Elite Screens CineTension2 Series Quick reference guide

PRODUCT WHITE PAPER
http://www.elitescreens.com
1
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
CINETENSION2 SERIES
Section 1: Screen Design
1.1 What is it for?
CineTenison2 is a robust and well made electric motorized projector screen. A full IR/RF,
RJ45 and 5-12 volt trigger control package is included.
1.2 How does it work?
Its tab-tensioned material provides uniform flatness and has a wide viewing angle. The
1.0 gain material is also 4K Ultra HD and active 3D ready. It drops and retracts by means of
a powerful tubular motor and its sliding installation brackets ensure a perfectly centered
installation.
Section 2: Product Features
2.1 Characteristics
Screen Material
•160° wide viewing angle
•4K Ultra HD, Active 3D, and HDR Ready
•Standard 4-side black masking borders
•Available in the following range of diagonal sizes
•84" - 150" in 4:3 format
•84" - 135" in 16:9 format
•96" - 153" in 2.35:1 format
Design and Installation
•Floating installation brackets provide easy alignment with wood studs to accommodate a
wall or ceiling installation
•Black Aluminum housing with enamel coating is moisture resistant (white housing for 180"
version)
•Shipped ready to plug & play with installation kit containing brackets, screws, and bubble
leveler included
•Optional in-ceiling trim kit - sold separately
•Optional extended 11x4 or 12x8 L brackets - sold separately
Control System
•Standard Infrared (IR) and Optional ZR800D IR Universal Learning Remote system
•Standard Radio Frequency (RF) remote control operates screen from 100 feet away
•Low-voltage detachable 3-way wall switch for in-line control
•Extended IR "eye" sensor for in-ceiling Infrared operation

PRODUCT WHITE PAPER
http://www.elitescreens.com
2
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
•Wireless 5-12 volt trigger included for synchronized screen operation with the projector's
power cycle
•RJ45 port allows 3rd party control system integration
•Optional ZR800D IR Universal Remote Control and In-wall switch available - sold separately
Quality and Reliability
•Tubular motor allows swift operation with a superior weight tolerance and operational
lifespan
•Certified by AMX and CRESTRON
•Conforms to ANSI/UL STD. 60950-1
•Certified to CAN/CSA STD. C22.2
•2-year Parts & Labor manufacturer's warranty
•3-year warranty offered through ENR-G program (Education, Non-Profit, Religious and
Government)
2.2 Model Numbers
Model Number
Diag.
Size
Aspect
Ratio
Viewing
Height
(in)
Viewing
Width
(in)
Screen Material Gain
Case
Color
N.W.
(lbs)
G.W.
(lbs)
Packing Dims.
(LxWxH)
TE110HW2-A1080P2 110" 16:9 53.9 95.9 AcousticPro1080P2 1.0 Black 47.2 64.8 120.8"x7.5"x9.8"
TE100HC2 100" 16:9 49.0 87.2 CineGrey 1.0 Black 45.9 61.2 110.0"x7.5"x9.8"
TE135HC2 135" 16:9 66.2 117.7 CineGrey 1.0 Black 52.9 73.4 141.8"x7.5"x9.8"
TE92HC2 92" 16:9 45.1 80.2 CineGrey 1.0 Black 42.6 57.8 103.3"x7.5"x9.8"
TE100VW2 100" 4:3 60.0 80.0 CineWhite® 1.1 Black 43.0 59.5 103.5"x7.5"x9.8"
TE100VW2-E12 100" 4:3 60.0 80.0 CineWhite® 1.1 Black 44.5 59.5 103.5"x7.5"x9.8"
TE103C-E24 103" 2.35:1 40.3 94.8 CineWhite® 1.1 Black 43.2 59.5 130.0"x7.5"x9.5"
TE106XW2-E24 106" 16:10 56.2 89.9 CineWhite® 1.1 Black 41.4 56.9 115.0"x7.5"x9.5"
TE116XW2 116" 16:10 61.5 98.4 CineWhite® 1.1 Black 50.3 68.8 123.0"x7.5"x9.5"
TE120VW2 120" 4:3 72.0 96.0 CineWhite® 1.1 Black 47.8 65.5 120.7"x7.5"x9.5"
TE125C-E20 125" 2.35:1 48.9 115.0 CineWhite® 1.1 Black 50.1 68.3 139.8"x7.5"x9.5"
TE128XW2-E12 128" 16:10 67.8 108.5 CineWhite® 1.1 Black 47.4 66.1 133.5"x7.5"x9.5"
TE135VW2 135" 4:3 81.0 108.0 CineWhite® 1.1 Black 51.5 70.6 132.8"x7.5"x9.8"
TE138C-E16 138" 2.35:1 54.0 127.0 CineWhite® 1.1 Black 54.7 74.9 151.5"x7.5"x9.5"
TE139XW2 139" 16:10 73.7 117.9 CineWhite® 1.1 Black 55.1 75.6 141.8"x7.8"x9.5"
TE150VW2 150" 4:3 90.0 120.0 CineWhite® 1.1 Black 56.4 77.2 145.7"x7.5"x9.8"
TE153C-E12 153" 2.35:1 59.9 140.8 CineWhite® 1.1 Black 60.7 82.4 165.5"x7.5"x9.5"
TE84HW2 84" 16:9 41.2 73.2 CineWhite® 1.1 Black 36.9 54.5 97.1"x7.9"x9.8"

