Elk Products ELK-P624 User manual

828-397-4200 www.elkproducts.com
Email: [email protected]
PO Box 100 • Hildebran, NC 28637 • USA
WARNING: Cancer and Reproductive Harm
www.P65Warnings.ca.gov
!
Power Supply and
Battery Charger
ELK-P624
APPLICATION:
The ELK-P624 is engineered to be a trouble-free
general-purpose power supply/charger. It features
automatic reset "fuseless" overload protection
which eliminates service calls to replace blown
fuses. The output voltage is easily selected with
easy to change mini-jumpers.
Features or Specications subject to change without notice.
Power Supply and
Battery Charger
ELK-P624
762158 00624 1
FEATURES & SPECIFICATIONS:
• Selectable 6, 12, or 24 VDC Regulated Output
• Visual AC and DC Power Indicator LEDs
• AC and DC Surge Suppression
• Built-In Battery Charging Circuit
• Standby Battery Capacity: 1.2 to 10Ah
• Size: 3" X 3" (76.2mm X 76.2mm )
• Auto-Reset Overload Protection: 2.5 Amps
• Lifetime Limited Warranty
6, 12, or 24 Volt DC
Selectable 6, 12, or 24 Volt DC
Instructions Printed On Inside
* Try these other ne ELK products *
M1 Cross Platform Control
M1G Full Featured Security & Automation Control
M1KP LCD Keypad, 2 x 16 Character, backlighted
M1XIN 16 Zone (input) expander. Up to 12 per sys.
M1XOVR 16 Output expander. 8 voltage/8 Relays
M1RB 8 relay board for use w/Ctrl, XOVR, or XOV
M1DBH Data Bus wiring hub for multiple homeruns
M1XEP Ethernet port expander/interface
M1XSP Serial port expander for additional serial ports.
Rust Free Sirens / Speakers
1RT Speaker & Stainless Steel Enclosure
150RT Siren & Stainless Steel Enclosure
Speakers & Sirens
44 Speaker, 30 W,8 Ohm Compact Horn
45 Siren, Compact Horn, 118db
M120 Siren, 107db, Mini Horn
SP15 Speaker, 15 watt, Small Horn
SP30 Speaker, 30 watt, Horn
SP35 Speaker, 20 watt, Interior
SP40 Speaker, 40 watt, Horn
SS15 Siren, Dual Tone, 110db, Horn
SS30 Siren, Dual Tone, 120db, Horn
SS36 Siren, Dual Tone, 105db, Interior
ECHO™ Sirens & Speakers
73 ECHO Speaker, 20 Watt, Interior
74 ECHO Dual Tone Siren, Interior
Siren & Voice Drivers
100 High Performance Siren Driver
110 Voice Siren Driver, English & Spanish
120 Recordable Voice Module and Siren
124 Recordable Voice Module, 4 Channels
Surge Suppressors
950 Surge Suppressor, Phone & Power Line
951 Surge Suppressor, Phone - Single Line
952 Surge Suppressor, Phone - Inline Modular
955 Surge Suppressor, Phone - Dual Line
Relay Modules
912 Compact Relay,12 Vdc, SPDT
912B Heavy Duty Compact Relay,12/24 Vdc, SPDT
924 Sensitive Relay, 12/24 Vdc, DPDT
941 Alarm Output Director
960 Delay Timer Relay, 1 sec. to 60 min.
Power Products
1250 Battery, Lead Acid, 12v, 5Ah
1280 Battery, Lead Acid, 12v, 8Ah
P112 12 Volts DC, 1 Amp Power Supply w/Enclosure
P124 24 Volts DC, 800mA Power Supply w/Enclosure
P1216 12 Volts DC, 1.5 Amp Power Supply
P412 12 Volts DC, 4 Amp Power Supply
P624 Power Supply & Battery Charger
965 Low Battery Cutoff and Power Switch
TRG1640 Transformer, 16.5VAC @ 45 VA
TRG2440 Transformer, 24VAC @ 40 VA
Accessories
129 Computer Sound Card Interface
800 Audio Amplier, 10 Watts
900-2 “B” Connectors,Unlled,500 pcs
902-2 “B” Connectors,Gel lled,500 pcs
999 Double Sided Tape
SL1 Strobe Light, 4 colors available
WK1 Wall Mount Kit for SL1 Strobes
For more information contact your local Distributor or:
ELK PRODUCTS,INC 828-397-4200 FAX [phone]
http://www.elkproducts.com Email: [email protected]
01/19
** Higher output current (up to 2.5 Amps) may be drawn for a short time
provided a fully charged battery is connected.
