Quick Installation Guide
I-Series 4 Android All-In-One
Power-over-Ethernet (POE) Module Kit
© 2021 Elo Touch Solutions, Inc. All rights reserved.
The information in this document is subject to change without notice. Elo Touch Solutions, Inc. and its Affiliates (collectively “Elo”) makes no
representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a
particular purpose. Elo reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation
of Elo to notify any person of such revisions or changes.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior
written permission of Elo Touch Solutions, Inc.
Elo and the Elo logo are either trademarks or registered trademarks of Elo Touch Solutions, Inc.
America
800-ELO-TOUCH
Tel [phone]
[email protected]
Europe (EMEA)
Tel [phone]
[email protected]
Asia Pacific
Tel [phone]
[email protected]
Elo Technical Support
Online self-help: www.elotouch.com/support
Contents
1x Power-over-Ethernet (POE) Module
1x VESA mount spacer
2x M3x8 at-head screws
VESA mounting screws
Power Limitation Note
The Power-over-Ethernet (POE) Module does not provide enough power to
support all I-Series system features. Some features are disabled when using the
POE Module. See the user guide for a detailed list of available features when
using this adaptor kit.

Remove left side cable security cover and unplug ethernet and
power cable from the device before installing the Power-over-
Ethernet (POE) Module. DO NOT install or remove the module
with either of these cables connected or the I-Series 4 will
be damaged. Damage caused by installation with the cable(s)
attached is not covered under Elo warranty.
Remove screw, then lift o󰀨 POE docking cover.
Plug Elo POE module into recess, ensuring connector on bottom of
adaptor lines up with connector on back of the I-Series 4.
Optional 100x100 VESA spacer mounting: Place the spacer over the Elo
POE module before adding VESA mounting bracket.
Attach wallmount or stand mounting brackets (not included) with screws long
enough to pass through the POE module and into the threaded holes of the
I-Series 4 VESA mount. Maximum screw depth is 5mm.
Elo includes two types of M4x12mm screws that work with standard 2.6mm
thick VESA brackets. Other brackets may require di󰀨erent length screws.
1 3 5
6
24Secure Elo POE module to the I-Series 4 using the included M3x8
screws. The power and ethernet cables can now be reconnected to the
system.
5mm hole, x10
VESA spacer
Connector
