ElmoTech TXL-700 User manual

Ankle Tag
TXL-700
USER MANUAL
10 December 2002

ElmoTech Ltd.TXL-700 - User Manual
1
Table of Contents
1. Foreword....................................................................................2
2. Installing the Ankle Tag. ...........................................................3
3. General Rules for the Client ......................................................6
4. Maintenance Instructions...........................................................7
4.1. Cleaning the Ankle Tag .............................................................7
4.2. Ankle Tag Straps Replacement..................................................8
5. FCC Notices.............................................................................10

ElmoTech Ltd.TXL-700 - User Manual
2
1. Foreword
The Ankle Tag (TXL-700) is a transmitter used in home arrest
systems.
The Ankle Tag (LSQ-TXL-700) is transmitting on an American
FCC tested and approved frequency; whereas the European
version (TXL-700-2) is transmitting on a European tested and
approved frequency. From a user interface and function point of
view the two models are identical; therefore this user manual
serves both versions.

ElmoTech Ltd.TXL-700 - User Manual
2. Installing the Ankle Tag.
Hold the transmitter in your hand with the 4 metal pins (2 pairs,
along the strap) pointing forward.
Hold the Electronic Key in your other hand, with the black
button pointing toward the open or free end of the strap.
Press the Electronic Key down over one pair of metal pins (it
does not matter which) with the two touch points on the
Electronic Key matching
the pair of metal pins on
the Transmitter strap.
Hold the Electronic key in
this position while you do
the next step.
Press the red button on the
Electronic Key down for
one second; the red light
turns steadily on for two
(2) seconds.
If the transmitter successfully receives the reset command, the
red light, on the Electronic Key, will flash for two (2) seconds.
Note that if the Tag has failed to receive the startup command the
red light will turn off after the initial two (2) seconds ON.
If the Electronic Key battery is low the red light will immediately
flash for two (2) seconds, once the red button is pressed. (No
command is sent to the transmitter).
3

ElmoTech Ltd.TXL-700 - User Manual
4
Place the Tag on its side, on a non-metal surface, for 30 seconds.
Attaching the Transmitter
Place a strap holder over the short strap
(strap with pin side) of the Transmitter.
Attach the female Clip to the underside
of the Transmitter’s short strap (to lie
against the Offenders skin). Check that
the closed end of the clip fits with the
edge of the strap and make sure the
silver line is visible.
Wrap the Transmitter around the offender’s ankle at its narrowest
point ensuring that the protruding side of the Transmitter is
directed upwards.
Cover the female clip with the long strap
ensuring that all pins on the short strap
are protruding.
Slide the strap holder over the end of the
long strap in order to hold it in place.
Cover the female clip with the male clip
ensuring that the four pins on the male
clip fit correctly into the female clip (the
grooves on the side of each clip must
match).

ElmoTech Ltd.TXL-700 - User Manual
5
Ask the Offender to stand up and move around to insure that the
Tag is comfortable.
Fasten the two Clips with the locking tool. Be sure to fasten all
the four pins well. An audible clicking sound should be heard,
indicating that the Clips are closed properly.
Don’t install the Tag over a thick sock, since the Tag will get
too loose once the sock is removed. If the Tag is installed
without a sock, instruct the offender that he should not put on a
very thick sock, and then try to pull it under the Tag. The
Offender may wear a thin sock underneath and a thick sock
over the Tag.

ElmoTech Ltd.TXL-700 - User Manual
6
•
•
3. General Rules for the Client
The Transmitter is a waterproof wristwatch and there is no need
to remove it when taking a bath or a shower. You can even wear
it when swimming and diving in a swimming pool or taking a
sauna bath.
Turn the Transmitter’s transmission off when admitting to a
hospital, either for a visit or for hospitalization, since the
transmitted signal may affect other medical instrumentation.
Turn the Transmitter’s transmission off when boarding a flight,
since the transmitted signal may affect the aircraft’s avionics thus
impairing flight safety.
Turning the Transmitter’s transmission off should be done by an
authorized personnel, as follows:
Press the electronic key’s BLACK button down for one
second, the red light turns steadily ON for two (2) seconds.
If the shut down command has been successfully received,
the red light on the Electronic Key will flash for two (2)
seconds.
Note that if the transmitter has failed to receive the shut down
command the red light will turn off after the initial two (2)
seconds ON.
If the Electronic Key battery is low the red light will
immediately flash for two (2) seconds, once the black button is
pressed. (No command is sent to the transmitter).

ElmoTech Ltd.TXL-700 - User Manual
7
4. Maintenance Instructions
4.1. Cleaning the Ankle Tag
A soft brush and any cleaning solution are all that is needed to
clean the Ankle Tag TXL-700.
Alcohol based solutions; Soapy water or Lysol can be used to
clean the Tag. For additional safety and user comfort it is
Recommended that after cleaning with any of the above the Tag
be washed with clear water before it is reused.
Holding it at the end of the long strap, spray the Tag with
cleaning solution of choice (see above). Alternatively you can
simply drop the Tag in the cleaning solution.
Using a piece of cloth or a paper towel, dry the outer side of the
Tag. Lay the Tag on the towel with its inner side facing up.
Using a soft brush or another piece of cloth/towel gently scrub
the inner side of the Tag.
Wash the Tag in clear water. Dry the Tag using a piece of
cloth/paper towel or simply let it dry.

ElmoTech Ltd.TXL-700 - User Manual
8
4.2. Ankle Tag Straps Replacement
Possible reasons for a replacing a strap could be:
• Visible damage to one or both straps.
• Reception of strap tamper alarms, with no visual reason
seen.
• Tag does not calibrate.
Turn the Tag off with the electronic key.
Using the supplied snake eye screwdriver, open the screw that
holds the strap clasp and remove the strap clasp.
Gently shake the strap loose from the Tag body. Be careful not to
damage the metal pins on the Tag body.
Position the new strap over the Tag body. Notice that the two
small holes on the strap have to lie exactly over the two metal
pins.
Gently place the strap down over the metal pins and press down
along the seam of the strap, snugly fitting the entire strap to the
Tag.
Put the strap clasp back in place (the wider side pointing in-
wards).
Close the screw with the screwdriver. It has to be closed firmly,
but not too tight since this can damage the strap.

ElmoTech Ltd.TXL-700 - User Manual
9
Activate the Tag with the electronic key, close the strap and test
for “strap closed” message reception.

ElmoTech Ltd.TXL-700 - User Manual
10
5. FCC Notices
Inside plastic body situated “Loaded” antenna, which connected
to PCB by 1cm wire.
This note is applicable to the American Ankle Tag (LSQ-TXL-700)
NOTE
The Ankle Tag TXL-700 complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
This device has been tested and found to comply with the limits
of the Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
device generates, uses and can radiate radio frequency energy
and, if installed and used in accordance with the instruction, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this device does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to correct the interference by one or more of the
following measures
• Reorient or relocate the receiving antenna

ElmoTech Ltd.TXL-700 - User Manual
11
• Increase the separation between the equipment and the
receiver.
• Consult the dealer or an experienced radio/TV technician for
help.
CAUTION
Any changes or modifications not expressly approved by the
grantee of this device could void the user’s authority to operate
the equipment.
For Customer Support contact:
ElmoTech Ltd.
Corporate Headquarters
P.O. Box 13236,
2 Ha-Barzel St.,
Ramat Ha-Chayal,
61132 Tel Aviv
Israel
Tel: [phone]
Fax: [phone]
Visit us at: www.elmotech.com
