Elektra Beckum Niagara Star 20 User manual

Niagara
Star 20
D
Betriebsanleitung
Unterwasserleuchte
G
Operating Instructions
Underwater light fixture
L0001_11 Seite 1 Donnerstag, 16. Juli 1998 15:17 Uhr

D
Deutschland
Die beiliegende Garantiekarte senden Sie bitte an uns
zurück.
Den Kaufbeleg bitte aufbewahren! Ein Anspruch auf
Garantieleistungen besteht nur gegen Vorlage des Kauf-
belegs.
Die Adresse Ihrer nächstgelegenen Werksvertretung finden
Sie auf der hinteren Umschlagseite.
1.
G
Great Britain
Please return the enclosed warranty card to us.
Retain proof of purchase! You are only entitled to claim war-
ranty against proof of purchase.
Please see back cover for manufacturer representative´s
address nearest you.
2.
L0001_11 Seite 2 Donnerstag, 16. Juli 1998 15:17 Uhr

Niagara Star 20
2.1
Underwater light fixture Niagara Star 20
With the underwater light fixture aquaria, decorative fountains and garden ponds can
be illuminated from under water – also in colour with the coloured light shades sup-
plied.
Special fasteners on the fixture’s base allow for the combination of several light fix-
tures. A clip provides for simple mounting directly to the pump.
Read these instructions thoroughly before commissioning this appliance.
Safety first!
To prevent personal injury and damage to the appliance, please note:
· Never reach into the water before not all immersed electrical equipment is
switched OFF and their power cables unplugged.
· Connect this light only to a power source matching the specifications stated in
the „technical specifications“ section.
· This light can only be operated submerged in water ; if not submerged the
light’s casing overheats.
· The transformer is suitable for outdoor operation; however it can not be placed in
water.
· Ensure that power supply cable and plug do not get wet.
Lay out the power cable so that is raises to the power outlet.
· Extension cables need to be splash-proof; they shall not lay in water.
· The light can not be used outdoors at sub-zero temperatures.
· The transformer is protected against overheating and short-circuit of the light. If
the light should go out, unplug for approx. 5 minutes. If the light does not come
on after plugging in again, replace the halogen lamp (see next page). If the light
still does not work the transformer is defunct.
· Do not attempt to repair a damaged cable or the transformer. Have repaired by a
qualified electrician.
L0001_11 Seite 1 Donnerstag, 16. Juli 1998 15:17 Uhr

Niagara Star 20
2.2
Into the water!
B
Danger! Electric potential.
Risk of personal injury by electric shock if the power supply cable, plug or an
extension cable becomes wet. Always keep dry!
Mounting on base
· Fit light shade of desired colour.
· Place light on fixing screw of base.
· Tighten wing nut.
· Place light into water (weight down base with
gravel if necessary) and adjust.
· Lay out power cable.
Mounting on pump
· Fit light shade of desired colour.
· Slide clip into groove of pump casing.
· Attach light with clip to riser pipe of pump
and adjust.
· Lay out power cable.
Lights on!
· To turn light on plug power supply cable in.
Replacing the halogen lamp
· Loosen and remove screws (4 pcs);
· Remove casing lid and glass cover.
· Pull halogen lamp from socket and replace.
3
Grease and sweat deposits reduce the halogen lamp's service life. Do not
touch lamp with bare hands.
· Check that seal is undamaged and in correct position.
· Replace glass cover and casing lid, secure with screws.
3
Ensure correct positioning of the casing lid; the projection serves as seal for
the groove.
L0001_11 Seite 2 Donnerstag, 16. Juli 1998 15:17 Uhr

Niagara Star 20
2.3
Technical specifications
Spare parts
Transformer
Supply voltage (50…60 Hz) 230V
Output voltage 12V
Power input 33W
Power output 20VA
Rated output current 1.7A
Max. ambient temperature 35
° C
Protection class power cable plug IP 24
Protection class transformer IP 65
Light
Operation voltage 12V
Power input 20W
Protection class light IP 68
Max. submersion depth 2,0m
colour shade set
0903052260
halogen lamp
0903052279
L0001_11 Seite 3 Donnerstag, 16. Juli 1998 15:17 Uhr

