Aeon CineWhite®A8K Series
EDGE FREE®Acoustically Transparent Fixed Frame Screen
USER’S GUIDE
M Type
Product Description:
The Aeon Series is a fixed frame projection screen that uses Elite’s EDGE FREE® technology. The EDGE FREE®
design resembles a giant size flat panel TV display. The Aeon includes a bezel trim to further enhance the frame
appearance and absorb projector overshoot. An optional LED kit is available for backlighting.
The screen material included is our ISF Certified CineWhite®A8K.which has an ultra-fine projection surface that
is acoustically transparent for front projection. It is precisely formulated for high-resolution projectors to offer
accurate color fidelity but also designed to allow speaker placement behind the screen while its bonded black backing
reduces light loss to enhance contrast.
In order for the CineWhite® A8K to maintain its projection qualities and optimum performance please refer to the list
below for proper maintenance and cleaning.
•Use a soft bristle brush to spot clean for dust.
•Dip a soft bristle toothbrush in mild soap and water to clean light stains.
•Never rub or apply pressure when cleaning the surface.
•Never attempt to use any solutions, chemicals or abrasive cleaners on the screen surface.
•To avoid damaging the screen, avoid touching it directly with your fingers, pens/pencils or any other sharp or
abrasive objects.

Rev.08232021JA www.elitescreens.com U-00235 2
1. Frame and Edge Trim Parts List
Qty
item
2 pcs
Main Frame Parts
Qty
item
2 pcs
Edge Trim Parts
Part A.
vertical frame
Part D.
Part B.
½ horizontal frame
Part E.
Part C.
½ horizontal frame
Part F.
2. Hardware Parts List
a. M4*4
b. D5*4
c. M4*4
d. D5*4
e. M4*4
f. M4*4
g.
h.
i.
j.
k.
l.
m.
n.
o.
p.
q.
r.
Red
Black

Rev.08232021JA www.elitescreens.com U-00235 3
Frame Assembly
Step 1: Place the included soft padded sponge sheet on a clean area where the screen will be assembled.
Step 2: Position the pieces of the frame on the sponge sheet in the arrangement shown below
Step 3: Insert center joint (a/b) connectors into one-half of the horizontal frame (B/C) and secure with the M4x7
screws (M) as shown in the illustration below.
Tip: The center joint (b) with the larger diameter holes should be on top.
Step 4: Connect the elbow joints (c/d) to the top and bottom sections of the vertical frame. Once inserted, connect
the vertical sections to the horizontal frame sections. Make sure all holes are in alignment and the frame pieces are
flush (no gaps). They should form perfect right angles.
Tip: The elbow joint (d) with the larger diameter holes should be on top.
Item
Parts List
103”
123”
135”
150”
a.
Center Joints- M4 (bottom position)
2
2
2
2
b.
Center Joints-D5 (top position)
2
2
2
2
c.
Elbow Joints M4 (bottom position)
4
4
4
4
d.
Elbow Joints D5 (top position)
4
4
4
4
e.
Side cover Center Joints- M4
2
2
2
2
f.
Side cover Elbow Joints M4
4
4
4
4
g.
M4x7 Screws
24
24
24
24
h.
Spring
52
60
68
72
i.
Spring Hook
2
2
2
2
j.
wall brackets
4
4
4
4
k.
Φ5x50 Wall Screws
8
8
8
8
l.
Hollow Wall anchors
8
8
8
8
m.
M4x4 Screws
24
24
24
24
n.
Angle cover
4
4
4
4
o.
Center Support Bar
1
1
1
1
p.
White gloves
2
2
2
2
q.
Spring
4
4
4
4
r.
Φ3 mm Long Iron (sides) rod/ Short rod (top/bottom)
2/4
2/4
2/4
2/4
c.
d.
b.
a.
a.
b.
g.
…
Sponge Sheet
Sponge Sheet

Rev.08232021JA www.elitescreens.com U-00235 4
c
c
c
c
c
c
c
c
c
c
Step 5: Secure the elbow joints by fastening them with M4x7 screws ( g) , 4 at each corner.
Screen Material
Step 6: Put on the white gloves (p) and carefully unroll the screen material on a clean surface from the roller to the
other side as shown below. The back side of the screen material should be placed upwards.
Step 7: Insert the rods (r) through the sleeves according to their corresponding lengths on each edge of the screen
as shown below. The short rods (top/bottom) will overlap to secure a firm grasp in the middle areas.
Step 8: Carefully and gently place the assembled frame on top of the screen material in the marked areas as shown
below. Make sure to not allow the angle edge of the frame to come in direct contact with the screen material to
avoid puncturing it.
2. Hardware Parts List
a.
b.
c.
d.
e.
f.
g.
h.
i
j.
k.
l.
m.
Back side
*Make sure the frame corners are positioned
in the marked areas of the material.
Front
Back Side
g.
Back Side
c
r. (Red tips)
c
Back Side
r. (Black tips)
Back
Side
Back
Side
c
c
c
c
c
c
c
c
c
c

