P2 PRODUCT INTRODUCTION
WARNING
1. PRODUCT INTRODUCTION
Emaux FLEX Valve Actuator is a universal actuator which can work with most major manufactures’
automatic controls and valves, operating on 2-way and 3-way valves. Adjustable cams give high
flexibility for accurate position. Slim design with corrosion-proof casing, When paired for use with new
Emaux 2-way and 3-way the user with reliable automation over valve control.valves ,it provides
2. SPECIFICATIONS
2.1 Dimension
Code
Model
Material
Voltage
Cycles
Wire
Cable Length
91609013
FLEX ACT-
PC
24V AC
50 60 Hz/
3 conductor
Black Common
Red Switch Leg
White Switch Leg
-
()
()
()
6m (18ft)

P3 INSTALLATION & OPERATION
3. INSTALLATION & OPERATION
There are 4 different positions for mounting the Valve Actuator to the . The cam settings
may have to be changed depending on the location of the inlet port (the port where water enters).
3-way valve
The Arrows are showing which screws required to change to long screws.
NOTE:
Port1
Port2
Port3
Port3
Port3
Port3
Port2
Port2
Port2
Port1
Port1
Port1
(Standard)
AB
CD
4 different positions of mounting the Valve Actuator to the .3-way valve
Fig. 1

P4 BASIC CAM SETTING
3.1 Basic cam setting
Test your Actuator
a. Default
b. If you need to make adjustment
Both upper and lower CAM are
pointing to the “12 o’clock”
Connect your actuator to control system
Use manual mode to test arrow position
Refer to 3.3 and 3.4 to adjust.
Fig. 2
(3-way valve)
Use the chart to determine the correct basic cam setting by
using standard clock positions. The below shows the cam
settings for 3-way valves.
chart
Mounting
option
Inlet
(Water enters port)
Basic Cam Setting
Port Where Water Exits
UPPER CAM
LOWER CAM
Port
Port
A
(standard)
1
9 o'clock
6 o'clock
2
3
2
(standard)
12 o'clock
12 o'clock
1
3
3
6 o'clock
3 o'clock
1
2
B
1
12 o'clock
9 o'clock
2
3
2
3 o'clock
3 o'clock
1
3
3
9 o'clock
6 o'clock
1
2
C
1
6 o'clock
3 o'clock
2
3
2
9 o'clock
9 o'clock
1
3
3
3 o'clock
12 o'clock
1
2
D
1
3 o'clock
12 o'clock
2
3
2
6 o'clock
6 o'clock
1
3
3
12 o'clock
9 o'clock
1
2
(2-way valve)
For the actuators mounted on 2-way valves. the cam settings are the same . The shows
the cam settings for 2-way valves.
in all cases chart
Basic Cam Setting
UPPER CAM
LOWER CAM
3 o’clock
6 o’clock

P5 MOUNTING INSTRUCTIONS
3.2 Mounting Instructions
1. Remove the knob and handle from the valve
2. Refer to to determine which four screws
to remove.
3. Place the valve handle on the actuator shaft
and tighten the knob.
4. Align the smallest tooth on the actuator shaft
with the smallest slot on the valve diverter.
5. With the two shafts engaged, rotate the
actuator until the holes on the actuator align
with the screw holes on the cover.
6. Using the 4 long screws (M6x55) provided to
secure it in place. .
Fig.1
Do not over-tighten
Procedure:
smallest tooth
smallest slot
Fig. 3
smallest tooth smallest slot
Actuator Shaft Valve Diverter
Factory default is matched with standard
mount. If the valve is connected in a standard
installation, there is no need to perform a cam
adjustment.
Note:
3.3 Toggle Switch
ON1 - Diverter rotate clockwise
OFF - Stop
ON2 - Diverter rotate - clockwise
counter ON 1
OFF
ON 2
3.4 Advanced Cam Setting
1. Move the toggle switch to OFF (Centre) position.
2. Remove the knob and the handle from the actuator shaft.
3. Remove four screws on the actuator and open the cover.
4. The cams are located under the cover bushing and on the actuator shaft. Slide the cams off the shaft
splines and rotate them to the desired position. Refer to the chart in Basic Cam Settings for determining
the position of the cam.
Fig. 4

P6 SYNCHRONIZATION
5. For advanced cam settings, the design of the shaft has
been divided into 28 directions to customize water flow for
your installation. Each of them is around 13 degrees from the
other. Users may select partial open, semi-open, partial close,
etc.). These settings are not listed in the chart. The 12 o’clock
(small slot) is always the reference of every setting (Fig. 2).
The upper cam affects the clockwise position stop point. The
lower cam affects the counter-clockwise rotation stop point.
6. The toggle switch on the bottom of the valve actuator can
be used to verify if the new adjustment is correct (switch
between ON1 and ON2).
7. Replace cover and handle and tighten screws and the
locking knob.
8. Put toggle switch back to ON1 or ON2 position.the
Fig. 5
Advanced cam setting should be performed by pool technician.
Note:
3.5 Synchronization
A typical pool with a spa might have 3-6 diverter valves to control the flow of water through the pool
and spa. If one is rotating in the opposite direction to the other, the actuators have to be adjusted to
bring them into Sync. Simply flip the toggle switch of the Actuator between ON1 and ON2.
3.6 Manual Override (MO)
Turn power OFF to all filtration pumps before doing this action, to minimize the
possibility of any injury or damage.
CAUTION
1. Turn the toggle switch to the OFF position.
2. Unscrew anti clockwise the knob for 1 turn approximately.
3. Push down the handle and knob. This will disengage the gear train and allow the handle, thus the
diverter, to move to any position.
4. Make sure to turn the actuator to the automatic position after manual override. Turn clockwise or
counter clockwise slightly until you feel the shaft slide up into the gear train. Then, turn the knob
clockwise to lock the handle.
5. Tighten the knob.
6. Flip toggle switch back to the original position.
The valve position may have to be adjusted manually when necessary. This happens when the controller
is not accessible or following a power failure. Follow the instructions below.