PRODUCT WHITE PAPER
http://www.elitescreens.com
3
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
TE84HW2-E30 84" 16:9 41.2 73.2 CineWhite® 1.1 Black 38.5 55.4 98.2"x7.9"x9.8"
TE92VW2 92" 4:3 55.2 73.6 CineWhite® 1.1 Black 29.1 42.0 94.0"x7.3"x8.5"
TE94XW2 94" 16:10 49.8 79.7 CineWhite® 1.1 Black 37.5 52.9 103.3"x7.5"x9.8"
TE96C-E24 96" 2.35:1 37.6 88.3 CineWhite® 1.1 Black 39.4 55.1 113.0"x7.5"x9.5"
TE84VW2 84" 4:3 50.4 67.2 CineWhite® 1.1 Black 27.6 41.0 89.4"x6.7"x9.0"
TE100VG2 100" 4:3 60.0 80.0 PowerGain 1.8 Black 43.0 59.5 103.5"x7.5"x9.8"
TE84HG2 84" 16:9 41.2 73.2 PowerGain 1.8 Black 27.0 41.5 94.0"x7.3"x8.5"
TE84VG2 84" 4:3 50.4 67.2 PowerGain 1.8 Black 27.6 39.4 89.4"x6.7"x9.0"
TE92HG2 92" 16:9 45.1 80.2 PowerGain 1.8 Black 42.6 57.8 103.3"X7.5"X9.8"
TE92VG2 92" 4:3 55.2 73.6 PowerGain 1.8 Black 29.1 42.0 94.0"x6.7"x9.0"
TE120HD2 120" 16:9 58.8 104.6 AirBright 3D2 2.0 Black 52.7 70.6 130.0"x7.9"x9.8"
Section 3: Screen Material Specifications
3.1.1 AcousticPro 1080P2 Characteristics
The AcousticPro 1080P2 has a matte white
surface with a 1.0 gain that provides excellent
color neutrality for superb color reproduction
along with wide diffusion uniformity. The
angular weave material is designed to allow
wall-speaker sound to breathe through the
screen while eliminating the visual artifact known
as moiré effect. The precision angled mesh of the
material allows viewers to enjoy a visually
superior presentation with strong color neutrality and artifact-free performance. The material
is perfect for use with native 1080P projectors for home cinema and commercial applications.
Features & Benefits
•Acoustically Transparent Matte White (angular weave)
•Gain: 1.0 / Viewing Angle: 160° (80° L/R)
•Superb off-axis luminance
•Optimal color neutrality; color shift is not compromised
•Works best with 1080P DLP projectors and 720P (reduces moiré effect)
•Black backing eliminates backlighting artifacts from light bleed-through (only on fixed frame
models)
•Mean attenuation of -2.05dB

