EMC2 CloudBoost 100 Parts list manual

EMC CloudBoost 100
Version 2.0
Hardware Component Replacement Guide
P/N 302-002-471
REV. 02

Copyright © 2015 EMC Corporation. All rights reserved. Published in the USA.
Published December, 2015
EMC believes the information in this publication is accurate as of its publication date. The information is subject to change
without notice.
The information in this publication is provided as is. EMC Corporation makes no representations or warranties of any kind with
respect to the information in this publication, and specifically disclaims implied warranties of merchantability or fitness for a
particular purpose. Use, copying, and distribution of any EMC software described in this publication requires an applicable
software license.
EMC², EMC, and the EMC logo are registered trademarks or trademarks of EMC Corporation in the United States and other
countries. All other trademarks used herein are the property of their respective owners.
For the most up-to-date regulatory document for your product line, go to EMC Online Support (https://support.emc.com).
EMC Corporation
Hopkinton, Massachusetts 01748-9103
1-508-435-1000 In North America 1-866-464-7381
www.EMC.com
2EMC CloudBoost 100 2.0 Hardware Component Replacement Guide

5
7
CloudBoost 100 Overview 9
Related documentation................................................................................. 10
Tools and supplies needed........................................................................... 10
Avoiding electrostatic discharge (ESD) damage ............................................ 10
Emergency procedures (without an ESD kit)...................................................11
Hardware acclimation times.......................................................................... 11
Removing, installing, or storing replaceable units......................................... 12
Unpacking a part...........................................................................................13
Disk Drive Replacement 15
Overview: CloudBoost 100 system disk drives...............................................16
Identify a failed disk drive............................................................................. 16
Remove and install a disk drive..................................................................... 17
Remove the bezel.............................................................................17
Remove and install a disk dive......................................................... 17
Verify the replacement disk........................................................................... 18
Complete the procedure................................................................................19
DAE Technical Specifications and Operating Limits 21
Fire suppressant disclaimer...........................................................................22
Disk drive type.............................................................................................. 22
Dimensions and weight.................................................................................22
Power requirements...................................................................................... 22
System operating limits.................................................................................24
Environmental recovery....................................................................24
Shipping and storage requirements...............................................................24
Shock and Vibration......................................................................................25
Air quality requirements................................................................................ 25
Disk Replacement for a DAE Shelf 27
Identify a failed disk drive............................................................................. 28
Opening the console..................................................................................... 28
Unlocking and removing the front bezel........................................................ 29
Removing a disk filler module....................................................................... 30
Unpacking a part...........................................................................................31
Installing a new or replacement disk............................................................. 31
Installing and locking the front bezel.............................................................32
Closing the console.......................................................................................33
Verify the replacement disk........................................................................... 33
CloudBoost Disk Array Expansion Replacement 35
Figures
Tables
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
CONTENTS
EMC CloudBoost 100 2.0 Hardware Component Replacement Guide 3

Shut down the system...................................................................................36
Disconnecting a DAE from the back-end bus..................................................36
Disconnecting DAE power cords.................................................................... 37
Opening the console..................................................................................... 37
Unlocking and removing the front bezel........................................................ 38
Removing a DAE from the cabinet..................................................................40
Unpacking a part...........................................................................................41
Installing an empty DAE on the rails.............................................................. 42
Transferring components from the faulted DAE to the replacement DAE.........44
Removing a power/cooling module.................................................. 44
Installing a power/cooling module................................................... 44
Removing an LCC............................................................................. 45
Installing an LCC.............................................................................. 46
Transferring disks and disk filler modules........................................ 47
Connecting powers to the replacement enclosure..........................................50
Verifying DAE status...................................................................................... 51
Connecting the back-end bus to the DAE....................................................... 52
Installing and locking the front bezel.............................................................52
Closing the console.......................................................................................53
Restart the system ........................................................................................53
Verify the disk array expansion shelf replacement ........................................ 53
CONTENTS
4EMC CloudBoost 100 2.0 Hardware Component Replacement Guide

