Brief Instruction
Mounting of WS1000 Color
Item numbers 60121-60128 (WS1000 Color)
Warning, mains voltage! National legal regulations are to be
observed. Installation, inspection, commissioning and
troubleshooting of the device must only be carried out by a
competent electrician.
Notes on wireless equipment
When planning facilities with devices that communicate via radio, adequate radio
reception must be guaranteed. The range will be limited by legal regulation and
structural circumstances. Avoid sources of interference and obstacles between re-
ceiver and transmitter, that could disturb the wireless communication. Those
would be for example:
• Walls and ceilings (especially concrete and solar protection glazing).
• Metal surfaces next to the wireless participants (e. g. aluminium
construction of a conservatory).
• Other wireless devices and powerful local transmitters (e.g. wireless
headphones), which transmit on the same frequency. Please maintain a
minimum distance of 30 cm between wireless transmitters for that reason.
Preparing the installation location
The device must only be installed and used in dry, interior
spaces. Avoid condensation.
Cut-out dimensions for concealed box (approx.): W=229 mm | H=163 mm | D=62
mm:
An external antenna can be connected in order to improve wireless communicati-
ons. During installation, a conduit 50 cm in length should be placed beneath the
recessed housing, in which the external antenna can be mounted (antenna dimen-
sions approx. 565 x 8 x 5, L × W × H in mm):
Preparing for installation
The lid cover is only attached by a hinge. Take care not to lose it.
Wall-fitting
Cavity wall fitting
Assembling the control unit with concealed box
During electrical installation, please introduce all connection cables into the con-
cealed box through the lower or upper side wall. In the process, keep the individual
connection wires short to prevent long reserve loops.
After connecting the cables screw the lower section of the housing (with the moun-
ting plate) onto the concealed box. Connect the flat ribbon cable to the display.
Put the lid cover on the upper section of the housing (frame with display). Put the
upper section of the housing onto the lower section of the housing from above and
move it downwards until the bottom edges are aligned. Screw on the upper secti-
on.
Structure of the connector board WS1000 Color
Connection diagram
Drive and MF outputs WS1000 Color:
per drive output max. 400 W,
total max. 1.5 kW
The manual with additional information about commissioning,
functions and use of the controls WS1000 Color can be down-
loaded from www.elsner-elektronik.de in the menu area "Ser-
vice/Downloads".
Conduit angled diagonally dow-
nwards (for cable access from
above or below)
Conduit angled vertically downwards (only
for cable access from above!)
concealed concealed
45°
cable
cable
box box
M16 conduit, 50 cm in length M16 conduit,
50 cm in length
To take off the front plate, remove the
screws beneath the lid.
Push the upper section of the housing
(frame with display) up a little and lift it
off.
Caution: The display is connected
with a flat-ribbon cable to the circuit
board in the concealed box. Loosen
the plug so that the upper section
can be removed.
The lower section of the housing together
with the wall-mounting plate is attached
to the concealed box with 3 screws: Loo-
sen the screws and take off the lower part.
Remove the circuit board from the con-
cealed box to be installed a keep it in a
place where it is protected from dirt. It
may never be exposed to dust or mo-
isture!
For fitting, screw the cover (board) on to
the concealed box with the enclosed
screws.
Clamp the concealed box to the wall with
the four enclosed screws.
Upon delivery, the pouch containing the
assembly screws can be found in the con-
trol unit’s flush-mounted casing.
or
1 Multifunctional output 1
(potential-free)
2 Multifunctional output 2 (pot.-free)
3 Multifunctional output 3 (pot.-free)
4 Multifunctional output 4 (pot.-free)
5 Outer conductor L1
6 Outer conductor L1
7 Drive group 1
8 Drive group 2
9 Drive group 3
10 Drive group 4
11 Drive group 5
12 Drive group 6
13 Drive group 7
14 Drive group 8
15 Drive group 9
16 Drive group 10
17 Mains connection L/N/PE 230 V/50
Hz
18 Wall button 1 (terminals 1-3)
Wall button 2 (terminals 4-6)
Wall button 3 (terminals 7-9)
Wall button 4 (terminals 10-12)
19 Wall button 5 (terminals 1-3)
Wall button 6 (terminals 4-6)
Wall button 7 (terminals 7-9)
Wall button 8 (terminals 10-12),
20 Wall button 9 (terminals 1-3)
Wall button 10 (terminals 4-6),
21*Multifunctional input 1
(terminals 1-3)
Multifunctional input 2
(terminals 4-6)
22 Weather station (terminals 1-2)
Wire assignment: red = 1, black = 2,
yellow and white = not connected
23*Multifunctional input 3
(terminals 3-5)
Multifunctional input 4
(terminals 6-8)
24 Connector for flat-ribbon cable to
front board
25 Microfuse T6.3 A (Drive 1-5)
26 Microfuse T6.3 A (Drive 6-10)
27 Microfuse T630 mA
28 Slot KNX interface
* Supply voltage indoor sensor possi-
ble via MF inputs
(No. 21, terminals 1(+), 2(-) | 4(+),
5(-) and No. 23, term. 3(+), 4(-) | 6(+),
7(-)), max. 400 mA altogether.
20
12
34
5
6
78910 11
12 13 14 15 16 17
18
19
21 22 23
24
25
26
27
28
EN

Mounting of WS1000 Color 2
Mounting of WS1000 Color • Version: 27.05.2021 • Technical changes and errors excepted. • Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany • www.elsner-elektronik.de • Technical Service: +49 (0) 7033 / 30945-250
Inputs WS1000 Color:
Connection examples for multifunctional outputs
Connecting 230 V consumers to MF outputs
Connecting low-voltage consumers and potential-free contacts to MF
outputs
Technical specifications Control Unit WS1000 Color
The product conforms with the provisions of EU directives.
multifunctional outputs 1-4 WS1000 Color/Style
multifunctional outputs 1-2 WS1 Color/Style
MF output 1 MF output 2 MF output 3
neutral conductor
heating valve 230 V
lamp 230 V
Contactor / Relay (on-site)
MF output 4
L1 / L1connector
ventilator 230 V
F1 6,3A slow-blow
radiant heater
Housing Plastic material (partially painted)
Colours • White glossy (similar to RAL 9003 Signal White)
/ light grey (similar to RAL 7035 Light Grey)
• Aluminium (similar to RAL 9006 White Aluminium)
/ graphite (similar to RAL 7024 Graphite grey)
Mounting Flush/cavity wall
Dimensions Central unit approx. 250 × 182 × 43 (W × H × D, mm),
concealed box approx. 235 × 169 × 62 (W × H × D, mm)
Ambient temperature Operation 0…+55°C, Storage -30…+70°C
Ambient humidity 5...95% RH, avoid bedewing
Operating voltage 230 V AC, 50 Hz
Power consumption Stand-by max. 16 W
Load capacity
drive outputs
per drive output max. 400 W,
total max. 1.5 kW
Frequency
wireless channels
868.2 MHz
Degree of protection IP 20
multifunctional outputs 1-4 WS1000 Color/Style
multifunctional outputs 1-2 WS1 Color/Style
MF output 1 MF output 2 MF output 3 MF output 4
e.g. 24 V (ext.power supply)
heating valve 24 V
other consumers 24 V
signal contact for e.g.
rain / wind / frost /
smoke detector / alarm
thermostat
(on-site)
replacement