PRODUCT WHITE PAPER
http://www.elitescreens.com
4
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
3.2.1 CineGrey Characteristics
CineGrey (Tension High Contrast Grey) is designed for
low contrast DLP and LCD Home Cinema Projectors.
Its superior flatness makes the CineGrey ideal for
home theater use. It enhances black levels while
minimizing loss in color reproduction. Uniform
diffusion surface has black-backing to eliminate light
penetration and is easily washable with mild soap and
water.
*Manufacturer's Tip: if your projector's contrast ratio is more than 2000:1, we recommend
you use CineWhite material for a brighter picture.
Features & Benefits
•Multi-layer PVC with texture and surface coating
•Enhances color contrast and black levels
•Gain: 1.0
•View Angle: 160° (80° ±LR)
•Mildew Resistant
•Black backing
•Surface can be cleaned with (water) moist cotton cloth
•Active 3D, 4K Ultra HD, and HDR ready
3.2.2 CineGrey Gain and Viewing Angle Chart
Specifications
Thickness 0.3 mm
Weight 350 g/m²
Maximum Height 3.2 M (10 ft)
On-axis Gain 1.0
Half-Gain Angle At 50°

PRODUCT WHITE PAPER
http://www.elitescreens.com
5
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
3.3.1 CineWhite® Characteristics
CineWhite® (Tension Matte White) has broad
light dispersion through diffusion uniformity,
black & white contrast and true color rendition
making it the most versatile in Elite's tensions
screen product lines. This tension PVC surface
is the best choice for today's high-contrast
ratio projectors in commercial or residential presentations. The CineWhite® material equals the
performance to our MaxWhite® product, but improves the experience with the superior
surface flatness. Uniform diffusion surface has black-backing to eliminate light penetration
and is easily washable with mild soap and water.
Features & Benefits
•Multi-layer PVC (Polyvinyl chloride) with texture and surface coating
•Gain: 1.1
•View Angle: 180° (90° ±LR)
•Full Lambertian Diffuser- no half gain drop
•Produces exceptional picture quality for any
presentation
•Mildew Resistant
•Active 3D, 4K Ultra HD, and HDR ready
•Surface can be cleaned with (water) moist cotton cloth
3.3.2 CineWhite® Gain and Viewing Angle Chart
Specifications
Thickness 0.27 mm
Weight 350 g/m²
Maximum Height 3.2 M (10 ft)
On-axis Gain 1.0
Half-Gain Angle Does not reach half gain

PRODUCT WHITE PAPER
http://www.elitescreens.com
6
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
3.4.1 PowerGain Characteristics
The PowerGain is perfect for environments
where total ambient light control cannot be
attained. This is an angular reflective material
that provides crisp color reproduction, black &
white contrast and resists hot spotting in the
presence of ambient light. The textured
pearlescent material has black-backing to avoid
light penetration and can be safely cleaned with
mild soap and water.
*Manufacturer's tip: Use a high resolution-low output DLP projector for the best results with
this material.
Features & Benefits
•Multi-layer PVC (Polyvinyl chloride) with texture and surface coating
•Gain: 1.8
•View Angle: 120° (60° ±LR)
•Mildew Resistant
•Black backing
•Active 3D, 4K Ultra HD, and HDR ready
•Surface can be cleaned with (water) moist cotton cloth
3.5.1 AirBright 3D2 Characteristics
Elite’s AirBright 3D2 is a Polarized 3D silver front
projection screen material. It is designed to
preserve polarization for passive 3D Dual
Projector Systems and has arguably proven itself
to be the best solution for three-dimensional
home theater presentations. It provides superb
brightness and contrast for either a regular
2-dimensional or full-immersion 3D
imaging. The material supports 2.0 gain reflectivity with strong black levels and a wide 120°
viewing angle. These features make the AirBright 3D2 ideal for professional grade passive 3D
applications in either a commercial or residential environment.

