Johnson Controls TEC-2647-4 User manual

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
1
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two
Outputs Installation Instructions
Applications
The TEC26x7-4 Series Thermostat Controllers are
BACnet® Master-Slave/Token-Passing (MS/TP)
networked devices that provide control of local
hydronic reheat valves, pressure dependent Variable
Air Volume (VAV) equipment with or without local
reheat, or other zoning equipment using an on/off,
floating, or proportional 0 to 10 VDC control input. The
technologically advanced TEC26x7-4 Series
Thermostat Controllers feature a Building Automation
System (BAS) BACnet MS/TP communication
capability that enables remote monitoring and
programming for efficient space temperature control.
The TEC26x7-4 Series Thermostat Controllers feature
an intuitive user interface with backlit display that
makes setup and operation quick and easy. The
thermostat controllers also employ a unique,
Proportional-Integral (PI) time-proportioning algorithm
that virtually eliminates temperature offset associated
with traditional, differential-based thermostat
controllers.
North American Emissions Compliance
United States
Canada
Installation
Location Considerations
Locate the TEC26x7-4 Series Thermostat Controller:
• on a partitioning wall, approximately 5 ft (1.5 m)
above the floor in a location of average
temperature
• away from direct sunlight, radiant heat, outside
walls, behind doors, air discharge grills, stairwells,
or outside doors
• away from steam or water pipes, warm air stacks,
unconditioned areas (not heated or cooled), or
sources of electrical interference
Note: Allow for vertical air circulation to the
TEC26x7-4 Series Thermostat Controller.
IMPORTANT: The TEC26x7-4 Series Thermostat
Controllers are intended to provide an input to
equipment under normal operating conditions.
Where failure or malfunction of the thermostat
controller could lead to personal injury or property
damage to the controlled equipment or other
property, additional precautions must be designed
into the control system. Incorporate and maintain
other devices, such as supervisory or alarm systems
or safety or limit controls, intended to warn of or
protect against failure or malfunction of the
thermostat controller.
This equipment has been tested and found to
comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when this equipment is
operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference, in which case
the user will be required to correct the interference
at his/her own expense.
This Class (A) digital apparatus meets all the
requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la Classe (A) respecte
toutes les exigences du Règlement sur le matériel
brouilleur du Canada.

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
2
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
To install the thermostat controller:
1. Use a Phillips-head screwdriver to remove the
security screw if it is installed on the bottom of the
thermostat controller cover.
Note: Normally, the security screw is packaged
separately in a plastic bag with the thermostat
controller. Skip this step if the screw is not installed
on the bottom of the cover.
2. Pull the bottom edge of the thermostat controller
cover and open the thermostat controller as
illustrated in Figure 1.
3. Carefully pull the locking tabs on the right side of
the thermostat controller mounting base and
unlock the Printed Circuit Board (PCB). Open the
PCB to the left as illustrated in Figure 2.
4. Pull approximately 6 in. (152 mm) of wire from the
wall and insert the wire through the hole in the
thermostat controller mounting base.
5. Align the thermostat controller mounting base on
the wall and use the base as a template to mark
the two mounting hole locations.
6. Position the thermostat mounting base so that the
arrow on the base points upward to indicate the top
of the thermostat.
Note: If you need to install the thermostat on an
electrical junction box, use 2-1/2 x 4 in.
(63 x 101 mm) square boxes with mud ring covers,
and avoid smaller 1-1/2 x 4 in. (38 x 101 mm)
square or 3 x 2 in. (76 x 51 mm) boxes. This
procedure ensures you have enough space for
cabling and end-of-line devices, if needed.
Note: For surface-mount applications, use
durable mounting hardware such as Molly bolt
anchors that cannot be easily pulled out of the
mounting surface.
7. Secure the base to the wall surface using two
mounting screws as illustrated in Figure 3.
Note: Be careful not to overtighten the mounting
screws.
8. Swing the PCB back to the right and carefully snap
it into the locking tabs on the thermostat controller
mounting base.
9. Remove the screw terminal blocks that are
attached to a disposable adhesive. Figure 4
illustrates the locations of the screw terminal
blocks on the thermostat controller.
Figure 1: Removing the Thermostat
Controller Cover
FIG:cvr_rmvl
Figure 2: Opening the Thermostat Controller PCB
FIG:prcrctbrd
PCB
Locking
Ta b s
Figure 3: Securing the Thermostat Controller
Mounting Base to the Wall
FIG:mntbs

