Elvaco CMi4130 User manual

CMi4130 User’s Manual English
CMi4130
User’s Manual
English
v1.1

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 2 (25)
[2020-06]
V1.1
Contents
1DOCUMENT NOTES...................................................................................................................... 3
1.1 COPYRIGHT AND TRADEMARK................................................................................................ 3
1.2 CONTACTS........................................................................................................................... 3
2IMPORTANT USAGE AND SAFETY INFORMATION .................................................................. 4
3USING THIS MANUAL................................................................................................................... 5
3.1 PURPOSE AND AUDIENCE...................................................................................................... 5
3.2 ONLINE RESOURCES............................................................................................................. 5
3.3 SYMBOLS............................................................................................................................. 5
4INTRODUCTION............................................................................................................................. 6
4.1 PURPOSE............................................................................................................................. 6
4.2 APPLICATION DESCRIPTION................................................................................................... 6
4.3 PRODUCT FEATURES ............................................................................................................ 6
4.4 COMPATIBILITY..................................................................................................................... 6
5GETTING STARTED ...................................................................................................................... 7
5.1 PURPOSE............................................................................................................................. 7
5.2 PRODUCT SPECIFICATION...................................................................................................... 7
5.3 MOUNT AND START-UP THE DEVICE ....................................................................................... 7
5.3.1 Mounting and connection...................................................................................................7
5.3.2 Connection of antenna.......................................................................................................7
5.3.3 Network preparation...........................................................................................................7
5.3.4 Activation............................................................................................................................8
5.3.5 Switch off/reboot module....................................................................................................9
6ADMINISTRATION REFERENCE................................................................................................ 10
6.1 PURPOSE........................................................................................................................... 10
6.2 SECURITY AND ACCESS CONTROL........................................................................................ 10
6.3 CONFIGURATION OPTIONS................................................................................................... 10
6.4 TIME HANDLING .................................................................................................................. 11
6.5 ADAPTIVE DATA RATE (ADR)............................................................................................... 11
6.6 TRANSMIT INTERVAL........................................................................................................... 12
6.6.1 EcoMode..........................................................................................................................12
6.7 MESSAGE FORMATS ........................................................................................................... 12
6.7.1 Message structure............................................................................................................12
6.7.2 Structure and payload......................................................................................................13
6.7.3 Meter communication error message...............................................................................20
6.8 DOWNLINK ......................................................................................................................... 20
7TECHNICAL SPECIFICATIONS.................................................................................................. 22
8TYPE APPROVALS ..................................................................................................................... 23
9DOCUMENT HISTORY ................................................................................................................ 24
9.1 VERSIONS.......................................................................................................................... 24
10 REFERENCES.............................................................................................................................. 25
10.1 TERMS AND ABBREVIATIONS................................................................................................ 25
10.2 NUMBER REPRESENTATION................................................................................................. 25
10.3 EUROPEAN STANDARDS ..................................................................................................... 25

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 3 (25)
[2020-06]
V1.1
1 Document notes
All information in this manual, including product data, diagrams, charts, etc. represents information on
products at the time of publication, and is subject to change without prior notice due to product
improvements or other reasons. It is recommended that customers contact Elvaco AB for the latest
product information before purchasing a CMi Series product.
The documentation and product are provided on an “as is” basis only and may contain deficiencies or
inadequacies. Elvaco AB takes no responsibility for damages, liabilities or other losses by using this
product.
1.1 Copyright and trademark
© 2020, Elvaco AB. All rights reserved. No part of the contents of this manual may be transmitted or
reproduced in any form by any means without the written permission of Elvaco AB. Printed in Sweden.
CMi Series is a trademark of Elvaco AB, Sweden.
1.2 Contacts
Elvaco AB Headquarter
Kabelgatan 2T
434 37 Kungsbacka
SWEDEN
Phone: [phone]
E-Mail: [email protected]
Elvaco AB Technical Support
Phone: [phone]
E-Mail: [e-mail]
Online: http://www.elvaco.com

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 4 (25)
[2020-06]
V1.1
2 Important usage and safety information
The following safety precautions must be observed during all phases of the operation, usage, service or
repair of any CMi Series product. Users of the product are advised to convey the information to users and
operating personnel and to incorporate these guidelines into all manuals supplied with the product.
Failure to comply with these precautions violates safety standards of design, manufacture and intended
use of the product. Elvaco AB assumes no liability for customer’s failure to comply with these
precautions.
CMi4130 receives and transmits radio frequency energy while switched on. Remember that interference
can occur if the product is used close to TV sets, radios, computers or inadequately shielded equipment.
Follow any special regulations and always switch off the product wherever forbidden, or when you
suspect that it may cause interference or danger.

