Viconics R850 Series User manual

R850 SERIES
R850V STEP CONTROLLER
WITH INTEGRATED VERNIER STAGE
•Pulsed or analog 0 to 10 Vdc vernier stage
•4 or 8 step models
•Up to 16 stage total with a slave unit
•Test button
DESCRIPTION
The Viconics R850V series step controller is designed for
cost effective, precise modulation of multi-stage control
application. A common application is a multi step electric
duct heater.
An integrated vernier control output will give a precise and
full modulation of the load from 0 to 100% of the total
capacity.
FEATURES AND BENEFITS
Microcomputer-based design Accuracy and reliability
Adjustable inter-stage delay Provides flexibility in
replacement applications
Adjustable Vernier ratio Simplifies design of
proportional stage
Choice of pulsed or analog
Vernier output
Permits use of SCR or lower
cost SSR
Up to 16 stages One product family can handle
all applications
Choice of LIFO or FIFO
sequencing
Increased flexibility of FIFO
permits even use of contactors
Test button Quick troubleshooting
MODELS AVAILABLE
The R850-V is available in 2 models
•R850V-4 4 stage unit
•R850V-8 8 stage unit
If more than 8 stage are required, the R850-V8 can be used
as a master unit with another R850V as a slave unit. Adding
another unit ( R850-V4 or R850-V8 ) can bring the total step
number up to 12 or 16.
OVERRIDE TEST BUTTON
The override test button can be used to by-pass the
interstage delay and bring on all stage at one time. This
simplifies the verification of configured maximum number of
stage.
A status LED per step will come on for each of the configured
stage.
SPECIFICATIONS
Operating
Conditions:
0°C to 80°C ( 32°F to 176°F )
0 % to 95 % R.H. non-condensing
Relay outputs: Isolated relay 30 Vac @ 1.0 amps. max. per
output, up to a maximum of 4.0 amps. total
per R850 controller. See application note 02.
Vernier stage: Vdc pulsed: 6 Vdc, 30 mA max.
0 to 10 Vdc 5 mA max.
Input
impedance:
0 to 10 Vdc into 10 KΩminimum
Power supply: 24 Vac -15%, +10% 50/60 Hz; 4 VA
Use a Class 1 ( properly fused ) or Class 2,
CSA or UL recognized transformer for power
supply & relay outputs.
Specifications and equipment are subject to change without prior notice.
INPUT SIGNAL
The R850V has four INPUT dip switch (S1 to S4) to select the control signal input:
They are compatible with industry standard signals.
DIP SWITCH ADJUSTMENTS & WIRING CONTROL INPUT
Input Signal Switch Switch #1 Switch #2 Switch #3 Switch #4
0 to 10 Vdc control signal ( 2 to 10 Vdc control range ) Off Off Off On
4 to 20 mA control signal Off Off On Off
0 to 135 Ωcontrol signal On On Off Off
If a slave unit is used, wire the control signal input to the master unit only
Innovative Control Solutions For Your Needs
(2) Vernier stage selection
OFF = 0 to 10 Vdc (SCR)
ON = Vdc pulsed signal (SSR)
4 to 20 mA
0 to 135
Ω
21 3 4
ON
21 3 4 (1) Sequence of operation
(LIFO or FIFO)
OFF = LIFO (Last IN, First OUT)
ON = FIFO (First IN, First OUT)
R850V-8
0 to 10 Vdc
signal selection
(1-4) Input
ON
21 3 4
ON
I
N
P
U
T
21 43
S
ON
1
W
(3-6) Number of steps selection
(see next pages for details)
C
O
N
T
R
O
L
421 3 56
S
ON
2W
4 to 20 mA
(2) Vernier stage selection
OFF = 0 to 10 Vdc (SCR)
ON = Vdc pulsed signal (SSR)
(1) Sequence of operation
(LIFO or FIFO)
OFF = LIFO (Last IN, First OUT)
ON = FIFO (First IN, First OUT)
Ω
0 to 135
1234
ON
1 32 4
2WS
(3-4) Number of steps selection
(see next pages for details)
S
signal selection
(1-4) Input
0 to 10 Vdc
ON
132 4
ON
I
N
P
U
T
1 32 44
C
O
N
T
R
O
L
3122 4
W1
R850V-4
ON ON

2
2 To 10 Vdc Or 0 To 10 Vdc Stand Alone Thermostat
( Power To The Thermostat Is Supplied By The R850V ) 0 To 135ΩStand Alone Thermostat
