Lustertone®Undermount
Single Bowl Sink with Apron
Model ELUHF2520
®
SPECIFICATIONS
GENERAL
Highest quality sink, with integral apron, seamlessly drawn of
#18 gauge, type 304 (18-8) nickel bearing stainless steel.
Underside of sink is fully protected by heavy duty Sound
Guard™undercoating. Designed to accept waste disposer.
DESIGN FEATURES
Bowl Depth: 7-7/8".
Finish: Exposed surfaces are hand blended to a lustrous high-
lighted satin finish. ELUHF models have highlighted inside top
bowl radius.
Underside: Underside of sink is fully protected by heavy duty
Sound Guard™undercoating to prevent condensation and
deaden sound.
OTHER
Drain Opening: 3-1/2".
Note: For solid surface countertop installations only.
Installation: See illustrated profile below.
Countertop mounting clips are packed with every sink.
OPTIONAL ACCESSORIES
Rinsing Basket: LKRB1520 and LKERBSS.
Cutting Boards: CB1716 and CBC1714.
Elkay Manufacturing Company 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A.
©2002 Elkay Mfg. Co.
(Rev. 7/02) 1-143B
www.elkay.com
Model ELUHF2520
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice. This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
8"
APRON
3/8" R
1-5/8"
1-3/4" R
7-7/8"
BOWL
3/8" R 3-1/4"
15-3/4"
20-1/2"
1-1/2"
25"
21"2"
5"
Model ELUHF2520 Illustrated
TOP VIEW
SIDE VIEW
ALL DIMENSIONS IN INCHES. TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
COUNTERTOP CONTOUR EDGE
TO CUSTOMER DESIRE
MOUNTING
BRACKET
1/2"
SILICONE CAULK
(NOT FURNISHED)
SINK
1-1/8"
FASTENER
(NOT FURNISHED)
Installation Profile of
ELUHF Single Bowl Model
Elkay recommends ELUHF sinks are
installed with a 1/2" reveal as shown.
SINK DIMENSIONS (INCHES)*
*Length is left to right. Width is front to back.
Ship.
Model Overall Inside Bowl Wt.
Number L W L W D Lbs.
ELUHF2520 25 201/221 153/477/823