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 5 (25)
[2020-06]
V1.1
3 Using this manual
3.1 Purpose and audience
This manual provides all information needed to mount, deploy and configure CMi4130 and targets
installers and system integrators.
3.2 Online resources
To download the latest version of this user’s manual, or to find information in other languages, please
visit http://www.elvaco.com/.
3.3 Symbols
The following symbols are used throughout the manual to emphasize important information and useful
tips:
The Note symbol is used to mark information that is important to take into consideration for
safety reasons or to assure correct operation of the meter connectivity module.
The Tip symbol is used to mark information intended to help you get the most out of your
product. It might for example be used to highlight a possible customization option related to the
current section.
Table 1 provides information on how the product should be used.
Symbol
Description
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Contact your Local Authority for recycling advise.
Electrostatic-sensitive device. Please observe the necessary ESD protective measures when
installing the module.
Table 1: Usage information

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 6 (25)
[2020-06]
V1.1
4 Introduction
4.1 Purpose
This chapter provides a general description of CMi4130. In the next-coming sections you will learn more
about possible applications for the product and how CMi4130 can be combined with other products to
build versatile solutions.
4.2 Application description
CMi4130 is a cost-effective meter connectivity module, which is mounted in an Itron CF ECHO II heat
meter or an Itron CF 51/55 calculator. It uses a very energy-efficient scheme to deliver meter data to a
receiving (application) server over a LoRaWAN network. Meter data is securely transmitted, using
LoRaWAN end-to-end security scheme. CMi4130 can be retrofitted into already-deployed meters or
mounted in the meter before deployment.
4.3 Product features
CMi4130 offers a combination of battery operation with very long lifetime and a versatile application
through its many configuration options. Key features of the module include:
•Extensive battery lifetime
The module’s EcoMode feature enables the module to achieve a battery-lifetime of at least 11+1
years.
•No meter installation needed
As soon as the meter connectivity module has been mounted in the meter and activated, it will
join the LoRaWAN network and start to deliver meter data, i.e. no manual steps need to be taken
in order to install the product in the meter.
•Quick commissioning
With Elvaco’s One-Touch Commissioning (OTC), deployment, configuration and key transferring
can be performed in a secure and flexible way. Use the Elvaco OTC App to enter your desired
settings and place your phone next to the meter. New settings will be applied via NFC.
•A unique and flexible message scheme
CMi4130 has several different message formats to choose from. This makes it easy to customize
the product to the unique demands of your application.
4.4 Compatibility
CMi4130 is compatible with Itron ECHO II heat meters and Itron CF 51/55 calculators.

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 7 (25)
[2020-06]
V1.1
5 Getting started
5.1 Purpose
This chapter provides instructions on how to get started with CMi4130. After reading and carefully
following each step of this chapter, your meter connectivity module should be mounted and connected to
the LoRaWAN network.
5.2 Product specification
5.3 Mount and start-up the device
5.3.1 Mounting and connection
CMi4130 is mounted in the module slot of an Itron CF 51/55/ECHO II. Grab the device by the outer
edges, gently press it into position.
5.3.2 Connection of antenna
CMi4130 is available in two different versions, with internal antenna (CMi4130Int) and with external
antenna (CMi4130Ext). If using the external antenna version of the module, the antenna is connected
using an SMA connector.
If using an external antenna, make sure to mount it at least 0.5 meters away from the meter
in order not to cause interference.
5.3.3 Network preparation
In order for the module to connect to the LoRaWAN network, it needs to be added in the network server.
More specifically, the following device information needs to be registered: Device EUI, Application key
and Join EUI. (If using ABP mode, the following information should be registered instead: Application
Session key, Network Session key and Device address.)
Elvaco strongly recommends using Over-the-air activation (OTAA) to facilitate deployment
and minimize the risk of duplicated keys.
1. NFC antenna
2. LoRa antenna
3. Green LED
4. Red LED
5. Battery
6. Push button