PRODUCT WHITE PAPER
http://www.elitescreens.com
7
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Features & Benefits
•Tensioned 3D polarized silver screen surface provides a sharp uniform picture
•Active 3D, 4K Ultra HD, and HDR ready
•96% polarization retention
•Gain: 2.0
•Wide View Angle: 120° (L&R 60°)
•Screen size up to 350" 16:9 in Fixed Frame format
•Screen surface can be cleaned with mild soap and water
•Mildew Resistant
•Custom Sizes available
•Perfect companion piece for Airflex5D - 2D/3D Multi-Projector Stacking System to form as
a professional grade passive 3D system.
Section 4: Execution
4.1 Important Safety & Warning Precautions
Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO
extra Black Top Drop in the roller. Please be aware of this as it will void your warranty with
Elite Screens. Unapproved changes or modifications (except for cutting the power cord for
hardwire installations) to this unit are prohibited and will void your warranty. For more
information, please contact our Technical Support Department at [phone] Ext. 604.
•Please retain this user’s guide for future reference.
•To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the
manufacturer.
•Handle the unit carefully during transportation to avoid any damages.
•To ensure safe and reliable operation, direct connection to a properly grounded power source is advised.
•The power outlet supplying power to the unit should be close to the unit and easily accessible.
•Do not install the unit on uneven, inclined surfaces;
•Do not install in damp places to avoid an electric shock or short circuit.
•Do not place any heavy objects over the power cord.
•Position the power cord properly to avoid creating a trip obstacle.
•To avoid an electrical shock or fire, due to a loose contact or short circuit, do not overload the power cord.
•The internal & external parts of this unit are not end user serviceable. Do not attempt to disassemble this
unit by yourself. No one except authorized technicians can open and make repairs to this unit.
•Make sure the power source that this unit is connected to has a continuous power flow.

PRODUCT WHITE PAPER
http://www.elitescreens.com
8
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
•If there is need to use an extension cord, make sure the cord has an equal rating as the appliance to avoid
over heat.
•Do not handle the power plug when your hands are wet or your feet are in contact with water.
•Properly dispose of this equipment according to the environmental regulations in your area when product
is no longer of service.
Do not use this unit under the following circumstances.
•Disconnect the power cord under the conditions of heavy rain, wind thunder or lightning.
•Avoid direct sun light, rain shower and moisture.
•Keep away from fire sources and high temperature to prevent this device from overheating.
•Cut off the power supply first before transportation or maintenance.
•To avoid possible injury and/or an electric shock, do not attempt to use this screen if there is obvious
damage or if there are any evident broken parts.
Installation Warning
The instructions provided in this user’s guide are for reference only. Please consult a
professional installation company for further installation and safety advice. The installer must
insure that proper mounting hardware is used to provide adequate strength suitable for the
installation. Elite Screens is not liable for any faulty installations. For limit adjustment
instructions, please contact our Technical Support Department at [phone] Ext. 604
The Screen’s Top Black Drop is already set to its maximum drop distance. There is NO extra top black
drop in the roller. Please be aware of this as it will void the limitation of your warranty.
Individual modifications to this product are prohibited and will void the warranty with the
manufacturer. Please contact Elite Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur on a particular installation. If this
equipment causes harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures.

