Electrolux E24WC160ES - Icon Wine Coolers Operating manual

Publication #5995543203 July 2009
Technical Service Manual
Wine Cellar

Basic Information
1-1
Safe Servicing Practices For All Appliances
Avoid personal injury and/or property damage by observing important Safe Servicing Practices.
Following are some limited examples of safe practices:
1. DO NOT attempt a product repair if you have any doubts as to your ability to complete the repair in a safe and
satisfactory manner.
2. Always use the correct Replacement Parts as indicated in the parts documentation. Substitutions may defeat
compliance with Safety Standards Set For Home Appliances. Do not exceed maximum recommended wattage on
light bulb replacements. Doing so could blow fuses and/or damage transformers.
3. Before servicing or moving an appliance:
• Remove power cord from the electrical outlet, trip circuit breaker to the OFF position, or remove fuse.
• Turn off water supply if applicable.
• Turn off gas supply if applicable.
4. Never interfere with the proper operation of any safety device.
5. Use ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE. Substitutions may defeat
compliance with Safety Standards Set For Home Appliances.
6. GROUNDING: The standard color coding for safety ground wires is GREEN, or GREEN with YELLOW STRIPES.
Ground leads are not to be used as current carrying conductors. It is EXTREMELY important that
the service technician reestablish all safety grounds prior to completion of service. Failure to do so will create
a hazard.
7. Prior to returning the product to service, ensure that:
• All electrical connections are correct and secure.
• All electrical leads are properly dressed and secured away from sharp edges, high-temperature components,
and moving parts.
• All non-insulated electrical terminals, connectors, heaters, etc. are adequately spaced away from all metal
parts and panels.
• All safety grounds (both internal and external) are correctly and securely connected.
• All panels are properly and securely reassembled.
© 2009 Electrolux Home Products, Inc.
ATTENTION!!!
This service manual is intended for use by persons having electrical and mechanical training and a level
of knowledge of these subjects generally considered acceptable in the appliance repair trade. Electrolux
Home Products, Inc. cannot be responsible, nor assume any liability, for injury or damage of any kind
arising from the use of this manual.

Basic Information
This Manual has been prepared to provide Electrolux Service Personnel with Operation and
Service Information for an Electrolux ICON Wine Cellar Model #E24WC160ES.
Table of Contents
1-2
Section 1 Basic Information ................................. 1-1
Safe Servicing Practices For All Appliances............. 1-1
Table of Contents...................................................... 1-2
Important Safety Instructions.................................... 1-3
Safety Precautions ................................................ 1-3
Definitions.............................................................. 1-3
General Safety ...................................................... 1-3
Child Safety ........................................................... 1-3
Proper Disposal of Refrigerators........................... 1-3
Warranty ................................................................... 1-4
Data Plate................................................................. 1-5
Model Number Breakdown....................................... 1-5
Serial Number Breakdown........................................ 1-5
Shipping Damage..................................................... 1-5
Questions? ............................................................... 1-5
Accessories .............................................................. 1-5
Section 2 Installation.............................................. 2-1
Installation ................................................................ 2-1
Electrical Information................................................ 2-3
Installation Of Guides And Shelf Supports ............... 2-4
Section 3 Operation and Maintenance ................. 3-1
Temperature Setting ................................................. 3-1
Maintenance............................................................. 3-1
How To Store Different Types Of Bottles................... 3-1
Mix Bottle Types........................................................ 3-2
Sliding Shelf.............................................................. 3-2
Section 4 Sealed System ....................................... 4-1
Warnings and Important Notes................................. 4-1
Introduction............................................................... 4-2
The Absorption System ............................................ 4-2
Description of Function............................................. 4-3
Boiler ..................................................................... 4-3
Condenser............................................................. 4-3
Evaporator............................................................. 4-3
Absorber................................................................ 4-3
Important ............................................................... 4-3
Description of Function............................................. 4-3
Electric Thermostat ............................................... 4-3
Gas Thermostat..................................................... 4-3
Thermocouple ....................................................... 4-3
Gas Control Valve.................................................. 4-3
Gas Filter............................................................... 4-3
Piezo Ignition......................................................... 4-3
Burner ................................................................... 4-3
Re-ignitor............................................................... 4-4
Flue Baffle ............................................................. 4-4
Burner Jet.............................................................. 4-4
Gas Components...................................................... 4-4
Electrical Components.............................................. 4-4
Section 5 Troubleshooting.................................. 5-1
Troubleshooting Chart ............................................ 5-1
Poor Cooling In All Modes ...................................... 5-2
No Cooling On 230V AC......................................... 5-3
Poor Cooling On 230V AC...................................... 5-3
No Cooling On 12V DC .......................................... 5-3
Poor Cooling On 12V DC........................................ 5-4
No Cooling On Gas But Cooling On 230V AC........ 5-4
Flame Does Not Ignite............................................ 5-5
Flame Does Not Stay On........................................ 5-6
Poor Cooling On Gas But Normal
Cooling On 230V AC .............................................. 5-7
Freezer Flap Does Not Close ................................. 5-9
Section 6 Parts List & Exploded Views.............. 6-1
Exploded View ........................................................ 6-1
Parts List ................................................................ 6-2
Section 7 Wiring Diagram ................................... 7-1
Wiring Diagram....................................................... 7-1