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
3
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Wiring
When an existing thermostat controller is replaced,
remove and label the wires to identify the terminal
functions. When a TEC26x7-4 Series Thermostat
Controller is replaced, simply remove the old screw
terminal blocks and reinsert them onto the PCB of the
replacement thermostat controller.
To wire the thermostat controller:
1. Strip the ends of each wire 1/4 in. (6 mm) and
connect them to the appropriate screw terminals as
indicated in Table 1 and Figure 5 through
Figure 18.
Note: For more details on wiring the MS/TP
Communications Bus, refer to the MS/TP
Communications Bus Technical Bulletin
(LIT-12011034).
2. Carefully push any excess wire back into the wall.
Note: Seal the hole in the wall with fireproof
material to prevent drafts from affecting the
ambient temperature readings.
3. Reinsert the screw terminal blocks onto the PCB.
4. Reattach the MS/TP communication wires to the
terminal block.
Note: If multiple wires are inserted into the
terminals, be sure to properly twist the wires
together prior to inserting them into the terminal
connectors.
5. Reattach the thermostat controller cover to the
mounting base (top side first).
6. Use a Phillips-head screwdriver to reinstall the
security screw on the bottom of the thermostat
controller cover.
IMPORTANT: Because some of the objects may
not directly correlate to a previous version, you must
rediscover all point objects for the TEC26x7-4
version. For detailed information on this mapping,
refer to the TEC BACnet® MS/TP Network Series
Thermostat Controllers Technical Bulletin
(LIT-12011592).
!
CAUTION: Risk of Electric Shock.
Disconnect the power supply before
making electrical connections to avoid
electric shock.
Figure 4: Removing the Screw Terminal Blocks
FIG:trmnl_blcks
!
CAUTION: Risk of Property Damage.
Do not apply power to the system before
checking all wiring connections. Short
circuited or improperly connected wires
may result in permanent damage to the
equipment.
IMPORTANT: Make all wiring connections in
accordance with local, national, and regional
regulations. Do not exceed the electrical ratings of
the TEC26x7-4 Series Thermostat Controller.

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
4
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
4
Table 1: Terminal Identification (See Figure 5.)
Terminal
Number
Terminal Label Function
TEC2627-4
(On/Off or
Floating Control)
TEC2647-4
(Proportional
0 to 10 VDC Control)
4 24 V~ Hot 24 V~ Hot 24 VAC from Transformer
5 24 V~ Com 24 V~ Com 24 VAC (Common) from Transformer
6 BO5 Aux BO5 Aux Aux BO (Auxiliary Output)
7 BO5 Aux BO5 Aux Aux BO (Auxiliary Output)
8 BO3 Blank Open Heat
9 BO4 AO2 Close Heat
10 BO1 AO1 Open Cool
11 BO2 Blank Close Cool
12 BI1 BI1 Configurable Binary Input 1
13 RS RS Remote Sensor
14 Scom Scom Sensor Common
15 BI2 BI2 Configurable Binary Input 2
16 UI3 UI3 Configurable Universal Input 3
Blank +, –, REF +, –, REF MS/TP Bus

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
5
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
5
Figure 5: Wiring the TEC26x7-4 Series Thermostat Controller (See Table 1.)
FIG:wrng_26x7
–
+REF
Supervisory
Controller
BI2 UI3
BI1
Scom
- OR -
Remote Inputs
Supply Sensor
Changeover Sensor
Voltage-Free
Contact
• COC/NH
Normally Heat
Closed Contact
= Cold Water
• COC/NC
Normally Cool
Closed Contact
= Hot Water
Voltage-Free
Contact
• Door
• Remote
Override
• Filter Alarm
• Service Alarm
Voltage-Free
Contact
• Remote NSB
• Motion
• Window
Three-Pole
Right Top
Connector
9 10 11 12 13 14 15 16
REF
–
+
BO2
BO5
Aux
BO5
Aux
Scom
BO1/
AO1
UI3
BI1 BI2
BO3
Two-Pole
Left Top
Connector
24 V~
Hot
24 V~
Com
BO4/
AO2
RS
Same 24 VAC
Power Source for Auxiliary Output
(24 VAC Maximum)
Separate 24 VAC
Power Source for Auxiliary Output
(24 VAC Maximum)
BO5
Aux
BO5
Aux
24 VAC
Thermostat Power
24 V~
Com
24 V~
Hot
BO5
Aux
BO5
Aux
Aux Contact
(Isolated Common)
• Reheat
• Lighting
• On/Off Actuation
• Exhaust Fan
Aux
Aux
24 VAC
Thermostat Power
24 V~
Com
24 V~
Hot
Eight-Pole Bottom Connector
4 5
6 7 8

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
6
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Figure 6: Wiring the TEC2627-4 Thermostat Controller for Floating Control
(Pressure-Dependent VAV Cooling Only)
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Floating
Actuator
UI3 COS
24 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
FIG:tec2627_clng_only
Figure 7: Wiring the TEC2647-4 Thermostat Controller for Proportional 0 to 10 VDC Control
(Pressure-Dependent VAV Cooling Only)
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Proportional
Actuator
FIG:tec2647_clng_only
0 to 10
VDC
UI3 COS
24 V~ Com
24 V~ Hot
AO1
Figure 8: Wiring the TEC2627-4 Thermostat Controller for Floating Control
(Pressure-Dependent VAV Heating/Cooling with Changeover)
FIG:tec2627_htng_cl
ng_chngvr
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Floating
Actuator
Supply Air
Temperature Sensor
UI3 COS
24 V~ Com
24 V~ Hot
BO1 Open
BO2 Close

