MiTAC TYAN S5552 User manual

http://www.tyan.com
1
S5552
Version 1.0d
Copyright
Copyright © 2018 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
TYAN®is a trademark of MiTAC International Corporation.
Intel®is a trademark of Intel®Corporation.
AMI, AMI BIOS are trademarks of AMI Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN®products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

http://www.tyan.com
2
Contents
S5552............................................................................................................1
Before you begin…....................................................................................3
Chapter 1: Instruction ................................................................................4
1.1 Congratulations .................................................................................4
1.2 Hardware Specifications....................................................................4
1.3 Software Specifications...................................................................14
Chapter 2: Board Installation...................................................................15
2.1 Board Image....................................................................................16
2.2 Block Diagram.................................................................................17
2.3 Motherboard Mechanical Drawing...................................................18
2.4Board Parts, Jumpers and Connectors...........................................19
2.5Installing the Processor and Heatsink.............................................26
2.6Tips on Installing Motherboard in Chassis ......................................30
2.7Installing the Memory ......................................................................32
2.8Attaching Drive Cables....................................................................36
2.9Installing Add-In Cards....................................................................37
2.10 Connecting External Devices ........................................................38
2.11 Installing the Power Supply...........................................................40
2.12 Finishing Up...................................................................................40
Chapter 3: BIOS Setup .............................................................................41
3.1 About the BIOS................................................................................41
3.2 Main Menu.......................................................................................43
3.3 Advanced Menu...............................................................................44
3.4 Chipset Menu ..................................................................................79
3.5Server Management........................................................................90
3.6Security............................................................................................94
3.7Boot ...............................................................................................101
3.8Save & Exit....................................................................................107
Chapter 4: Diagnostics...........................................................................109
4.1 Flash Utility....................................................................................109
4.2 AMIBIOS Post Code (Aptio)..........................................................110
Appendix I: Fan and Temp Sensors .....................................................117
Glossary...................................................................................................121
Technical Support ..................................................................................127

http://www.tyan.com
3
Before you begin…
Check the box contents!
The retail motherboard package should contain the following:
S5552 Motherboard x 1
SATA Single Cable x 2
Rear IO shielding x 1
1 x S5552 Quick Installation Guide
IMPORTANT NOTE:
1. Sales samples may not come with any of the accessories listed above.
If you have ordered a sales sample and you are missing any of the above items,
please contact your sales representative to help order accessories.
2. Please help to download user manual and driver from www.tyan.com

http://www.tyan.com
4
Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN®S5552 motherboard, based on the Intel®
C242/C246 chipset. The S5552 is designed to support Intel®Xeon® E-2200/-2100
series processors, 9th/8th Gen. Intel Core i3, Intel®Celeron®G4900 Series and
Intel®Pentium®G5000 Series Processors. Support UDIMM ECC DDR4
2666/2400/2133, up to 128 GB DDR4memory. Leveraging advanced technology
from Intel®, the S5552 is capable of offering scalable 32 and 64-bit computing, high-
bandwidth memory design, and lightning-fast PCI-E bus implementation.
The S5552 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S5552 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN® website at http://www.tyan.com. There you can find
all the information on all TYAN®products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S5552GM2NR Specifications
Processor
Q'ty / Socket Type
(1) LGA1151
Supported CPU
Series
Intel Xeon E-2200/2100 series
processors, 9th/8th Gen. Intel Core
i3 processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage
Max up to 95W
Chipset
PCH
Intel C242
Memory
Supported DIMM Qty
(4) DIMM slots
DIMM Type / Speed
UDIMM ECC DDR4
2666/2400/2133
Capacity
Up to 128GB / *Follow latest Intel
DDR4 Memory POR
Memory channel
2 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x16 slot,
(1) PCI-E Gen3 x8 slot ( w/ x2 link),

