elsner elektronik KNX T6-UN-B4 Guide

EN
Installation and Adjustment
KNX T6-UN-B4
Temperature Evaluation Unit
Item number 70222

3 Contents
Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany
Temperature evaluation unit KNX T6-UN-B4
Status: 17.12.2019 • Errors excepted. Subject to technical changes.
1. Description ........................................................................................... 5
1.1. Deliverables .............................................................................................................. 5
1.2. Technical data ........................................................................................................... 5
2. Installation and start-up ....................................................................... 6
2.1. Installation notes ...................................................................................................... 6
2.2. Installation position .................................................................................................. 7
2.3. Connection ................................................................................................................ 7
2.4. Notes on mounting and commissioning ................................................................ 8
3. Addressing of the device at the bus .................................................... 8
4. Transfer protocol ................................................................................. 9
4.1. List of all communications objects ......................................................................... 9
5. Parameter setting .............................................................................. 24
5.1. Behaviour on power failure/ restoration of power .............................................. 24
5.2. General settings ..................................................................................................... 24
5.3. Temperature measured values ............................................................................. 24
5.3.1. Measured value 1...6 ................................................................................... 24
5.4. Threshold value ...................................................................................................... 25
5.4.1. Threshold values 1...6 ................................................................................. 25
5.5. Temperature control .............................................................................................. 27
5.5.1. Control 1...6 ................................................................................................. 27
5.5.2. General set point values ............................................................................. 29
5.5.3. Heating control level 1/2 ............................................................................. 32
5.5.4. Cooling control level 1/2 ............................................................................. 34
5.6. Interfaces ................................................................................................................. 36
5.6.1. Interface 1...4 ............................................................................................... 36
5.6.2. Control modes for drive control ................................................................ 39
5.7. Logic ........................................................................................................................ 41
5.7.1. AND and/or OR logic 1 / 2 / 3 / 4 ................................................................ 41
5.7.2. AND logic connection inputs ..................................................................... 43
5.7.3. Connection inputs of the OR logic ............................................................. 44

4 Clarification of signs
This manual is amended periodically and will be brought into line with new software
releases. The change status (software version and date) can be found in the contents footer.
If you have a device with a later software version, please check
www.elsner-elektronik.de in the menu area "Service" to find out whether a more up-to-
date version of the manual is available.
Clarification of signs used in this manual
Installation, inspection, commissioning and troubleshooting of the device
must only be carried out by a competent electrician.
Safety advice.
Safety advice for working on electrical connections, components,
etc.
DANGER! ... indicates an immediately hazardous situation which will lead to
death or severe injuries if it is not avoided.
WARNING! ... indicates a potentially hazardous situation which may lead to
death or severe injuries if it is not avoided.
CAUTION! ... indicates a potentially hazardous situation which may lead to
trivial or minor injuries if it is not avoided.
ATTENTION! ... indicates a situation which may lead to damage to property if it is
not avoided.
ETS In the ETS tables, the parameter default settings are marked by
underlining.