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
7
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
7
Figure 9: Wiring the TEC2647-4 Thermostat Controller for Proportional 0 to 10 VDC Control
(Pressure-Dependent VAV Heating/Cooling with Changeover)
FIG:tec2647_htng_clng_chngvr
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Proportional
Actuator
Supply Air
Temperature Sensor
0 to 10
VDC
UI3 COS
24 V~ Com
24 V~ Hot
AO1
Figure 10: Wiring the TEC2627-4 Thermostat Controller for Floating Control
(Pressure-Dependent VAV Heating Cooling with Changeover and Reheat)
FIG:tec2627_htng_clng_chngvr
_rht
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Heating/Cooling
and On/Off
Duct Heater
Floating
Actuator
Supply Air
Temperature Sensor
1
C
UI3 COS
24 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
BO5-Aux
BO5-Aux
Figure 11: Wiring the TEC2647-4 Thermostat Controller for Proportional 0 to 10 VDC Control
(Pressure-Dependent VAV Heating/Cooling with Changeover and Reheat)
FIG:tec2647_htng_clng_chngvr_rht
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Heating/Cooling
and On/Off
Duct Heater
Proportional
Actuator
Supply Air
Temperature Sensor
1
C
0 to 10
VDC
UI3 COS
24 V~ Com
24 V~ Hot
AO1
BO5-Aux
BO5-Aux
AO2

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
8
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
8
Figure 12: Wiring the TEC2627-4 Thermostat Controller for Floating Control
(Heating/Cooling Hydronic Valve Control)
FIG:tec2627_htng_clng_hdrn
c
Room Temperature
Control Thermostat
UI3 COS
24 V~ Com
24 V~ Hot
BO1 Open
BO2 Close
Figure 13: Wiring the TEC2647-4 Thermostat Controller for Proportional 0 to 10 VDC Control
(Heating/Cooling Hydronic Valve Control)
FIG:tec2647_htng_clng_hdrnc
Room Temperature
Control Thermostat
0 to 10
VDC
UI3 COS
24 V~ Com
24 V~ Hot
AO1
Figure 14: Wiring the TEC2627-4 Thermostat Controller for Floating Control
(Heating/Cooling Hydronic Valve Control with Changeover)
FIG:tec2627_htng_clng_hdr
nc_chngvr
Floating
Heating/Cooling
Val ve
Optional Water
Supply Sensor
Room Temperature
Control Thermostat Supply Water
Temperature Sensor
UI3 COS
24 V~ Com
24 V~ Hot
BO1 Open
BO2 Close

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
9
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Figure 15: Wiring the TEC2647-4 Thermostat Controller for Proportional 0 to 10 VDC Control
(Heating/Cooling Hydronic Valve Control with Changeover)
FIG:tec2647_htng_clng_hdrnc_chngvr
Proportional
Heating/Cooling
Val ve
Optional Water
Supply Sensor
Room Temperature
Control Thermostat
Supply Water
Temperature Sensor
0 to 10
VDC
UI3 COS
24 V~ Com
24 V~ Hot
AO1
Figure 16: Wiring the TEC2627-4 Thermostat Controller for On/Off Control
Two-Pipe Applications Four-Pipe Applications
TEC2627onoff
24 V~
Com
24 V~
Hot
or
24 V~
Com
24 V~
Hot
Cooling
Val ve
or
Heating
Val ve
or
Figure 17: Wiring the TEC2627-4 Thermostat Controller for Floating Control
Two-Pipe Applications Four-Pipe Applications
TEC2627floating
24 V~
Com
24 V~
Hot
BO1
Cooling
Val ve
Heating
Val ve
BO2 BO3 BO4
24 V~
Com
24 V~
Hot
BO1
Heating/Cooling
Val ve
BO2