http://www.tyan.com
5
(2) PCI-E Gen.3 x1 slots
LAN
Q'ty / Port
(2) GbE ports,
(1) PHY dedicated for IPMI
Controller
Intel I210
PHY
Realtek RTL8211E
Storage
SATA
Connector
(4) SATA
Controller
Intel C242
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
sSATA
Connector
(2) SATA-DOM
Controller
Intel C242
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200 @60Hz
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.1 Gen2 ports (at rear),
(4) USB3.1 Gen1 ports (2 at rear,
2 via Cable)
COM
(2) ports (1 at rear, 1 via cable)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(2) GbE ports,
(1) Dedicated for IPMI
SATA
(4) SATA-III connectors +
(2) SATA-DOM connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM
24-bit high quality video

http://www.tyan.com
6
Feature
compression, Supports storage
over IP and remote platform-flash,
USB 2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states S5,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
6.1, SMBIOS 3.1/PnP/Wake on
LAN
Physical Dimension
Form Factor
ATX
Board Dimension
12"x9.6" (305x243.8mm)
Regulation
FCC (SDoC)
Class B
CE (DoC)
Class B
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Operating System
OS supported list
Please refer to our AVL support
lists.
Package Contains
Motherboard
(1) S5552 Motherboard
Manual
(1) Quick Installation Guide

http://www.tyan.com
7
S5552GM4NR Specifications
Processor
Q'ty / Socket Type
(1) LGA1151
Supported CPU
Series
Intel Xeon E-2200/2100 series
processors, 9th/8th Gen. Intel Core
i3 processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage
Max up to 95W
Chipset
PCH
Intel C242
Memory
Supported DIMM Qty
(4) DIMM slots
DIMM Type / Speed
UDIMM ECC DDR4 2666/2400/2133
Capacity
Up to 128GB / *Follow latest Intel
DDR4 Memory POR
Memory channel
2 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x16 slot,
(1) PCI-E Gen3 x8 slot ( w/ x2 link),
(2) PCI-E Gen.3 x1 slots
LAN
Q'ty / Port
(4) GbE ports
(1) PHY dedicated for IPMI
Controller
Intel I210
PHY
Realtek RTL8211E
Storage
SATA
Connector
(4) SATA
Controller
Intel C242
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
sSATA
Connector
(2) SATA-DOM
Controller
Intel C242
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200 @60Hz
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.1 Gen2 ports (at rear),
(4) USB3.1 Gen1 ports (2 at rear, 2
via Cable)

http://www.tyan.com
8
COM
(2) ports (1 at rear, 1 via cable)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(4) GbE ports,
(1) Dedicated for IPMI
SATA
(4) SATA-III connectors
(2) SATA-DOM connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage
over IP and remote platform-flash,
USB 2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states S5,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
6.1, SMBIOS 3.1/PnP/Wake on
LAN
Physical Dimension
Form Factor
ATX
Board Dimension
12"x9.6" (305x243.8mm)
Regulation
FCC (SDoC)
Class B
CE (DoC)
Class B
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes

http://www.tyan.com
9
Operating System
OS supported list
Please refer to our AVL support
lists.
Package Contains
Motherboard
(1) S5552 Motherboard
Manual
(1) Quick Installation Guide
S5552WGM4NR Specifications
Processor
Q'ty / Socket Type
(1) LGA1151
Supported CPU
Series
Intel Xeon E-2200/2100 series
processors, 9th/8th Gen. Intel Core
i3 processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage
Max up to 95W
Chipset
PCH
Intel C242
Memory
Supported DIMM Qty
(4) DIMM slots
DIMM Type / Speed
UDIMM ECC DDR4 2666/2400/2133
Capacity
Up to 128GB / *Follow latest Intel
DDR4 Memory POR
Memory channel
2 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x8 slot ( w/ x2 link),
(1) PCI-E Gen3 x16 slot (w/ x8 link),
(2) PCI-E Gen.3 x1 slots
LAN
Q'ty / Port
(4) GbE ports
(1) PHY dedicated for IPMI
Controller
Intel I210
PHY
Realtek RTL8211E
Storage
SAS
Connector
(2) Mini-SAS HD
connectors (totally
support 8 ports)
Controller
LSI SAS3008
Speed
12.0 Gb/s
RAID
RAID 0/1/1E/10 (LSI
Integrated RAID)