Transformer Input Continuous
Output Current**
6V Setting: 12VAC, 40VA 1.2A
12V Setting: 16.5VAC, 40VA 1.0A
24V Setting: 24VAC, 40VA 800mA

APPLICATIONS AND WIRING DIAGRAMS
AC Transformer Input Terminals
IMPORTANT! Connect proper Transformer
according to desired output voltage!
For 6V DC Output, connect a 12V, 40VA
For 12V DC Output, connect a 16.5, 40VA
For 24V DC Output, connect a 24V, 40VA
LED Status Indicators
(Green) (Red)
AC DC Indication
ON / ON AC input is on / DC output is on. Normal.
OFF / ON AC input is off / DC output is from Battery only. Step
down Transformer is defective or unplugged, or the
AC outlet is off. Battery will eventually discharge.
ON / OFF AC input is on / DC output is off. The auto-reset
overload protector is likely open due to an overload
short circuit. Try reducing some of the device load.
OFF / OFF AC input is off / DC output is off.
Battery Wires
Connect to rechargable
Lead-acid battery
1.2 Ah up to 10 Ah
(Red = "+", Black = "-")
AC
TRANSFORMER
- +
DC OUTPUT AC DC BATTERY
+‐
F12.5AMP
JP1 JP2
ONFOR12V ONFOR24V
BOTHOFF=6V
.
..
.
BLKRED
ELK‐6246,12,OR24VPOWERSUPPLY
Auto-Reset (Fuseless) Overload
Protector - 2.5 Amp
Automatically resets when short or
overload is removed.
JP1 JP2
6V
.
..
.
JP1 JP2
12V
.
..
..
.
.
.
JP1 JP2
24V
DC Output Terminals
Connect device(s) to be powered.
Observe + / - polarity!
Caution!
Heatsink
maybeHot
6VPoweredDevice
1.2AMaximum
ContinuousCurrent
‐
+
12V
40VA
Transformer
+-
6V Battery
AC
TRANSFORMER
- +
DC OUTPUT AC DC BATTERY
+‐
F12.5AMP
JP1 JP2
ONFOR12V
ONFOR24V
BOTHOFF=6V
.
..
.
BLKRED
ELK‐6246,12,OR24VPOWERSUPPLY
12VPoweredDevice
1.0AMaximum
ContinuousCurrent
‐
+
16.5V
40VA
Transformer
+ -
12V Battery
AC
TRANSFORMER
- +
DC OUTPUT AC DC BATTERY
+‐
F12.5AMP
JP1 JP2
ONFOR12V
ONFOR24V
BOTHOFF=6V
.
..
.
BLKRED
ELK‐6246,12,OR24VPOWERSUPPLY
6 VOLT MODE
For 6 volt output, remove the small black mini-jumper
from the header pins marked JP1 and JP2. (See Figure
1 above) Then connect a 12VAC, 40VA transformer to
the AC TRANSFORMER terminals and connect a 6V
battery to the red (+) and black (-) battery wires. The
mini-jumper may be discarded or stored for later use
by placing one side onto a single header pin.
12 VOLT MODE
For 12 volt output, place the small black mini-jumper
on the header pins marked JP1. (See Figure 1 above)
Make certain that header pin JP2 is vacant. Connect a
16.5 VAC, 40VA transformer to the AC TRANSFORMER
terminals and connect a 12V battery to the red (+)
and black (-) battery wires.
24 VOLT MODE
For 24 volt output, place the small black mini-jumper
on the header pins marked JP2. (See Figure 1 above)
Connect a 24 VAC, 40VA transformer to the AC
TRANSFORMER terminals and connect a 24V battery
to the red (+) and black (-) battery wires.
24VPoweredDevice
800mAMaximum
ContinuousCurrent
‐
+
24V
40VA
Transformer
+-
24V Battery
AC
TRANSFORMER
- +
DC OUTPUT AC DC BATTERY
+‐
F12.5AMP
JP1 JP2
ONFOR12V
ONFOR24V
BOTHOFF=6V
.
..
.
BLKRED
ELK‐6246,12,OR24VPOWERSUPPLY