Basic Information
1-3
Important Safety Instructions
Safety Precautions
Do not attempt to install, operate or service the unit until
you have read the safety precautions in this manual.
Safety items throughout this manual are labeled with a
Danger, Warning, or Caution based on the risk type.
Definitions
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid possible
injury or death.
General Safety
• Do not store or use gasoline or other flammable
liquids near this or any other appliance.
Read product labels for warnings regarding
flammability and other hazards.
• Do not operate the refrigerator in the presence of
explosive fumes.
• Avoid contact with any moving parts of the automatic
ice maker.
• Remove all staples from the carton to avoid injury.
Staples can also damage finishes if they come in
contact with other appliances or furniture.
Child Safety
Packing Materials:
• Packing cartons covered with rugs, bedspreads,
plastic sheets, or stretch wrap may become airtight
chambers and can quickly cause suffocation.
• Destroy or recycle the product’s carton, plastic bags,
and any other exterior wrapping material immediately
after the unit is unpacked. Children should never
play with these items.
Child Entrapment and Suffocation:
• These problems are not limited to the past.
Whether junked, abandoned, or temporarily stored
(even for a few hours), unattended refrigeration units
are dangerous. Please take the precautions listed
below.
Proper Disposal of Refrigerators/Freezers
Electrolux Home Products Inc. strongly encourages
responsible appliance recycling/disposal methods.
Check with your utility company or visit
www.recyclemyoldfridge.com for more information
on recycling your old refrigeration unit.
Before you recycle or dispose of your old refrigeration
unit:
• Remove the doors.
• Leave the shelves and baskets in place so children
may not easily climb inside.
• Have refrigerant and compressor oil removed by a
qualified service technician.
DANGER INDICATES AN IMMINENTLY
HAZARDOUS SITUATION WHICH, IF NOT AVOIDED,
WILL RESULT IN DEATH OR SERIOUS INJURY.
WARNING INDICATES A POTENTIALLY
HAZARDOUS SITUATION WHICH, IF NOT AVOIDED,
COULD RESULT IN DEATH OR SERIOUS INJURY.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
Indicates installation, operation, or maintenance
information which is important but not hazard
related.

