
40 °C
60 °C - Cold
1200 rpm
1200 rpm - 400 rpm 4.0 kg
Synthetic items or mixed fabric items. Normally
soiled items.
Délicats
30 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm 2.0 kg
Delicate fabrics such as acrylics, viscose and
mixed fabrics requiring gentler washing. Nor‐
mally and lightly soiled items.
Soie
30 °C
1000 rpm
1000 rpm - 400 rpm 0.5 kg
Special programme for silk and mixed synthetic
items.
Laine/à la main
40 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm 1.5 kg
Machine washable wool, hand washable wool
and other fabrics with «hand washing» care sym‐
bol3).
Propre & Sec 3h/3kg
30 °C
40 °C - 30 °C
1200 rpm 3.0 kg Mixed fabrics (cotton and synthetic items).
Complete programme to wash and dry laundry
loads up to 3 kg in one go. It only lasts 3 hours.
Also, the indicator appears on the display.
20 ENGLISH