PRODUCT WHITE PAPER
http://www.elitescreens.com
9
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Reorient or relocate the receiving antenna of the device which may be casing the
interference.
Increase the separation between the screen and the device’s receiver.
Connect the equipment into a different power outlet other than the device.
Pre-Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with
foreign particles such as dust, sawdust, and/or liquids.
NOTE:
Regardless of the mounting method, the screen should be securely supported so that the
vibration or pulling on the viewing surface will not cause the casing to become loose or fall. The
installer must insure the fasteners that are used are of adequate strength and suitable for the
installation location.
4.2 Controls and Accessories
A. IR Remote B. RF Remote C. Wall switch control box D. 5-12 volt trigger cable
E. IR extended “eye” receiver F. Wireless 5-12v (3.5 mm)
mono trigger cable
G. AAA batteries H. Bubble leveler
4.3 Screen Operation
Electric Current: Depending upon region, your Elite Screen will operate on 100v, 110v, or 220v voltage.
After ensuring the power outlet & screen are compatible (voltage), plug the power cord into power outlet.
Once the screen has power, you’ll be able to control it using any of the 6 methods described below.

PRODUCT WHITE PAPER
http://www.elitescreens.com
10
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
3-way Wall switch
3-prong power cable
Red: DC 12 +
Green: 0 V
-
RJ-45 input for 5-12V Trigger
IR “Eye” Receiver
UP
STOP
DOWN
Fig.1
IR/RF remote
Fig.2
Fig.3
5. 5-12 volt trigger (Item D, Fig 4):The built-in
5-
12V trigger input allows your screen to
synchronize its drop & rise with the projector’s
power cycle. The screen deploys when the
projector powers up and will retract when the
projector powers down. The 5-12 volt RJ45 cable
connects to your projector’s trigger output via a
separate cable that may or may not be provided by
the manufacturer of the projector. The trigger
feature will not work without an output cable from
the projector, but it can be tested by connecting the
Red (+) and Green (-) cable to a 9-volt battery.
Fig.4
1. IR remote control (ItemA, Fig 1): The Infrared functions by direct line of
sight contact with a beam range of 30 feet. Aim the IR remote at the circular
window located on the left side of the screen
2. IR “Eye” Receiver (Item E, Fig 2): The IR “Eye” Receiver plugs directly into
the screen’s RJ-45 input to present a low profile line-of-sight control option for
your IR remote control even in a recessed ceiling installation.
3. RF Remote Control (Item B): The radio waves eliminate the need for a direct
line of sight with a range of 100 feet.
4. 3-Way Wall Switch (Item C, Fig 3): The 3-way wall switch is a wall mount
control box with an up/stop/down button and plugs directly into the screen’s
RJ-45 input.
6 ways to control your CineTension 2
5-12 Volt Trigger Cable

PRODUCT WHITE PAPER
http://www.elitescreens.com
11
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
6. Wireless 5-12 volt trigger (Item F, Fig 5):
The RF remote control serves as a dual purpose,
independently as a handheld remote control, or
in conjunction with the Wireless 5-12 volt
trigger cable. The radio frequency technology
can be programmed to send a wireless signal to
synchronize its drop/rise with the projector’s
power cycle.
4.4 Hardware Parts List
A. M12 Dry-wall anchor x 4 or 6 B. Bolt x 2 or 3 C. Masonry Screw x 4 or 6 C. Extruded Hanging Bracket x 2 or 3
120” & above x 3 brackets
4.5 Installation Instructions
Wall Screws included with this product are complementary and may not be adequate for all mounting
surfaces. Consult with a professional installer or hardware store for proper mounting screws and anchors.
Please consult a professional installer. Elite Screens is not liable for any faulty installations.
DC 5-12V out
The back of the projector
Wireless5-12V trigger cable
UP
Stop
Down
Fig 5
Here’s how to set up your Wireless 5-12 volt trigger | Synchronization Instructions
Step1: Connect one end of the 3.5 mm wireless 5-12 volt trigger cable to the RF remote.
Step 2: Connect the other 3.5 mm end of the wireless 5-12 volt trigger cable to your projector
Step 3: Make sure to unplug your screen from the power outlet
Step 4: Hold the UP button on your RF remote
Step 5: While holding the UP button, plug the screen back to the power outlet
Step 6: Wait 5 seconds and then release the UP button
Step 7: Your 5-12V wireless trigger should now be activated with your screen and ready to be used
and able to control your screen with your projector’s power cycle
Repeat the steps again if not successful.
(Please be aware, the projector on/off cycle may take longer to fully activate. It usually takes around
20-30 seconds for full off and on cycle each time)