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 8 (25)
[2020-06]
V1.1
5.3.4 Activation
Module activation
Upon delivery, CMi4130 is set to passive mode, which means no messages will be transmitted from the
module. The module can be activated in one of the following ways:
a) By using the module push button: Press down the push button of the module for at least five
seconds until the green LED lights up.
b) By using the Elvaco OTC App: Open the Elvaco OTC app (downloadable via Google Play) and
scan the module (make sure NFC is activated on the phone). Remove the front enclosure of the
meter if needed. Go to Apply mode, set the Power mode to “active” and click Apply settings.
Place the phone next to the module. New settings are applied via NFC. You can make sure that
the module has joined the LoRaWAN network correctly by checking the “network join” field in the
Inspect tab of the OTC App.
Network join
When activated, CMi4130 will attempt to join the LoRaWAN network. The phase is indicated by short
flash on red light, then green and red LED lights up for 1 second, followed by short flashes on the green
LED until the module has joined the LoRaWAN network. When CMi4130 succeeds in joining the
LoRaWAN network, the green LED will light up for 8 seconds, as illustrated by Fel! Hittar inte r
eferenskälla.Figure 1.
Figure 1: Network join LED indication
If the module fails to join the LoRaWAN network, it will perform retries until it succeeds. The time between
each attempt will increase for every attempt until it is performed once every day. A new join attempt cycle
can be manually started anytime by using the push button to reboot the module or by deactivating and
activating the module using the Elvaco OTC App.
When the module has joined the LoRaWAN network, it will perform three quick transmissions (regardless
of transmit interval settings) before starting to use its configured transmit interval settings. By using the
Elvaco OTC App, you can easily verify that the module is successfully communicating with the meter
(“Meter communication”) and is connected to the LoRaWAN network (“Network joined”).
Soft start
In rare cases, if the battery is weak, the module will perform a soft start to be able to start-up despite the
condition of the battery. The soft start takes 10 minutes to complete. The red LED will blink shortly every
10th second until the start-up has completed.
Figure 2: Soft start LED indication

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 9 (25)
[2020-06]
V1.1
5.3.5 Switch off/reboot module
To reboot the module, press and hold the push button (2) for 5-15 seconds. Release the button when the
green LED is lit.
To switch off the module, press and hold the push button (2) for 15-20 seconds. Release the button when
the red LED is lit.
Figure 3: Reboot/switch off module

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 10 (25)
[2020-06]
V1.1
6 Administration reference
6.1 Purpose
This chapter contains detailed information about configuring options and the different message formats of
CMi4130.
6.2 Security and access control
CMi4130 has a configuration lock feature, which prevents unauthorized access to the module. When
configuration lock has been enabled, a Product Access Key will be needed to access the device. For
more information about security and access control for CMi4130, please refer to the One-touch
commissioning (OTC) documentation, available on the Elvaco website.
6.3 Configuration options
CMi4130 is configured via the Elvaco OTC App. It uses NFC to transfer settings to the module.
Downlink may also be used to for some applications, see section 6.8 Downlink for more information.
Please note that the Elvaco OTC app is only compatible with Android phones with Android
5.0 or later.
Table 2 provides a summary of all parameters and settings in CMi4130.
Field name
(Abbr.)
Description
Default value
Device
access
Locked device &
correct Product
Access Key
or
Open device
Device
access
Locked
device &
no Product
Access
Key
Downlink
Meter ID
Meter identification number of
the meter. Not configurable.
N/A
Readable
Readable
N/A
Power mode
Used to activate/deactivate the
module.
Passive
Readable /
Writeable
Readable
N/A
Message
format
The message format
determines the structure and
payload of the telegram sent
from the module.
0x0F
(Standard)
Readable /
Writeable
Readable
Writeable
EcoMode
When activated, 11+1 years of
battery-life is guaranteed by
adapting the transmit interval of
the module to current signal
conditions.
On
Readable /
Writeable
Readable
Writeable
Transmit
interval
Sets the number of minutes
between each transmission
from the module.
60 min
Readable /
Writeable
Readable
Writeable
Date & Time
Date and time set for the meter.
N/A
Readable
Readable
N/A

