Elkay Soft Sides ECDFPW314FPC Installation manual

Page1 98011C (Rev. J - 1/08)
ECDFPW314FP
Installation/Care/UseManual
Soft Sides™Freeze Resistant Fountain
IMPORTANT! INSTALLER PLEASE NOTE.
THEGROUNDINGOFELECTRICALEQUIPMENTSUCHASTELEPHONE,COMPUTERS,ETC.TO
WATER LINESISACOMMON PROCEDURE.THIS GROUNDING MAYBEINTHEBUILDINGORMAY
OCCURAWAYFROMTHE BUILDING.THISGROUNDINGCANCAUSEELECTRICALFEEDBACK
INTOAFOUNTAIN,CREATINGANELECTROLYSISWHICHCAUSESAMETALLICTASTE ORAN
INCREASEINTHEMETALCONTENTOFTHEWATER.THISCONDITIONISAVOIDABLEBYUSING
THEPROPERMATERIALSASINDICATED.ANYDRAINFITTINGSPROVIDEDBYTHE INSTALLER
SHOULDBEMADEOFPLASTICTO ELECTRICALLYISOLATETHEFOUNTAINFROMTHEBUILDING
PLUMBINGSYSTEM.
IMPORTANT
ALLSERVICETOBE PERFORMEDBYANAUTHORIZED SERVICEPERSON
Toassureyouinstallthismodeleasilyandcorrectly,PLEASEREADTHESESIMPLE
INSTRUCTIONSBEFORESTARTINGTHEINSTALLATION.CHECKYOUR
INSTALLATIONFORCOMPLIANCEWITHPLUMBING,ELECTRICALANDOTHER
APPLICABLECODES.Afterinstallation,leavetheseinstructionsinsidethefountainfor
futurereference.ThisFreezeResistantFountainisshippedintwoseparatecartons.
ThesecondcartoncontainstheFreezeResistantPackageLKFRB1thatisinstalledon
aninteriorheatedwall.Theinteriorspacemustmaintainaminimumtemperatureof50°
F(10°C).RefertotheFreezeResistantPackagefortherough-indimensionsforinstal-
lation.
Installer

Page2
98011C (Rev. J - 1/08)
ECDFPW314FP
LEGEND A= RECOMMENDED WATER SUPPLY LOCATION. 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUBBED 1-1/2" (38mm) FROM WALL. SHUT OFF BY OTHERS. B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4" O.D. DRAIN. NOTE:REINFORCE THE WALLIN THESHADEDAREAS
ECDFPW314FPC
MOUNTINGBOLTANDACCESS HOLE LAYOUT
FIG.1

Page3 98011C (Rev. J - 1/08)
ECDFPW314FP
ECDFPW314FPC
ROUGH-INDRAWING
1. Wall should already be framed for the fountains using dimensions shown in Fig. 1. Shown dimensions pertain to installation location. These dimensions are required for compliance with ANSI Standard A117.1. and ADA (Framing shown for reference only). 2. Remove bottom covers from fountains and save the screws. 3. Install the fountains using bolts and washers (provided). Tighten securely. 4. Attach drain tubes to fountains and cut to required length using the freeze resistant boxes as guides. 5. Install freeze-resistant boxes - see box instructions. 6. Replace bottom covers. FIG.2

Page4
98011C (Rev. J - 1/08)
ECDFPW314FP
FIG. 6 FIG. 7
FIG. 3 FIG. 4
See Fig. 7
See Fig. 3 FIG. 5
CABLESHEATHADJUSTMENT
To IncreaseFree Play
To ReduceFree Play
Note: Fountain Style May Vary