5 Description
Temperature evaluation unit KNX T6-UN-B4 • Version: 17.12.2019 • Technical Changes and Errors excepted.
1. Description
The Temperature evaluation unit KNX T6-UN-B4 has six inputs for T-100 or T-130
temperature sensors and four analogue/digital inputs, which can for example be used
for buttons or T-NTC temperature sensors. The temperature measurement values for
all inputs can be processed with external measurement values to provide a combined
value (total temperature, average temperature).
All measured values can be used for the control of threshold value-dependent
switching outputs. Six PI controllers control the heating and cooling (one- or two-
stage). Logic gates can be used to set up additional operations.
Functions:
•6 temperature inputs for T-100 or T-130 sensors
•4 analogue/binary inputs, for example for buttons or T-NTC temperature
sensors
•Combined value calculation for all connected temperature sensors
(proportion of internal measurement value and external value can be set as a
percentage)
•Threshold values can be adjusted per parameter or via communication
objects
•6 PI controllers for heating and cooling (one- or two-stage).
•4 AND and 4 OR logic gates with 4 for each input. 16 logic inputs (in the form
of communication objects) can be used as inputs for the logic gates. The output
of each gate can be configured optionally as 1-bit or 2 x 8-bit
Configuration is made using the KNX software ETS. The product file can be
downloaded from the Elsner Elektronik website on www.elsner-elektronik.de in the
“Service” menu.
1.1. Deliverables
• Temperature evaluation unit
Optional accessories:
(not included in the deliverables):
• T-100 (no. 30517) or T-130 (no. 30518) temperature sensors for temperature
inputs
• T-NTC temperature sensor (no. 30516) for analogue/binary inputs
1.2. Technical data
Housing Plastic
Colour white
Assembly Installation
Protection category IP 20
Dimensions of evaluation
electronics
approx. 38 × 47 × 32 (W × H × D, mm)

6 Installation and start-up
Temperature evaluation unit KNX T6-UN-B4 • Version: 17.12.2019 • Technical Changes and Errors excepted.
The product conforms with the provisions of EU directives.
2. Installation and start-up
2.1. Installation notes
Installation, testing, operational start-up and troubleshooting should
only be performed by an electrician.
CAUTION!
Live voltage!
There are unprotected live components inside the device.
• National legal regulations are to be followed.
• Ensure that all lines to be assembled are free of voltage and take
precautions against accidental switching on.
• Do not use the device if it is damaged.
• Take the device or system out of service and secure it against
unintentional use, if it can be assumed, that risk-free operation is no
longer guaranteed.
The device is only to be used for its intended purpose. Any improper modification or
failure to follow the operating instructions voids any and all warranty and guarantee
claims.
After unpacking the device, check it immediately for possible mechanical damage. If it
has been damaged in transport, inform the supplier immediately.
The device may only be used as a fixed-site installation; that means only when
assembled and after conclusion of all installation and operational start-up tasks and
only in the surroundings designated for it.
Weight approx. 40 g
Ambient temperature Operation -30…+70°C, storage -55…+125°C
Ambient humidity max. 95% RH, avoid condensation
Operating voltage KNX bus voltage
Bus current max. 8 mA
Data output KNX +/- bus connector terminal
BCU type Integrated microcontroller
PEI type 0
Group addresses max. 1024
Assignments max. 1024
Communication objects 333
Inputs 6× temperature sensor
4× analogue/binary

7 Installation and start-up
Temperature evaluation unit KNX T6-UN-B4 • Version: 17.12.2019 • Technical Changes and Errors excepted.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
2.2. Installation position
The evaluation electronics of the sensor is installed in a socket. When selecting an
installation location for the measuring sensor, please ensure that the measurement
results are affected as little as possible by external influences. Possible sources of
interference include:
• Direct sunlight
• Drafts from windows and doors
• Warming or cooling of the building structure on which the sensor is mounted,
e.g. due to sunlight, heating or cold water pipes
• Connection lines which lead from warmer or colder areas to the sensor
Temperature variations from such sources of interference must be corrected in the ETS
in order to ensure the specified accuracy of the sensor (temperature offset).
2.3. Connection
The cables of the T-100, T-130 and T-NTC temperature sensors can be extended to a
maximum of 10 m.
GND
PRG-LED
PRG button
(recessed)
(recessed)
1
GND
2
GND
3
GND
4
GND
5
GND
6
GND
4
3
2
1
GND
B: Analogue/binary inputs
(Buttons, T-NTC sensors)
KNX clamp
T: Temperature inputs
(T-100, T-130 sensors)
B1
B2
B3
B4
T6
T5
T4
T3
T2
T1

8 Addressing of the device at the bus
Temperature evaluation unit KNX T6-UN-B4 • Version: 17.12.2019 • Technical Changes and Errors excepted.
2.4. Notes on mounting and commissioning
Never expose the device to water (e.g. rain) or dust. This can damage the electronics.
You must not exceed a relative humidity of 95%. Avoid condensation.
After the bus voltage has been applied, the device will enter an initialisation phase
lasting a few seconds. During this phase no information can be received or sent via the
bus.
3. Addressing of the device at the bus
The device is supplied with the bus address 15.15.255. You can program another
address into the ETS by overwriting the 15.15.255 address or by teaching via the
programming button.