2 To 10 Vdc Or 0 To 10 Vdc From D.D.C.
Building Automation System
4 To 20 mA From D.D.C.
Building Automation System
24 VAC POWER & RELAY OUTPUT WIRING
The wiring diagrams are for the R850V-8 models with 8 outputs. The wiring for the R850V-4 is the same except that the unit only
has 4 outputs.
Terminals
Screw terminal & connector #1 Common
Screw terminal & connector #2 24 Vac
Screw terminal & connector #3 Control Signal input
•It is not necessary to ground any leg of the transformer to earth with the controller card.
•The controller uses internally a half wave rectifier bridge. On 0 to 10 Vdc control signal, the reference of the control signal is the
Common of the power supply of the SCR controller card.
•Use a Class 1 ( properly fused ) or Class 2, CSA or UL recognized transformer.
•4 STAGE APPLICATION R850V-4
R850V-4 Control SwitchNumber
of stage Switch #3 Switch #4
1Off Off
2On Off
3Off On
4On On
Common
24 Vac
0 to 10 Vdc
output
2 Vdc = 0% capacity
10 Vdc = 100% capacit
y
1 2 3
1
123
ON
4
I
N
P U
T
R
W
B
0 Ohms = 0% capacity
135 Ohms = 100% capacit
y
1 2 3
1
123
ON
4
I
N
P U T
-
+
2 Vdc = 0% capacity
10 Vdc = 100% capacit
y
1 2 3
1
123
ON
4
I
N
P U T
4 mA = 0% capacity
2
0 mA = 100% capacit
y
-
+
1 2 3
1
123
ON
4
I
N
P U
T
JUNE 99 REV.1
TEST
RATIO(%)
100 200
150
VR2
1 2 3
123
ON
4
I
N
P U
T C
O
N T R
O
L
001-0102
DELAY(s)
120
60
30
90
12 3
COM
V S C8 C7 C6 C5 C4 C3 C2 C1 C
POWER
123
ON
4
C1
24 Vac contactor coils
C2 C3 C4
R850V-4

3
•8 STAGE APPLICATION R850V-8
R850V-8 Control SwitchNumber
of stage Switch #3 Switch #4 Switch #5 Switch #6
1Off Off Off Off
2On Off Off Off
3Off On Off Off
4On On Off Off
5Off Off On Off
6On Off On Off
7Off On On Off
8On On On Off
•12 STAGE APPLICATION R850V-8 MASTER UNIT, R850V-4 SLAVE UNIT ( See also slave application section at the end )
R850V-8 Master Unit Control Switch R850V-4 Slave UnitNumber
of stage Switch #3 Switch #4 Switch #5 Switch #6 Switch #3 Switch #4
9Off Off Off On Off Off
10 On Off Off On On Off
11 Off On Off On Off On
12 On On Off On On On
The intensity of the yellow status LED on the master unit is proportional to the slave output.
JUNE 99 REV.1
TEST
RATIO(%)
100 20 0
150
VR2
1 2 3
123
ON
4123
ON
4 5 6
I
N
P U T C O N
T
R O
L
001- 01 02
DELAY(s)
120
60
30
90
12 3
COM
V S C8 C7 C6 C5 C4 C3 C2 C1 C
POWER
C1
24 Vac contactor coils
C2 C3 C4 C5 C6 C7 C8
R850V-8
JU
N
E
99
R
EV
.1
TE
ST
R
AT
IO
(%
)
10
0
20
0
15
0
V
R2
123 123
ON
4
I
NPUTCONTROL
00
1-
01
02
D
EL
A
Y(
s)
12
0
60
30
90
1
2
3
CO
M
V
S
C8C7C6C5C4C3C2C1
C
P
O
W
E
123
ON
4
JU
N
E
99
R
EV
.1
TE
ST
R
AT
IO
(%
)
10
0
20
0
15
0
V
R2
123 12 3
ON
4123
ON
4 5 6
I
NPUTCONTROL
00
1-
01
02
D
EL
A
Y(
s)
12
0
60
30
90
1
2
3
CO
M
V
S
C8
C7
C6C5C4C3C2C1
C
P
O
W
E
24 Vac contactor coils 24 Vac contactor coils
R850V-8
C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12
R850V-4
Use vernier output of master
if vernier control is required
Note: Set all control signal INPUT dip switch to OFF on slave unit.

