elero VarioTec-868 JA User manual

181004602_EN_1215
Operating instructions (translation)
Please keep these instructions in a safe place!
EN
VarioTec-868 JA
VarioTec-868 RM
28 350 0001
28 340 0002

Safety instructions
EN | 3
Safety instructions 2
Explanation of displays and buttons ........................................ 3
General information .................................................................... 4
Designated use............................................................................ 4
Installation.................................................................................... 5
Connection as a drive controller ............................................... 5
Connection as a group controller.............................................. 6
Factory settings........................................................................... 7
Explanation of functions ............................................................ 7
Manual/Automatic sliding switch ..................................... 7
Alarm signal control light ................................................. 8
Reset button .................................................................... 8
P button ........................................................................... 8
Group control.................................................................... 8
Intermediate position ........................................................ 8
Ventilation/reverse position .............................................. 9
Drive controller ................................................................. 9
Group controller................................................................ 9
Selecting roller shutter/awning or venetian
blind mode ........................................................................ 9
Manual operation functions ............................................ 10
Automatic operation functions ........................................ 10
Programming menu .................................................................. 10
Programming intermediate position................................ 10
Programming ventilation/reverse position ...................... 11
Deleting ventilation/reverse position............................... 11
Adjustment to intermediate position ............................... 11
Deleting intermediate position ........................................ 11
Adjustment to ventilation position................................... 12
Adjustment to reverse position.................................................... 12
Programming radio channels................................................... 13
Technical data ........................................................................... 14
Cleaning ..................................................................................... 14
Troubleshooting ........................................................................ 15
General declaration of conformity........................................... 15
Contents
2 | EN
Important safety instructions!
Always observe the following instructions.
Risk of injury by electric shock.
• All terminal connections to a 230 V network must
be made by an authorised electrician.
• Before assembly, always disconnect the mains
lead from the power supply.
• The provisions of the local public utilities and sti-
pulations for wet and damp rooms in accordance
with VDE 100 must be observed during system
installation.
• For use in dry rooms only.
• Use unmodified elero original parts only.
• Keep persons away from the systems guide track.
• Keep children away from controls.
• Always comply with national stipulations.
• If the system is controlled by one or more
devices, the system guide track must be visible
during operation.
• Only cables with sufficient electric strength may
be used to connect control cables (protective low
voltages).
• The equipment contains small parts that could be
swallowed.
Warning!

General information / Designated use
EN | 5
General information
The VarioTec-868 JA/RM device operates your roller shutters/sun
protection systems on the basis of manual or external control com-
mands.
The VarioTec-868 JA/RM device can be operated manually at all
times.
The VarioTec-868 JA/RM is characterised by its user-friendly
operation.
Designated use
The VarioTec-868 JA may be used to operate venetian blinds only.
The VarioTec-868 RM may be used to operate roller shutters and
awnings only.
This device may only be used in connection with equipment from
other manufacturers following consultation with your local retailer.
• Please note that radio-controlled systems may not be used in
areas with a high risk of interference (e.g. hospitals, airports).
• The remote control is solely for use with equipment and systems
in which malfunctions in the hand-held transmitter or receiver
would not pose any risk to persons, animals or property or which
contain safety devices to eliminate such risks.
• The operator is not protected from interference from other
telecommunications systems and terminal equipment
(e.g. even from radio-controlled systems which are properly
operated in the same frequency range).
• Radio receivers may only be used in combination with equipment
and systems stipulated in manufacturers’ specifications.
Note: Radio stations transmitting in the same frequency range
may cause reception interference.
Please note that the operating range of the radio signal is
limited by legislation as well as by the product design.
Explanation of displays and buttons
4 | EN
9DULR7HF-$50
3RV
3RV
5HVHW
'2:1EXWWRQ
6723EXWWRQ
83EXWWRQ
$ODUPVLJQDO
&RYHU
0DQXDO$XWRPDWLF
326EXWWRQ
326EXWWRQ
5HVHWEXWWRQ
3
3EXWWRQ
Explanation of displays and buttons
Buttons beneath the cover
Encoding switch (located on back of device)
9DULR7HF-$50
3RV
3RV
5HVHW
'2:1EXWWRQ
6723EXWWRQ
83EXWWRQ
$ODUPVLJQDO
&RYHU
0DQXDO$XWRPDWLF
326EXWWRQ
326EXWWRQ
5HVHWEXWWRQ
3
3EXWWRQ
1 Upper position → Alarm signal function OFF.
Lower position →Alarm signal function ON.
2 Upper position →Group controller
Lower position →Driver controller
3 Upper position → Without function
Lower position → Default setting
→ JA/RM operation