http://www.tyan.com
10
SATA
Connector
(4) SATA
Controller
Intel C242
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
sSATA
Connector
(2) SATA-DOM
Controller
Intel C242
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200 @60Hz
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.1 Gen2 ports (at rear),
(4) USB3.1 Gen1 ports (2 at rear, 2
via Cable)
COM
(2) ports (1 at rear, 1 via cable)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(4) GbE ports,
(1) Dedicated for IPMI
SAS
(2) Mini-SAS HD (4-in-1) connectors
SATA
(4) SATA-III connectors
(2) SATA-DOM connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage
over IP and remote platform-flash,
USB 2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),

http://www.tyan.com
11
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states S5,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
6.1, SMBIOS 3.1/PnP/Wake on
LAN
Physical Dimension
Form Factor
ATX
Board Dimension
12"x9.6" (305x243.8mm)
Regulation
FCC (SDoC)
Class B
CE (DoC)
Class B
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Operating System
OS supported list
Please refer to our AVL support
lists.
Package Contains
Motherboard
(1) S5552 Motherboard
Manual
(1) Quick Installation Guide

http://www.tyan.com
12
S5552WGM4NR-EX Specifications
Processor
Q'ty / Socket Type
(1) LGA1151
Supported CPU
Series
Intel Xeon E-2200/2100 series
processors, 9th/8th Gen. Intel Core
i3 processors, Intel Celeron G4900
Series Processors and Intel
Pentium Processor G5000 Series
Thermal Design
Power (TDP) Wattage
Max up to 95W
Chipset
PCH
Intel C246
Memory
Supported DIMM Qty
(4) DIMM slots
DIMM Type / Speed
UDIMM ECC DDR4 2666/2400/2133
Capacity
Up to 128GB / *Follow latest Intel
DDR4 Memory POR
Memory channel
2 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x8 slot ( w/ x4 link),
(1) PCI-E Gen3 x16 slot (w/ x8 link),
(2) PCI-E Gen.3 x1 slots
PCI
(1) PCI 32-bit slot
LAN
Q'ty / Port
(4) GbE ports
(1) PHY dedicated for IPMI
Controller
Intel I210
PHY
Realtek RTL8211E
Storage
SAS
Connector
(2) Mini-SAS HD
connectors
(totally support 8 ports)
Controller
LSI SAS3008
Speed
12.0 Gb/s
RAID
RAID 0/1/1E/10 (LSI
Integrated RAID)
SATA
Connector
(6) SATA
Controller
Intel C246
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
sSATA
Connector
(2) SATA-DOM
Controller
Intel C246
Speed
6.0 Gb/s

http://www.tyan.com
13
RAID
RAID 0/1/10/5 (Intel
RSTe)
Graphic
VGA
Connector type
(1) D-Sub 15-pin
Resolution
Up to 1920x1200
@60Hz
Chipset
Aspeed AST2500
Display Port
Connector type
(1)Display port 1.2
Resolution
Up to 4096X2304
@60Hz
Chipset
Intel Processor Graphics
(pGFX)
Input /Output
USB
(4) USB3.1 Gen2 ports (at rear),
(2) USB3.1 Gen1 ports (via Cable)
COM
(2) ports (1 at rear, 1 via cable)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(4) GbE ports,
(1) Dedicated for IPMI
SAS
(2) Mini-SAS HD (4-in-1)
connectors
SATA
(6) SATA-III connectors
(2) SATA-DOM connectors
Display port
(1) Display port 1.2
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage
over IP and remote platform-flash,
USB 2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB

http://www.tyan.com
14
Feature
Hardware Monitor, PXE boot
support, ACPI sleeping states S5,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
6.1, SMBIOS 3.1/PnP/Wake on
LAN
Physical Dimension
Form Factor
ATX
Board Dimension
12"x9.6" (305x243.8mm)
Regulation
FCC (SDoC)
Class B
CE (DoC)
Class B
Operating Environment
Operating Temp.
0°C ~ 55°C (32°F~ 131°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Operating System
OS supported list
Please refer to our AVL support
lists.
Package Contains
Motherboard
(1) S5552 Motherboard
Manual
(1) Quick Installation Guide
1.3 Software Specifications
For the latest AST2500 User’s Guide and OS (operation system) support, please
visit the Tyan’s Web site at http://www.tyan.com for the latest information