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 11 (25)
[2020-06]
V1.1
Set absolute
time
Sets the time of the meter.
N/A
Writeable
N/A
N/A
Set Time
Relative
Adjusts the time of the meter
relative to the current time.
N/A
N/A
N/A
Writeable
Set UTC
offset
Sets the UTC offset of the
meter.
N/A
Readable /
Writeable
Readable
Writeable
Configuration
Lock
Locks the module to prevent
unauthorized access.
Open
Readable /
Writeable
Readable
Writeable
LoRaWAN settings
Device EUI
Unique module identification
number. Not configurable.
Device-unique
64-bit number
Readable
Readable
N/A
Activation
type
Sets the way the device joins
the LoRaWAN network.
OTAA
Readable /
Writeable
Readable
N/A
Network join
Displays whether the module
has joined the LoRaWAN
network or not.
N/A
Readable
Readable
N/A
Join EUI
Application ID that determines
where data ends up.
0x 94 19 3A 03 09
00 00 01 (internal
antenna version)
0x 94 19 3A 03 0A
00 00 01 (external
antenna version)
Readable /
Writeable
Readable
N/A
Device
address
32-bit address used by the
module to identify itself on the
LoRaWAN network.
0x 00 00 00 00
Readable /
Writeable
N/A
N/A
Current data
rate
The current data rate used for
the module.
N/A
Readable
Readable
N/A
Table 2: Configuration options
6.4 Time handling
The module relies on the meter’s clock for keeping time. Time in the meter is assumed to be in standard
local time (no DST). When synchronizing time in the meter using the OTC App, local standard time is
always used, even if DST is in effect. The timestamped meter data sent from the module can be adjusted
to be sent in UTC by specifying the “UTC offset” configuration parameter. The UTC offset will be
subtracted from the timestamp prior to transmission. If the meter is in Sweden, which uses CET (Central
European Time), it should have UTC offset set to +60 (+1h). In this case at time 12.00 a telegram is sent
with timestamp 11.00 as this is the corresponding UTC time. A meter in New York (USA) should have a
UTC offset of -300 (-5h) etc. A UTC offset of 0 means the meter time is used as-is.
6.5 Adaptive data rate (ADR)
CMi4140 uses Adaptive Data Rate (ADR), part of the LoRaWAN standard, where the network server
determines the optimal rate of communication for the module based on current signal conditions. In best
case, the module will use its highest data rate (DR5) in order to be as energy efficient as possible. When

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 12 (25)
[2020-06]
V1.1
signal conditions are poor, the network server will incrementally lower the data rate until it is able to
receive the message. When the data rate is low, the energy consumption per telegram will increase.
6.6 Transmit interval
The transmit interval is used to set how frequently the module should transmit data on the LoRaWAN
network. The parameter can be set to a value between 5 and 1440 (i.e. between 5-minute and daily
values.)
6.6.1 EcoMode
When EcoMode is active, a battery-lifetime of at least 11+1 years is guaranteed for the module. The
module is able to achieve this by using a table of allowed transmit intervals settings for each data rate.
When radio conditions are poor (and data rate is low), the module will be able to send data less
frequently in order to conserve battery-life. When signal conditions are good, the module will be able to
send data more frequently. When EcoMode is enabled, the module will continuously check if the set
transmit interval is “allowed” by the EcoMode table. If a longer transmit interval is needed for the specific
data rate in order to achieve 11 years of battery life, the module will adjust the parameter accordingly.
Table 3 shows the transmit intervals that the module will use for different data rates in order to achieve a
11-year battery-life.
Data rate
Transmit interval
DR0
240 min
DR1
120 min
DR2
60 min
DR3
60 min
DR4-DR5
30 min
Table 3: Transmit intervals for different data rates in EcoMode
.
If EcoMode has been disabled, guarantees about battery-life is no longer valid (even if
EcoMode is activated later).
6.7 Message formats
CMi4130 has six different message formats: Standard, Compact, JSON, Scheduled –Daily redundant,
Scheduled –Extended and Combined heat/cooling. Each message format will be described in detail in
this section.
6.7.1 Message structure
Message formats Standard, Compact, Scheduled –Daily redundant, Scheduled –Extended and
Combined heat/cooling are encoded on M-Bus format (date/time field are encoded on M-Bus format F).
Message format JSON is encoded on JSON format. All messages begin with one byte specifying the
message format used.
All M-Bus encoded messages begin with one byte specifying the message format used. Then follows a
sequence of data information blocks (DIBs), each one containing a data information field (DIF), a value
information field (VIF) and a data field (DATA). The structure of the telegram is illustrated in Figure 4.

