ELGO Electronic EMSC2 Series User manual

Operating Manual
SERIES EMSC2/LMSC2
Magnetic Linear Encoder with 1 Vpp Sine/Cosine Outputs
EMSC is only functional with the ELGO MB20-20 magnetic tape (2 mm pole pitch)!
LMSC is only functional with the ELGO MB20-50 magnetic tape (5 mm pole pitch)!
Compact incremental magnetic sensors with integrated evaluation circuit
and speed proportional sine/cosine outputs
-EMSC: 2 mm measurement movement ≙1 signal period
-LMSC: 5 mm measurement movement ≙1 signal period
Distance to magnetic tape max. 0.8 mm (EMSC) / max. 2 mm (LMSC)
Non-contact and wear-free magnetic measuring principle
Suitable for linear and radial measurement applications
799000855 / Rev. 0 / 2018-12-18
Translation of the original operating manual

- 2 -
Publisher
ELGO Electronic GmbH & Co. KG
Carl-Benz-Str. 1
D-78239 Rielasingen-Worblingen
Technical Support
[phone]
[phone]
[email protected]
Document- No.
799000855
Document- Name
EMSC-LMSC2-000-MA-E_51-18
Document- Revision
Rev. 0
Issue Date
2018-12-18
Copyright
© 2018, ELGO Electronic GmbH & Co. KG

Contents
- 3 -
1Contents
1Contents ............................................................................................. 3
2List of Figures..................................................................................... 4
3List of Tables ...................................................................................... 4
4General, Safety, Transport and Storage ........................................... 5
4.1 Information Operating Manual .............................................................................5
4.2 Explanation of Symbols ........................................................................................5
4.3Statement of Warranties.......................................................................................6
4.4 Demounting and Disposal....................................................................................6
4.5 General Causes of Risk........................................................................................6
4.6 Personal Protective Equipment...............................................................................6
4.7 Conventional Use ...............................................................................................7
4.8 Safety Instructions for Transport, Unpacking and Loading ..........................................7
4.9 Handling of Packaging Material ............................................................................7
4.10 Inspection of Transport ........................................................................................7
4.11 Storage .............................................................................................................7
5Product Features ................................................................................ 8
5.1 Functional Principle.............................................................................................8
5.2 Magnetic Tape Variants .......................................................................................8
5.3 Representation of the Waveforms...........................................................................9
6Technical Data ................................................................................. 10
6.1 Identification ....................................................................................................10
6.2 Dimensions Sensor............................................................................................10
6.3 Technical Data of the Sin/Cos Output Signals .......................................................10
6.4 Technical Data Sensor .......................................................................................11
6.5Technical Data Magnetic Tape............................................................................12
7Installation and First Start-Up......................................................... 13
7.1 Operating Area ................................................................................................13
7.2 Installation of the Sensor ....................................................................................14
7.3 Installation of the Magnetic Tape.........................................................................16
8Connections...................................................................................... 19
8.1 Cable and Pin Assignment..................................................................................19
9Disturbances, Maintenance, Cleaning............................................. 20
9.1 Fault Clearance................................................................................................20
9.2 Re-start after Fault Clearance..............................................................................20
9.3 Maintenance.................................................................................................... 21
9.4 Cleaning .........................................................................................................21

Contents
- 4 -
10 Type Designation ............................................................................. 22
10.1 Accessories ......................................................................................................22
11 Index ................................................................................................ 23
2List of Figures
Figure 1: Magnetic tape ............................................................................................................................ 8
Figure 2: Representation of the Waveforms ................................................................................................. 9
Figure 3: Example of a follow-up circuit...................................................................................................... 9
Figure 4: Dimensions Sensor ................................................................................................................... 10
Figure 5: Alignment of the Sensor ............................................................................................................ 14
Figure 7: Mounting Tolerances ................................................................................................................ 15
Figure 5: Components of the magnetic tape ............................................................................................. 16
Figure 6: Handling ................................................................................................................................. 17
3List of Tables
Table 1: Mounting tolerances .................................................................................................................. 15
Table 2: Resistance against chemical influence.......................................................................................... 18
Table 3: Pin Assignment open cable ends ................................................................................................. 19
Table 4: Pin assignment Option D1, 9-pin D-SUB plug (ELGO standard) .................................................... 19
Table 5: Accessories ............................................................................................................................... 22

