E-Series Touchcomputer User Guide
Elo TouchSystems E-Series LCD Multi-function Touchcomputer

TE Connectivity Touch Solutions
Elo TouchSystems
E-Series Touchcomputer User Guide
Multi-function Touchcomputer
Revision B
SW601671
TE Connectivity Touch Solutions
1-800-ELOTOUCH (1-800-356-8682)
www.elotouch.com

E-SERIES TOUCHCOMPUTER ERROR!UNKNOWN DOCUMENT PROPERTY NAME.
iii
Copyright © 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All
Rights Reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or by any means,
including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without
prior written permission of Tyco Electronics Corporation.
Disclaimer
The information in this document is subject to change without notice. Tyco Electronics
Corporation and its Affiliates in the TE Touch Solutions business unit in the TE Connectivity Ltd.
family of companies (collectively "TE") makes no representations or warranties with respect to
the contents hereof, and specifically disclaims any implied warranties of merchantability or
fitness for a particular purpose. TE reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of TE to notify any person of
such revisions or changes.
Trademark Acknowledgments
Elo (logo), Elo TouchSystems, iTouch, TE Connectivity, TE connectivity (logo) and TE
(logo) are trademarks of the TE Connectivity Ltd. family of companies. Other product
names mentioned herein may be trademarks or registered trademarks of their
respective owners.

E-SERIES TOUCHCOMPUTER ERROR!UNKNOWN DOCUMENT PROPERTY NAME.iv
Table of Contents
Chapter 1: Setup......................................................................................1
Unpacking Your Touchcomputer.....................................................................................1
Adjusting the Display.......................................................................................................2
Calibrating the Touchscreen in Microsoft Windows Operating Systems ......................... 3
Additional Mounting Option for Your System...................................................................4
Chapter 2: Operation...............................................................................5
Elo TouchSystems – E-Series Hardware Monitoring Utility.............................................5
LED Functionality............................................................................................................ 6
Accessing the Input/Output Panel................................................................................... 7
Chapter 3: Safety and Maintenance.......................................................8
Safety..............................................................................................................................8
Care and Handling ..........................................................................................................9
Chapter 4: Technical Support...............................................................11
Technical Assistance..................................................................................................... 11
Regulatory Information............................................................................12
Warranty ...................................................................................................15

E-Series Touchcomputer User Guide 1
C H A P T E R
1
SETUP
This chapter discusses how to set up and test your touchcomputer.
Unpacking Your Touchcomputer
Check that the following items are present and in good condition:
Touchcomputer Power cable US/Canada
Wall Mounting
Brackets and Screws
(8 x M4, 1 x M3)
Power cable Europe
Driver CD and
Quick Install Guide Power Adapter

E-Series Touchcomputer User Guide 2
Adjusting the Display
The display screen can be adjusted from -17 to +75 degrees, as shown below.
CAUTION: To prevent tipping or dropping, be sure to hold the base when
adjusting the display.
17°
75°
-17°+75°

E-Series Touchcomputer User Guide 3
Calibrating the Touchscreen in Microsoft Windows Operating
Systems
The touchscreen is pre-calibrated for accurate touch response.
If for any reason the touchscreen needs to be recalibrated, right-click the Elo icon
in the Taskbar and then click “Properties.” The following window opens.
Click the Align button. This launches the calibration program. The window shown
below opens. Follow the instructions to calibrate the touchscreen.