Front HDD drives and LEDs.............................................................................................16
Removing the bezel....................................................................................................... 17
Removing a disk drive....................................................................................................18
Opening the console......................................................................................................29
Releasing the front bezel .............................................................................................. 30
Removing the front bezel............................................................................................... 30
Removing a disk filler module........................................................................................31
Installing a disk............................................................................................................. 32
Installing the front bezel................................................................................................ 33
Unplugging a SAS cable.................................................................................................36
Unplugging the AC power cord....................................................................................... 37
Opening the console......................................................................................................38
Releasing the front bezel .............................................................................................. 39
Removing the front bezel............................................................................................... 39
Removing the screws that secure the enclosure to the front of the cabinet.....................41
Sliding the enclosure out of the cabinet.........................................................................41
Sliding the enclosure onto the rails................................................................................42
Rail tabs inserted into the enclosure notches ................................................................43
Securing enclosure to the front of the cabinet ............................................................... 43
Removing a power/cooling module (AC module shown).................................................44
Installing a power/cooling module (AC module shown)..................................................45
Removing an LCC........................................................................................................... 46
Installing an LCC............................................................................................................46
Removing a disk............................................................................................................ 47
Installing a disk............................................................................................................. 48
Removing a disk filler module........................................................................................49
Installing a disk filler module ........................................................................................50
Plugging in and securing an AC power cord....................................................................51
Enclosure status LEDs....................................................................................................51
Enclosure fault LED........................................................................................................52
Installing the front bezel................................................................................................ 53
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
FIGURES
EMC CloudBoost 100 2.0 Hardware Component Replacement Guide 5

FIGURES
6EMC CloudBoost 100 2.0 Hardware Component Replacement Guide

Hardware acclimation times (systems and components)................................................12
DAE6S AC power specifications..................................................................................... 23
Shipping and storage requirements............................................................................... 24
1
2
3
TABLES
EMC CloudBoost 100 2.0 Hardware Component Replacement Guide 7

TABLES
8EMC CloudBoost 100 2.0 Hardware Component Replacement Guide

CHAPTER 1
CloudBoost 100 Overview
This document provides procedures for replacing components of a CloudBoost 100
system.
lRelated documentation......................................................................................... 10
lTools and supplies needed....................................................................................10
lAvoiding electrostatic discharge (ESD) damage .................................................... 10
lEmergency procedures (without an ESD kit)...........................................................11
lHardware acclimation times.................................................................................. 11
lRemoving, installing, or storing replaceable units..................................................12
lUnpacking a part...................................................................................................13
CloudBoost 100 Overview 9

Related documentation
EMC® provides a variety of document types to support our products. End-user documents
include hardware installation guides, release notes, user guides, administrator guides,
part replacement guides, and others. Integration documents describe how to integrate
CloudBoost™ with other EMC or third-party backup applications.
Note
Local copies of a document may be out of date. Always look for the current version of a
document in the EMC Cloud Portal at https://console.dpccloud.com.
Tools and supplies needed
These tools and supplies may be helpful for the installation and setup tasks for a system.
lNull modem cable (DB-9 female to female), plus spare
lUSB-to-DB-9 serial (male connector) converter cable if the laptop does not have a
serial port, plus spare
lPower adapter, C13 to NEMA 5-15 (if based in North America), or a power cord for
your laptop power adapter with a C13 plug, so that you can power your laptop from a
rack PDU
lAntistatic wrist strap and conductive foam pad
lScrewdrivers:
nPhillips #2 with a 12 inch or longer blade
nPhillips #2 (standard-length blade)
nPhillips #1
nFlat head 3/16 inch
nFlat head 1/4 inch
nTorx T10
lFlashlight
lNeedle nose pliers
lDiagonal wire cutters (for cutting tie wraps)
l2 GB USB flash memory drive
lTie wraps (4 inch and 8 inch)
l(recommended) Roll of 5/8 inch Velcro cable tie material (3M Scotchmate SJ-3401 or
similar)
Avoiding electrostatic discharge (ESD) damage
When replacing or installing hardware units, you can inadvertently damage the sensitive
electronic circuits in the equipment by simply touching them. Electrostatic charge that
has accumulated on your body discharges through the circuits. If the air in the work area
is very dry, running a humidifier in the work area will help decrease the risk of ESD
damage. Follow the procedures below to prevent damage to the equipment.
Be aware of the following requirements:
CloudBoost 100 Overview
10 EMC CloudBoost 100 2.0 Hardware Component Replacement Guide