General, Safety, Transport and Storage
- 5 -
4General, Safety, Transport and Storage
4.1 Information Operating Manual
This manual contains important information regarding the handling of the device. For your own safety and operational safety, please ob-
serve all safety warnings and instructions. Precondition for safe operation is the compliance with the specified safety and handling instruc-
tions. Moreover, the existing local accident prevention regulations and the general safety rules at the site of operation have to be observed.
Please read the operating manual carefully before starting to work with the device! It is part of the product and should be kept close to the
device and accessible for the staff at any time. The illustrations in the manual are for better demonstration of the facts. They are not neces-
sarily to scale and can slightly differ from the actual design.
4.2 Explanation of Symbols
Special notes in this manual are characterized by symbols.
The notes are introduced by signal words which express the magnitude of danger.
Please follow this advice and act carefully in order to avoid accidents, damage, and injuries.
Warning notes:
DANGER!
This symbol in connection with the signal word “Danger” indicates an immediate danger for the life and health of
persons. Failure to heed these instructions can result in serious damage to health and even fatal injury.
WARNING!
This symbol in connection with the word „Warning” means a possibly impending danger for the life and health of
persons. Failure to heed these instructions can result in serious damage to health and even fatal injury.
CAUTION!
This symbol in connection with the signal word “Caution” indicates a possibly dangerous situation. Failure to heed
these instructions can lead to minor injuries or damage of property.
Special safety instructions:
DANGER!
This symbol in connection with the signal word “Danger” indicates an immediate danger for the life and health of
persons due to voltage.
Failure to heed these instructions can result in serious damage to health and even fatal injury. The operations may
only be carried out by a professional electrician.
Tips and recommendations:
NOTE!
…points out useful tips and recommendations as well as information for an efficient and trouble-free operation.
Reference marks:
Marks a reference to another chapter of this manual.
Marks a reference to another chapter of another document.

General, Safety, Transport and Storage
- 6 -
4.3 Statement of Warranties
The producer guarantees the functional capability of the process engineering and the selected parameters.
4.4 Demounting and Disposal
Unless acceptance and disposal of returned goods are agreed upon, demount the device considering the safety instructions of this manual
and dispose it with respect to the environment.
Before demounting, disconnect the power supply and secure against re-start. Then disconnect the supply lines physically and discharge
remaining energy. Remove operational supplies and other material.
Disposal:
Recycle the decomposed elements: Metal components in scrap metal, Electronic components in electronic scrap, Recycle plastic compo-
nents, dispose the remaining components according to their material consistence.
CAUTION!
Wrong disposal causes environmental damages!
Electronic scrap, electronic components, lubricants and other auxiliary materials are subject to special refuse and can
only be disposed by authorized specialists!
Local authorities and waste management facilities provide information about environmentally sound disposal.
Safety
CAUTION!
Please read the operating manual carefully, before using the device! Observe the installation instructions! Only start
up the device if you have understood the operating manual. The operating company is obliged to take appropriate
safety measure.
The initial operation may only be performed by qualified and trained staff.
Selection and installation of the devices as well as their embedding into the controlling system require qualified
knowledge of the applicable laws and normative requirements on the part of the machine manufacturer.
4.5 General Causes of Risk
This chapter gives an overview of all important safety aspects to guarantee an optimal protection of employees and a safe and trouble-free
operation. Non-observance of the instructions mentioned in this operating manual can result in hazardous situations.
4.6 Personal Protective Equipment
Employees have to wear protective clothing during the installation of the device to minimize danger of health.
Therefore:
Change into protective clothing before performing the works and wear them throughout the process.
Additionally observe the labels regarding protective clothing in the operating area.
Protective clothing:
PROTECTIVE CLOTHING
… is close-fitting working clothing with light tear strength, tight sleeves and without distant parts. It serves preliminari-
ly for protection against being gripped by flexible machine parts.
Do not wear rings, necklaces or other jewellery.
PROTECTIVE GLOVES
…for protecting the hands against abrasion, wear and other injury of the skin.
PROTECTIVE HELMET
…for protection against injuries of the head.