Basic Information
1-4
WINECELLAR WARRANTY The winecellar is protected by this warranty
THROUGH OUR AUTHORIZED SERVICERS,
WE WILL:
FULL ONE-YEAR
WARRANTY
WARRANTY
PERIOD
THE CONSUMER WILL BE
RESPONSIBLE FOR:
One year from
original purchase
date.
Pay all costs for repairing or replacing any parts
of this appliance which prove to be defective in
materials or workmanship.
LIMITED 2nd - 5th
YEAR WARRANTY
(Cabinet Liner and
Sealed System)
LIMITED
WARRANTY
(Applicable to the
State og Alaska)
Costs of service calls
that are listed under
NORMAL RESPONSIBILITIES
OF THE CONSUMER. *
Second through
fifth years from
original purchase
date.
Repair or replace any parts in the cabinet liner or
sealed refrigeration system
(compressor,condenser,evaporator,dryer or
tubing) which prove to be defective in mareials or
workmanship.
Costs for pickup and delivery of
the appliance required because of
service. Costs for labor,parts and
transportation other than with
respect to the cabinet liner or
sealed refrigerator system.
Time periods
listed above.
All of the provisions of the full warranties above
and the exclusions listed below apply.
Costs of the technician´s travel
to the home and any costs for
pick up and delivery of the
appliance required because of
service.
In the U.S.A., your appliance is warranted by Electrolux Home Products, Inc. We authorize no person to change or add to any of our obligations
under this warranty. Our obligations for service and parts under this warranty must be prformed by us or an authorized Electrolux Home
Products, Inc. serviser. In Canada, your appliance is warranted by Electrolux Canada Corp.
This warranty applies only to products in ordinary household use, and the consumer is responsible
for the items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by a licensed and insured professional in accordance with instructions provided
with the appliance and in accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown
fuses, repair of loose connections or defects in house wiring.
4. Expenses for making the applience accessible for servicing, such as removal of trim,
cupboards, shelves, etc., which are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or flourescent tubes ( on models with these features)
This warranty does not cover the following:
1 CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND
INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY
IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential
damages, so this limitation or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for
appliances not in ordinary household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Electrolux Home
products, Inc., Electrolux Canada Corp., or its authorized servicers; use of parts other than
genuine Electrolux Home products parts; obtained from persons other than such
servicers; or external causes such as abuse, misuse, inadeqaute power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and can not be
readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill estab-
lishes the warranty period should service be required. If service is performed, it is in your best interest to
obtain and keep all receipts. This written warranty gives you specific legal rights. You may also have other
rights that vary from state to state. Service under this warranty must be obtained buy contacting Electrolux
Home Products, Inc. or Electrolux Canada Corp.
This warranty only applies in the 50 States of the U.S.A and Puerto Rico, and Canada. Product features or specifications as described or
illustrated are subject to change without notice. All warranties are made by Electrolux Home Products, Inc. In Canada, your appliances is
warranted by Electrolux Canada Corp.
* NORMAL
RESPONSIBILITIES
OF THE CUSTOMER
EXCLUSIONS
IF YOU NEED
SERVICE
USA
877-435-3287
ELECTROLUX HOME PRODUCTS, Inc.
P.O. Box 212378
CANADA
866-213-9397
ELECTROLUX CANADA Corp.
6150 McLaughlin Road
Mississauga, Ontario

Basic Information
Data Plate
Check the data plate inside the wine cellar at the top
left for details on voltage and refrigerant information.
The Model and Serial number will be listed on the data
plate.
1-5
Brand Type
Capacity
Product
Style/
Level
Year
Color
Feature
Wine
Cellar 24 WC 0 EE16S
noitacifitnedItcudorP
rotaregirfeR=A
srezeerF=B
srehsaW=C
sreyrD=D
sretneCyrdnuaL=E
segnaR=F
rehsawhsiD=H
evaworciM=P/G
reifidimuheD=N
4A11
22 3345
Model Number Breakdown
Serial Number Breakdown
Shipping Damage
Inspect the wine cellar for shipping damage.You must
report any damage to the company responsible for the
delivery within the legal or stated time for this type of
product. If there is no such established report time, the
damage must be reported within seven days of
delivery.
Questions?
For toll-free telephone support in the U.S. and Canada:
1-877-4ELECTROLUX ( 1-877-435-3287 )
For online support and internet product information:
Electrolux Platinum Star Service Web Site
(www.electroluxplatinumstarservice.com)
Accessories
Check that the following accessories are attached to the
Wine Cellar or in the separate cardboard box for
accessories which is placed inside the wine cellar.
At the back:
1. Distance bar (to ensure distance to wall behind)
Accessories box:
1. Instruction manual
2. Handle + Socket head screwdriver ( 2 mm )
3. Drip tray
4. Shelf support
5. Storage shelf
6. Wooden bar
Necessary additional tools not included:
1. Screwdriver (star quad )
2. Adjustable wrench
1
4
3
2
1
5
6
Distance Bar
Figure 1-1.