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
10
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Connecting the MS/TP Bus
To connect the MS/TP Bus:
1. Set the MS/TP address of the TEC BACnet MS/TP
Network Series Thermostat Controller per the
engineering drawings and test for bus voltage,
polarity, and isolation prior to wiring the MS/TP
Bus. Use the Com addr parameter to set the
MS/TP address for the thermostat controller.
Note: The wiring rules for the MS/TP Bus differ
from the wiring rules for the N2 Bus. For more
details on wiring the MS/TP Communications Bus,
refer to the MS/TP Communications Bus Technical
Bulletin (LIT-12011034).
2. Observe the polarity when connecting the bus
wires to the thermostat controller.
3. After the bus wires are connected to the first
thermostat controller, continue in a daisy-chained
fashion to the next thermostat controller.
Note: The bus wiring must be twisted-pair lines.
Do not run the bus wiring in the same conduit as
line voltage wiring (30 VAC or above) or other
wiring that switches power to highly inductive loads
(such as contactors, coils, motors, or generators).
The MS/TP Bus requires proper termination and
biasing at each end of a segment (a segment is a
physically continuous length of wire). Because the
rooftop controller is not equipped with end-of-line
termination, a Johnson Controls MS-BACEOL-0
End-of-Line Terminator (see Table 5; ordered
separately) or similar device is recommended to
provide this end-of-line termination. An end-of-line
terminator is required if a supervisory controller is not
at the end of the segment. If a supervisory controller is
at the end of the segment, then the end-of-line
terminator switch on the supervisory controller must be
set in the ON position.
The thermostat controller has automatic baud rate
detection. Do not exceed the maximum number of
devices allowed on a field bus. Be sure that the wiring
terminations are set correctly and that all
communication wiring is daisy-chained with no taps.
A small green light under the thermostat controller
cover (on the left edge when facing the thermostat
controller) indicates the communications mode when
the thermostat controller is operating.
The following blink codes may be seen:
•Short-Short-Long: Indicates that the baud rate is
known and that communication is active.
•Short-Short: Indicates that the thermostat
controller is scanning for the correct baud rate and
that there is no communication.
•Off: Indicates that there is no power to the
thermostat controller or that the MS/TP wiring
polarity is reversed.
•Long: Indicates that the MS/TP communication
daughter board is the wrong type for the main
board.
MS/TP Thermostat Controller Mapping
For detailed information on MS/TP Bus objects and
thermostat controller mapping, refer to the TEC
BACnet MS/TP Network Series Thermostat Controllers
Technical Bulletin (LIT-12011592).
Figure 18: Wiring the TEC2647-4 Thermostat Controller for Proportional Control
Two-Pipe Applications Four-Pipe Applications
TEC2647proportional
Heating/Cooling
Val ve
24 V~
Com
24 V~
Hot
AO1 AO2
Cooling
Val ve
Heating
Val ve
24 V~
Com
24 V~
Hot
AO1

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
11
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Setup and Adjustments
Thermostat Controller User Interface Keys
The TEC26x7-4 Series Thermostat Controller user
interface consists of three keys on the front cover
(Figure 19). The function of each key is as follows:
•OVERRIDE key overrides the unoccupied mode to
occupied at the local user interface for the
specified TOccTime. (TOccTime is defined by
selecting the appropriate time period in the Installer
Configuration Menu.) If one of the binary inputs is
configured to operate as a remote override contact,
this OVERRIDE function is disabled. The
OVERRIDE key also allows access to the Installer
Configuration Menu. See the Configuring the
TEC26x7-4 Series Thermostat Controller section.
•UP/DOWN arrow keys change the configuration
parameters and activate a setpoint adjustment.
Backlit Liquid Crystal Display (LCD)
The TEC26x7-4 Series Thermostat Controllers include
a 2-line, 8-character backlit display. Low-level
backlighting is present during normal operation, and it
brightens when any user interface key is pressed. The
backlight returns to low level when the thermostat
controller is left unattended for 45 seconds.
Light-Emitting Diodes (LEDs)
Two LEDs are included to call for heat or call for
cooling:
• The heat LED is on when heating is on.
• The cool LED is on when cooling is on.
Status Display Menu
The Status Display Menu is displayed during normal
thermostat controller operation. This menu
continuously scrolls through the following parameters:
• Room Temperature
• System Mode
• Occupancy Status
(Occupied/Unoccupied/Override)
• Applicable Alarms (The backlight lights up as an
alarm condition is displayed.)
Note: An option is available within the Installer
Configuration Menu to lock out the scrolling display and
show only the Room Temperature parameter.
Figure 19: Front Cover of Thermostat Controller
70.0ºF
Room Temp
Backlit, plain text
Liquid Crystal Display (LCD)
is easy to read in any condition.
Three keys on the thermostat controller
make operation easy and intuitive.
Light-Emitting Diodes (LEDs)
indicate system activity.
FIG:frnt_vw_26x7