General, Safety, Transport and Storage
- 7 -
4.7 Conventional Use
The ELGO-device is only conceived for the conventional use described in this manual.
The ELGO length measuring system EMSC2/LMSC2 only serves to measure lengths, positions and distances.
CAUTION!
Danger through non-conventional use!
Non-intended use and non-observance of this operating manual can lead to dangerous situations.
Therefore:
Only use the device as described
Strictly follow the instructions of this manual
Avoid in particular:
Remodelling, refitting or changing of the construction or single components with the intention to alter the
functionality or scope of the device.
Claims resulting from damages due to non-conventional use are not possible.
Only the operator is liable for damages caused by non-conventional use.
4.8 Safety Instructions for Transport, Unpacking and Loading
CAUTION!
Transport the package (box, palette etc.) professionally. Do not throw, hit or fold it.
4.9 Handling of Packaging Material
Notes for proper disposal: 4.4
4.10 Inspection of Transport
Check the delivery immediately after the receipt for completeness and transport damage.
In case of externally recognizable transport damages:
Do not accept the delivery or only accept under reserve.
Note the extent of damages on the transportation documents or delivery note.
File complaint immediately.
NOTE!
Claim any damage immediately after recognizing it. The claims for damage must be filed in the lawful reclaim peri-
ods.
4.11 Storage
Store the device only under the following conditions:
Do not store outside
Keep dry and dust-free
Do not expose to aggressive media
Protect from direct sun light
Avoid mechanical shocks
Storage temperature (6) needs to be observed
Relative humidity (6) must not be exceeded
Inspect packages regularly if stored for an extensive period of time (>3 months)

Product Features
- 8 -
5Product Features
The EMSC2/LMSC2 is an incremental magnetic length measur-
ing system with 1 Vpp sine/cosine outputs. The sensor technology
and evaluation electronics are located in a compact housing,
which can be mounted horizontally or (if option L is ordered)
vertically to the magnetic tape.
The magnetic tape required for the measurement is glued onto a
flat surface with the supplied adhesive tape.
Depending on the version, a mounting distance of the sensor of max. 0.8 mm (EMSC) resp. max. 2.0 mm
(LMSC) to the magnetic tape must be observed.
The measuring system offers decisive advantages:
Measuring lengths theoretically unlimited
Resolution of EMSC: 2 mm = 1 signal period
Resolution of LMSC: 5 mm = 1 signal period
Very robust against contamination
Sensor/mounting position horizontal or (optional) vertical possible
Compact housing design and easy installation
5.1 Functional Principle
The basis of the magnetic incremental encoders consists of a scanning technology, which scans the north and
south poles on the coded magnetic tape and produces a single Sine/Cosine wave for each pole.
Depending on refinement of the interpolation, together with the pole distance of the magnetic tape, the resolu-
tion of the measuring system is determined. The evaluation circuit prepare the signals accordingly and output
them as sine/cosine waves (channels Sin+ / Cos+ and Sin−/ Cos−) with a level of 1 Vpp (see also 5.3
Representation of the Waveforms).
Figure 1: Magnetic tape
5.2 Magnetic Tape Variants
Depending on the selected measuring system (LMSC or EMSC) different ELGO magnetic tapes must be used:
The LMSC variant uses the ELGO magnetic tape type MB20-50-10-1-R with 5 mm pole pitch.
For the EMSC, however, the magnetic tape type MB20-20-10-1-R with 2 mm pole pitch must be used.
If the interpolation rates are higher than 200 when using the EMSC, we recommend using the high-
precision magnetic tape MB20-20-10-1-R-HG, which is available at an extra charge (refer also to sec-
tion 10.1 Accessories).
N N N NS S S S N N N NS S S S N NS SN NS SS

Product Features
- 9 -
5.3 Representation of the Waveforms
Figure 2: Representation of the waveforms
5.3.1 Example of a follow-up circuit
Figure 3: Example of a follow-up circuit
cos
cos Um (cos)
Signal voltages
Mechanical angle 
sin
sin Um (sin)
Differential signal (cos - cos)
Differential signal (sin - sin)
0
Signal voltages
Mechanical angle 
0
Distance
Distance