1-6
Basic Information
Notes

2-1
Installation Information
Installation
Please read all instructions completely before attempting
to install or operate the unit..
For best performance, air needs to circulate freely over
the cooling unit behind the wine cellar. The freestanding
design of the cellar means that it should stand at least 1”
(25 mm) from the rear and side walls. Allow a clearance
of at least 4” (100 mm) above the wine cellar.
(See Figure 2-1)
Adjust the feet of the wine cellar so that it is level from
back-to-front and side-to side. Use a leveling tool if
necessary. (See Figure 2-2)
1. Remove the shipping pallet on which your wine
cellar rests.
2. IMPORTANT! Adjust the feet to allow a 1-3/16”
(30mm) clearance under the wine cellar.
3. Attach the distance bar using the two screws at the
top back on each side of the cellar. The rod ensures
the correct distance to the wall behind.
(See Figure 2-3).
4. For optimum performance, please place your wine
cellar far away from any source of heat (radiator,
range or intense sunlight).
THIS PRODUCT IS INTENDED FOR INDOOR USE
ONLY. INSTALLATION OR USE OF THIS PRODUCT
OUTDOORS, OR IN ANY AREA EXPOSED TO THE
ELEMENTS , MAY CAUSE SERIOUS INJURY,
PRODUCT DAMAGE, OR PROPERTY DAMAGE.
Please note that it must be possible to open the
wine cellar door at least 90° to allow the sliding
shelves to be pulled out.
Wall
Wall
(30 mm)
1”
(25mm)
Rear
Distance Bar
Distance Bar
1-3/16”
1”
(25mm)
Figure 2-1.
Figure 2-3.
Figure 2-2.

Installation Information
2-2
5. Attach the driptray on the back as shown in
Figure 2-4. The screws are already attached at the
back.
6. Fit door handle to the door. (See Figure 2-5).
7. Check that the charcoal filter is in place at the top
left corner inside the wine cellar. (See Figure 2-6)
The inside ventilation charcoal filter should be
replaced every second year. The filter is fitted in
the upper left corner inside the wine cellar.
8. Plug in the wine cellar and turn it on with the S1
switch. (See Figure 2-7)
Figure 2-5.
Figure 2-6.
Figure 2-4.
S1
Switch
Figure 2-7.

Installation Information
2-3
Electrical Information
• The wine cellar operates on a single phase
alternating current (AC). Please check that the
voltage shown on the serial plate corresponds to your
power supply. All wine cellars require a connection
to an electrical power source. Improper hook-up can
result in a safety hazard and potential damage to the
product or contents!
Proper installation, in accordance with the
manufacturer´s specifications and all local codes, is
the sole responsibility of the consumer. The
manufacturer is not responsible for any installation
expenses or damages incurred due to improper
installation. If you are insure of your ability to safely
connect electric power to the unit, consult a licensed
and insured professional to perform all electrical
work.
• If the power cord is damaged, it should be replaced
by the manufacturer, service technician, or a
qualified person.
• Never unplug the wine cellar by pulling on the power
cord. Always grip the plug firmly and pull straight out
from the receptacle to prevent
damaging the power cord.
• To avoid electrical shock, unplug the wine cellar
before cleaning and before replacing a light bulb or
LED light.
• Performance may be affected if the voltage varies
by 10% or more. Operating the wine cellar with
insufficient power can damage the compressor.
Such damage is not covered under your warranty.
• Do not plug the unit into an outlet controlled by a wall
switch or pull cord to prevent the wine cellar from
being turned off accidentally.
YOU MUST FOLLOW THESE GUIDELINES TO
ENSURE THAT THE WINE CELLAR SAFETY
MECHANISMS ARE OPERATING CORRECTLY.
To turn off power to your wine cellar, unplug the
power cord from the wall outlet.
THE WINE CELLAR MUST BE GROUNDED.
ELECTRICAL LEADS MUST BE ROUTED AND
SECURED SO THAT THEY CANNOT COME INTO
CONTACT WITH HOT OR SHARP PARTS OF THE
WINE CELLAR.