PRODUCT WHITE PAPER
http://www.elitescreens.com
12
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
1. Insert each Bolt (B) through the right & left slide channel located on the top of the screen’s case.
2. Slide the Extruded Hanging Bracket (D) through the rail located below the slide channel until it
meets with the top of the Bolt (B) and slightly secure the lug-nuts located on the top & bottom of the
bolt to attach the bracket.
3. Mark the installation location to drill your hole. Insert the proper screw and secure the bolts to the
bracket.
4. Example of the CineTension 2 installed to a wall, ceiling and enclosed.
Flush mount to
wall
Flush mount to
ceiling
Enclosed
installation
*Allow 2” of spacing
between the front and
back of the screen casing.
Top hole for ceiling installation
Back hole for wall installation
A & C
B
A & C
D
PARTS

PRODUCT WHITE PAPER
http://www.elitescreens.com
13
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
4.6 Adjusting the Tension String
There are adjustment knobs located at the end of the weight bar of the screen. If for any reason the tension
string(s) is loose, you can re-tension it by adjusting the tension string(s) knobs. The tension should be equally
balanced in order to provide a flat, uniform projection surface.
Attention: The screen’s tension has been preset to achieve its best performance. The
aforementioned adjustments are typically not required. Prior to making adjustments, please
contact Elite Screens for assistance to avoid damaging the screen and voiding your warranty.
Section 5: Product Specifications
5.1 Dimensions
Model
Number
A A1 A2 A3 B B1 B2 B3 B4 B5 B6 B8 C C1 C2 G1 G2 G3 G4 G5 G6 G7 G8
Unit: Inches
TE110HW2
-A1080P2
113.4 95.9 104.5 108.9 70.4 53.9 63.7 68.4 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE100HC2 103 87.2 94.6 98.4 65.5 49 58.8 63.5 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE135HC2 135.4 117.7 126.3 130.9 80.7 66.2 74 78.7 3.8 4.7 6.7 4 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE92HC2 96 80.2 87.7 91.5 61.5 45.1 54.8 59.6 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE100VW2 96 80 87.5 91.5 76.5 60 69.8 74.5 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE100VW2
-E12
96 80 87.5 91.5 82.5 60 75.8 80.5 3.8 4.7 6.7 12 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
Direction of
wrapping thread
Adjusting Knob
Adjustment method: Pull out the
adjusting knob and rotate it to
tighten or loosen tension string. The
direction to tighten/loosen the string
will depend on the direction of the
wrapping thread.
Attention: The string and screen
will lose all tension if the string is
loosened to its maximum. To reverse
this, simply turn the knob in the
opposite direction.

