Elite Screens Ceiling Trim Kit User manual

www.elitescreens.com / [e-mail] / 877-511-1211
Ceiling Trim Kit

www.elitescreens.com / [e-mail] / 877-511-1211
Nomenclature for the Elite Screens Ceiling Trim Kit
*For your convenience, the components have been numbered in
correspondence with a brief description and detail picture.
④
⑥
⑧
⑦
②
③
①
⑤

www.elitescreens.com / [e-mail] / 877-511-1211 ③
③ left installation
plank
① Suspension Bar- 4PCS
(39” /1000±80mm each)
⑧ assembly bolt/nut
-10PCS
⑦mounting screw
- 8PCS
⑥right installation
plank -1PC
⑤ right bracket -1PC
② left bracket - 1PC
④ceiling panel - 2PCS

Step 1:
Set left and right brackets on the end caps of the screen
casing. The mounting (#8) screws assembly bolt/nut set
will pass through the assembly bar and attach to the
brackets.
Step 2:
Install the ceiling panel. Use (# 7) mounting screws to
attach the left and right installation planks. (*Note:
Left/Right is designated from the perspective of the viewer
looking at the projection surface)
www.elitescreens.com / [e-mail] / 877-511-1211

www.elitescreens.com / [e-mail] / 877-511-1211
Step 3:
Attach the (#4) suspension bar using (#8) Screws type. Overlap
hanging bar to determine various length you need in the ceiling.
⑤

www.elitescreens.com / [e-mail] / 877-511-1211
Assembling dimension instruction:
Unit： INCH/ CM

www.elitescreens.com / [e-mail] / 877-511-1211
Warranty Policy
*Valid in the US and Canada only
•Two (2) year warranty parts and labor from purchase date as follows (except for
refurbished units as specified below):
•Each party will be responsible for one way shipping during the warranty
return/exchange.
•DOA (Defective On Arrival): Must be reported within 7 business days of receipt.
An RMA (Return Merchandise Authorization) number must be issued in order to
process a replacement. Elite Screens will replace the DOA (Defective on Arrival)
unit with a brand new replacement *(see exceptions below) after the DOA unit is
received and/or confirmed defective. Once the product is received, Elite
Screens will send out a new *unit to the customer by ground service (subject to
inventory availability). Should a problem be reported after the 7-day grace
period, the item must be shipped to us for warranty repair.
•Missing Parts must be reported within the 7-day (DOA) grace period. If reported
after 7 days, customer will be only be responsible for shipping and handling
fees up to 30 days. If reported after 30 days of receipt, customer is responsible
for cost of the parts and shipping & handling fees.
zFor Sales Questions, please contact [e-mail]
zFor any technical inquiries, Please contact [e-mail]
zFor warranty Claim, Please contact [email protected]
REGISTER YOUR WARRANTY WITH ELITE SCREENS INC.
www.elitescreens.com/register.html
If you have any installation pictures of Elite Screens, you’d like to share with us, please
email your pictures to [email protected]