Installation Information
2-4
Installation Of Guides And Shelf
Supports
Install guides for the sliding shelves by placing the rear
hook of the guide in front of the desired hole in the rear
row ( Arrow 1 Figure 2-8 ). Push in the direction of the
arrow, then do the same with the front hook.
(Arrow 2 Figure 2-8)
1
2
12
Figure 2-8.
Figure 2-9.
The reinforcement bar is a shelf support and must
not be removed for safety reasons.
Reinforcement
Bar
Figure 2-10.
To install the shelf support for the storage shelf, place the
support hooks in the holes at desired level, press in as
arrow 1 indicates and push down as arrow 2 indicates
(See Figure 2-9).

Operation and Maintenance
3-1
Temperature Setting
The wine cellar is equipped with an electronic control for
programming the temperature inside the wine cellar. The
wine will be stored between 50°F (10°C) and 59°F (15°C)
according to expert advice.
The temperature pre-set in the factory is shown on the
display. The temperature, [pre-set at 54°F (12°C)], can
be changed on demand between 46°F (8°C) and 64°F
(18°C) depending on the wine stored.
1. Press button [1] (See Figure 3-1). While pressing
button [1] go to next point (2).
2. Use buttons [2] and [3] (See Figure 3-1) to lower or
increase the temperature.
3. Please allow 6 seconds for the control system to
record the new pre-set value.
1
2
3
Figure 3-1.
Maintenance
It is recommended that you keep the wine cellar as
clean as possible. Unplug the wine cellar before
cleaning.
Do not use any abrasive or strong scented substances.
Use a smooth cloth or sponge and light detergent.
It is very important to check regularly that the air
circulation underneath and behind the cellar is not
blocked. Condensation collects in a small cup at the
back of the cellar. The cup has a sponge which helps
the condensation to evaporate. Check that the plastic
pipe routing the water from the inside to the cup is not
blocked by dust or dirt.
If the wine cellar fails to work, check the following
before proceeding with troubleshooting the unit:
• Is the power supply fuse intact ?
• Is the electric power plug properly inserted in its
receptacle ?
• Is the wine cellar switched on ?
The wine cellar is equipped with overheating protection.
Check whether this has been triggered or not.
How To Store Different Types Of
Bottles
Bottles should be stored in your wine cellar according
to their size. The most well known types of bottles are
the “Bordeaux” and the “Burgundy”. These bottles are
not all identical. The most widely recognized bottles
are the “Tradition” and the “Légère”. The “Champenoise”
and the “flûte d’Alsace” bottles have different diameters
and heights. Take these differences into account when
storing your wine and avoid mixing the bottles.
It is important to store bottles on their side in order for
the cork to remain in contact with the wine. Place
bottles top to bottom in the cellar for optimum volume
use. The illustrations show the best way to stack the
“Burgundy” and the “Bordeaux Tradition”.
Figure 3-2. Bordeaux Tradition
Figure 3-3. Burgundy Tradition

Operation and Maintenance
3-2
Sliding Shelf
Use the sliding shelf when storing specially shaped
bottles.
Only one layer of bottles on a sliding shelf !
Mix Bottle Types
Example of mix bottle types placed on a shelf.
Wooden Bar
Figure 3-5.
Figure 3-4.
Figure 3-6.

