Electrovision T143FG User manual

T143FG
27-element Tri-bar Aerial
Can be exterior or loft-mounted
Simple, fast assembly
Boosts picture and audio quality of both analogue
and digital television signals
Wideband, for complete universal UHF reception
HD-ready - compatible with DVB-T programmes
Suitable for Freeview
Page 1

IMPORTANT
Installer and Users please note:
These instructions should be read carefully and left with the
user of the product for future reference.
INSTALLATION
1. Fold out the two outer bars as shown below, and secure in
place with the screws provided.
2. Attach the dipole to the centre bar as shown below:
3. Attach the two reflectors using the wingnuts supplied.
Page 2

4. Attach to the mast in the orientation shown in the picture
below.
5. Orientate the aerial so that it points to the nearest
transmitter. You can find the location of your nearest
transmitter at http://www.ukfree.tv/transmitter.php
If there is an obstruction in the direction of the transmitter,
then pointing the aerial slightly to one side of the obstruction
may result in improved reception.
If in doubt, observe other aerials installed in the
neighbourhood, and point the aerial in the same direction.
6. Connect the coaxial cable to the F-connector on the dipole
unit.
7. Connect a TV coax plug to the other end of the coaxial
cable and plug into to the aerial input of the television
If using a ready-made cable with F-connectors on both ends,
adaptors are available, part number F399A (F-socket to TV-
coax plug) from your local Electrovision dealer (see
www.electrovision.co.uk and click the "dealers" link)
OPERATION
These aerials are intended for use with analogue and digital
television receivers in Band IV and Band V (MHz to 860MHz).
They are wideband aerials, so can be used whenever Group A,
Group B, Group CD, or Group W aerials are specified.
Page 3

TECHNICAL SPECIFICATION
Dimensions: 1040×505×740 mm
Weight: 1.8 kg
Material: aluminium alloy
Connection: F-connector
Band: IV/V
Group: W
Operating frequency: 470-860 MHz
These aerials are not suitable for use with FM radio (Band II,
87.MHz to 108MHz) or DAB radio (Band III, 174MHz to 230MHz)
DISPOSAL AND RECYCLING
You must not dispose of this appliance with domestic household
waste.
Most local authorities have specific collection system for appliances
and disposal is free of charge to the end-user.
When replacing an existing appliance with a similar new appliance
your retailer may take the old appliance for disposal.
SERVICE WARRANTY
Electrovision guarantees the product free from defects in materials
and workmanship for a period of twelve months.
Should this unit be operated under conditions other than those
recommended, or any attempts made to service or modify the unit,
then the warranty will be rendered void.
The product you buy may sometimes differ slightly from illustrations.
This warranty is in addition to, and does not affect, your statutory
rights.
If you have any problems with this product, please call our Help Desk
on [phone].
Electrovision Ltd.,
Lancots Lane, Sutton,
St. Helens, Merseyside.
WA9 3EX
website: www.electrovision.co.uk
Page 4