+(A - A)
A
A
120 Ω
R1
R1
R1
R1

Technical Data
- 10 -
6Technical Data
6.1 Identification
The type label serves for the identification of the unit. It is located on the housing of the sensor and gives the
exact type designation (=order reference, 10) with the corresponding part number. Furthermore, the type
label contains a unique, traceable device number. When corresponding with ELGO please always indicate this
data.
6.2 Dimensions Sensor
Figure 4: Dimensions Sensor
6.3 Technical Data of the Sin/Cos Output Signals
Parameter
Designation
min.
typ.
max.
Unit
Medium voltage
Um (sin),
Um (cos)
2.4
2.5
2.6
V
Amplitude
sin –sin
cos - cos
400
500
600
mV
Ratio
(sin - sin) /
(cos - cos)
0.9
1.0
1.1
-
Phase shift

89
90
91
° Degrees
Distortion factor
K
-
-
2
%
30
12.5
Magnetic tape
17
4
21
25
25
Ø 3.4

Technical Data
- 11 -
6.4 Technical Data Sensor
EMSC2/LMSC2 (Standard Version)
Mechanical Data
Measuring principle
incremental
Repeat accuracy
depending on evaluation electronics
System accuracy in µm at 20° C
(L = measuring length in m)
EMSC: ± (20 + 20 x L)
LMSC: ± (25 + 20 x L)
Distance sensor - magnetic tape
EMSC: max. 0.8 mm
LMSC: max. 2.0 mm
Sensor housing material
zinc die cast
Sensor housing dimensions
L x W x H = 30 x 12.5 x 25 mm (6.2)
Required magnetic tape
LMSC: MB20-50-10-1-R
EMSC: MB20-20-10-1-R (recommended for interpolation rates up to 200)
or MB20-20-10-1-R-HG (recommended for interpolation rates >200)
Basic pole pitch
EMSC: 2 mm / LMSC: 5 mm
Maximum measuring length
theoretically unlimited
Connections
standard: open cable ends
optional: 9-pin D-SUB connector
Sensor cable
standard length: 1.5 m (others on request)
Weight
ca. 35 g without cable; cable approx. 60 g/m
Electrical Data
Power supply voltage
5 VDC ±25 mV
Current consumption
max. 120 mA
Output signals
SIN+, COS+, SIN−, COS−
Output levels
1 Vss
Output frequency per channel
EMSC: max. 10 kHz
LMSC: max. 4 kHz
Output current per channel
max. 20 mA
Resolution
EMSC: 2 mm movement ≙1 signal period
LMSC: 5 mm movement ≙1 signal period
Operating speed
max. 10 m/s
Environmental Conditions
Storage temperature
-25 … +85° C
Operation temperature
-10 … +70° C
(-25 … +85° C on request)
Humidity
max. 95 %, non-condensing
Protection class
IP67

Technical Data
- 12 -
6.5 Technical Data Magnetic Tape
The magnetic tape consists of two components:
The actual magnetic tape which carries the position information
A mechanical stainless steel back iron
Magnetic Tape MB20-20-10-1-R and MB20-50-10-1-R
Coding
incremental, single track system
Pole pitch
MB20-20-10-1-R: 2 mm
MB20-50-10-1-R: 5 mm
Operation temperature installed
-20 … +65° C
(-20 … +80° C when using without adhesive tape, options „B“ or „D“)
Storage temperature uninstalled
Short-term: -10 … +60° C
Medium-term: 0 …+40° C
Long-term: +18° C
(-20 … +80° C when using without adhesive tape, options „B“ or „D“)
Gluing temperature
+18 … +30° C
Relative humidity
max. 95 %, non-condensing
Accuracy at 20° C in µm
± (25 µm + 20 µm x L) L = measuring length in meters
Material carrier tape
precision strip 1.4310 / X10CrNi 18-8 (EN 10088-3)
Double-faced adhesive tape
3M-9088 (observe instructions), others on request
Dimensions
with carrier tape, without adhesive tape:
10 mm (± 0,1) x 1.35 mm (± 0.11)
with carrier tape + adhesive tape, without protection foil:
10 mm (± 0,1) x 1.56 mm (± 0.13)
with carrier tape + adhesive tape + protection foil:
10 mm (± 0,1) x 1.63 mm (± 0.14)
Length expansion coefficient
16 x 10-6 1/K
Thermal length expansion
∆L[m] = L[m] x [1/K] x ∆[K]
(L = tape length in meters, ∆= relative temperature change)
Bending radius
min. 60 mm
Available lengths
32 m (up to 70m on request)
Weight of the magnetic tape
ca. 62 g/m (incl. magnetic tape and cover tape)
Tape imprint
ELGO standard, printing color black, digit height >= 5 mm
Influence of external magnets
External magnetic fields must not exceed 64 mT (640 Oe; 52 kA/m) on the
surface of the magnetic tape because this could damage or destroy the code
on the tape.
Protection class
IP65