E-Series Touchcomputer User Guide 4
Additional Mounting Option for Your System
1) Mounting on the wall or pole
2) Second monitor mount onto your system (any monitor under 2.5 Kg with 75mm
VESA mount)

E-Series Touchcomputer User Guide 5
C H A P T E R
2
OPERATION
This chapter describes how to interact with the Elo TouchSystems diagnostic tool,
power LED, and input/output panel.
Elo TouchSystems – E-Series Hardware Monitoring Utility
How to Install
The utility is included in the driver CD. Please go to “E-Series Hardware Monitor”
folder located on the driver CD to install the utility.
E-Series Hardware Monitor Menu

E-Series Touchcomputer User Guide 6
The Hardware Monitor tool provides the following features.
Feature Description
System Display the BIOS version, operating system version, memory
information, and drive information.
Display Adjust brightness.
•Brightness: Adjust the backlight of the monitor.
Hardware
Monitor Monitor the CPU temperature, system temperature, and system output voltages.
Setting Set alarms when the CPU temperature, system temperature, and
output voltages that meet the setting criterion.
Alarm Display the record of all alarms.
About General information for the E-Series diagnostic tool.
LED Functionality
The E-Series base has a LED indicating the state of the touchcomputer. The
table below shows LED state and corresponding color.
LED Color to Observer State
Off No input power — Off mode
Red Input power present – Off or Hibernation mode
Orange Input power present — Standby mode S3
Blinking Green Input power present — Standby mode S1
Green Input power present — Power on

E-Series Touchcomputer User Guide 7
Accessing the Input/Output Panel
To access the input/output (I/O) ports, remove the I/O cover at the left of the unit.
A security screw is included and may be used to secure the front cover to the
touchcomputer. Below are the I/O descriptions:
Note: As a safety precaution, always leave the I/O cover attached when the system is
powered on.

E-Series Touchcomputer User Guide 8
C H A P T E R
3
SAFETY AND MAINTENANCE
Safety
Important information regarding the proper setup and maintenance of your touchcomputer:
•To reduce the risk of electric shock, follow all safety notices and never open the
touchcomputer case.
•Turn off the product before cleaning (refer to “Care and Handling” for proper cleaning
methods).
•Your touchcomputer is equipped with a 3-wire, grounding power cord. The power
cord plug only fits into a grounded outlet. Do not attempt to fit the plug into an outlet
that has not been configured for this purpose. Do not use a damaged power cord.
Only use the power cord that comes with your Elo TouchSystems touchcomputer.
Use of an unauthorized power cord might invalidate your warranty.
•The slots located on the sides and top of the touchcomputer case are for ventilation.
Do not block or insert anything inside the ventilation slots.
•It is important that your touchcomputer remains dry. Do not pour liquid into or onto
your touchcomputer. If your touchcomputer becomes wet, do not attempt to repair it
yourself. Contact Elo Customer Service for instructions.

E-Series Touchcomputer User Guide 9
Care and Handling
The following tips help keep your touchcomputer functioning at the optimal level.
To avoid risk of electric shock, do not disassemble the power adapter or display
unit cabinet. The unit is not user serviceable. Remember to unplug the display
unit from the power outlet before cleaning.
Do not use alcohol (methyl, ethyl, or isopropyl) or any strong solvent. Do not use
thinner or benzene, abrasive cleaners, or compressed air.
To clean the display unit cabinet, use a cloth lightly dampened with a mild
detergent.
Avoid getting liquids inside your touchcomputer. If liquid does get inside, have a
qualified service technician check it before you power it on again.
Do not wipe the screen with a cloth or sponge that could scratch the surface.
To clean the touchscreen, use window or glass cleaner. Put the cleaner on the
rag and wipe the touchscreen. Never apply the cleaner directly on the
touchscreen.
WEEE Directive
In the European Union, the Waste Electrical and Electronic Equipment (WEEE)
directive label shown to the left indicates that this product should not be disposed
of with household waste. It should be deposited at an appropriate facility for
recovery and recycling.