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
12
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Configuring the TEC26x7-4 Series Thermostat
Controller
The TEC26x7-4 Series Thermostat Controller ships
from the factory with default settings for all configurable
parameters. The default settings are shown in Table 4.
To reconfigure the parameters via the thermostat
controller, follow the steps in this section.
1. To access the Installer Configuration Menu, press
and hold the OVERRIDE key for approximately
8 seconds.
Note: If the Password parameter is configured,
Password 0 appears on the thermostat controller
display indicating that the configured password is
required to proceed. Use the UP/DOWN arrow
keys to indicate the configured password, then
press the OVERRIDE key to proceed through the
Installer Configuration Menu parameters.
2. Once the Installer Configuration Menu begins,
release and press the OVERRIDE key to scroll
through the parameters listed in Table 4.
3. When the desired parameter is displayed, use the
UP/DOWN arrow keys to choose the desired
selection option.
4. Press and release the OVERRIDE key to continue
scrolling through the parameters.
When the thermostat controller is in the Installer
Configuration Menu and left unattended for
approximately 8 seconds, the thermostat controller
reverts to the Status Display Menu.
Configuring Inputs BI1, BI2, and UI3
When BI1 and BI2 are configured for an alarm
condition, an alarm condition is displayed locally when
the input is closed. An alarm message is included on
the scrolling Status Display Menu and when the
message is displayed, the backlight momentarily
lights up.
The UI3 input provides changeover of hot/cold water
switching or supply air temperature monitoring at the
thermostat controller.
Each input can be configured to the Selection Options
included in Table 4.
Configuring the Output Options (Out1Conf)
For applications that enable heating/cooling operation
from the same output, choose the selection option (2.0)
in the Out1Conf parameter. For applications that
enable heating/cooling operation from different outputs,
choose the selection option (4.0).
Configuring the Sequence of Operation
(SeqOpera)
Choose the appropriate sequence of operation. The
modes presented are user-dependent on the sequence
of operation selected. For two-pipe applications using a
changeover sensor, choose the selection option
(0): Cooling Only. Changeover occurs between
Cooling Only and Heating Only. See Figure 20
through Figure 25 for sequence of operation examples.
Table 2: Selection Options for Sequence of Operation in Two-Pipe Applications
Selection
Option
Control
Curve
Terminal Numbers Used (See Table 1 and Figure 5.)
On/Off Control Floating Control Proportional
0to10VDCControl
(0): Cooling Only See Figure 20. 10: N.O. Cooling
11: N.C. Cooling
10: Open Cooling
11: Closed Cooling
10: Proportional Cooling
(1): Heating Only See Figure 21. 10: N.O. Heating
11: N.C. Heating
10: Open Heating
11: Closed Heating
10: Proportional Heating
(2): Cooling and Reheat See Figure 22. 6 and 7: Reheat
10: N.O. Cooling
11: N.C. Cooling
6 and 7: Reheat
10: Open Cooling
11: Closed Cooling
6 and 7: Reheat
10: Proportional Cooling
(3): Heating and Reheat See Figure 23. 6 and 7: Reheat
10: N.O. Heating
11: N.C. Heating
6 and 7: Reheat
10: Open Heating
11: Closed Heating
6 and 7: Reheat
10: Proportional Heating

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
13
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Table 3: Selection Options for Sequence of Operation in Four-Pipe Applications
Selection
Option
Control
Curve
Terminal Numbers Used (See Table 1 and Figure 5.)
On/Off Control Floating Control Proportional
0 to 10 VDC Control
(0): Cooling Only See Figure 20. 10: Normally Open
(N.O.) Cooling
11: Normally Closed
(N.C.) Cooling
10: Open Cooling
11: Closed Cooling
10: Proportional Cooling
(1): Heating Only See Figure 21. 8: N.O. Heating
9: N.C. Heating
8: Open Heating
9: Closed Heating
9: Proportional Heating
(2): Cooling and Reheat See Figure 22. 6 and 7: Reheat
10: N.O. Cooling
11: N.C. Cooling
6 and 7: Reheat
10: Open Cooling
11: Closed Cooling
6 and 7: Reheat
10: Proportional Cooling
(3): Heating and Reheat See Figure 23. 6 and 7: Reheat
8: N.O. Heating
9: N.C. Heating
6 and 7: Reheat
8: Open Heating
9: Closed Heating
6 and 7: Reheat
9: Proportional Heating
(4): Cool/Heat Four-Pipe See Figure 24. 8: N.O. Heating
9: N.C. Heating
10: N.O. Cooling
11: N.C. Cooling
8: Open Heating
9: Closed Heating
10: Open Cooling
11: Closed Cooling
9: Proportional Heating
10: Proportional Cooling
(5): Cool/Heat Four-Pipe
and Reheat
See Figure 25. 6 and 7: Reheat
8: N.O. Heating
9: N.C. Heating
10: N.O. Cooling
11: N.C. Cooling
6 and 7: Reheat
8: Open Heating
9: Closed Heating
10: Open Cooling
11: Closed Cooling
6 and 7: Reheat
9: Proportional Heating
10: Proportional Cooling
Figure 20: Cooling Only,
Two- or Four-Pipe Applications
Temperature Increase
(Increments of 1F°/0.5C°)
Device Closed
Cooling Setpoint
Device Opened
On/Off, Floating,
or Proportional
Output
FIG:clng_nly
Figure 21: Heating Only,
Two- or Four-Pipe Applications
Temperature Increase
(Increments of 1F°/0.5C°)
Device Closed
Heating Setpoint
Device Opened
On/Off, Floating,
or Proportional
Output
FIG:htng_nly
Figure 22: Cooling with Reheat,
Two- or Four-Pipe Applications
Temperature Increase
(Increments of 1F°/0.5C°)
Heating Setpoint
Device
Closed
Cooling Setpoint
Device
Opened
FIG:clng_wth_rht
Deadband
Reheat
On/Off, Floating,
or Proportional
Outputs
Heating Output
Cooling Output
Off
Off
On
On

