Elonex eTouch User manual

Using Apps
Advanced Task Killer
Your eTouch‘multi-tasks’so programs are never shut down until you
turn the tablet o. With too many programs open you may notice a drop in
performance so its best to periodically close some down. To do this, swipe
the Advanced Task Killer icon downwards, tap“open Advanced Task Killer”,
then un-tick the apps you wish to keep open and tap“KILL selected apps” to
close the selected apps.
Security
You can increase the security
settings to protect your eTouch™ by
using a unique unlock pattern. Tap
to Settings > Location and Security
> Set Unlock Pattern and follow
the on-screen instructions.
Please note that
your unlock
pattern should
use at least 4
dots and the
eTouch™ will be
more secure with a greater number
of dots included in the pattern.
Program Menu
On the right hand side of your home screen is the Program menu icon. Tap
the square icon in the centre to open a menu of your installed apps. To open
an app just tap it once and it will launch.
Menu Icons
At the top of your screen are the Menu icons.These give you important
information about the status of the eTouch™ as well as options and shortcuts.
You can quickly see whether you are connected to Wi-Fi (the number of Wi-Fi
bars increase or decrease depending on the signal strength), the amount of
charge in your battery, or increase or decrease the volume. Tap the Back
button to go back to the previous screen.
Tap the Menu Icon at any time to bring up a menu of options relevant
to the screen you have open. For example on the home screen, tapping the
menu icon brings up ways to change your homescreen, and if you have the
eMail app open the menu icon brings up options to do with your eMail.
Android is a trademark of Google Inc. Use of this
trademark is subject to Google Permissions
QUICK
START
GUIDE
Wi-Fi Signal Strength
Battery Charge
Volume Down
Volume Up
Back
Menu
Return to Homescreen
Program Menu
Telephony / 3G
(included for future use)
Connecting to
Wi-Fi
Follow the instructions below to
connect to a Wi-Fi Connection:
:: From the home screen tap
Settings, then Wireless and
networks.
:: Then tap Wi-Fi to turn on the
eTouch™’s Wi-Fi module
(please note that this will use your
battery life faster).
:: Tap Wi-Fi Settings, then Add
Wi-Fi Network. The eTouch™ will
then automatically scan for
available Wi-Fi hotspots.
:: Select the desired Wi-Fi hotspot
from the list.
:: If the hotspot doesn't have a
password it will automatically
connect, however if it ‘secure’, a
password window will pop up
letting you enter the correct
password. For password details
refer to your ISP or the sta at the
internet cafe/coee shop etc.
:: You should now be connected and
can surf the Internet by tapping
the Browser icon. To view a web
page tap the white bar at the top
of the screen to enter a web
address, or tap the Google search
bar to enter a search term.
Files and Folders
To browse your les and folders tap the ES File Explorer. The rst time you use it
you need to agree to the EULA terms & conditions by pressing Accept.
To copy and paste les from one folder to another, tap and hold the original
le for about 1 second. A menu will pop up with options to Open As, Cut, Copy,
Delete, Select All, Compress, Send or view the Properties. Tap Copy (to create a
duplicate of the le) or Move (to move the existing le). You can then navigate
to the destination folder where you want to copy the le and press the
clipboard icon at the bottom of the screen. Then tap the le once more and tap
Paste.
Connecting to a PC
The easiest way of transferring les to and from your tablet is using a Micro SD
Card. However, you can connect the tablet to a PC or laptop using a mini USB
cable. With the eTouch turned ON, connect the cable between the Micro USB
port on the top of your eTouch to the USB port on your PC or laptop. Swipe the
notication bar at the top of the screen downwards to show a notication
“USB Connected, Select to copy les to/from your computer”. Tap this and
then “Turn on USB Storage” to enable data transfer.
On your PC or laptop the tablet will show up as
“Removable Device”(just like a normal USB stick)
and you can drag and drop, or copy and paste les
to and from the eTouch’s folder.
Wi-Fi Connection
Troubleshooting
If you have trouble connecting to
your Wi-Fi please check the
following:
:: Check you have included any
CaPiTaL letters as most passwords
are case sensitive
:: Check you haven’t got CAPS lock
toggled ON.
:: Check you have the correct
password for the hotspot and it
hasn’t been changed.
If you still can’t connect there may
be a temporary conict with your
router’s security authentication.
Please contact your Internet Service
Provider, requesting to temporarily
lower the router’s security
encryption to WEP which will allow
the Tablet to connect to the
internet.
Once connected, you should have
no further problems with getting
online you can request that the ISP
return the encryption to its former
status. This can all be done over the
phone in a couple of minutes.