4
JUNE 9 9
REV.1
TEST
RATIO(%)
100 20 0
150
VR2
1 2 3
123
ON
4123
ON
4 5 6
I
N P
U T C O N
T
R O
L
001-0102
DELAY(s)
120
60
30
90
123
COM
V S C8 C7 C6 C5 C4 C3 C2 C1 C
POWER
7.075"
0.325" 3.450" 0.250"3.050"
3.675"
2.700"
0.225"
Vernier output green LED
Slave output yellow LED
Power indicating
green LED
0.325"
0.425"
•16 STAGE APPLICATION R850V-8 MASTER UNIT, R850V-4 SLAVE UNIT ( See also slave application section at the end )
R850V-8 Master Unit Control Switch R850V-8 Slave Unit Control SwitchNumber
of stage Switch #3 Switch #4 Switch #5 Switch #6 Switch #3 Switch #4 Switch #5 Switch #6
9Off Off Off On Off Off Off Off
10 On Off Off On On Off Off Off
11 Off On Off On Off On Off Off
12 On On Off On On On Off Off
13 Off Off On On Off Off On Off
14 On Off On On On Off On Off
15 Off On On On Off On On Off
16 On On On On On On On Off
The intensity of the yellow status LED on the master unit is proportional to the slave output.
R850V DIMENSIONS & INSTALLATION
Install on the mounting plate on the electrical cabinet using five #6 pan head metal screw. Do not over torque the screws to prevent
damage to the board. Specifications and equipment are subject to change without prior notice.
All R850V series controls are for use only as operating controls. Whenever a control failure could lead to personal
injury and/or loss of property, it becomes the responsibility of the user to add safety devices and/or alarm system
to protect against such catastrophic failures.
JUNE 99 REV.1
TEST
RATIO(%)
100 200
150
VR2
1 2 3
123
ON
4123
ON
4 5 6
I
N P U
T C
O
N
T
R
O
L
001-0102
DELAY(s)
120
60
30
90
123
COM V S C8 C7 C6 C5 C4 C3 C2 C1 C
POWER
JUNE 99
REV.1
TEST
RATIO(%)
100 200
150
VR2
1 2 3
123
ON
4123
ON
4 5 6
I
N P
U T C O N
T
R O
L
001-0102
DELAY(s)
120
60
30
90
12 3
COM
V S C8 C7 C6 C5 C4 C3 C2 C1 C
POWER
24 Vac contactor coils 24 Vac contactor coils
R850V-8
C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 C16
R850V-8
Use vernier output of master
if vernier control is required
Note: Set all control signal INPUT dip switch to OFF on slave unit.

5
LIFO / FIFO ADJUSTMENT
The R850V series features 2 different staging sequences:
•LIFO LAST IN FIRST OUT ( CONTROL SWITCH #1 OFF, FACTORY DEFAULT )
This is the regular mode, Stage #1 will always be the first to energize and the last stage to de-energize
•FIFO FIRST IN FIRST OUT ( CONTROL SWITCH #1 ON )
In this mode, the stages are rotated to ensure a more uniform wear of the contactors and elements. For example, on an increase in
demand, stage 1 will be energized following by stage 2, etc. On a decrease in demand, stage 1 will de-energized first followed by
stage 2, etc.
Please verify that if this mode is enabled, the manufactured product still complies with active codes and regulations.
VERNIER STAGE SELECTION AND WIRING
The Viconics R850V series step controller has an integrated vernier control output. This output will give a precise and full
modulation of the load from 0 to 100% of the total capacity of the unit. If a master slave application is used, always connect the
vernier output of the master unit.