Page5 98011C (Rev. J - 1/08)
ECDFPW314FP
Thefreeze resistant package must bemounted on an interior wallin a heated area. The roomtemperature of the interior
heated area must be 50° F (10° C) or higher. The freeze resistant package may be surface or recessed mounted. If recess
mounted the surface of the cover must be flush with the interior wall surface. The package is furnished with screws for
mounting the cover to the box. If the box is recess mounted, do not fasten the top and bottom of the cover to the box. Use
the holes on the front only.
1. Assemble the operating cable to the fountain bracket. (Fountain should be mounted to exterior wall) Create a loop in
the cable and thread the free end of the cable through the wall into the freeze resistant box. The adjustment nuts should
be in the middle of threaded area on the operating cable. See Figure 7
2. Connectfree end of operating cableto the valve-operatingbracket. The end of the cablesmust be recessed into the
indents on the pivot brackets.
3. Remove cable free play by adjusting the jam nuts on the ends of the operating cable. See Figure 4
4. Connect water line from fountain bubbler into freeze resistant box. The connection to the box uses a quick connect
water fitting. Position the water line, in the fountain, to drain back into interior mounted box. Any water left standing, in
theexterior line, can freeze.
To insert tubing, push tube straight into fitting until it reaches a positive stop. To remove tubing from the fittings, relieve
water pressure, push in on dark gray collar while pulling out on the tubing. See Figure 9
5. Connect drain and water supply lines to the freeze resistant fountain. Refer to Figure 1 for component positions. Inline
strainer must be used on the inlet water line.
Start-up
1. Turn on building water supply and check all connections for leaks. Repair as required.
2. Stream height is factory set at 35 PSI. If stream height needs to be changed adjust the regulator in the freeze resistant
package. Clockwise adjustment raises stream height, counter clockwise adjustment will lower stream.
3. Adjustoperating cable asrequired. Cable system shouldhave a minimal amount offree play toallow for propervalve
operation. If the system is too tight the valve will stay in the on position creating constant water flow. Too much free
playwill result in non-operationof the valvewith the push-buttons.
4. Note: Water from the drain back tube in the freeze resistant package, will continue to run while the valve is actuated.
5. After cable system is adjusted properly stuff flexible insulation into any openings between the outside wall and the
interiorbox.
6. Recheck all connections. If all connections are leak free replace cover on the freeze resistant box and fountain.
FIG. 8
NOTE:WATERFLOWDIRECTION
BUILDINGWATER
INLET
SERVICESTOP
(NOT FURNISHED)
1/4"O.D. TUBE
WATER INLET
3/8"O.D. UNPLATED
COPPERTUBE CONNECT
COLDWATERSUPPLY
TUBE IS
SECURED
IN POSITION
SIMPLY PUSH IN
TUBE TO ATTACH PUSH IN COLLET TO RELEASE TUBE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
RELEASE TUBE
FIG. 9
OPERATIONOF QUICK CONNECT FITTINGS

Page6
98011C (Rev. J - 1/08)
ECDFPW314FP
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL1.800.323.0620
ELKAYMANUFACTURING COMPANY• 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
PARTNO.ITEMNO. PARTSLIST
Drain - Strainer
Bracket-RegulatorMounting
Push Button
Push Button Sleeve
Bracket-Basin
Bracket-Basin Pivot
Retainer
SnapBushing
Bumper-Reg. Valve Assy
Cap Screw
Screw #10 X .50 Pinned Torx
Fountain Arm - Long
Bottom Cover Plate - Long
Back Panel
Hex Nut
Push Button (Extension)
Gasket
Bubbler - Nipple
Bubbler Assembly
Poly Tubing (Cut To Length)
Mounting Plate Assy
Drain - Tailpipe
DrainAdapter
Gasket - Tail Pipe
Pivot Rod
Washer - Flat .339/.359ID Steel
Screw - Mach. 5/16-18 x 3/4
Bit-PinnedTorx
40575C
28824C
45662C
45737C
27945C
27946C
40206000
50198C
51667C
75672C
75570C
28790C
55000665
28290C
40045C
55919C
100322740560
15009C
98118C
56092C
28286C
45679C
45805C
50074C
70379C
75541C
111577243890
75520C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
NS
DESCRIPTION
FIG. 13
FIG. 11
FIG. 12
FIG. 10
FIG. 10
19
20
11 13 22,23,24
18
17
14
21
26, 27
25
2
9
15
7
5
8
6
12
1
3
4
10
16
8