Rev.08232021JA www.elitescreens.com U-00235 5
Center Support Bar
Step 9: Insert the Center Support Bar (o)into the upper top groove on the back of the frame with the bottom end
near the approximate center point of the frame and rotate it in at an angle so that both ends of the bar are in alignment
with the groove.
Diagonal Sizes of 150” and below use 1 x Center Support Bar
Step 10: Hook one end of the spring and secure inside the groove of the frame, use the spring hook (h) to attach
the spring to the hole located on the screen material’s outer edge in the following order.
Begin by first attaching the center points on both vertical (left/right) sides, steps 1-2. Then the center points on both
horizontal (top/bottom) sides, steps 3-4. Once all center points have been secured, make sure the screen material is
still within the marked areas before proceeding to attach the next springs.
Continue attaching the rest of the springs to the material in the following order in steps 5-12.
h.
i.
5
6
7
8
9
11
10
12
Spring must hook
both overlapping
short rods
3
4
1
2
p.

Rev.08232021JA www.elitescreens.com U-00235 6
Note (after all springs have been attached):
Correct material installation –Corners of the screen material are properly wrapped around the corner edges of the
frame and material is evenly tensioned and flat, creating a nicely taut surface.
Incorrect material installation –The corners of the screen material are not properly wrapped along the edge of the
frame leaving the material with unbalanced tension and an uneven finish. To correct, detach springs from material at
the corner(s) where material does not lie flat along the edge of the frame, reposition the material so that it lies flat
and wraps along the edge of the frame, and reattach springs to the material.
Note: Please make note of the yellow label and spring in the center of the frame. This is an indicator to start the
screen material installation process from the middle area of the frame.
How to avoid getting ripples on the screen’s material surface
Solution: Pull and smooth out the material using your hand from the center to the corners, creating a nicely taut
surface as shown below.
Edge Trim Installation
ATTENTION: THE TOP EDGE TRIM PIECE WITH THE LOGO SHOULD BE INSTALLED ON THE TOP.
Step 11: Place the edge trim frame pieces over each end of the frame.
To avoid ripples forming in the material it is imperative that all of the corners are properly wrapped around the
edges as illustrated in the check mark diagrams.

Rev.08232021JA www.elitescreens.com U-00235 7
Connect edge trim frames (e/f) together using the M4 center joint (e) and secure with four of the M4x4 screws (m)
as show in Step 1. Repeat for other side.
Once both top and bottom edge trim frames have been connected, attach the vertical (left/right) sides edge trim
frames (d) using the elbow joints (f) and secure with four M4x4 screws (m) on all corners, Step 2.
Step 12: Install the angle cover (n) on each corner of the frame using the M4x4 screws (m).
Note: The angle cover screws holes align with the screw holes on the elbow joint.
Step 13: Install the springs (q) in each middle area to further support the bezel trim edge frame.
1
1
2
2
2
2
f.
m
e.
m
.
q.
o.
Tear off the double-sided tape.

Rev.08232021JA www.elitescreens.com U-00235 8
Wall Installation
Step 14: Measure the overall length and height of the frame and drill holes for the top brackets. Line up the wall
brackets with the drilled holes on the installation location and screw them in using a Phillips screwdriver. If not
installing into a structural wood stud, use a hollow wall anchor then screw in the M5x50 wood screws with a
screwdriver. Make sure the brackets are leveled.
Step 15: Position the fixed frame screen onto the top wall brackets as shown below and push down at the center of
the top of the frame to secure.
For Technical Support or an Elite Screens contact in your area, visit
www.elitescreens.com
Model/Size
X = Wall bracket
distance
X1 = Bracket hole
distance
Y = Top/Bottom Wall
Bracket Height
AR103H
1200mm (47.24”)
30mm (1.18”)
1110mm (43.7”)
AR123H
1400mm (55.12”)
30mm (1.18”)
1360mm (53.54”)
AR135H
1500mm (59.06”)
30mm (1.18”)
1520mm (59.84”)
AR150H
1600mm (62.99”)
30mm (1.18”)
1710mm (67.32”)
Don’t lock the screw to the bottom.
k.
j.