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 13 (25)
[2020-06]
V1.1
Figure 4: CMi4130 M-Bus message structure
For message format JSON, the data is presented as ASCII.
Field
Size
Description
Message format
identifier
1 byte
0x0F = Standard
0x10 = Compact
0x11 = JSON
0x12 = Scheduled –Daily redundant
0x13 = Scheduled - Extended
0x14 = Combined heat/cooling
Table 4: CMi4130 message formats
6.7.2 Structure and payload
In this section, a detailed description of the structure and payload for each message format is presented.
Standard
Figure 5 illustrates the structure of message format Standard. For a detailed description of the payload,
see Table 5.
Figure 5: Structure, message format Standard
DIB
Field
Size
Data type
Description
0
Message
format
identifier
1 byte
-
0x0F (Standard)
1
Energy
6 bytes
INT32
Energy consumption (Wh, J)
0403xxxxxxxx = xxxxxxxx Wh
0404xxxxxxxx = xxxxxxxx * 10 Wh
0405xxxxxxxx = xxxxxxxx * 100 Wh
0406xxxxxxxx = xxxxxxxx kWh
040Exxxxxxxx = xxxxxxxx MJ
040Fxxxxxxxx = xxxxxxxx * 10 MJ

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 14 (25)
[2020-06]
V1.1
2
Volume
6 bytes
INT32
Volume (m3)
0413xxxxxxxx = xxxxxxxx * 0.001 m3
0414xxxxxxxx = xxxxxxxx * 0.01 m3
0415xxxxxxxx = xxxxxxxx * 0.1 m3
0416xxxxxxxx = xxxxxxxx m3
0417xxxxxxxx = xxxxxxxx * 10 m3
3
Power
4 bytes
INT16
Power (W)
022Bxxxx = xxxx W
022Cxxxx = xxxx * 10 W
022Dxxxx = xxxx * 100 W
022Exxxx = xxxx kW
022Fxxxx = xxxx * 10 kW
4
Flow
4 bytes
INT16
Flow (m3/h)
023Bxxxx = xxxx * 0.001 m3/h
023Cxxxx = xxxx * 0.01 m3/h
023Dxxxx = xxxx * 0.1 m3/h
023Exxxx = xxxx m3/h
023Fxxxx = xxxx * 10 m3/h
5
Fw temp
4 bytes
INT16
Forward temperature (°C)
0258xxxx = xxxx * 0.001 °C
0259xxxx = xxxx * 0.01 °C
025Axxxx = xxxx * 0.1 °C
025Bxxxx = xxxx °C
6
Rt temp
4 bytes
INT16
Return temperature (°C)
025Cxxxx = xxxx * 0.001 °C
025Dxxxx = xxxx * 0.01 °C
025Exxxx = xxxx * 0.1 °C
025Fxxxx = xxxx °C
7
Meter ID
6 bytes
According to M-Bus
EN13757-3
identification field
Meter ID
0C78xxxxxxxx
8
Alarm
codes
5 bytes
INT16
Error and warning flags
02FD17xxxx
For further information about Alarm
codes please refer to the meter’s manual
Table 5: Payload, message format Standard
Compact
Figure 6 illustrates the structure for message format Compact. For a detailed description of the payload,
see Table 6.
Figure 6: Structure, message format Compact
DIB
Field
Size
Data type
Description