4. MAINTENANCE
P7 MAINTENANCE
The FLEX Valve Actuator has 2 seals which require lubrication once a year. These seals are located at the
top and bottom of the actuator, where the shaft exits the actuator housing. Please follow the steps to
lubricate those seals:
Lubricate
1. Turn the actuator power OFF.
2. Remove the knob and the handle.
3. Spread a small amount of silicone base lubricant around the
actuator shaft where it enters the cover (See Fig. 6).
4. Reinstall the handle and knob, do not over-tighten.
5. Push down on the knob and handle to force the actuator
into manual override.
6. Spread a small amount of lubricant around the actuator shaft
where it protrudes from the bottom of the actuator.
7. Turn the handle once around to spread the lubricant.
8. Pull up on the handle and let it click into place.
9. Tighten the knob.
Fig. 6
To avoid electric shock which can result in property damage, severe injury or
death, disconnect power to the system at the main circuit breaker before
servicing.
To minimize the risk of injury and avoid damage to the equipment, use a properly
sized, listed Class 2 transformer for connection to the power supply.
WARNING
Relay1: Voltage connect control
Relay2: Turn control
White
Red
RELAY1 RELAY2
5. WIRING DIAGRAMS

P8 MAINTENANCE
The internal circuit of the actuator is based on a motor that turns the valve, 2 limit switches, to know the
2 stop positions, a capacitor, for possible peaks in the line, and a switch controlling the tension of the
red wire (turn one way) or white wire (turn the other way).
In the following image, you can see how the connection of the 2 actuators would be. For each
connected actuator, the amperage will rise by about 1A and the fuse will have to be modified.
WhiteWhite

P9 TROUBLESHOOTING
6. TROUBLESHOOTING
Problem
Cause
Solution
The actuator handle
oscillates.
Lack of valve seal lubrication.
Obstruction in the valve body
Lubricate valve. See the
“Maintenance” section.
The actuator motor works but
the valve diverter does not
turn.
The actuator shaft has
broken.
Replace the actuator shaft.
Actuator in manual position.
Pull up on the handle while
rotating.
The gear train was damaged.
Replace gear or shaft.
The actuator motor does not
turn.
No power to the actuator.
Check voltage between black
(common) wire and each
switch leg (red, white)
Toggle switch in the OFF
position.
Flip toggle switch to ON 1 or
ON 2 positions.
The motor has failed.
Replace motor.
Failed or broken microswitch.
Replace microswitch.
Both cams are in contact with
their microswitches.
Check the cam setting
section.
The actuator rotates in one
direction but not back again.
Broken or damaged
microswitch.
Replace microswitch.
Bad connection(s).
Check all connections.
Bad control relay switch.
At the power source check
the operation of the control
relay or switch.
Broken wire.
Check red and white wires.
Water inside the valve
actuator
Damaged seals.
Replace seals.

P10 SPARE PART LIST
7. SPARE PART LIST
Key No.
Part No.
Description
Qty
1
112010166
M5 x 15 Screw
4
2
57200003
Housing Cover
1
3
111000053
Cover O ring-
1
4
57200005
Lock Plate
1
5
E042810
M35x7Screw.
1
6
57200006
Cover Bushing
1
7
57200007
Cam
2
8
111040083
Gasket
1
9
E042811
Motor Synchronous
with M4 x 8 screws
and washers
( [2]
[2])
1
10
E042812
Micro Switch Assembly
(With M2.3 x 10 screw)
1
11
57200008
Switch Nest
2
12
E042813
Circuit Board with M4
x 12 screws
(
)
1
13
03011364
M4 x 12 Screw
5
14
57200001
Plate
1
15
57200009
Shaft
1
16
E042814
Pivot 3()
1
17
E042815
Gear Set 4()
1
18
57200002
Spacer
1
19
112010168
M6 x 52 Screw
4
20
57200004
Housing
1
21
106234778
Cable module
1
22
112060025
Spring
1
1
2
3
5
7
8
9
10
11
12
13
14
15
16
17
21
19
20
22
4
6

P11 TERMS OF THE WARRANTY
8. TERMS OF THE WARRANTY
As original purchaser of this equipment have purchased from Emaux Water Technology Co Ltd, through
Authorized International Distributor or Dealer, warrants its products free from defects in materials and
workmanship under normal use during warranty period. The warranty period begins on the day of
purchase and extends only to the original purchaser. It is not transferable to anyone who subsequently
purchases the product from you. It excludes all expendable parts.
During the warranty period, Emaux authorized reseller will repair or replace defective parts with new
parts or, at the option of Emaux, serviceable used parts that are equivalent or superior to new parts in
performance.
This Limited Warranty extends only to products purchased from Emaux authorized reseller. This Limited
Warranty does not extend to any product that has been damaged or rendered defective
(a) as a result of accident, misuse or abuse;
(b) as a result of an act of God;
(c) by operation outside the usage parameters stated herein;
(d) by the use of parts not manufactured or sold by Emaux;
(e) by modification of the product;
(f) as a result of war or terrorist attack; or
(g) as a result of service by anyone other than Emaux authorized reseller or authorized agent.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, EMAUX MAKES NO OTHER WARRANTIES
EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. EMAUX EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS
LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE
TERMS OF THIS EXPRESS LIMITED WARRANTY.

YOUR PREMIER SUPPLIER
EMAUX WATER TECHNOLOGY CO., LTD
www.emauxgroup.com