9 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
4. Transfer protocol
Units:
Temperatures in degrees Celsius
4.1. List of all communications objects
Abbreviation flags:
C Communication
R Read
WWrite
T Transfer
UUpdate
No. Text Function Flags DPT type Size
1 Software version Output R-CT [217.1] DPT_Version 2 bytes
11 Temperature sensor 1
measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
12 Temperature sensor 1
external measured value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
13 Temperature sensor 1
overall measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
14 Temperature sensor 1 fault Output R-CT [1.1] DPT_Switch 1 bit
21 Temperature sensor 2
measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
22 Temperature sensor 2
external measured value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
23 Temperature sensor 2
overall measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
24 Temperature sensor 2 fault Output R-CT [1.1] DPT_Switch 1 bit
31 Temperature sensor 3
measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
32 Temperature sensor 3
external measured value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
33 Temperature sensor 3
overall measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
34 Temperature sensor 3 fault Output R-CT [1.1] DPT_Switch 1 bit
41 Temperature sensor 4
measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
42 Temperature sensor 4
external measured value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
43 Temperature sensor 4
overall measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
44 Temperature sensor 4 fault Output R-CT [1.1] DPT_Switch 1 bit

10 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
51 Temperature sensor 5
measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
52 Temperature sensor 5
external measured value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
53 Temperature sensor 5
overall measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
54 Temperature sensor 5 fault Output R-CT [1.1] DPT_Switch 1 bit
61 Temperature sensor 6
measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
62 Temperature sensor 6
external measured value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
63 Temperature sensor 6
overall measured value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
64 Temperature sensor 6 fault Output R-CT [1.1] DPT_Switch 1 bit
81 Threshold value 1:
Measured value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
82 Threshold value 1:
Absolute value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
83 Threshold value 1: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
84 Threshold value 1:
Switching delay from 0 to 1
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
85 Threshold value 1:
Switching delay from 1 to 0
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
86 Threshold value 1:
Switching output
Output R-CT [1.1] DPT_Switch 1 bit
87 Threshold value 1:
Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
101 Threshold value 2:
Measured value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
102 Threshold value 2:
Absolute value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
103 Threshold value 2: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
104 Threshold value 2:
Switching delay from 0 to 1
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
105 Threshold value 2:
Switching delay from 1 to 0
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
106 Threshold value 2:
Switching output
Output R-CT [1.1] DPT_Switch 1 bit
107 Threshold value 2:
Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
121 Threshold value 3:
Measured value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
No. Text Function Flags DPT type Size

11 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
122 Threshold value 3:
Absolute value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
123 Threshold value 3: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
124 Threshold value 3:
Switching delay from 0 to 1
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
125 Threshold value 3:
Switching delay from 1 to 0
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
126 Threshold value 3:
Switching output
Output R-CT [1.1] DPT_Switch 1 bit
127 Threshold value 3:
Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
141 Threshold value 4:
Measured value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
142 Threshold value 4:
Absolute value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
143 Threshold value 4: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
144 Threshold value 4:
Switching delay from 0 to 1
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
145 Threshold value 4:
Switching delay from 1 to 0
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
146 Threshold value 4:
Switching output
Output R-CT [1.1] DPT_Switch 1 bit
147 Threshold value 4:
Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
161 Threshold value 5:
Measured value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
162 Threshold value 5:
Absolute value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
163 Threshold value 5: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
164 Threshold value 5:
Switching delay from 0 to 1
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
165 Threshold value 5:
Switching delay from 1 to 0
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
166 Threshold value 5:
Switching output
Output R-CT [1.1] DPT_Switch 1 bit
167 Threshold value 5:
Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
181 Threshold value 6:
Measured value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
182 Threshold value 6:
Absolute value
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
183 Threshold value 6: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
184 Threshold value 6:
Switching delay from 0 to 1
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
No. Text Function Flags DPT type Size