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
14
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
14
Figure 23: Heating with Reheat,
Two- or Four-Pipe Applications
Temperature Increase
(Increments of 1F°/0.5C°)
FIG:htg_wth_
rht
0%
100%
Reheat
On/Off, Floating,
or Proportional
Output
Off
Off
On
On
Figure 24: Heating/Cooling,
Four-Pipe Applications
Temperature Increase
(Increments of 1F°/0.5C°)
Heating Setpoint
Device
Closed
Cooling Setpoint
Device
Opened
FIG:htng_clng
Deadband
On/Off, Floating,
or Proportional
Outputs
Heating Output
Cooling Output
Device
Closed
Device
Opened
Figure 25: Heating/Cooling with Reheat, Four-Pipe Applications
Temperature Increase
(Increments of 1F°/0.5C°)
Heating Setpoint
Device
Closed
Device
Closed
Device
Opened
Cooling Setpoint
Device
Opened
FIG:htng_clng_rht
Deadband
Reheat
Output
On/Off, Floating,
or Proportional
Outputs
Heating Output
Cooling Output
Off
Off
On
On

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
15
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
15
Table 4: Installer Configuration Menu (Part 1 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options
Pswrd Sets the protective access
password to prevent unauthorized
access to the Installer Configuration
Menu.
Default: 0
Note: The default setting does not
lock out access to the Installer
Configuration Menu.
Range: 0to 1,000
Com addr MS/TP address at the thermostat
controller; coincides with the
address assigned at the supervisory
controller.
Default: 254
Range: 004 to 127
BI1 Configuration of Binary Input 1.
Default: None
(None): No function is associated with an input.
(Rem NSB): Remote Night Setback (NSB) via a time clock input, an
occupancy sensor, or from a voltage-free contact.
Contact open = Occupied; contact closed = Unoccupied.
(MotionNO*): Temporary occupancy request via a motion detector
input. Contact open = Unoccupied. When the contact closes, the
thermostat controller goes into the occupied mode for a specified
TOccTime. Once the TOccTime begins, the thermostat controller
remains in the occupied mode if the contact is open, until the
TOccTime expires.
(MotionNC*): Temporary occupancy request via a motion detector
input. Contact closed = Unoccupied. When the contact opens, the
thermostat controller goes into the occupied mode for a specified
TOccTime. Once the TOccTime begins, the thermostat controller
remains in the occupied mode if the contact is closed, until the
TOccTime expires.
(Window**): Cancels the thermostat controller heating or cooling
action when a window is open. A Window alarm is displayed
indicating that the window needs to be closed to resume heating or
cooling.
* These settings disable any local override function.
** When this setting is selected, the heating and or cooling outputs
are enabled only when the contact is closed. If the fan is set to Auto,
it is enabled only when the contact is closed. If the fan is set to On, it
is not affected by this setting.