2Q




123

Connection
EN | 7
Installation / Connection
6 | EN
Installation
To other
control devices
Individual
VarioTec-868
Venetian blind
pushbutton
21
N L
64 53
Central
C
1~
M
N
L
Mains
PE
230 V/50 Hz
Connection as a drive controller
You can find the structure of a controller on elero.com in the down-
load area under „Installation instructions and circuit diagrams“.
Warning!
Risk of injury by electric shock!
• Terminal connections must be carried out by an
authorised electrician!
• If more than one drive is operated using the
VarioTec-868 JA/RM, the drives must be decoupled
by relay controls.
• The switched current of the device must be observed
at all times!
To other
control devices
Individual
VarioTec-868
Venetian blind
pushbutton
21
N L
64 53
Central
C
N
L
Mains
230 V/50 Hz
variotec1
Output
Input
To other
control devices
Connection as a group controller
For details on suitable control systems, please refer to the con-
trol product catalogue.
Warning!
Risk of injury by electric shock !
• Terminal connections must be carried out by an
authorised electrician!
3. Replace the protective caps on the power supply unit.
4. Secure the power supply unit in the box.
5. Insert the operating device into the frame and plug it into
the power supply unit.
1. Remove the protective caps.
2. Connect.
1. Remove the protective caps.
2. Connect.
Note!
Always use a shielded
control wire . . . 0.8 mm
or JY-ST telephone
line . . . 0.6 mm.
Note: The encoding switch 2 located on the back of the
VarioTec-868 device can be used to select group or drive
control.
3. Replace the protective caps on the power supply unit.
4. Secure the power supply unit in the box.
5. Insert the operating device into the frame and plug it into the
power supply unit.
Note!
Always use a shielded
control wire . . . 0.8 mm
or JY-ST telephone
line . . . 0.6 mm.

Explanation of functions
EN | 9
Reset button:
Press the Reset button (with a ballpoint pen or similar object)
to delete the intermediate position and the ventilation/reverse
position.
P button
Press the Pbutton to simulate power interruption (in order to
programme the transmitter).
POS ▼
The Pos ▼button can be used to programme an intermediate
position.
POS ▲
The Pos ▲button can be used to programme a ventilation/
reverse position.
Group control:
Group control refers to the simultaneous operation of several
drives.
Intermediate position:
The intermediate position lies between the upper and lower limits
of the roller shutters/sun protection system and can be freely
selected. The roller shutters/sun protection system can be moved
into this position from the upper end limit after programming.
To do so, press the DOWN button twice in quick succession.
When the system is in venetian blind mode, it is also possible to
programme a reverse position. In this case, this command will be
automatically executed following the intermediate position com-
mand.
Explanation of functions
8 | EN
Explanation of functions
Manual/Automatic sliding switch
In the “MANUAL “ mode, only manual control commands and
alarm signals are executed.
When the sliding switch is set to “AUTO”, automatic control
commands are carried out (e.g. control signals via group control
inputs).
Alarm signal control light
An alarm signal is a continuous switching signal at the group or
individual control inputs which lasts for more than 5 seconds.
If the alarm signal control light is illuminated, this indicates an
alarm signal. The encoding switch 1 can be used to switch the
ALARM SIGNAL function on or off.
Factory settings
Encoding switch factory setting
1. Lower position Alarm signal function ON.
2. Lower position Driver controller.

Function menu / Programming menu
EN | 1110 | EN
Explanation of functions
Functions
Manual operation functions
• UP, STOP, DOWN
• Intermediate position
• Ventilation/reverse position
• Alarm signals
Automatic operation functions
• External automatic control commands
• UP, STOP, DOWN
• Intermediate position
• Ventilation/reverse position
• Alarm signals
Ventilation/reverse:
The ventilation/reverse position lies between the upper and lower
limits of the roller shutters/sun protection system and can be freely
selected. Your roller shutters can be moved into this position from
the lower end limit until the ventilation slats are open.
In venetian blind mode, the blind slats are turned.
To do so, press the UP button twice in quick succession .
Drive controller:
If the VarioTec-868 JA/RM device is being used as a drive
controller, the drive is directly connected to the VarioTec-868
device, in which case external signals are converted into control
commands. Encoding switch 2 must be set to the lower position.
Group controller:
If the VarioTec-868 JA/RM device is being used as a group
controller, additional group and drive control devices can be
connected. Encoding switch 2 must be set to the upper position.
Programming
Programming the intermediate position
Prerequisite: The shutter/canopy/blind is in the upper end
limit position.
1. Press and hold the Pos ▼programming button.
2. Keeping this button pressed, press the DOWN button
until the desired intermediate position has been reached.
Adjustments can be made with the UP or DOWN buttons.
3. Release the Pos ▼the programming button. The
intermediate position is now stored.
The control light will flash 3 times briefly