Installation and First Start-Up
- 13 -
7Installation and First Start-Up
CAUTION
Please read the operating manual carefully before using the device! Strictly observe the Instal-
lation instructions! In case of damage caused by failure to observe this operating manual, the
warranty expires.
ELGO is not liable for any secondary damage and for damage to persons, property or assets.
The operator is obliged to take appropriate safety measures.
The first start-up may only be performed by qualified staff that has been trained and author-
ized by the operator.
7.1 Operating Area
WARNING!
Do not use the device in explosive or corrosive environments!
The device must not be installed close to sources of strong inductive or capacitive interference
or strong electrostatic fields!
CAUTION!
The electrical connections must be made by suitably qualified personnel in accordance with
local regulations.
The device may be designed for switchboard mounting. During work on the switchboard, all
components must be de-energized if there is a danger of touching the energized parts!
(protection against contacts)
Wiring works may only be performed in the de-energized state!
Thin cable strands have to be equipped with end sleeves!
Before switching on the device, connections and plug connectors have to be checked!
The device must be mounted in a way that it is protected against harmful environmental influ-
ences such as splashing water, solvents, vibration, shock and severe pollution and the operat-
ing temperature must not be exceeded.

Installation and First Start-Up
- 14 -
7.2 Installation of the Sensor
For mounting the sensor two M3 screws are required.
Observe the mounting tolerances stated in section 7.2.2.
7.2.1 Alignment of Sensor / Magnetic Tape
Since the active sensor surface is not in the center of the sensor housing, it should be ensured that the sensor
head is aligned and mounted such that the active sensor surface is in the middle of the magnetic tape. This is
achieved in a simple manner and without additional equipment. Just use the correct side of the sensor (see fig-
ure below) and install it flush with the magnetic tape.
Figure 5: Alignment of the Sensor
5
Marker
Magnetic tape top view
EMSC:
0.1... 0.8 mm
LMSC:
0.1... 2.0 mm
7.5
12.5
12.5
17.5
Cable outlet
The entire active sensor surface must be installed
within the permitted distance to the magnetic tape.
When mounting, please just make
sure that the sensor is flush with
the magnetic tape on this side.
Cable outlet
Standard (horizontal) Option L (vertical) Top view
EMSC:
0.1... 0.8 mm
LMSC:
0.1... 2.0 mm

Installation and First Start-Up
- 15 -
7.2.2 Mounting Tolerances
The tolerances apply equally to both mounting variants resp. regardless of whether the sensor is mounted hori-
zontally (standard) or vertically (option L).
Table 1: Mounting tolerances
Tolerances
Sensor distance to the tape
EMSC: 0.1 …max. 0.8 mm
LMSC: 0.1 … max. 2.0 mm
Pitch (longitudinal)
The maximum sensor distance must not be exceeded at any position
Pitch (lateral)
±0.5°
Yaw angle
±0.5°
Offset (lateral)
± 2.5 mm
Figure 6: Mounting Tolerances
Sensor distance Pitch (lateral)
Pitch (longitudinal) Offset (lateral)
D
Yaw angle
±0.5 °
±2.5 mm
EMSC = 0.1... 0.8 mm
LMSC = 0.1... 2.0 mm
EMSC = max. 0.8 mm
LMSC = max. 2.0 mm