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 15 (25)
[2020-06]
V1.1
0
Message
format
identifier
1 byte
-
0x10 (= Compact)
1
Energy
6 bytes
INT32
Energy consumption (Wh, J)
0403xxxxxxxx = xxxxxxxx Wh
0404xxxxxxxx = xxxxxxxx * 10 Wh
0405xxxxxxxx = xxxxxxxx * 100 Wh
0406xxxxxxxx = xxxxxxxx kWh
0407xxxxxxxx = xxxxxxxx * 10 kWh
040Exxxxxxxx = xxxxxxxx MJ
040Fxxxxxxxx = xxxxxxxx * 10 MJ
2
Meter ID
6 bytes
According to M-Bus
EN13757-3 identification field
Meter ID
0C78xxxxxxxx
3
Alarm
codes
5 bytes
INT16
Alarm codes
02FD17xxxx
For further information about Alarm
codes please refer to the meter’s manual
Table 6: Payload, message format Compact
JSON
For message format JSON, the data is presented in a plain text format. Table 7 provides a description of
all fields included in the telegram.
Field
Description
Message format
identifier
11 (Message format JSON)
Energy
Energy consumption
Unit
Unit of energy consumption (Wh, kWh, MWh,
GWh, J, kJ, MJ or GJ)
Meter ID
Identification number of the meter in which the
module is mounted.
Table 7: Fields, message format JSON
An example of a telegram for message format JSON is presented below:
Figure 7: JSON message example
Scheduled mode
For message formats of type “Scheduled” (Scheduled –Daily redundant and Scheduled –Extended), two
types of messages will be transmitted from the module - a clock message and a data message. The
difference between the two is described in Table 8. A detailed description of the payload of the clock
message is provided in Table 9.
Message
Time interval
Description
Clock
message
Once per day
The clock message presents the current time of the
meter. It can be used to verify that the clock is
correct and has not drifted more than accepted.
Data message
Determined by Transmit
interval parameter.
The actual meter data collected from the meter. For
more information, see Table 11 and Table 12.
{"E":12345678,"U":"kWh","ID":87654321}

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 16 (25)
[2020-06]
V1.1
Table 8: Clock message and data message
DIB
Field
Size
Data type
Description
0
Message
format
identifier
1 byte
-
0xFA (=Clock message)
1
Date/time
6 bytes
32 bit binary integer
M-Bus type F
046Dxxxxxx = Valid date/time message
346Dxxxxxx = Invalid date/time message
Table 9: Payload, clock message
The clock message will be transmitted once every day and the data message at least (regulated by
transmit interval parameter or EcoMode) once every day. The transmit interval can only be set the values
listed in Table 10.
Note that although the meter readout will occur on top-of-the-hour, the data message will not necessarily
be transmitted at that exact time. The LoRa transmission will occur after a random delay of 0-15 minutes
to decrease the risk of collisions. The readout for the clock message occurs at a random hour (00:00-
23:00) at a random minute in the 35-45 interval and will be transmitted immediately after the readout.
When using message format Scheduled, the transmit interval cannot not be set to higher
than 1440 minutes.
Parameter
Values
Unit
Transmit interval
60, 120, 180, 240, 360, 480, 720, 1440
Minutes
Table 10: Transmit interval options for Scheduled message formats.
Scheduled- daily redundant
The data message of Scheduled mode-daily redundant contains an accumulated daily energy field, which
is updated at 24:00 each day. In other words, depending on transmit interval settings and data rate, the
field will be included in between 1-24 telegrams per day. This will increase the probability of the value
being received. For example, if the transmit interval is set to “2”, the accumulated energy read at 24:00
will be transmitted 12 times during the 24 next coming hours (every 2nd hour).
Figure 8: Structure, message format Scheduled –daily redundant
DIB
Field
Size
Data type
Description
0
Message
format
identifier
1 byte
-
0x12 (Scheduled –daily redundant)
1
Energy
6 bytes
INT32
Energy consumption (Wh, J)
0403xxxxxxxx = xxxxxxxx Wh
0404xxxxxxxx = xxxxxxxx * 10 Wh
0405xxxxxxxx = xxxxxxxx * 100 Wh
0406xxxxxxxx = xxxxxxxx kWh
0407xxxxxxxx = xxxxxxxx * 10 kWh
040Exxxxxxxx = xxxxxxxx MJ
040Fxxxxxxxx = xxxxxxxx * 10 MJ