E-Series Touchcomputer User Guide 10
UL Directive
E-Series touchcomputer has included a lithium battery on the motherboard.
There is a risk of explosion if battery is replaced by an incorrect type. Please dispose of used
batteries according the region instructions.
China RoHS

E-Series Touchcomputer User Guide 11
C H A P T E R
4
TECHNICAL SUPPORT
Technical Assistance
There are two methods to obtain contact information for technical assistance on
the touchcomputer:
•The web
•The phone
Using the Web
For technical support, go to www.elotouch.com/go/contactsupport.
For current Elo news, product updates, and announcements, or to register to
receive our Touchcomputer newsletter, go to www.elotouch.com/go/news.
Using the Phone
For technical support, see the table at the end of the user guide for contact
information.

E-Series Touchcomputer User Guide 12
REGULATORY INFORMATION
I. Electrical Safety Information
A) Compliance is required with respect to the voltage, frequency, and current
requirements indicated on the manufacturer’s label. Connection to a different
power source than those specified herein may result in improper operation,
damage to the equipment, invalidation of warranty, or a fire hazard if the
requirements are not followed.
B) There are no operator-serviceable parts inside this equipment. There are
hazardous voltages generated by this equipment which constitute a safety
hazard. Service should be provided only by a qualified service technician.
C) This equipment is provided with a detachable power cord which has an
integral safety ground wire intended for connection to a grounded safety outlet.
1) Do not substitute the cord with other than the provided approved type.
Under no circumstances use an adapter plug to connect to a 2-wire outlet as
this defeats the continuity of the grounding wire.
2) The equipment requires the use of the ground wire as a part of the safety
certification. Modification or misuse can provide a shock hazard that can
result in serious injury or death.
3) Contact a qualified electrician or the manufacturer if there are questions
about the installation prior to connecting the equipment to main power.
II. Emissions and Immunity Information
A) Notice to Users in the United States: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of
FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential or commercial installation. This equipment
generates, uses, and can radiate radio frequency energy, and if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
B) Notice to Users in Canada: This equipment complies with the Class B limits
for radio noise emissions from digital apparatus as established by the Radio
Interference Regulations of Industry Canada.
C) Notice to Users in the European Union: Use only the provided power cords
and interconnecting cabling provided with the equipment. Substitution of provided
cords and cabling may compromise electrical safety or CE Mark Certification for
emissions or immunity as required by the following standards: This Information

E-Series Touchcomputer User Guide 13
Technology Equipment (ITE) is required to have a CE Mark on the
manufacturer’s label which means that the equipment has been tested to the
following Directives and Standards:
This equipment has been tested to the requirements for the CE Mark as required
by EMC Directive 2004/108/EC indicated in European Standard EN 55022 Class
B and the Low Voltage Directive 2006/95/EC as indicated in European Standard
EN 60950-1.
D) General Information to all Users: This equipment generates, uses, and can
radiate radio frequency energy. If not installed and used according to this manual,
the equipment may cause interference with radio and television communications.
There is, however, no guarantee that interference will not occur in any particular
installation due to site-specific factors.
1) In order to meet emission and immunity requirements, the user must
observe the following:
a) Use only the provided cables to connect the Elo touchcomputer.
b) To ensure compliance, use only the provided manufacturer’s approved
power cord.
c) The user is cautioned that changes or modifications to the equipment
not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
2) If this equipment appears to cause interference with radio or television
reception, or any other device:
a) Verify as an emission source by turning the equipment off and on.
b) If you determine that this equipment is causing the interference, try to
correct the interference by using one or more of the following measures:
i) Move the digital device away from the affected receiver.
ii) Reposition (turn) the digital device with respect to the affected
receiver.
iii) Reorient the affected receiver’s antenna.
iv) Plug the digital device into a different AC outlet so the digital
device and the receiver are on different branch circuits.
v) Disconnect and remove any I/O cables that the digital device does
not use. (Unterminated I/O cables are a potential source of high RF
emission levels.)
vi) Plug the digital device into only a grounded outlet receptacle. Do
not use AC adapter plugs. (Removing or cutting the line cord ground
may increase RF emission levels and may also present a lethal shock
hazard to the user.)