Installation and First Start-Up
- 16 -
7.3 Installation of the Magnetic Tape
NOTE External Magnetic Fields
The magnetic tape must not be influenced by external magnetic fields!
The magnetic tape must not come into direct contact with other magnetic fields (e.g. perma-
nent magnets, magnetic clamps, electromagnets, magnetic stands)! This may cause irrepara-
ble damage, which will compromise the measuring accuracy or even the functioning.
7.3.1 The Magnetic Tape MB20-20-10-1-R / MB20-50-10-1-R
In the standard case, the magnetic tape is delivered as described
It is installed by gluing it to the respective mounting surface.
The magnetic tape consists of 2 pre-assembled components:
A magnetized, flexible plastic tape (Pos. 3), which is connected with a magnetically conductive steel
tape as inference band (Pos. 4) and is supplied with an adhesive tape (Pos. 5).
A magnetized permeable cover tape (Pos. 1), which serves for the mechanical protection of the plastic
tape (not required for the measurement) and is supplied with an adhesive tape (Pos. 2).
Therefore a divergent tape structure and scope of delivery is also possible.
The cover tape is also available separately
Figure 7: Components of the magnetic tape
Pos. 1: Stainless steel cover tape
Pos. 2: Double-sided tape
Pos. 3: Magnetized plastic tape
Pos. 4: carrier tape stainless steel
Pos. 5: Double-sided tape
Pos. 6: Mounting surface, for example machine bed

Installation and First Start-Up
- 17 -
7.3.2 Handling
In order to avoid tension in the tape, it must not be stretched, compressed or twisted.
It should be stored with the magnetized plastic tape to the outside (see Figure 8), the minimum bending radius
must be noted here
Figure 8: Handling
7.3.3 Processing hint for the gluing of magnetic tapes
Surface-Preparation: In order to guarantee optimal adhesion, all anti-adhesive contamination (e.g. oil, grease,
dust, separating agents) has to be removed using solvents with residue-free evaporation.
Suitable agents are ketones or alcohols. Typical solvents for cleaning the surface are a 50/50 isopropyl alco-
hol/water mixture or heptane. Those agents are offered by Loctite and 3M among others as surface cleaners.
When using solvents, always observe the manufacturer instructions! If the surface is copper, brass etc., it should
be sealed to avoid oxidation.
Contact-Pressure: The strength of the adhesion is directly dependent on the contact the adhesive can form with
the surface. Therefore it is important to use as much pressure as possible when gluing the tape, possibly by us-
ing aids such as draw rolls. The optimum contact pressure is 4…5 kg/cm2).
Gluing temperature: The optimal gluing temperature is between + 18° C and 30° C. Avoid colder sticking sur-
faces than + 10°C, because in this case the adhesive becomes too hard and perhaps a sufficient immediate
adhesion is hardly to achieve. After proper sticking, the stability of the connection is ensured also when the tem-
perature is below zero. The final tackiness of a sticking is from experience reached after approximately 72 hours
(at + 21° C). For gluing use only the supplied adhesive tape.
7.3.4 Cutting and Gluing
Before starting the gluing process, both the magnetic and the cover tape have to be cut to the required length
Length cover tape = measuring length + sensor length + 50mm (end caps)
NOTE!
When sticking the magnetic tape pay attention to the markings on the tape and the Sensor.
Improper installation does not provide the correct values. A already glued magnetic tape is
destroyed after the removal, and cannot be used again. Note also the direction of counting
of the measuring system
Preferably the magnetic tape should be glued close to an edge or into a groove, which
should be deep enough to embed the magnetic tape and the cover tape.
When unprotected, the cover tape may peel off!
Therefore: Use tape end caps (10.1) or let the cover tape overlap the end of the magnetic
tape and fix it with a screw.
Magnetized
Plastic tape
Steel tape