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 17 (25)
[2020-06]
V1.1
2
Volume
6 bytes
INT32
Volume (m3)
0413xxxxxxxx = xxxxxxxx * 0.001 m3
0414xxxxxxxx = xxxxxxxx * 0.01 m3
0415xxxxxxxx = xxxxxxxx * 0.1 m3
0416xxxxxxxx = xxxxxxxx m3
0417xxxxxxxx = xxxxxxxx * 10 m3
3
Meter ID
6 bytes
According to M-
Bus EN13757-3
identification field
Meter ID
0C78xxxxxxxx
4
Alarm codes
5 bytes
INT16
Error and warning flags
02FD17xxxx
For further information about Alarm
codes please refer to the meter’s manual
5
Meter
date/time
6 bytes
INT32
Meter date and time (YY-MM-DD HH:MM)
046Dxxxxxxxx
Bit 31-28 = Year-high*
Bit 27-24 = Month
Bit 23-21 = Year-low*
Bit 20-16 = Day
Bit 15 = Summertime flag**
Bit 14-13 = Century
Bit 12-8 = Hour
Bit 7 = Error flag
Bit 6 = Reserved for future use***
Bit 5-0 = Minute
*The year is read by combining the year-high
and year-low field. For example, year-high =
0010 and year-low = 010 => year = 0010010
**0 = standard time, 1= daylight-saving time
***0 = timestamp is valid, 1 = timestamp is not
valid
6
Accumulated
energy at
24:00
6
Bytes
INT32
Energy consumption (Wh, J)
0403xxxxxxxx = xxxxxxxx Wh
0404xxxxxxxx = xxxxxxxx * 10 Wh
0405xxxxxxxx = xxxxxxxx * 100 Wh
0406xxxxxxxx = xxxxxxxx kWh
0407xxxxxxxx = xxxxxxxx * 10 kWh
040Exxxxxxxx = xxxxxxxx MJ
040Fxxxxxxxx = xxxxxxxx * 10 MJ
Note: Before a midnight reading has been
performed the Function field of the DIF is set
to “value during error state” to indicate that the
value is not valid.
Table 11: Payload, message format Scheduled –daily redundant
Scheduled- Extended
The data message of Scheduled mode-Extended contains all the data fields from message format
Standard. In addition to these, it also includes the meter date/time to transmit messages on the full hour.

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 18 (25)
[2020-06]
V1.1
As for all Scheduled message formats, the transmit interval can only be set to the values included in
Table 10.
A detailed description of the payload in the message format is presented in Table 12.
DIB
Field
Size
Data type
Description
0
Message
format
1 byte
-
0x13 (Scheduled –Extended)
1
Energy
6 bytes
INT32
Energy consumption (Wh, J)
0403xxxxxxxx = xxxxxxxx Wh
0404xxxxxxxx = xxxxxxxx * 10 Wh
0405xxxxxxxx = xxxxxxxx * 100 Wh
0406xxxxxxxx = xxxxxxxx kWh
0407xxxxxxxx = xxxxxxxx * 10 kWh
040Exxxxxxxx = xxxxxxxx MJ
040Fxxxxxxxx = xxxxxxxx * 10 MJ
2
Volume
6 bytes
INT32
Volume (m3)
0413xxxxxxxx = xxxxxxxx * 0.001 m3
0414xxxxxxxx = xxxxxxxx * 0.01 m3
0415xxxxxxxx = xxxxxxxx * 0.1 m3
0416xxxxxxxx = xxxxxxxx m3
0417xxxxxxxx = xxxxxxxx * 10 m3
3
Power / Flow
/ Fw temp /
Rt temp
12 bytes
INT64
Byte 0-2 = DIF/VIF codes, 0x07FFA0
Byte 3 = Scaling of Power/Flow
- Bit 6..4 (n), 10n-3 W, n = 0..7
- Bit 2..0 (m), 10m-6 litres/h, m = 0..7
Byte 4-5 = Fw temp (lsByte -> msByte), °C, 2
decimals
Byte 6-7 = Rt temp (lsByte -> msByte), °C, 2
decimals
Byte 8-9 = Flow (lsByte -> msByte), 10m-3 m3/h
Byte 10-11 = Power (lsByte -> msByte), 10n-3 W
4
Meter ID/
Alarm codes
9 bytes
INT48
Byte 0-2 = DIF/VIF codes, 0x06FF21
Byte 3-4 = Alarm codes (lsByte -> msByte)
Byte 5-8 = Meter ID (lsByte -> msByte)