http://www.tyan.com
15
Chapter 2: Board Installation
You are now ready to install your motherboard.
How to install our products right… the first time
The first thing you should do is read this user’s manual. It contains important
information that will make configuration and setup much easier. Here are some
precautions you should take when installing your motherboard:
(1) Ground yourself properly before removing your motherboard from the
antistatic bag. Unplug the power from your computer power supply and
then touch a safely grounded object to release static charge (i.e. power
supply case). For the safest conditions, MiTAC recommends wearing a
static safety wrist strap.
(2) Hold the motherboard by its edges and do not touch the bottom of the
board, or flex the board in any way.
(3) Avoid touching the motherboard components, IC chips, connectors,
memory modules, and leads.
(4) Place the motherboard on a grounded antistatic surface or on the antistatic
bag that the board was shipped in.
(5) Inspect the board for damage.
The following pages include details on how to install your motherboard into your
chassis, as well as installing the processor, memory, disk drives and cables.
Caution!
1. To avoid damaging the motherboard and associated
components, do not use torque force greater than
5~7kgf/cm (4.35~6.09 lb/in) on each mounting screw
for motherboard installation.
2. Do not apply power to the board if it has been
damaged.

http://www.tyan.com
16
2.1 Board Image
S5552
This picture is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above picture.

http://www.tyan.com
17
2.2 Block Diagram
S5552 Block Diagram

http://www.tyan.com
18
2.3 Motherboard Mechanical Drawing

http://www.tyan.com
19
2.4 Board Parts, Jumpers and Connectors
This diagram is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above diagram. The
DIMM slot numbers shown above can be used as a reference when reviewing the
DIMM population guidelines shown later in the manual. For the latest board revision,
please visit our web site at http://www.tyan.com.

http://www.tyan.com
20
Motherboard Components
Connectors
1. ID_Button (SW1)
18.SYS_FAN_FP (J39)
2. USB3.1x2+LAN PHY RJ45 (J62)
19.COM Port.2(J57)
3. VGA + COM Port1 (J56)
20.SATA 6(J20)
4. ATX Power Connector 8P(PW2)
21.SATA 0(SATA-DOM1) (J16)
5. Display Port (J58)+
USB3.1Port x 2 (J61)
22.SATA 4(J15)
6. LAN3 LED Header (J65)
23.SATA 1(SATA-DOM2)(J19)
7. LAN3 RJ45 + LAN4 RJ45(J52)
24.SATA 5(J17)
8. LAN1 RJ45 + LAN2 RJ45(J51)
25.SATA 3(J23)
9. LAN4 LED Header (J66)
26.SATA 2(J21)
10. SYS_FAN4 (J35)
27.SYS_ FAN3 (J40)
11. SYS_FAN5 (J37)
28.SATA 7 (J22)
12. IPMB Header (J31)
29.SAS 0-3 (J79)
13. TYAN Module Header (DBG_HD1)
30.SYS_FAN2 (J38)
14. SAS 4~7 (J78)
31.SYS_FAN1 (J36)
15. FPB USB2.0/ USB3.1x2 (J74)
32.CPU0_FAN (J34)
16. HDD BP SATA SGPIO (J24)
33. PSMI Header (J50)
17. Front Panel Header(Power
Button/Reset Button/HDD Active
LED/Power On LED) (J32)
34. ATX Power Connector 24P (PW1)
35. PHY LED Header (J67)
Headers/Jumpers
a. Clear CMOS Jumper (Load BIOS
Default Set Up) (J12)
b. ME Firmware Update (J10)
c. Intruder Header (J33)
PCIE Slots
A. PCIE 3.0 Slot x16 (J55)
D. PCIE 3.0 Slot x1 (J76)
B. PCIE 3.0 Slot x8 (J54)
E. PCI Slot (J83)
C. PCIE 3.0 Slot x1 (J75)
LEDs
i CATERR LED(LED1)
iv SAS Error LED (LED 13)
ii BMC Heartbeat LED (LED2)
v SAS Active LED (LED 14)
iii ID LED(LED12)