Sealed System
4-1
Electrolux does not permit the use of recovered refrigerant in the servicing of our products for in-warranty
and out-of-warranty repairs or for products covered by service contracts. Therefore, only new refrigerant or
refrigerant that has been reclaimed back to new specifications by a refrigerant manufacturer is to be used.
Effective July 1, 1992, the United States clean air act governs the disposal of refrigerants such as R-134a.
Therefore, when discharging or purging the sealed system use an EPA approved refrigerant recovery
system as outlined in the final rule on the protection of stratospheric ozone and refrigerant recycling, which
was published in the Federal Register May 14, 1993.
The purpose of this section is to give the service technician an understanding of the absorbtion type
sealed system service. Persons attempting to use this service manual to make repairs to sealed system
refrigeration systems should have electrical training as well as training in sealed system repairs. The
person making the repairs must know and understand all laws (Local and International) governing
handling of all refrigerants. The technician must be trained in the use of recovery and recycling equipment.
Electrolux Home Products, Inc. cannot be responsible, nor assume any liability, for injury or damage of any
kind arising from the use of this manual.
Instructions given here are furnished as a guide. Persons attempting to use these instructions to
make repairs to the sealed refrigeration system should have a working knowledge of refrigeration and
previous training on sealed system repair, and an EPA certification for servicing refrigeration systems.

Sealed System
4-1
Electrolux does not permit the use of recovered refrigerant in the servicing of our products for in-warranty
and out-of-warranty repairs or for products covered by service contracts. Therefore, only new refrigerant or
refrigerant that has been reclaimed back to new specifications by a refrigerant manufacturer is to be used.
Effective July 1, 1992, the United States clean air act governs the disposal of refrigerants such as R-134a.
Therefore, when discharging or purging the sealed system use an EPA approved refrigerant recovery
system as outlined in the final rule on the protection of stratospheric ozone and refrigerant recycling, which
was published in the Federal Register May 14, 1993.
The purpose of this section is to give the service technician an understanding of the absorbtion type
sealed system service. Persons attempting to use this service manual to make repairs to sealed system
refrigeration systems should have electrical training as well as training in sealed system repairs. The
person making the repairs must know and understand all laws (Local and International) governing
handling of all refrigerants. The technician must be trained in the use of recovery and recycling equipment.
Electrolux Home Products, Inc. cannot be responsible, nor assume any liability, for injury or damage of any
kind arising from the use of this manual.
Instructions given here are furnished as a guide. Persons attempting to use these instructions to
make repairs to the sealed refrigeration system should have a working knowledge of refrigeration and
previous training on sealed system repair, and an EPA certification for servicing refrigeration systems.

Sealed System
4-2
Introduction
In 1922, the Swedish engineers Baltzar v. Platen and Carl Munters developed a continuously working absorption
cooling unit which is not subject to mechanical wear and tear (unit has no moving parts), and which uses an auxiliary
gas (hydrogen) as its pressure equalizing gas. Until the present day, absorber aggregates have been utilizing this
principle. An absorption unit consists of steel pipes which are welded together to form a complex pipe system which
generates the different thermodynamic conditions required for the absorption process. The success of these
refrigerators results from their silent operation, long life span (no moving parts), and the different methods for
powering them (main operation: 120-230V, battery operation: 12V, operation by gas, oil and alternative energy
sources). This feature makes these refrigerators ideally suited for use in hotels or leisure vehicles.
Absorber Vessel
Absorber
Condenser
Evaporator
Gas Temperature
Exchanger
Pump
Boiler
Liquid Temperature
Exchanger
Ammonia Vapour
Hydrogen Gas
Hydrogen & Ammonia Vapour
Weak Ammonia Solution
Liquid Ammonia Solution
Strong Ammonia Solution
The Absorption System

