Elements LINQ LQ48012 User manual

7 in 2 TB Pro Multiport Hub
Model #: LQ48012
Product Manual
Package Contents
USB-C Pro Multiport Hub x1,
User Manual x1
www.LINQbyELEMENTS.dk
Thank you for purchasing our
7 in 2 TB Pro Multiport Hub.
Please read this user manual
carefully and keep it in a safe place
for future reference. If you need
any assistance, please contact our
support team with your product
model number and order number of
relevant sales channel.
System Requirements:
MacOSX v10.0 or above operating
systems
Plug and play:
Yes
Product Specications
Overview
HDMI Output Port
Up to 4k UHD (3840 x 2160@
60Hz), supports 1440p / 1080p /
720p / 480p / 360p
USB-A Super Speed+
Super Speed USB-A 3.2 Gen 2,
Max data transfer speed 5Gbps
Power Supply up to 4.5W Max.
USB-C PD Port
Charging up to 100W of Power
Delivery 3.0 (Only for laptop
charging)
USB-C TB Pass-through
Thunderbolt™ 3.0 Pass-through,
Support Max 40Gbps, Max 100W
SD & TF Card Slot
Supported memory card capacity
up to 512GB.
Dual USB-C Connector
Compatible with Thunderbolt 3,
Dedicated design for use with dual
USB TypeC port Macbook.
USB-C Power Delivery
Port up to 100W
(Only for Charging)
HDMI Output Port
up to 4K @ 60Hz
USB-C Thunderbolt™
Pass-through
USB-A Super Speed+
up to 10Gbps
SD & TF Card Slot
High Speed
Hub Power LED

Notes
1. Only one hub is included, power
adapters, SD/TF memory cards,
cables or other accessories are
not included.
2. The 100W charging speed can
only be acquired when used with
a 100W rated USB-C PD cable.
3. The USB Data Ports of this
product supports Max. 5V
900mAh total charging output.
4. For more stable connection
when using high-power devices,
connect a PD Power Adaptor to
the USB-C female PD port.
5. The USB-C PD port of this
product is only for charging
USB-C laptops whose USB-C
Port supports USB Power
Delivery (PD). The PD USB-C port
of this product does not support
data transfer.
6. The USB-C Thunderbolt™ 3.0
Pass-through and supports both
data & Power Delivery.
7. A 4K capable display and a 4K
capable HDMI cable are required
to achieve 3840 x 2160 resolution.
8. HDMI 1.4 cables only support
30Hz, HDMI 2.0 cables support
4K up to 60Hz.
9. 4K 60Hz Compatibility requires a
DP 1.4 compatible type-C port on
your device.
How to Use
Plug the USB-C connector of the
Hub into the USB-C port on your
USB-C laptop.
1. USB-C Power Delivery: Charge
your laptop by plugging the
USB-C Charger to the Multiport
Hub USB-C Female Power
Delivery (PD) port.
2. HDMI Output: Connect to your
UHDTV or projector with an
HDMI 2.0 cable via the HDMI
output port and watch videos
from your USB-C laptop on
your TV or other HDMI-enabled
devices.
3. USB-C Thunderbolt™ Pass-
through: Oers a connection
with genuine maximum speed
and versatility. Transferring data
at speeds of up to 40Gbps that
also supports power up to 100W
and can support 2x 4K Monitors
@ 60Hz or even 1x 6K Monitor @
60Hz!
4. USB-A Super Speed+: Connect
your smart phone, tablet, mouse,
keyboard, hard drive or other USB
peripherals via the USB-A 3.2
ports and transfer data between
your computer and connected
device.
5. SD/TF Card Reader: Insert your
memory card into the SD/TF
Card Slot to directly access les
stored in the SD/TF card on your
USB-C laptop. SD/TF memory
cards can be used on the hub
simultaneously.
Troubleshooting
if you experience any issues or have
any question regarding the hub,
please visit the support and FAQ page
on our website for most up to date
information.
LINQ | Support
https://linqbyelements.dk/support.html
Compatibilities
Details regarding compatibility of
devices can be found on our website
or consult your devices manual.
visit:
www.LINQbyELEMENTS.dk