12 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
185 Threshold value 6:
Switching delay from 1 to 0
Input -WC- [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
186 Threshold value 6:
Switching output
Output R-CT [1.1] DPT_Switch 1 bit
187 Threshold value 6:
Switching output block
Input -WC- [1.1] DPT_Switch 1 bit
201 Temp. contr.1: Measured
value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
202 Temp. contr.1: HVAC mode
(priority 1)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
203 Temp. contr.1: HVAC mode
(priority 2)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
205 Temp. contr.1: Mode frost/
heat protection activation
Input -WC- [1.1] DPT_Switch 1 bit
206 Temp. contr.1: Block Input -WC- [1.1] DPT_Switch 1 bit
207 Temp. contr.1: Current
setpoint
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
208 Temp. contr.1: Switching
object (heating / cooling)
Input -WC- [1.1] DPT_Switch 1 bit
209 Temp. contr.1: Setpoint
comfort heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
210 Temp. contr.1: Setpoint
comfort heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
211 Temp. contr.1: Setpoint
comfort cooling
Input
output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
212 Temp. contr.1: Setpoint
comfort cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
213 Temp. contr.1: Setpoint
standby heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
214 Temp. contr.1: Setpoint
standby heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
215 Temp. contr.1: Setpoint
standby cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
216 Temp. contr.1: Setpoint
standby cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
217 Temp. contr.1: Setpoint
eco heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
218 Temp. contr.1: Setpoint,
eco heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
219 Temp. contr.1: Setpoint
eco cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
220 Temp. contr.1: Setpoint,
eco cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
No. Text Function Flags DPT type Size

13 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
221 Temp. contr.1: Control
variable stage 1
Output R-CT [5.1] DPT_Scaling 1 byte
222 Temp. contr.1: Control
variable stage 2
Output R-CT [5.1] DPT_Scaling 1 byte
223 Temp. contr.1: Control
variable cooling level 1
Output R-CT [5.1] DPT_Scaling 1 byte
224 Temp. contr.1: Control
variable cooling level 2
Output R-CT [5.1] DPT_Scaling 1 byte
225 Temp. contr.1: Status
heating level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
226 Temp. contr.1: Status
heating level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
227 Temp. contr.1: Status
cooling level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
228 Temp. contr.1: Status
cooling level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
229 Temp. contr.1: Comfort
extension time
Input RWCT [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
230 Temp. contr.1: Comfort
extension status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
241 Temp. contr.2: Measured
value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
242 Temp. contr.2: HVAC mode
(priority 1)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
243 Temp. contr.2: HVAC mode
(priority 2)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
245 Temp. contr.2: Mode frost/
heat protection activation
Input -WC- [1.1] DPT_Switch 1 bit
246 Temp. contr.2: Block Input -WC- [1.1] DPT_Switch 1 bit
247 Temp. contr.2: Current
setpoint
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
248 Temp. contr.2: Switching
object (heating / cooling)
Input -WC- [1.1] DPT_Switch 1 bit
249 Temp. contr.2: Setpoint
comfort heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
250 Temp. contr.2: Setpoint
comfort heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
251 Temp. contr.2: Setpoint
comfort cooling
Input
output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
252 Temp. contr.2: Setpoint
comfort cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
No. Text Function Flags DPT type Size