PRODUCT WHITE PAPER
http://www.elitescreens.com
14
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Model
Number
A A1 A2 A3 B B1 B2 B3 B4 B5 B6 B8 C C1 C2 G1 G2 G3 G4 G5 G6 G7 G8
TE103C
-E24
113.4 94.8 103.5 108.9 74.8 40.3 68.1 72.8 3.8 4.7 6.7 24 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE106XW2
-E24
107.2 89.9 97.4 102.7 90.7 56.2 84 88.7 3.8 4.7 6.7 24 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE116XW2 115.4 98.4 105.9 110.8 78 61.5 71.3 76 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE120VW2 113.4 96 104.6 108.9 86.5 72 79.8 84.5 3.8 4.7 6.7 4 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE125C-E20 132.3 115 123.7 127.8 79.4 48.9 72.7 77.4 3.8 4.7 6.7 20 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE128XW2
-E12
125.4 108.5 116 120.9 90.3 67.8 83.6 88.3 3.8 4.7 6.7 12 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE135VW2 125.4 108 116.7 120.9 95.5 81 88.8 93.5 3.8 4.7 6.7 4 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE138C-E16 144.3 127 135.6 139.8 80.5 54 73.8 78.5 3.8 4.7 6.7 16 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE139XW2 135.4 117.9 126.5 130.9 88.1 73.7 81.5 86.2 3.8 4.7 6.7 4 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE150VW2 138.2 120 128.7 133.7 104.5 90 97.8 102.5 3.8 4.7 6.7 4 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE153C-E12 158.1 140.8 149.4 153.5 82.4 59.9 75.7 80.4 3.8 4.7 6.7 12 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE84HW2 89.8 73.2 80.7 84.6 57.6 41.2 50.9 55.7 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE84HW2
-E30
89.8 73.2 80.7 84.6 81.7 41.2 75 79.7 3.8 4.7 6.7 30 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE92VW2 89.8 73.6 81.1 84.6 71.7 55.2 65 69.7 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE94XW2 96 79.7 87.2 91.5 66.3 49.8 59.6 64.3 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE96C-E24 105.6 88.3 95.8 101.1 72.1 37.6 65.4 70.1 3.8 4.7 6.7 24 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE84VW2 83.1 67.2 74.7 78 66.9 50.4 60.2 64.9 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE100VG2 96 80 87.5 91.5 76.5 60 69.8 74.5 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE84HG2 89.8 73.2 80.7 84.6 57.6 41.2 50.9 55.7 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE84VG2 83.1 67.2 74.7 78 66.9 50.4 60.2 64.9 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE92HG2 96 80.2 87.7 91.5 61.5 45.1 54.8 59.6 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE92VG2 89.8 73.6 81.1 84.6 71.7 55.2 65 69.7 3.8 4.7 6.7 6 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
TE120HD2 122.3 104.6 113.3 117.8 73.3 58.8 66.6 71.3 3.8 4.7 6.7 4 4.8 0.9 5.2 3.4 1.9 1.4 0.7 4.1 2.2 0.8 0.4
Unit: mm
TE110HW2
-A1080P2
2880 2436 2654 2766 1788 1369 1618 1737 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE100HC2 2616 2215 2403 2499 1664 1245 1494 1613 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE135HC2 3439 2990 3208 3325 2050 1681 1880 1999 97 119 170 102 122 23 132 86 48 36 18 104 56 20 10
TE92HC2 2438 2037 2228 2324 1562 1146 1392 1514 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10