Sealed System
4-3
Description of Function
1. Boiler:
The strong ammonia solution is heated, which sends
ammonia gas to the condenser. The weak ammonia
solution returns through the liquid heat exchanger to
the absorber.
2. Condenser:
The ammonia gas is condensed to liquid by heat
dissipation.
3. Evaporator:
The liquid ammonia flows into the evaporator. The
evaporation of ammonia in the hydrogen atmosphere
absorbs heat. The heavier ammonia/hydrogen
mixture flows down to the absorber vessel.
4. Absorber:
The rising ammonia gas is absorbed by the weak
solution which flows down to the absorber vessel.
Hydrogen is separated from ammonia and then rises
to the evaporator.
Important
1. The cooling unit needs ventilation.
2. The cooling performance depends on air circulation.
3. The condenser component is affected by heat. Heat
accumulation leads to performance loss.
4. Correct installation of the Electrolux ventilation grilles
ensures best possible performance.
Features of the optimum installation:
1. Ventilation grilles with a free cross-section= 250cm2.
2. Upper ventilation grille positioned above the
condenser.
3. Distance between cooling unit and wall must be
approximately 3/4” to 1” (20-25mm).
4. Heat deflector to the upper grille, to guide heated air
out.
Depending on the model, the cooling unit function is more
or less dependent on position. When checking function,
the cooling unit should be level front to back and side to
side.
Description of Function
Electric Thermostat:
Senses with the capillary tube temperature, and switches
power to the heater on and off.
Gas Thermostat:
Senses with the capillary tube temperature, and opens or
closes the main gas supply (bypass remains open
constantly because of pilot flame).
Thermocouple:
When the thermocouple tip is heated by the gas flame,
electricity is generated. This feeds the safety valve
solenoid which keeps the valve open as long as the flame
burns.
Gas Control Valve:
In conjunction with the gas thermostat, this gas control
devise allows either an open or closed position. A Zero,
Min, Mid and Max Position valve is used in products not
having gas thermostats. Both types have a built in safety
device. By pressing the safety valve button, the gas
flow to the burner is opened. When the flame is lit, the
thermocouple powers the valve solenoid and the valve
remains open. If the flame is extinguished, the valve
closes.
Gas Filter:
It is positioned in the gas supply pipe and may obstruct
the gas flow if it is dirty or damp. This obstruction can
result in poor cooling or no cooling in gas mode.
Piezo Ignition:
Pressure produces high voltage in the piezoelectric
crystal. The high voltage gives via ignition cable and an
electrode, a spark in the burner where the gas is lit.
Burner:
Consists of burner housing, mixing chamber and burner
jet. The burner jets are marked with numbers. Only jets
with the correct number for the model in question must
be used.

Sealed System
Electrode
Burner
Aeration Hole
Burner Jet
Thermocouple
Gas Supply Pipe
Gas Control Valve
Ignition Device
Ignition Cable
Piezo Igniter
Cover
Reigniter
Ignition Cable Complete
Gas Filter
Gas Connection
Gas Thermostat
With Electrode
Flue Baffle
Switch
4-4
Re-ignitor:
An electric re-ignitor powered by a supply voltage of approximately 12V, generates via an ignition cable and an
electrode, a spark in the burner where the gas is lit.
The re-ignitor automatically repeats this operation until a “feedback” signal to the electronics registers the presence
of a flame. On the re-ignitor, there is a voltage supply connection which is powered by the re-ignitor switch. There is
also a connection for the switch control light.
Flue Baffle:
This distributes the heat in the boiler area during the gas operation (not required for all models). A performance loss
occurs if this baffle is missing. The length of baffle will vary depending on model.
Burner Jet:
Burner jets are designed for the specific gas operating pressure (28 to 50 mbar). Only the burner jets specified for the
model and gas pressure stated on the data plate, must be used.
Electrical Components
Electric Thermostat
230 Volt Only
230 Volt Switch
12V/24V Switch
Heating Elements
Gas Components

Troubleshooting
5-1
Troubleshooting Chart
How long since start?
Installation OK?
Gas bottle empty
Voltage OK?
Switches ON?
Low voltage?
Heating elements OK?
Gas pressure OK?
Electrical connections OK?
Gas burner clean OK?
Burner jet OK?
Restricted gas flow?
Gas regulator OK?
Gas control or safety valve OK?
Thermostat OK?
Thermoelement OK?
Ignition electrode/cable OK?
Ignition device OK?
Flue baffle in position?
Thermomastic OK?
Cooling unit OK?
Ambient temperature too
high or to low?
No cooling on 230 V AC Poor cooling on 230 V AC No cooling on 12V/24V DC Poor cooling on 12V/24V DC No cooling on gas Poor cooling on gas No cooling on any energy source Poor cooling on any energy source Too cold
X
XX
XXX X
X
XX
X
X
XXX
XX
XX
XX
XX
X
X
X
X
X
XX XX
X
X
X
X
X
X
X
XX
XX
X
XXXX
X
XXX
