Quad-Wheel Kit
Item 1045
Assembly & Installation Instructions
Page 2
Questions? Problems?
Please DO NOT contact or return this item to
the retailer. Seek assistance directly from ELEY
Corporation using the information below.
Phone: 1-866-523-2363 (toll free)
MON- FRI, 8am to 5pm (CST)
E-mail: [email protected]
MON- FRI, 8am to 5pm (CST)
Online: The SUPPORT section on our website
www.eleyhosereels.com is available
24/7/365 and contains assembly
videos, repair instructions and FAQ’s.
Page 3
DETAIL C
SCALE 1 : 2.25
Using the hex key wrench that came with
your cart reel, remove screws that are
attached to the bumper, then remove
bumper from cart.
STEP 1
This step only
applies for previously
assembled two-wheel
cart reels.
©2016 Eley Corporation PO Box 22640 Lincoln, NE 68542-2640 Rev. 04/13
(Manual Part # 4025)
STEP 3
Ensure that the
protruding side of
the tube frame as
pictured.
STEP 2
