1"
(25mm)
7/16" (11mm) x
3/4" (19mm)
SLOT
STAINLESS STEEL BRACKETS
6-3/8"
(162mm)
5-3/8"
(137mm)
1-1/2"
(38mm) O.D.
8-7/8"
(225mm)
3-1/2" (89mm) DIA.
FOR LK18B DRAIN
1/4" R
(6mm)
JJ
I
A
C
E
DB
E
1/4" R
(6mm)
9-1/8"
(232mm)
36" (914mm)
SUGGESTED
FLOOR TO
RIM HEIGHT
SIDE
TOP
13-3/4"
(349mm)
7-3/4"
(197mm)
J
4-1/4"
(108mm)
G
KI
I
14"
(356mm)
1-1/2"
(38mm) 2-3/4"
(70mm)
1"
(25mm)
F
G GGH H
8-11/16"
(221mm)
7-11/16"
(195mm)
1/2"
(13mm)
7/16" (11mm)
DIA. HOLE
WALL HANGER
1/4" (6mm) x 1" (25mm)
LONG SLOT (6 PLACES)
WALL HANGER
G
K
I
7-3/4"
(197mm)
SEE OTHER SIDE FOR FAUCET
HOLE DRILLING CONFIGURATIONS
FRONT
43"
(1092mm)
Two Station Wall Mounted
Wash Sink
Models EWMA4820C and EWMA4820
®
SPECIFICATIONS
GENERAL
#14 gauge, type 304 (18-8), stainless steel multiple station
wash sink with 1/4" (6mm) radius coved corners. 1-1/2"
(38mm) wide inward sloping top channel rims, with 2" (51mm)
flat apron. Full length 10" (254mm) high backsplash. Exposed
surfaces are hand blended to a uniform lustrous satin finish.
Furnished with wall hangers and stainless steel support
brackets.
(CHECK MODEL SPECIFIED)
EWMA4820C
FURNISHED COMPLETE WITH:
SUPPLY: LK393ABH6. (Two) chrome plated mixing faucet with
BH6A 6" (152mm) wrist blade handles, swing 10-1/4"
(260mm) high gooseneck spout, AE19A vandal-
resistant anti-hose aerator.
DRAIN: LK18B. Stainless steel perforated strainer grid.
1-1/2" (38mm) O.D. x 4" (102mm) stainless steel
tailpiece.
Elkay 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A.
©2002 Elkay
(Rev. 9/02) 3-14G
www.elkay.com
Model EWMA4820C (Two station)
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
DIMENSIONS
FOLLOWING MODEL DOES NOT INCLUDE
SUPPLY AND DRAIN:
EWMA4820
SPECIFY FAUCET DRILLINGS AND LOCATION.
(See other side for standard faucet hole drilling configurations.)
Model Number EWMA4820
DIMS. in. mm DIMS. in. mm
A48 1219 G10 254
B20 508 H4 102
C45 1143 I2 51
D161/2419 J11/238
E24 610 K8 203
F40 1016
SPECIFICATIONS
®
Elkay 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A.
©2002 Elkay
3-14G (Rev. 9/02)
Two Station Wall Mounted
Wash Sink
Models EWMA4820C and EWMA4820
1-1/2" (38mm)
DIA. 4 HOLES
16"
(406mm) 3-1/2"
(89mm)
10"
(254mm)
1-1/4" (32mm)
DIA. 2 HOLES
12"
(305mm) 24"
(610mm) 12"
(305mm) 3-1/2"
(89mm)
10"
(254mm)
EWMA48202
EWMA48204
HOLE DRILLING CONFIGURATIONS
8"
(203mm) 8"
(203mm)
