ElfinX MC-2W User manual

http://www.elfinx.com MC-2W
2-Way Motorcycle alar m system
A r m:
Disarm:
Remote Start Engine:
1. Arm/Mute arm:
Press the button once, the siren would beep once , the alarm system is in
ARM mode. I move the motorcycle or ignition on, the siren will sound and the direction lights will
lash, the engine will be locked at the same time. And the remote controller will beep and show
icons in LCD display. Press any button, the icons will be removed.. Press again the lights will
lash once, the motorcycle is in mute arm status. When the motorcycle is moved, the direction
lights will lash and engine will be locked; i turn key to ACC ON, the siren will sound, the direction
lights will lash and engine will be locked. And the remote will beep and show icons as in normal
arm mode.
Function Oper ati on
Function Key
Ke yb o a rd lo c k
Disarm
Arm
Batter y
Assist a nt f unc t ion
Se n d in g sig n a l
Sh o c kin g a la rm
Sh o c kin g a la rm
Disa rm /Ig in itio n o ff
Arm / Anti- ro b b e ry
1
2. Disarm:
Press the button once, the siren would give 2 beeps, the lights would lash twice,
the motorcycle is in the DISARM status.
3. Locate motorr:
Press the button once, the direction light will lash 8 times, the siren will beep 8
times, and you can know where your motorcycle is.
4. Remote Start Engine:
Press the button twice within 3s to start the engine. Press on the
button or 3.5s, turn on the background light. A ter starting the engine by remote controller, the
engine will be on until you stop it by remote controller. You can drive the motorcycle without using
the key.
5. Adjust Sensitivit :
Adjust the sensitivity on the main rame by hand, turn clockwise to increase
sensitivity, turn anti-clockwise to decrease sensitivity. The sensitivity has been adjusted well when
leaving actory.
7. Anti-robber and assistance:
When the motorcycle is robbed and driven away, the owner-
driver can stop it by pressing the button once, the siren will sound urgently and the direction
lights will lash at the same time.
8. Code Learning:
In disarm mode, put the motorcycle key in the key lock and turn it rom ACC
OFF to ACC ON, 3 times in 3s, when the lights lash and the siren beeps once, press any button on
the remote controller in 10s, the direction lights will lash once, it means the system learn the
2

http://www.elfinx.com MC-2W
Code o the remote controller. The other remote controller can be learnt code in the same way.
( The code has been learnt well be ore leaving actory, the user need not learn it again i
unnecessary.)
Remark: one main rame could learn at most two remote controllers once.
9. Emergent disarming : I remote controller is lost, the driver need to turn key ON/OFF 8 times
within 8s, and disable the system.
10. Ke board lock : Press the buttons and at the same time and hold or 3.5 s to lock
keyboard ; press these two buttons or 3.5s again to unlock the keyboard.
3
Anti-theft main engine and common vehicle distribution wire
function contrast form
Vehicle Wire Mainframe
Wire Color
HONDA
Wire Color
SANYANG
Wire Color
YAMAHA
Wire Color
SUZUKI
Wire Col or
12v(+)
12v(-)
Key on+12v
Start Wire
Ignition off
(Up)
(Dowm)
Direction
Light
Direction
Light
Red
Black
Orange
Blue
Pink
Gray
Yellow
Yellow
Red
Black
Yellow/Red
Black and
White(Up)
Black and
White
(Down)
Lighte Blue
Orange
Green
Red
Black
Yellow/Red
Black and
White(Up)
Black and
White
(Down)
Light Blue
Orange
Green
Brown
Blue/White
Black and
White(Up)
Black and
White
(Down)
Deep Brown
Deep Green
Black
Red Red
Black/White
Orange
Black/White
(Remark1)
Black
Green
Ignition off
4