Programming menu
EN | 13
Programming menu
12 | EN
Programming the ventilation/reverse position
Prerequisite: The shutter/canopy/blind is in the lower end limit
position.
1. Press and hold the Pos ▲programming button.
2. Keeping this button pressed, press the UP button until
the desired ventilation/reverse position has been reached.
Adjustments can be made with the UP or DOWN buttons.
3. Release the Pos ▲programming button. The ventilation/
reverse position is now stored.
The control light will flash 3 times briefly.
Deleting ventilation/reverse position
Press and hold the Pos ▲programming button for more than
5 seconds. The ventilation/reverse position is now deleted.
The control light will flash 3 times briefly.
Adjustment to intermediate position
The shutter/canopy/blind can only be moved into the intermediate
position from the upper end limit position.
1. Press the DOWN button twice in quick succession.
The shutter/canopy/blind is adjusted into the stored
intermediate position.
Addition concerning VarioTec-868 JA
When the blind reaches the stored intermediate position the blind
slats are turned automatically (provided a reverse position has
been pre-programmed).
Deleting intermediate position
1. Press and hold the Pos ▼programming button for more than
5 seconds. The intermediate position is now deleted.
The control light will flash 3 times briefly.
Adjustment to reverse position with VarioTec-868 JA
(venetian blinds)
Venetian blinds can only be moved into the reverse position
from the lower end limit position.
1. Press UP button twice in quick succession.
The venetian blind is adjusted into the stored reverse
position.
Adjustment/fabric tension to ventilation position with
VarioTec-868 RM (roller shutters/awnings)
Roller shutters/awnings can only be moved into the
ventilation position from the lower end limit position.
1. Press the UP button twice in quick succession. The shut-
ters/awnings are adjusted into the stored ventilation positi-
on/fabric tension.
Deleting ventilation/reverse position
Press and hold the Pos ▲programming button for more than
5 seconds. The ventilation/reverse position is now deleted.
The control light will flash 3 times briefly.

Technical data / Cleaning
EN | 15
Programming transmitter / channel
14 | EN
Commissioning (connection of a tubular or venetian blind motor)
Precondition: The VarioTec-868 JA/RM is installed.
(→See Chapter connestion RM/JA)
The end positions must be set.
1. When the power supply is restored or by pressing the P-button
(min. 5 Sec) on the VarioTec-868 JA/RM , the device is ready to pro-
gramme for 5 minutes.
2. Programme the transmitter (Z see transmitter instructions).
3. To define the keyboard layout, press the UP button on the trans-
mitter as soon as the shutter/canopy/blind begins to move upwards
(after approx. 1 second).
The shutter/canopy/blind will come briefly to a halt.
Press the DOWN button on the transmitter as soon as the shutter/
canopy/blind begins to move downwards.
The shutter/canopy/blind will come to a halt.
The transmitter/channel has been successfully programmed.
Note: If more than one receiver is connected to the same mains
lead, all of these will be in programming mode simultane-
ously. The shutters/canopies/blinds will begin to move up
and down “at random”. The longer you take to carry out the
programming, the larger the offset becomes.
Individual channels can now be assigned to the relevant
receiver. The brief up and down movements can be stop-
ped by pressing the STOP button on one of the pre-pro-
grammed hand-held transmitters briefly.
Channel assignment/modification can now be carried out
without you having to disconnect individual channels.
For more details, refer to the operating instructions for your
transmitter.
Nominal voltage 230-240 V AC / 50-60 Hz
Switched current 5 A /250 V AC bei cos j = 1
System of protection IP 20
Protection class II
(only after correct installation)
Permissible ambient temperature 0 to +55 °C
Operating frequency 868,3 MHz
Type of installation Concealed: Ø58 mm
wall-mounted
Exposed: in appropriate
exposed casing
Max. number of transmitters 16 transmitters
Technical data
Cleaning
Clean the device with a damp cloth only. Do not use a clean-
sing agent as doing so may damage the plastic.

EN | 1716 | EN
Troubleshooting
Problem Cause Remedy
Drive is not Faulty connection. Check connection.
functioning.
VarioTec-868 JA/RM 1.Device is set to 1.Set the device to
does not carry out “MANUAL ”. “AUTO”.
external control 2.Alarm signal is active. 2.Wait until alarm
commands. signal disappears
or rectify the
problem that
triggered the signal.
Drive is not 1.Receiver is outside 1. Reduce distance
functioning. Alarm the radio operating to receiver.
signal is illuminated. range.
2.Transmitter is not 2.Programme
programmed in receiver.
the receiver.
General declaration of conformity:
The company elero GmbH hereby declares that the VarioTec-868
JA/RM device complies with the basic requirements and other
relevant regulations of the EC Directive 1999/5/EG.
Troubleshooting EC Declaration of conformity

EN | 1918 | EN

elero GmbH
Antriebstechnik
Maybachstr. 30
73278 Schlierbach
[email protected]
www.elero.com
309025 03
We reserve the right to make technical changes