ADJUSTMENTS
Functions of the units can be configured with six dip switch and 2 potentiometers.
Interstage delay potentiometer setting
A potentiometer is used to adjust the interstage delay from 30 seconds up 120 seconds.
This delay is active in 3 ways.
•Minimum time delay between each step activation when the control signal rises
•Minimum ON time when the step is activated
•Minimum time delay between each step de-activation when the control signal drops
Vernier stage ratio
A potentiometer is used to adjust the vernier stage ratio from 100% to 200% capacity of the other on/off
stage capacity.
RATIO SETTING ( See also slave application section at the end )
First adjust the vernier stage ratio potentiometer. This will insure a smooth capacity rise of the total load.
Example 1:
The total unit has 100 kW divided in 10 equal stage of 10 kW.
If only 10 kW is used as the modulating stage, then the heater would have 9 on/off mechanical stage plus
one modulating stage. This modulating stage has the same value as all the other stage. Adjust the vernier stage ratio
potentiometer to 100%.
Example 2:
The total unit still has 100 kW divided in 10 equal stage of 10 kW.
If 20 kW are used as the modulating stage, then the heater would have 8 on/off mechanical stage plus one modulating stage.
The modulating stage has twice the value as all the other stage. Adjust the vernier stage ratio potentiometer to 200%.
•TYPE OF VERNIER STAGE SETTING
The vernier stage output can be configured to operate either as a:
•Vdc pulsed output to activate an R810 power module
•0 to 10 Vdc analog output to activate an R820 SCR power controller.
•VERNIER STAGE WIRING
Control Switch #2 On Vdc pulsed to activate R810 power modules
Do not wire more than six R810 power module on the
vernier stage output
Respect the polarity between the R850 step controller
board an the R810 power modules
Connect Vto +
Connect COM to -
The green status LED on the master unit will cycle at
the same rate as the time proportioning vernier output
For more information, please refer to the R810 service
manual
RATIO(%)
100 200
150
VR2
COM
V S
+
-
R810
100 200
150
125 175
30 120
75
45
60 90
105
DELAY(s)
120
60
30
90

LIT-R850V-E03 6
Control Switch #2 Off 0 to 10 Vdc analog output to activate R820 SCR power controller
Set the R820 SCR power controller to accept a 0 to 10 Vdc control signal input
Switch #1, #2 & #3 Off Switch #4 On
The intensity of the green status LED on the master unit is proportional to vernier output
For more information, please refer to the R820 service manual
SLAVE APPLICATION SECTION
When using a unit for slave applications, it is important that the proper adjustments & setting be made to the unit for proper
operation of the system.
The yellow LED near the vernier output connector is proportional to the vernier output of the master unit ( 0 to 5 Vdc ).
On the slave unit:
•Set vernier ratio potentiometer to 100%
•Set interstage delay potentiometer to the same value as the master unit
•Set all control signal INPUT dip switch to OFF
TEST MODE BUTTON
The test mode button can be used to verify if the number of stage have been configured properly.
1. Press and hold the button for 3 to 4 seconds.
2. If a slave unit is used, press & hold the 2 units button simultaneously
3. All the selected stage will come on, one after the other until all selected number of stages are all on.
4. There is a delay of approximately 5 second between each step activation.
5. When all selected stage are on, they will stay on for approximately 30 seconds before shutting down.
Powering up the R850V controller while holding down the test button will by-pass the interstage delay for 10 minutes. During that
period, the unit will respond to a changing signal input very rapidly. Also hold down slave test button on start-up if a slave unit is
used. After that 10 minute period, the unit will function normally with the interstage delays active
Viconics Electronics Inc. 9245, Langelier Blvd, St-Leonard, Quebec, Canada H1P 3K9 www.viconics.com
[e-mail]
JUNE 99 REV.1
TEST
RATIO(%)
100 200
150 VR2
1 2 3
123
ON
4123
ON
456
I
N
P U
T C
O
N
T
R
O
L
001-0102
DELAY(s)
120
60
30
90
123
COM
V S C8 C7 C6 C5 C4 C3 C2 C1 C
POWER
1 2 3
R820
SCR Power Controller
1 2 3
123
ON
4
I
N
P U T