Aktiengesellschaft
Postfach 13 52, D-49703 Meppen
EG-Konformitätserklärung - EC conformity declaration - Déclaration de conformité CEE
EG-verklaring van overeenstemming - EF-overensstemmelsesattest - EG-konformitetsdeklaration
EF-konformitetserklæring - Selvitys ey-standardinmukaisuudesta - Dichiarazione di conformità CE
Declaración de conformidad-UE- Declaração de conformidade CE
Wir erklären, daß die Bauart der Maschine/des Gerätes - We declare that the design of the machine/appliance
Nous certifions que le type de la machine/de l’appareil - Wij verklaren dat de constructie van de machine/het apparaat
Vi erklærer, at konstruktionen af maskinen/apparatet - Härmed försäkrar vi att maskin/apparat - Vi erklærer at konstruksjonsmåten til maskin/apparat
Täten selvitämme, että alla mainittu kone/laite - Dichiariamo che il modello della macchina/dell’apparecchio
Declaramos, que el modelo de la máquina/aparato- Declaramos que o tipo de construção da máquina/do aparelho
UNTERWASSERSCHEINWERFER - SET
NIAGARASTAR 20
Art.-Nr. - Stock-no. - N ° d’ article - art.-nr. - art.-nr. - Art.-nr. - Art.-Nr. - tuotenumero - N ° Art. - Art.N ° - artigo n ° :
090 3051 876
folgenden einschlägigen Bestimmungen entspricht - corresponds with the following relevant regulations
est conforme aux règlements applicables suivants - aan de volgende terzake geldende voorschriften voldoet - opfylder følgende gældende bestemmelser
enligt sitt byggsätt motsvarar följande gällande föreskrifter - oppfyller de følgende gjeldende bestemmelser
vastaa seuraavia asiaa koskevia määräyksiä - corrisponde alle seguenti norme in materia
se ajusta a las siguientes directrices correspondientes - se enquadra com as seguintes disposições pertinentes:
EG-Richtlinie Elektromagnetische Verträglichkeit - EC-directive electro-magnetic compatibility - directive CEE sur la conformité électromagnétique
EG-richtlijn elektromagnetische compatibiliteit - EF-direktiv vedr. elektromagmetisk fordragelighed - EG-direktiv för elektromagnetisk tolerans
EF-direktiv om elektromagnetisk kompatibilitet - Sähkömagneettista toleranssitasoa koskeva EY-direktiivi - Direttiva CE compatibilità elettromagnetica
Directriz-UE Compatibilidad electromagnética - Directiva CE sobre compatibilidade electromagnética
89/336/EWG
93/68/EWG
EG-Niederspannungs-Richtlinie - EC-Low voltage directive - Directive CEE de basse tension
EG-laagspanningsrichtlijn - EF-lavspændingsdirektiv - EG-direktiv för lågspänning
EF-direktiv om lavspenning - Pienjännitettä koskeva EY-direktiivi - Direttiva CE per bassa tensione
Directriz para baja tensión-UE - Directiva CE sobre baixa tensão
73/23/EWG
93/68/EWG
Technischer Leiter - Technical Manager - Le responsable technique - Chef techniek - Teknisk leder - Produktledare
Teknisk leder - Tekninen johtaja - Direttore teccnico - Director técnico - O director técnico
D/GB/F/NL/DK/S/N/SF/I/E/P 1 000 840/98
L0001_11 Seite 4 Donnerstag, 16. Juli 1998 15:17 Uhr

Niagara Star 20
115 163 5683 D/GB 2998 1.1
Elektra Beckum AG
Daimlerstraße 1
D-49716 Meppen