Installation and First Start-Up
- 18 -
The tape must be glued smoothly on the surface. The measuring accuracy decreases if the tape is not even!
Before gluing the magnetic tape and the cover tape onto the surface, they should be left lying on the mounting
surface for ca. 30 minutes so that the temperature matches. This prevents strain in the tape due to thermal ex-
pansion.
Mounting steps:
1. Thoroughly clean surface (7.3.3)
2. Acclimatization: let magnetic tape and cover tape adjust their temperature
3. Remove the protection foil from the magnetic tape
4. Glue magnetic tape under great pressure
5. Thoroughly clean surface of magnetic tape
6. Remove the protection foil from the cover tape
7. Glue the cover tape under great pressure
8. Safeguard the ends of the cover tape against peeling off, e.g. by using end caps (10.1)
7.3.1 Resistance against Chemical Influence
Table 2: Resistance against chemical influence
Show no or little effect in constant contact after 2-5 years:
formic acid
glycerol 93°C
linseed oil
soy beans oil
cotton seed oil
N-hexane
lactic acid
formaldehyde 40%
Iso octane
petroleum
Show weak to moderate effects in constant contact after approximately 1 year:
acetone
gasoline
acetic acid 30%
oleic acid
acetylene
steam
acetic acid, pure acetic acid
sea water
ammonia
acetic acid 20%
isopropyl ether
stearic acid 70°C, anhydrous
kerosene
Have strong effects when contacting permanently after 1-5 months:
benzene
nitric acid 70%
turpentine
toluene
lacquer solvent
nitric acid, red, vitriolic
carbon tetrachloride
tetrahydrofuran
trichloroethylene
nitrobenzene
hydrochloric acid 37%, 93°C
xylene

Connections
- 19 -
8Connections
8.1 Cable and Pin Assignment
Table 3: Pin Assignment open cable ends
Drawing
Color
Function
Description
Open cable ends:
white
GND
0 VDC
brown
VCC
+ 5 VDC
green*
SIN+
sine positive
violet*
SIN−
sine negative
black*
COS+
cosine positive
grey*
COS−
cosine negative
yellow
N.C.
not connected
orange
N.C.
not connected
blank
PE
screen/shield/earth
Table 4: Pin assignment Option D1, 9-pin D-SUB plug (ELGO standard)
Drawing
Pin
Function
Description
9-poliger D-SUB:
Lötseite:
1
GND
0 VDC
2
VCC
+ 5 VDC
3*
SIN+
sine positive
6*
SIN−
sine negative
8*
COS+
cosine positive
9*
COS−
cosine negative
4
N.C.
not connected
5
N.C.
not connected
7
N.C.
not connected
housing
PE
screen/shield/earth
REMARK!
*) The lines for SIN+ / SIN− and COS+ / COS−
must be terminated on the customer side by using a 120 resistor.
54321
9 8 7 6
yellow green brown white
grey black orange violetShield
120 
120 
120 
120 

Disturbances, Maintenance, Cleaning
- 20 -
9Disturbances, Maintenance, Cleaning
This chapter describes possible causes for disturbances and measures for their removal. In case of increased disturbances, please follow the
measures for fault clearance in chapter 9.1.
In case of disturbances that cannot be eliminated by following the advice and the fault clearance measures given here, please contact the
manufacturer (see second page).
9.1 Fault Clearance
CAUTION!
The device, the connection line and the signal cable must not be installed next to sources of interference that emit
strong inductive or capacitive interference or strong electrostatic fields.
External perturbations can be avoided thorough suitable cable routing.
The screen of the signal output cable should only be connected to the following circuit on one side. The screens
should not be grounded on both sides. Signal cables always have to be routed separately from the load power line.
A safety distance of at least 0,5 m has to be kept from inductive and capacitive sources of interference such as con-
tactors, relays, motors, switching power supplies, clocked controllers etc.!
If interferences occur in spite of all the items stated above being observed, please proceed as follows:
1. Installation of RC-circuits via contactor coils of AC-contactors (e.g. 0,1 µF / 100 )
2. Installation of recovery diodes via DC-inductors
3. Installation of RC-circuits via the different motor phases (in the terminal box of the motor)
4. Do not connect protective earth and ground
5. Connect a mains filter ahead of the external power pack
9.2 Re-start after Fault Clearance
After the fault clearance:
1. Reset the emergency stop mechanism if necessary
2. Reset the error report at the super-ordinate system if necessary.
3. Ensure that there are no persons in the danger area.
4. Follow the instructions from chapter 7.
WARNING!
Danger of injury through non-conventional fault clearance!
Non-conventional fault clearance can lead to severe injuries and damage of property.
Therefore:
Any work to clear the faults may only be performed by sufficiently qualified staff
Arrange enough space before starting the works
Make sure that the mounting area is clean and tidy. Loose components and tools are sources of accidents.
If components need to be replaced:
Pay attention to a correct installation of the spare parts.
Reinstall all the fixing elements properly
Before turning on the device, ensure that all covers and safety equipment is installed correctly and functions
properly