PRODUCT WHITE PAPER
http://www.elitescreens.com
15
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Model
Number
A A1 A2 A3 B B1 B2 B3 B4 B5 B6 B8 C C1 C2 G1 G2 G3 G4 G5 G6 G7 G8
TE100VW2 2438 2032 2223 2324 1943 1524 1773 1892 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE100VW2
-E12
2438 2032 2223 2324 2096 1524 1925 2045 97 119 170 305 122 23 132 86 48 36 18 104 56 20 10
TE103C
-E24
2880 2408 2629 2766 1900 1024 1730 1849 97 119 170 610 122 23 132 86 48 36 18 104 56 20 10
TE106XW2
-E24
2723 2283 2474 2609 2304 1427 2134 2253 97 119 170 610 122 23 132 86 48 36 18 104 56 20 10
TE116XW2 2931 2499 2690 2814 1981 1562 1811 1930 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE120VW2 2880 2438 2657 2766 2197 1829 2027 2146 97 119 170 102 122 23 132 86 48 36 18 104 56 20 10
TE125C-E20 3360 2921 3142 3246 2017 1242 1847 1966 97 119 170 508 122 23 132 86 48 36 18 104 56 20 10
TE128XW2
-E12
3185 2756 2946 3071 2294 1722 2123 2243 97 119 170 305 122 23 132 86 48 36 18 104 56 20 10
TE135VW2 3185 2743 2964 3071 2426 2057 2256 2375 97 119 170 102 122 23 132 86 48 36 18 104 56 20 10
TE138C-E16 3665 3226 3444 3551 2045 1372 1875 1994 97 119 170 406 122 23 132 86 48 36 18 104 56 20 10
TE139XW2 3439 2995 3213 3325 2238 1872 2070 2189 97 119 170 102 122 23 132 86 48 36 18 104 56 20 10
TE150VW2 3510 3048 3269 3396 2654 2286 2484 2604 97 119 170 102 122 23 132 86 48 36 18 104 56 20 10
TE153C-E12 4016 3576 3795 3899 2093 1521 1923 2042 97 119 170 305 122 23 132 86 48 36 18 104 56 20 10
TE84HW2 2281 1859 2050 2149 1463 1046 1293 1415 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE84HW2
-E30
2281 1859 2050 2149 2075 1046 1905 2024 97 119 170 762 122 23 132 86 48 36 18 104 56 20 10
TE92VW2 2281 1869 2060 2149 1821 1402 1651 1770 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE94XW2 2438 2024 2215 2324 1684 1265 1514 1633 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE96C-E24 2682 2243 2433 2568 1831 955 1661 1781 97 119 170 610 122 23 132 86 48 36 18 104 56 20 10
TE84VW2 2111 1707 1897 1981 1699 1280 1529 1648 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE100VG2 2438 2032 2223 2324 1943 1524 1773 1892 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE84HG2 2281 1859 2050 2149 1463 1046 1293 1415 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE84VG2 2111 1707 1897 1981 1699 1280 1529 1648 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE92HG2 2438 2037 2228 2324 1562 1146 1392 1514 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE92VG2 2281 1869 2060 2149 1821 1402 1651 1770 97 119 170 152 122 23 132 86 48 36 18 104 56 20 10
TE120HD2 3106 2657 2878 2992 1862 1494 1692 1811 97 119 170 102 122 23 132 86 48 36 18 104 56 20 10

PRODUCT WHITE PAPER
http://www.elitescreens.com
16
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
5.2 Drawing
5.3 Pictures
CineTension2 Front View

PRODUCT WHITE PAPER
http://www.elitescreens.com
17
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Closed Casing
Casing/End Cap Detail

PRODUCT WHITE PAPER
http://www.elitescreens.com
18
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Weight Bar Detail
Remote Kit
Bracket Detail

PRODUCT WHITE PAPER
http://www.elitescreens.com
19
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Life Style

PRODUCT WHITE PAPER
http://www.elitescreens.com
20
EliteScreensInc.|EliteScreensEuropeGmbH|EliteScreensIndia|EliteScreensChinaLtd.
EliteScreensTaiwanCorp|EliteScreensJapan|EliteScreensAustralia
Section 6: About Elite Screens
6.1 Company Description
Elite Screens Inc. is a California based company that specializes in making quality commercial
and home-theater projection screens for the retail and custom install sales channels. Our
company began as an innovative venture into the projection market by manufacturing veterans
from the AV/IT industry. Elite Screens quickly established itself as an entry level commercial
and home theater screen manufacturer. This was accomplished by making a quality product
cost effective with a focus on mass-producing screen material, sizes and aspect ratios that were
most commonly preferred by AV customers in general. We focused on uniformity with what
would match the mainstream demographic while including extra features that are not usually
included by other manufacturers. In time, we progressed from just retail sales into the realm of
custom installer/integrator manufacture as our numerous reviews and awards will attest. We
stand behind our product and are so certain of customer satisfaction with the quality of our
product that we offer a 2-year manufacturer's warranty which is twice the industry standard. In
our continued devotion to excellence in products and service, we are committed to
implementing green practices with our production. We have adopted manufacturing methods
that promote conservative regulation of our energy needs. Our simple product designs
combined with the expertise of our permanent staff ensures that our entire line of products are
made by experienced hands devoted to the high standards of today’s audio-video consumer.
###