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
16
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
BI2 Configuration of Binary Input 2.
Default: None
(None): No function is associated with an input.
(Door Dry): Door contact only has an effect if BI1 is set to MotionNO
or MotionNC. (See the BI1 parameter in this table.) The occupancy
is now dictated via BI1 and BI2. Any motion detected sets the zone
to Occupied status. The zone remains permanently in occupied
mode until the door contact switch opens momentarily. The
thermostat controller then enters stand-by mode. If more
movements are detected, the occupied mode resumes. While the
door is opened, any movements detected by the remote PIR sensor
or the PIR accessory cover are ignored. Use a Normally Closed
contact switching device. Contact opened = Door opened,
Contact closed = Door closed.
(RemOVR): Temporary occupancy request via a remote input. This
override function is controlled by a manual remote occupancy
override. When enabled, this condition disables the override
capability of the thermostat controller.
(Filter): A Filter alarm is displayed. This alarm can be connected to
a differential pressure switch that monitors a filter.
(Service): A Service alarm is displayed on the thermostat controller
when the input is energized. This input can be tied into the air
conditioning unit control card, which provides an alarm should there
be a malfunction.
UI3 Configuration of Universal Input 3.
Default: None
(None): No function is associated with an input.
(COC/NH): Changeover Contact/Normally Heat: A dry contact input
is used to signal seasonal hot/cold water changeover. The contact
closes when cold water is present. Valid only for two-pipe systems.
(COC/NC): Changeover Contact/Normally Cool: A dry contact input
is used to signal seasonal hot/cold water changeover. The contact
closes when hot water is present. Valid only for two-pipe systems.
(COS): Changeover Analog Sensor: Used for hot/cold water
changeover switching. Valid only for two-pipe systems.
Note: Choose the selection option (0): Cooling Only for the
SeqOpera parameter to allow changeover to occur between
Cooling Only and Heating Only. Choose the selection option (2):
Cooling and Reheat to allow changeover to occur between
Cooling and Reheat and Heating and Reheat.
(SS): Supply Air Sensor Monitoring
MenuScro Gives the option of having the
display continuously scroll the
parameters.
Default: on
(off): The scroll is inactive.
(on): The scroll is active.
C or F Provides temperature scale options
for display.
Default: °F
(°C): Celsius scale
(°F): Fahrenheit scale
Table 4: Installer Configuration Menu (Part 2 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
17
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
17
Lockout Selectable Lockout Levels for
limiting end user keypad interaction.
Default: 0
Lockout
Level
Function
Unoccupied Override Occupied Temperature
Setpoints
(0) Access Access
(1) No Access Access
(2*) This lockout level is not used.
(3*) This lockout level is not used.
(4) Access No Access
(5) No Access No Access
* If lockout level (2) or (3) is selected, the lockout functions like
lockout level (0) or (1) respectively.
Out1Conf Defines the type of operation
needed for Output 1.
Default: 4.0
(2.0): Limits the number of sequences of operation available
from 0 to 3, and enables heat/cool operation from the same output.
(4.0): Allows access to all sequences of operation from 0 to 5, and
enables heat/cool operation from different outputs.
CntrlTyp Defines the control output for the
type of valves used in the
installation (TEC2627-4 model).
Default: Floating
(On/Off): For Normally Open (N.O.) or Normally Closed (N.C.)
24 VAC two-position valves.
(Floating): For proportional three-wire control of 24 VAC floating
valves.
SeqOpera Determines the sequence of
operation.
Default: 1
(0): Cooling Only (Off-Cool). The default is Cool.
(1): Heating Only (Off-Heat). The default is Heat.
(2): Cooling and Reheat (Off-Auto-Heat-Cool). The default is Auto.
(3): Heating and Reheat (Off-Heat). The default is Heat.
(4*): Cool/Heat Four-Pipe (Off-Auto-Heat-Cool). The default is Auto.
(5*): Cool/Heat Four-Pipe and Reheat (Off-Auto-Heat-Cool). The
default is Auto.
* Selection option (4.0) for Out1Conf only. (See Out1Conf parameter
earlier in this table.)
Note: Choose the selection option (0): Cooling Only when using a
changeover sensor to allow changeover to occur between Cooling
Only and Heating Only. Choose the selection option (2): Cooling
and Reheat when using a changeover sensor to allow changeover
to occur between Cooling and Reheat and Heating and Reheat.
St-By TM Sets the Stand-By timer value
(PIR models).
Default: 0.5 hours
Time delay between the moment the PIR cover detected the last
movement in the area and the time at which the thermostat
controller Stand-By mode and setpoints become active.
Range: 0.5 to 24.0 hrs adjustable in 0.5-hour increments
Unocc TM Sets the Unoccupied timer value
(PIR models).
Default: 0.0 hours
Time delay between the moment the thermostat controller toggled to
Stand-By mode and the time at which the thermostat controller
Unoccupied mode and setpoints become active. Setting this
parameter to the factory value (0.0 hours) disables the Unoccupied
timer. This prevents the thermostat controller from switching from
Stand-By mode to Unoccupied mode when PIR functions are used.
Range: 0.0 to 24.0 hrs adjustable in 0.5-hour increments
Table 4: Installer Configuration Menu (Part 3 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
18
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
18
St-By HT Sets Stand-by heating setpoint;
value is between occupied and
unoccupied heating setpoints.
Default: 69.0°F/20.6°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Note: When adjusting the
temperature, press the UP/
DOWN arrow keys to
change the temperature in
0.5F°/0.5C° increments;
press and hold the
UP/DOWN arrow keys
to change the temperature
in 5.0F°/5.0C° increments.
St-By CL Sets Stand-by cooling setpoint limit;
value is between occupied and
unoccupied cooling setpoints.
Default: 78.0°F/25.6°C
Range: 54.0°F/12.0°C to
100.0°F/37.5°C
Unocc HT Sets the Unoccupied Heating
setpoint value.
Default: 62.0°F/16.5°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Unocc CL Sets the Unoccupied Cooling
setpoint value.
Default: 80.0°F/26.5°C
Range: 54.0°F/12.0°C to
100.0°F/37.5°C
Heat max Sets the Occupied and Unoccupied
maximum Heating setpoint values.
Default: 90.0°F/32.0°C
Range: 40.0°F/4.5°C to
90.0°F/32.0°C
Cool min Sets the Occupied and Unoccupied
minimum Cooling setpoint values.
Default: 54.0°F/12.0°C
Range: 54.0°F/12.0°C to
100.0°F/37.5°C
Pband Proportional Band used by the PI
temperature control loop of the
thermostat controller.
Pband is not converted with C or F
scale and is always shown with a
range of 3 to 10.
Default: 3 (3F°/1.7C°)
Value F Scale Pband/C Scale Pband
33.0F°/1.7C°
44.0F°/2.2C°
55.0F°/2.8C°
66.0F°/3.3C°
77.0F°/3.9C°
88.0F°/4.4C°
99.0F°/5.0C°
10 10.0F°/5.6C°
Note: The use of a larger proportional band is not to use the
thermostat controller as a discharge air controller device. The use of
a larger proportional band can be used to solve issues for flawed
HVAC design with basic sizing and thermostat controller location
errors that cannot be worked around.
Set type Provides the option of temporarily
changing the heating or cooling
setpoint by pressing the UP/DOWN
arrow keys.
Default: permnent
(temporar): Local changes to the heating or cooling setpoints are
temporary, and remain effective for the specified TOccTime.
(permnent): Local changes to the heating or cooling setpoints are
permanently stored in the thermostat controller memory.
TOccTime Sets the duration of the Temporary
Occupancy Time when the heating
or cooling setpoints in the Occupied
mode are established by:
• an Override Function enabled in
the Main User Menu (when the
thermostat controller is in the
Unoccupied mode)
• a temporary heating or cooling
setpoint
Default: 2.0 hrs
Range: 0.0 to 24.0 hrs in 1-hour increments
Table 4: Installer Configuration Menu (Part 4 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
19
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Deadband Sets the minimum deadband
between the heating and cooling
setpoints.
Default: 2.0F°/1.0C°
Range: 2.0F°/1.0C° to 5.0F°/2.5C° (adjustable in 1.0F°/0.5C°
increments)
Cal RS Sets the desired room air sensor
calibration (offset). The offset can
be added to or subtracted from the
actual displayed room temperature.
Default: 0.0F°/0.0C°
Range: -5.0F°/-2.5C° to 5.0F°/2.5C° (adjustable in 1.0F°/0.5C°
increments)
Aux cont Determines the auxiliary contact
function and configuration.
Default: 0
(0) Not used,
or used for
reheat
If the Sequence of Operation is set to
reheat (2, 3, or 5), ignore this parameter.
(1) Auxiliary
N.O.
Occupied = contact
closed
Unoccupied = contact
open
The output
aligns with
occupancy.
(2) Auxiliary
N.C.
Occupied = contact open
Unoccupied = contact
closed
(3*) This selection option is not used.
(4*) This selection option is not used.
(5) Auxiliary On/Off control through the
auxiliary network command. The output
can be commanded through the network
for any required auxiliary functions via a
separate and dedicated network
variable.
The output
aligns with
the
secondary
network
occupancy
command.
* If option (3) or (4) is selected, the option functions like
option (1) or (2) respectively.
FL time Sets the maximum actuator stroke
timing (floating ContrlTyp
TEC2627-4 model).
Default: 1.5 min
Range: 0.5 to 9.0 min (adjustable in 0.5 minute increments)
Cph Sets the maximum number of
cycles per hour (on/off CntrlTyp
TEC2627-4 model).
Default: 4
Range: 3to 8 cycles per hour
RA/DA Choice of reverse or direct acting
analog output signal (TEC2647-4
model).
Default: DA
(RA): Reverse acting, 0 to 100% = 10 to 0 VDC
(DA): Direct acting, 0 to 100% = 0 to 10 VDC
Table 4: Installer Configuration Menu (Part 5 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options