Tech Support
If you have any diculties
connecting to the internet please
contact our support helpdesk on
0871 222 3456
(Mon- Fri, - 5p/min from a BT landline, other
networks and mobile will be considerably more
expensive).

0871 222 3456
(Mon- Fri national rate)
eMail Questions
[email protected]
Introduction
Please read this quick start guide
carefully to help you get the most
out of your eTouch™.
Package Contents
Before using your eTouch™, please
check your package contents to
ensure there aren’t any items
missing. If any of the listed items are
missing or damaged, please contact
your point of purchase for
assistance.
The package includes:
1. 7” eTouch™ Tablet
2. Mains USB Power Adaptor
3. Quick Start Guide
& Warranty Card
Setting up
Your tablet has a screen protector (a
thin lm to protect the screen
during transit). Please use the tab to
slowly and very carefully remove
this from the screen as it will reduce
the quality of the screen image.
Battery Charging
Your eTouch™ has a built in
3000mAh rechargeable lithium
battery which provides around 5
Hours battery life (depending on
usage).
The eTouch™ is supplied with no
charge in the battery and we
recommend that you charge the
battery for around 8 Hours for its
rst charge, to achieve the best
battery life.
Memory &
Expansion
Your eTouch™ comes with built in
storage but will also support up to
a huge 32GB Micro SD card to store
your favourite music, movies and
photos.
To insert a micro SD Card
Insert the card with the metallic
connectors facing downward until
you feel a click which will lock the
card into place.
To remove an SD Card
Go to Settings > SD Card and
device storage settings then tap
‘Unmount SD Card’to allow you to
safely disconnect the card from the
Tablet. Push the card gently
inwards until you hear a click and
then it will pop out.
Turning your eTouch™ on
Once you’ve charged the battery you can turn the eTouch™ ON by pressing
the power button and the Android™ OS will load. To unlock the screen
(its locked to avoid accidentally pressing buttons when not being used) slide
the padlock icon until it covers the green dot. The eTouch™
will then load you home screen for you to start navigating
to your chosen function. The screen will automatically
lock after a period of non-use (you can change the length of
this time period in the Settings menu)
To turn your Tablet OFF simply press and hold the Power
button for about 1 second and tap Power o then OK.
Program Menu
On the right hand side of your home screen is the Program menu icon. Tap
the square icon in the centre to open a menu of your installed apps. To open
an app just tap it once and it will launch.
About your Home Screen
Your Tablet’s home screens let you personalise your working environment to
suit your lifestyle. For example you can set up one screen with your favourite
apps on it, another screen with widgets to your favourite social networking
sites and another page with shortcuts to your work les.
To access your other home screens you can simply touch the screen and swipe
it left or right.
To add a widget or shortcut just ‘tap and hold’some blank space on your
home screen. A pop-up menu will appear so you can choose your widget
which will appear on the home screen. To move it around the home screen tap
and hold the icon until it becomes larger, then drag it to where you want it.
To delete a widget or shortcut, tap and hold the icon then drag it to the
recycle bin. The recycle bin icon appears in your program menu on the right
hand side of the screen.
Volume + / -
3.5mm
Audio Port
Back Button
micro SD Card slot
Speaker
DC Power Input
miniUSB (PC Link only)
7” LCD Touchscreen
LED Backlit, Capacitive Touch
Power Button
(Standby)
Microphone
Home Button (Click once)
Click to go to your homescreen
Recent Button (Click & Hold)
Click to view your recently used apps
About your
eTouch™
With its amazing LED backlit
touchscreen navigating around the
eTouch™ is as easy as a quick swipe
of your ngertips. The Android™ OS
is specically designed with large
buttons and icons which suit the
size of your ngers. You can touch,
tap and swipe the screen, just like
you’d use a mouse, but please don't
use sharp or pointed instruments as
you may damage the screen.
The eTouch™ has a built in
G-sensor which ips the screen
into any orientation, letting
you use it for games, in
landscape, portrait or even
ip it over to show a friend.
Help & Support
To help you get the best out of your
product we provide you with a
limited 1 year Return to Base
Warranty and Support Helpdesk
(see www.elonex.com for more
details).
For all technical support please
contact our helpdesk using the
details below:
FAQ’s and Updates
www.elonex.com/support
If you have any problems or
questions please
DO NOT take your eTouch™
back to the store.
Please contact us for some
helpful advice.
(this does not aect your Statutory Rights)
Setting the Time
& Date
Some of the eTouch™’s software
and widgets require the date and
time to be correct to function
correctly. To set the time and date
go to Settings > Date & time.
Uncheck the Automatic setting
then click Set Date, use the + and -
buttons to change the date and
then press Set. Click Set Time, use
the + and - buttons to change the
date and then press Set.
Please Note: If you run out of
battery life you will lose your time
and date settings.