14 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
253 Temp. contr.2: Setpoint
standby heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
254 Temp. contr.2: Setpoint
standby heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
255 Temp. contr.2: Setpoint
standby cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
256 Temp. contr.2: Setpoint
standby cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
257 Temp. contr.2: Setpoint
eco heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
258 Temp. contr.2: Setpoint,
eco heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
259 Temp. contr.2: Setpoint
eco cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
260 Temp. contr.2: Setpoint,
eco cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
261 Temp. contr.2: Control
variable stage 1
Output R-CT [5.1] DPT_Scaling 1 byte
262 Temp. contr.2: Control
variable stage 2
Output R-CT [5.1] DPT_Scaling 1 byte
263 Temp. contr.2: Control
variable cooling level 1
Output R-CT [5.1] DPT_Scaling 1 byte
264 Temp. contr.2: Control
variable cooling level 2
Output R-CT [5.1] DPT_Scaling 1 byte
265 Temp. contr.2: Status
heating level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
266 Temp. contr.2: Status
heating level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
267 Temp. contr.2: Status
cooling level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
268 Temp. contr.2: Status
cooling level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
269 Temp. contr.2: Comfort
extension time
Input RWCT [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
270 Temp. contr.2: Comfort
extension status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
281 Temp. contr.3: Measured
value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
282 Temp. contr.3: HVAC mode
(priority 1)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
No. Text Function Flags DPT type Size

15 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
283 Temp. contr.3: HVAC mode
(priority 2)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
285 Temp. contr.3: Mode frost/
heat protection activation
Input -WC- [1.1] DPT_Switch 1 bit
286 Temp. contr.3: Block Input -WC- [1.1] DPT_Switch 1 bit
287 Temp. contr.3: Current
setpoint
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
288 Temp. contr.3: Switching
object (heating / cooling)
Input -WC- [1.1] DPT_Switch 1 bit
289 Temp. contr.3: Setpoint
comfort heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
290 Temp. contr.3: Setpoint
comfort heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
291 Temp. contr.3: Setpoint
comfort cooling
Input
output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
292 Temp. contr.3: Setpoint
comfort cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
293 Temp. contr.3: Setpoint
standby heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
294 Temp. contr.3: Setpoint
standby heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
295 Temp. contr.3: Setpoint
standby cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
296 Temp. contr.3: Setpoint
standby cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
297 Temp. contr.3: Setpoint
eco heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
298 Temp. contr.3: Setpoint,
eco heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
299 Temp. contr.3: Setpoint
eco cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
300 Temp. contr.3: Setpoint,
eco cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
301 Temp. contr.3: Control
variable stage 1
Output R-CT [5.1] DPT_Scaling 1 byte
302 Temp. contr.3: Control
variable stage 2
Output R-CT [5.1] DPT_Scaling 1 byte
303 Temp. contr.3: Control
variable cooling level 1
Output R-CT [5.1] DPT_Scaling 1 byte
304 Temp. contr.3: Control
variable cooling level 2
Output R-CT [5.1] DPT_Scaling 1 byte
305 Temp. contr.3: Status
heating level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
No. Text Function Flags DPT type Size

16 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
306 Temp. contr.3: Status
heating level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
307 Temp. contr.3: Status
cooling level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
308 Temp. contr.3: Status
cooling level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
309 Temp. contr.3: Comfort
extension time
Input RWCT [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
310 Temp. contr.3: Comfort
extension status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
321 Temp. contr.4: Measured
value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
322 Temp. contr.4: HVAC mode
(priority 1)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
323 Temp. contr.4: HVAC mode
(priority 2)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
325 Temp. contr.4: Mode frost/
heat protection activation
Input -WC- [1.1] DPT_Switch 1 bit
326 Temp. contr.4: Block Input -WC- [1.1] DPT_Switch 1 bit
327 Temp. contr.4: Current
setpoint
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
328 Temp. contr.4: Switching
object (heating / cooling)
Input -WC- [1.1] DPT_Switch 1 bit
329 Temp. contr.4: Setpoint
comfort heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
330 Temp. contr.4: Setpoint
comfort heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
331 Temp. contr.4: Setpoint
comfort cooling
Input
output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
332 Temp. contr.4: Setpoint
comfort cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
333 Temp. contr.4: Setpoint
standby heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
334 Temp. contr.4: Setpoint
standby heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
335 Temp. contr.4: Setpoint
standby cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
336 Temp. contr.4: Setpoint
standby cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
337 Temp. contr.4: Setpoint
eco heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
No. Text Function Flags DPT type Size