E-Series Touchcomputer User Guide 14
vii) If you need additional help, consult your dealer, manufacturer, or
an experienced radio or television technician.
III. Agency Certifications
The following certifications have been issued for the touchcomputer:
•CE •China (CCC) •Russia (GOST)
•Ukraine
(UKSERTCOMPUT
ER)
•Belarus (BelGiss) •Croatia (KONCAR)
•Serbia (KVALITET) •Bosnia (KVALITET) •Israel (SII)
•Mexico (NOM CoC) ••

E-Series Touchcomputer User Guide 15
WARRANTY
Except as otherwise stated herein or in an order acknowledgment delivered to
Buyer, Seller warrants to Buyer that the Product shall be free of defects in
materials and workmanship. With the exception of the negotiated warranty
periods; the warranty for the touchcomputer and components of the product is
one year.
Seller makes no warranty regarding the model life of components. Seller’s
suppliers may at any time and from time to time make changes in the
components delivered as Products or components. Buyer shall notify Seller in
writing promptly (and in no case later than thirty (30) days after discovery) of the
failure of any Product to conform to the warranty set forth above; shall describe in
commercially reasonable detail in such notice the symptoms associated with
such failure; and shall provide to Seller the opportunity to inspect such Products
as installed, if possible. The notice must be received by Seller during the
Warranty Period for such product, unless otherwise directed in writing by the
Seller. Within thirty (30) days after submitting such notice, Buyer shall package
the allegedly defective Product in its original shipping carton(s) or a functional
equivalent and shall ship to Seller at Buyer’s expense and risk.
Within a reasonable time after receipt of the allegedly defective Product and
verification by Seller that the Product fails to meet the warranty set forth above,
Seller shall correct such failure by, at Seller’s options, either (i) modifying or
repairing the Product or (ii) replacing the Product. Such modification, repair, or
replacement and the return shipment of the Product with minimum insurance to
Buyer shall be at Seller’s expense. Buyer shall bear the risk of loss or damage in
transit, and may insure the Product. Buyer shall reimburse Seller for
transportation cost incurred for Product returned but not found by Seller to be
defective. Modification or repair, of Products may, at Seller’s option, take place
either at Seller’s facilities or at Buyer’s premises. If Seller is unable to modify,
repair, or replace a Product to conform to the warranty set forth above, then
Seller shall, at Seller’s option, either refund to Buyer or credit to Buyer’s account
the purchase price of the Product less depreciation calculated on a straight-line
basis over Seller’s stated Warranty Period.

E-Series Touchcomputer User Guide 16
THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR
BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET
FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR
IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS,
THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR
MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE. NO
EMPLOYEE OF SELLER OR ANY OTHER PARTY IS AUTHORIZED TO MAKE
ANY WARRANTY FOR THE GOODS OTHER THAN THE WARRANTY SET
FORTH HEREIN. SELLER’S LIABILITY UNDER THE WARRANTY SHALL BE
LIMITED TO A REFUND OF THE PURCHASE PRICE OF THE PRODUCT. IN
NO EVENT SHALL SELLER BE LIABLE FOR THE COST OF PROCUREMENT
OR INSTALLATION OF SUBSTITUTE GOODS BY BUYER OR FOR ANY
SPECIAL, CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES.
Buyer assumes the risk and agrees to indemnify Seller against and hold Seller
harmless from all liability relating to (i) assessing the suitability for Buyer’s
intended use of the Products and of any system design or drawing and (ii)
determining the compliance of Buyer’s use of the Products with applicable laws,
regulations, codes, and standards. Buyer retains and accepts full responsibility
for all warranty and other claims relating to or arising from Buyer’s products,
which include or incorporate Products or components manufactured or supplied
by Seller. Buyer is solely responsible for any and all representations and
warranties regarding the Products made or authorized by Buyer. Buyer will
indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or
expenses (including reasonable attorney’s fees) attributable to Buyer’s products
or representations or warranties concerning same.