FlexSys BACnet®MS/TP Networked Thermostat
TEC - 2647 - 4
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
20
Installation / Operation Manual
V160916
TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Troubleshooting
See Table 6 for display messaging and Table 7 for
troubleshooting details.
Accessories
All the accessories in Table 5 include mounting
hardware; contact the nearest Johnson Controls®
representative to order any of these parts.
Note: Review the technical specifications of the
accessories prior to their use in an application.
Repair Information
If the TEC26x7-4 Series Thermostat Controller fails to
operate within its specifications, replace the unit. For a
replacement thermostat controller, contact the nearest
Johnson Controls representative.
Reheat Sets the duty cycle time for reheat
output (if Option 2, 3, or 5 is chosen
in the SeqOpera parameter).
Default: 0
(1): 10 seconds (six cycles per minute), for various equipment with
solid-state relays that withstand short duty cycles such as electric
heat.
(0): 15 minutes (four cycles per hour), for various equipment with
mechanical relays or contactors controlling mechanical reheat
systems.
UI3 dis Displays the supply or changeover
temperature when UI3 is configured
as an analog input (supply sensor
or changeover sensor).
Default: -40°F/-40°C
Used as a diagnostic/service help, to troubleshoot and diagnose
sensor operation.
Table 4: Installer Configuration Menu (Part 6 of 6)
Parameter
Appearing
on Display
Description and Default Selection Options
Table 5: Accessories (Order Separately)
Code Number Description
TEC-7-PIR1Zone Controller Cover with Occupancy Sensor
SEN-600-1 Remote Indoor Air Temperature Sensor
TE-6361M-12Duct Mount Air Temperature Sensor
SEN-600-4 Remote Indoor Air Temperature Sensor with Occupancy Override and LED
TE-636S-1 Strap-Mount Temperature Sensor
MS-BACEOL-0 RS485 End-of-Line Terminator
1. The TEC-7-PIR Accessory Cover can be used to replace the existing cover on a non-PIR TEC26x7-4 Thermostat Controller
to provide occupancy sensing capability.
2. Additional TE-636xx-x Series 10k ohm Johnson Controls Type II Thermistor Sensors are available; refer to the
TE-6300 Series Temperature Sensors Product Bulletin (LIT-216320) for more details.
Table 6: Display Messages
Display Function
Service Indicates that there is a service alarm in accordance with the programmable Binary Input (BI2).
Filter Indicates that the filter(s) is dirty in accordance with the programmable Binary Input (BI2).
Window Indicates that an outside window or door is open and has cancelled the thermostat controller heating
or cooling action in accordance with the programmable Binary Input (BI1).