17 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
338 Temp. contr.4: Setpoint,
eco heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
339 Temp. contr.4: Setpoint
eco cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
340 Temp. contr.4: Setpoint,
eco cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
341 Temp. contr.4: Control
variable stage 1
Output R-CT [5.1] DPT_Scaling 1 byte
342 Temp. contr.4: Control
variable stage 2
Output R-CT [5.1] DPT_Scaling 1 byte
343 Temp. contr.4: Control
variable cooling level 1
Output R-CT [5.1] DPT_Scaling 1 byte
344 Temp. contr.4: Control
variable cooling level 2
Output R-CT [5.1] DPT_Scaling 1 byte
345 Temp. contr.4: Status
heating level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
346 Temp. contr.4: Status
heating level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
347 Temp. contr.4: Status
cooling level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
348 Temp. contr.4: Status
cooling level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
349 Temp. contr.4: Comfort
extension time
Input RWCT [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
350 Temp. contr.4: Comfort
extension status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
361 Temp. contr.5: Measured
value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
362 Temp. contr.5: HVAC mode
(priority 1)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
363 Temp. contr.5: HVAC mode
(priority 2)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
365 Temp. contr.5: Mode frost/
heat protection activation
Input -WC- [1.1] DPT_Switch 1 bit
366 Temp. contr.5: Block Input -WC- [1.1] DPT_Switch 1 bit
367 Temp. contr.5: Current
setpoint
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
368 Temp. contr.5: Switching
object (heating / cooling)
Input -WC- [1.1] DPT_Switch 1 bit
369 Temp. contr.5: Setpoint
comfort heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
No. Text Function Flags DPT type Size

18 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
370 Temp. contr.5: Setpoint
comfort heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
371 Temp. contr.5: Setpoint
comfort cooling
Input
output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
372 Temp. contr.5: Setpoint
comfort cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
373 Temp. contr.5: Setpoint
standby heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
374 Temp. contr.5: Setpoint
standby heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
375 Temp. contr.5: Setpoint
standby cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
376 Temp. contr.5: Setpoint
standby cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
377 Temp. contr.5: Setpoint
eco heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
378 Temp. contr.5: Setpoint,
eco heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
379 Temp. contr.5: Setpoint
eco cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
380 Temp. contr.5: Setpoint,
eco cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
381 Temp. contr.5: Control
variable stage 1
Output R-CT [5.1] DPT_Scaling 1 byte
382 Temp. contr.5: Control
variable stage 2
Output R-CT [5.1] DPT_Scaling 1 byte
383 Temp. contr.5: Control
variable cooling level 1
Output R-CT [5.1] DPT_Scaling 1 byte
384 Temp. contr.5: Control
variable cooling level 2
Output R-CT [5.1] DPT_Scaling 1 byte
385 Temp. contr.5: Status
heating level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
386 Temp. contr.5: Status
heating level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
387 Temp. contr.5: Status
cooling level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
388 Temp. contr.5: Status
cooling level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
389 Temp. contr.5: Comfort
extension time
Input RWCT [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
No. Text Function Flags DPT type Size

