Electrovision 32-Element User manual

32-Element, 44-Element, and
52-Element Outdoor Wideband
Aerials
Can be exterior or loft-mounted
Simple, fast assembly
Boosts picture and audio quality of both analogue
and digital television signals
Wideband, for complete universal UHF reception
HD-ready - compatible with DVB-T programmes
Suitable for Freeview
Page 1

IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with
the user of the product for future reference.
IDENTIFYING THE PARTS
Main boom Extension boom
(44- and 52- element only)
Reflectors Dipole
Cradle
(44- and 52-element only)
Page 2

INSTALLATION
1. On all models twist the directors until the plastic
brackets snap into place as shown.
2. On 44- and 52-Element models connect the two
halves of the boom together using the two brackets,
screw and wingnut, as shown above.
3. On all models attach the dipole using a wingnut.
Page 3

4. On 44- and 52-Element models attach the cradle.
5. On all models attach the reflectors using the plastic
bracket (supplied in two parts), a screw and a wingnut.
Page 4

5. On 44- and 52-Element models attach the cradle to
the top of the mast. (The mast must not extend above
the cradle)
On 32-element models attach the aerial to the mast as
shown below:
If the transmitter is horizontally polarised (most main
transmitters are horizontally polarised) mount as shown
in the left picture.
If the transmitter is vertically polarised (most local
repeaters are vertically polarised) mount as shown in the
right picture.
If in doubt, observe other aerials installed in the
neighbourhood.
Page 5

6. On all models connect the coaxial cable as shown
using 75 W low-loss coaxial cable. Never use 50 Ω coax,
or any other type of screened cable, as this will result in
a loss of signal.
7. Enhanced waterproofing can be achieved by putting a
small amount of silicone or petroleum jelly around the lid
of the connection box before assembling.
OPERATION
These aerials are intended for use with analogue and
digital television receivers in Band IV and Band V
(470MHz to 860MHz). They are wideband aerials, so
can be used whenever Group A, Group B, Group CD, or
Group W aerials are specified.
Page 6

32-Element aerials can be used in strong signal areas.
44-Element aerials can be used in medium or strong
signal areas.
52-Element aerials can be used in weak, medium or
strong signal areas.
These aerials are not suitable for use with FM radio
(Band II, 87.MHz to 108MHz) or DAB radio (Band III,
174MHz to 230MHz).
Orient the aerial so that it points to the nearest
transmitter. You can find the location of your nearest
transmitter at http://www.ukfree.tv/transmitter.php
If there is an obstruction in the direction of the
transmitter, then pointing the aerial slightly to one side
of the obstruction may result in improved reception.
If in doubt, observe other aerials installed in the
neighbourhood, and orient the aerial in the same
direction.
TECHNICAL SPECIFICATION
Dimensions: 32-element: 520×560×440mm
44-element: 1180×560×440mm
52-element: 1180×560×440mm
Weight: 32-element: 1.0kg
44-element: 1.2kg
52-element: 1.3kg
Material: aluminium alloy
Connection: screw terminals
Band: IV/V
Group: W
Operating frequency: 470-860MHz
Page 7

SERVICE WARRANTY
Electrovision guarantees the product free from defects in
materials and workmanship for a period of twelve
months.
Should this unit be operated under conditions other than
those recommended, or any attempts made to service
or modify the unit, then the warranty will be rendered
void.
The product you buy may sometimes differ slightly from
illustrations. This warranty is in addition to, and does not
affect, your statutory rights.
If you have any problems with this product, please call
our Help Desk on [phone].
Electrovision Ltd.,
Lancots Lane,
Sutton Oak,
St. Helens,
Merseyside.
WA9 3EX
website: www.electrovision.co.uk
DISPOSAL AND RECYCLING
You must not dispose of this aerial with domestic
household waste.
Most local authorities have specific collection system for
appliances and disposal is free of charge to the end-
user.
When replacing an existing aerial with a similar new
appliance your retailer may take the old aerial for
disposal.