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 19 (25)
[2020-06]
V1.1
5
Meter
date/time
6 bytes
INT32
Meter date and time (YY-MM-DD HH:MM)
046Dxxxxxxxx
Bit 31-28 = Year-high*
Bit 27-24 = Month
Bit 23-21 = Year-low*
Bit 20-16 = Day
Bit 15 = Summertime flag**
Bit 14-13 = Century
Bit 12-8 = Hour
Bit 7 = Error flag
Bit 6 = Reserved for future use***
Bit 5-0 = Minute
*The year is read by combining the year-high and
year-low field. For example, year-high = 0010 and
year-low = 010 => year = 0010010
**0 = standard time, 1= daylight-saving time
***0 = timestamp is valid, 1 = timestamp is not
valid
Table 12: Payload, message format Scheduled-Extended
Combined heat/cooling
Message format Combined heat/cooling is developed to be used in meters that measures both heating
and cooling energy.
Message format Combined heat/cooling is only meant to be used in combined heat/cooling
meters.
DIB
Field
Size
Data type
Description
0
Message
format
1 byte
-
0x14 (=Combined heat/cooling)
1
Heat
energy
6 bytes
INT32
Energy consumption (Wh, J)
0403xxxxxxxx = xxxxxxxx Wh
0404xxxxxxxx = xxxxxxxx * 10 Wh
0405xxxxxxxx = xxxxxxxx * 100 Wh
0406xxxxxxxx = xxxxxxxx kWh
0407xxxxxxxx = xxxxxxxx * 10 kWh
040Exxxxxxxx = xxxxxxxx MJ
040Fxxxxxxxx = xxxxxxxx * 10 MJ
2
Cooling
energy
8 bytes
INT32
Cooling energy consumption (Wh, J)
0483FF02xxxxxxxx = xxxxxxxx Wh
0484FF02xxxxxxxx = xxxxxxxx * 10 Wh
0485FF02xxxxxxxx = xxxxxxxx * 100 Wh
0486FF02xxxxxxxx = xxxxxxxx kWh
0487FF02xxxxxxxx = xxxxxxxx * 10 kWh
048EFF02xxxxxxxx = xxxxxxxx MJ
048FFF02xxxxxxxx = xxxxxxxx * 10 MJ
3
Volume
6 bytes
INT16
Volume (m3)

CMi4130 User’s Manual English
CMi4130 User’s Manual English
page | 20 (25)
[2020-06]
V1.1
0413xxxxxxxx = xxxxxxxx * 0.001 m3
0414xxxxxxxx = xxxxxxxx * 0.01 m3
0415xxxxxxxx = xxxxxxxx * 0.1 m3
0416xxxxxxxx = xxxxxxxx m3
0417xxxxxxxx = xxxxxxxx * 10 m3
4
Fw temp
4 bytes
INT16
Forward temperature (°C)
0258xxxx = xxxx * 0.001 °C
0259xxxx = xxxx * 0.01 °C
025Axxxx = xxxx * 0.1 °C
025Bxxxx = xxxx °C
5
Rt temp
4 bytes
INT16
Return temperature (°C)
025Cxxxx = xxxx * 0.001 °C
025Dxxxx = xxxx * 0.01 °C
025Exxxx = xxxx * 0.1 °C
025Fxxxx = xxxx °C
6
Meter ID
6 bytes
According to M-Bus
EN13757-3
identification field
Meter ID
0C78xxxxxxxx
7
Alarm
codes
5 bytes
INT16
Error and warning flags
02FD17xxxx
For further information about Alarm
codes please refer to the meter’s manual
Table 13: Payload, message format Combined heat/cooling
6.7.3 Meter communication error message
The payloads using M-Bus encoded data uses the Function field of the DIF to indicate errors. In this case
it is set to “value during error state” (M-Bus standard EN 13757-3:2013) and the value sent should not be
used. A typical case for this is when the module is unable to communicate with the meter and retrieve
meter values, in which case all the fields in the payload have the DIF indicating “value during error state”.
In case of erroneous data or if the module is unable to communicate with meter, bit 4-5 of the bit of the
DIF code (first byte of each index field) will be set to 11b. For example, a DIF code of 0x02 will be set to
0x32 in case of error. (This applies to all message format except JSON.) For message format JSON, the
actual value will be replaced with “null” in case of error state. If no meter communication is possible at all,
all fields have this error indication set.
6.8 Downlink
CMi4130 supports configuration via downlink, i.e. sending commands to an end-device via the LoRaWAN
network. Note that this feature should only be used sparingly due to bandwidth consideration.
Communication via downlink is sent on port 2 and can only be made in a short window after an uplink
transmission from module to server. Therefore, time-critical communication should not be performed over
downlink.
Downlink commands are structured according to the following format: “0x00” "TLV" "Number of bytes in
configuration" "Configuration". For a complete description of all available downlink commands, see Table
14.
Field name
TLV
Number of
bytes in
configuration
Configuration
Example