19 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
390 Temp. contr.5: Comfort
extension status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
401 Temp. contr.6: Measured
value
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
402 Temp. contr.6: HVAC mode
(priority 1)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
403 Temp. contr.6: HVAC mode
(priority 2)
Input -WC- [20.102] DPT_HVAC-
Mode
1 byte
405 Temp. contr.6: Mode frost/
heat protection activation
Input -WC- [1.1] DPT_Switch 1 bit
406 Temp. contr.6: Block Input -WC- [1.1] DPT_Switch 1 bit
407 Temp. contr.6: Current
setpoint
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
408 Temp. contr.6: Switching
object (heating / cooling)
Input -WC- [1.1] DPT_Switch 1 bit
409 Temp. contr.6: Setpoint
comfort heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
410 Temp. contr.6: Setpoint
comfort heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
411 Temp. contr.6: Setpoint
comfort cooling
Input
output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
412 Temp. contr.6: Setpoint
comfort cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
413 Temp. contr.6: Setpoint
standby heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
414 Temp. contr.6: Setpoint
standby heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
415 Temp. contr.6: Setpoint
standby cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
416 Temp. contr.6: Setpoint
standby cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
417 Temp. contr.6: Setpoint
eco heating
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
418 Temp. contr.6: Setpoint,
eco heating (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
419 Temp. contr.6: Setpoint
eco cooling
Input/
Output
RWCT [9.1] DPT_Val-
ue_Temp
2 bytes
420 Temp. contr.6: Setpoint,
eco cooling (1:+ | 0: -)
Input -WC- [1.1] DPT_Switch 1 bit
421 Temp. contr.6: Control
variable stage 1
Output R-CT [5.1] DPT_Scaling 1 byte
422 Temp. contr.6: Control
variable stage 2
Output R-CT [5.1] DPT_Scaling 1 byte
No. Text Function Flags DPT type Size

20 Transfer protocol
Temperature evaluation unit KNX T6-UN-B4 • Version: 17/12/2019 • Technical changes and errors excepted.
423 Temp. contr.6: Control
variable cooling level 1
Output R-CT [5.1] DPT_Scaling 1 byte
424 Temp. contr.6: Control
variable cooling level 2
Output R-CT [5.1] DPT_Scaling 1 byte
425 Temp. contr.6: Status
heating level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
426 Temp. contr.6: Status
heating level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
427 Temp. contr.6: Status
cooling level 1 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
428 Temp. contr.6: Status
cooling level 2 (1=ON |
0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
429 Temp. contr.6: Comfort
extension time
Input RWCT [7] 7.xxx[7.5] DPT_-
TimePeriodSec
2 bytes
430 Temp. contr.6: Comfort
extension status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
451 Push-button 1 long-term Output R-CT [1.8] DPT_UpDown 1 bit
452 Push-button 1 short-term Output R-CT [1.10] DPT_Start 1 bit
453 Push-button 1 switching Output R-CT [1.1] DPT_Switch 1 bit
454 Push button 1 dimming Input/
Output
RWCT [3.7] DPT_Con-
trol_Dimming
4 bit
455 Push-button 1 encoder
8bit
Output R-CT [5] 5.xxx 1 byte
456 Push-button 1 encoder
16 bit
Output R-CT [9] 9.xxx 2 bytes
457 Button 1 scenario
activation
Output R-CT [5] 5.xxx 1 byte
461 Push-button 2 long-term Output R-CT [1.8] DPT_UpDown 1 bit
462 Push-button 2 short-term Output R-CT [1.10] DPT_Start 1 bit
463 Push-button 2 switching Output R-CT [1.1] DPT_Switch 1 bit
464 Push button 2 dimming Input/
Output
RWCT [3.7] DPT_Con-
trol_Dimming
4 bit
465 Push-button 2 encoder
8bit
Output R-CT [5] 5.xxx 1 byte
466 Push-button 2 encoder
16 bit
Output R-CT [9] 9.xxx 2 bytes
467 Button 2 scenario
activation
Output R-CT [5] 5.xxx 1 byte
471 Push-button 3 long-term Output R-CT [1.8] DPT_UpDown 1 bit
No. Text Function Flags DPT type Size
